Campbell Hausfeld Air Compressor Operating Instructions Manual

See Warranty on page 8 for important information about commercial use of this product.
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Oil-Lubricated Compressors
Description
This residential oil-lubricated
compressor is designed for do-it-
yourselfers with a variety of home and
automotive jobs. These compressors
power spray guns, impact wrenches
and other tools. Compressed air from
this unit will contain moisture. Install a
water filter or air dryer if application
requires dry air.

Safety Guidelines

This manual contains information that is
very important to know and
understand. This information is provided
for SAFETY and to PREVENT EQUIPMENT
PROBLEMS. To help recognize this
information, observe the following
symbols.
an imminently hazardous situation
which, if not avoided, will result in
death or serious injury.
a potentially hazardous situation
which, if not avoided, could result in
death or serious injury.
a potentially hazardous situation
which, if not avoided, may result in
minor or moderate injury.
important information, that if not
followed, may cause damage to
equipment.
Unpacking
After unpacking the unit, inspect
carefully for any damage that may have
occurred during transit. Make sure to
tighten fittings, bolts, etc., before
putting unit into service. In case of
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for
© 2007 Campbell Hausfeld/Scott Fetzer
STOP!
Record the Model No., Serial No. and
date of purchase located on the base
below the pump in the space below.
Model No. ____________________
Serial No. ____________________
Danger
Date of purchase _________________
indicates
Retain these numbers for future
reference.
Warning
questions, damaged or missing parts,
indicates
please call 1-800-543-6400 for customer
assistance or call the nearest Campbell
Hausfeld Authorized Service Center.
Caution
Have the serial number, model number,
indicates
and parts list (with missing parts circled)
before calling.
Notice
indicates
unit if damaged during shipping,
handling or use. Damage may result in
bursting and cause injury or property
damage.
unattended. Leaving compressor in
AUTO position may allow it to turn on
inadvertently. To prevent this and
possible damage from power surge,
turn to OFF position after each use.
safekeeping.
For parts, product & service information
visit www.chpower.com
DO NOT RETURN THE
PRODUCT TO THE
RETAILER!
Do not
operate
Do not
run

Breathable Air Warning

This compressor/pump is not
equipped and should not be
used "as is" to supply breathing
quality air. For any application
of air for human consumption,
the air compressor/pump will
need to be fitted with suitable
in-line safety and alarm
equipment. This additional
equipment is necessary to
properly filter and purify the air
to meet minimal specifications
for Grade D breathing as
described in Compressed Gas
Association Commodity
Specification G 7.1 - 1966, OSHA
29 CFR 1910. 134, and/or
Canadian Standards
Associations (CSA).
DISCLAIMER OF WARRANTIES
In the event the compressor is
used for the purpose of
breathing air application and
proper in-line safety and alarm
equipment is not
simultaneously used, existing
warranties shall be voided, and
Campbell Hausfeld disclaims
any liability whatsoever for any
loss, personal injury or damage.
CALIFORNIA PROPOSITION 65
You can create dust when
you cut, sand, drill or grind
materials such as wood,
paint, metal, concrete, cement, or other
masonry. This dust often contains
chemicals known to cause cancer, birth
defects, or other reproductive harm.
Wear protective gear.
