Summary of Contents for MSI MP54G-BT
- Page 1 MP54G-BT (MS-6855) Wireless 11g + Bluetooth Combo MiniPCI Card User’s Guide...
-
Page 2: Fcc Caution
FCC Caution 1. The device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. -
Page 3: End Product Labeling
End Product Labeling This transmitter module is authorized only for use in device where antenna may be installed such that 20 cm may be maintained between antenna and users (for example access points, routers, wireless ADSL and similar equipment). The final end product must be labeled in a area with the following: “Contains TX FCC ID: GI4L-MS6855”. - Page 4 >>> 1.1 MP54G-BT (MS-6855) - Wireless 11g + Bluetooth Combo MiniPCI Card MSI MP54G-BT, the Wireless 11g + Bluetooth Combo miniPCI Card, is a Type IIIB card, which can be used to integrate with such systems as notebook, mini-barebone, PDA, portable PC.
- Page 5 >>> 1.2 How MP54G-BT Works 1.2.1 In WLAN Environment Ad-hoc Mode : An Ad-hoc network is a local area network or other small network, especially one with wireless or temporary plug-in connections, in which some of the network devices are part of the network only for the duration of a communications session.
- Page 6 Internet, email, file transfer, and printer sharing. The scale and range of the Infrastructure networking are larger and wider than that of the Ad-hoc networking. MP54G-BT MP54G-BT WLAN+Bluetooth Combo MiniPCI Card WLAN+Bluetooth Combo MiniPCI Card...
- Page 7 Every Bluetooth device that provides a service must be prepared to respond to a connection request. Bluetooth soft- ware is always running in the background on the server, ready to respond to connection requests. MP54G-BT WLAN+Bluetooth Combo MiniPCI Card Bluetooth-enabled Devices...
-
Page 8: Specifications
>>> 1.3 Specifications Hardware Form Factor 32-bit Type IIIB Specification Operation voltage 3.3V Antenna Connector Two antenna connectors Operating System Microsoft Windows 98SE/ME/2000 ® ® Environmental - Operating Temperature: 0 ~ 55 - Operating Humidity: 10 ~ 90%, non-condensing Dimensions (WxDxH) 59.75 x 44.6 x 3.5mm Weight 15 g WLAN... - Page 9 Channel IEEE 802.11g: Ch. 1-11 – N. America Ch. 1-13 – Japan Ch. 1-13– Europe ETSI Ch. 10-11 – Spain Ch. 10-13 – France IEEE 802.11b: Ch. 1-11 – N. America Ch. 1-14 – Japan Ch. 1-13– Europe ETSI Ch. 10-11 – Spain Ch.
- Page 10 Bluetooth Network Standard Bluetooth Class II v1.1 and v1.2 Specification Frequency Band 2.4-2.483 GHz Data Rate Up to 723kbps Channel 79 sub-channels Transmission FHSS (Frequency Hopping Spread Spectrum) Modulation GFSK Antenna Type One antenna connector support Power Consumption 100mA (maximum, continuous TX) Max.
-
Page 11: System Requirements
>>> 1.4 System Requirements Before installing MP54G-BT, your PC should meet the follow- ing items: - One desktop/notebook PC with an available MiniPCI slot. - Windows 98SE/ME/2000/XP operating system. ® - Minimum 5MB free disk space for installing the driver and utilities. -
Page 12: Product View
>>> 1.6 Product View WLAN 11g antenna connectors Connect to external antennas for enhanced data transmission and reception. The external antennas are well designed on the desktop or note- Bluetooth antenna book computers. Connector USB Connector Golden Finger C o n n e c t t o y o u r mainboard using the provided USB cable. -
Page 13: Hardware Installation
Hardware Installation The following diagrams provide you a basic installation for your MP54G-BT. The instruction below is suitable for most com- puters with MiniPCI slot. For more information about the MiniPCI module, please refer to your computer’s manual. Installing MP54G-BT: Locate the MiniPCI slot on the mainboard. - Page 14 Connect one end of the USB cable to the five-pin USB connector on MP54G-BT, and the other end to the USB connector locaed on your mainboard. Note: If the MiniPCI interface in your mainboard re- serves USB bus in pin 21 and 22, you can skip step 4.
-
Page 15: Software Installation
Setup CD to copy files during the installation. Please NOTE that the MP54G-BT should be installed into your computer before installing the driver and utility. Then, the operating system will detect a new device and start to con- figure the new device. - Page 16 1 1 1 1 1 Insert the software CD into your CD-ROM drive, and the Setup STEP program should launch automatically. If the Autorun program doesn’t launch automatically, click Start E:\setup.exe at the taskbar and select Run..Type (where your CD-drive) in the Open box and click OK to launch the Setup program manually.
- Page 17 3 3 3 3 3 Click the Install Bluetooth Driver button. STEP The welcome screen of InstallShield Wizard appears. Click Next. Read and accept the License Agreement; then, click Next. Click Next to install the driver in the default destination folder.
