Bigtide HL1916T User Manual

19 inch lcd monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
19INCH LCD MONITOR
REV A
User Manual
19"LCD Monitor
HL1916T/HL1916N

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HL1916T and is the answer not in the manual?

Questions and answers

Summary of Contents for Bigtide HL1916T

  • Page 1 19INCH LCD MONITOR REV A User Manual 19"LCD Monitor HL1916T/HL1916N...

  • Page 2: Table Of Contents

    19INCH LCD MONITOR REV A Contents 1. Application..................................1 2. Declarations ..................................2 Safety precautions .................................2 Environmental Requirements............................6 3. Installation..................................8 4. Start-up....................................9 4.1 Connecting the power and signal cables .........................9 4.1.1 Little cover (removing) ..........................10 4.1.2 Cable (attaching) ............................10 4.1.3 Little cover (attaching)..........................11 4.2 Switching on the display ............................12 4.3 Adjusting the image geometry ..........................12 4.4 Adjusting the brightness and contrast ........................12...

  • Page 3: Application

    19INCH LCD MONITOR REV A Federal Communications Commission(FCC) Statement You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the use’s authority to operate the equipment FCC-Class B This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to part 15 of the FCC Rules.

  • Page 4: Declarations

    19INCH LCD MONITOR REV A 2. Declarations Safety precautions Equipment With respect to electric shock, Fire and mechanical hazards only accordance with UL 60601-1 and CAN/CSA C22.2 No. 601.1 Regular maintenance and calibration are recommended Please note that liquid crystal displays such as the HL1916 do not have a failure rate of zero and image parameters may change over time (e.g.
  • Page 5 19INCH LCD MONITOR REV A Explanation of the symbols Attention: Consult the accompanying documents Alternation current (AC) Protective earth CAUTION:Risk of electric shock. Do not open. ATTENTION:Risque de choc electrique, Ne pas ouvrir Dispose of in accordance to your countries requirements European comformity China Quality Certification TUV approval mark...
  • Page 6 19INCH LCD MONITOR REV A Danger: There is a danger to life if the warning information is not observed. Severe personal injury or damage to property may occur. Do not open the unit yourself. Certain components inside the units are at high-voltage, i.e. touching these components presents a danger to life! Only use a perfect power supply cable A damaged power supply cable may result in a fire or electric shock.
  • Page 7 19INCH LCD MONITOR REV A Only use the signal cables and interface cables specified by the manufacturer for the installation. Use power cables with a PE contact. Only insert into sockets with a PE contact. For certain applications, the video earth can be separately connected to the PE via the additional PE connection in the plug panel (observe IEC 601-1-1).

  • Page 8: Environmental Requirements

    19INCH LCD MONITOR REV A Mounting screws Number Thread Strength Immersion depth Min. 10 mm; Max. 12 mm Torque Max. 3 Nm The permissible ambient temperature range (5 °C ... 40 °C) must not be violated. Do not subject device to unnecessary shocks. Take care when transporting! Use the original packaging! The panel in particular should be protected against shocks.
  • Page 9 19INCH LCD MONITOR REV A Lamp Disposal Lamp(s) inside this product contains mercury and must be recycled or disposed of according to state, local or federal law. For more information, Contact the electronic industries alliance at www.Elae.org. For lamp specific disposal information check www.lamprecycle.org.

  • Page 10: Installation

    19INCH LCD MONITOR REV A 3. Installation Provide adequate ventilation Ventilation slots are located on the rear of the housing. Ambient temperature The permissible ambient temperature range must not be violated. Minimize reflections The display should be positioned so that reflections of lights, windows, furniture with shiny surfaces or light-monochrome walls do not appear on the screen.

  • Page 11: Start-Up

    19INCH LCD MONITOR REV A 4. Start-up Caution In order to ensure safe operation of the equipment, close attention must be paid to the information contained in this Instruction Manual as well as the warnings in Section 2 "Safety precautions". Caution Information for end customer None of the settings must be changed on site by the user, otherwise the guarantee is canceled.

  • Page 12: Little Cover (Removing)

    19INCH LCD MONITOR REV A 4.1.1 Little cover (removing) Remove the one screws with an M4 Slot screwdriver (one turn suffices). Open the little cover and remove it 4.1.2 Cable (attaching) Connect the cables to the display.

  • Page 13: Little Cover (Attaching)

    19INCH LCD MONITOR REV A Connect the power cable 15-pin Sub-D connector: the flat panel display can be connected to the computer system using the Sub-D connector. The display is adapted using an OSD menu. DVI connection: The connection to the computer can also be made via the digital single link or via the analog channel of the DVI connection.

  • Page 14: Switching On The Display

    19INCH LCD MONITOR REV A 4.2 Switching on the display Switch on the flat panel display using the power switch. The operation LED lights up. 4.3 Adjusting the image geometry The display automatically recognizes the used standard, and set-up values for each standard are preprogrammed.

  • Page 15: Connections

    19INCH LCD MONITOR REV A 5. Connections 5.1 Connecting the flat panel display Note All screening precautions contained in the corresponding EMC guidelines must be observed. If these guidelines are not observed, interference signals could penetrate the monitor. Information on cable installation Only screened cables are permitted for the signal connections.

  • Page 16: Analog And Digital Inputs (Dvi-D, Vga)

    19INCH LCD MONITOR REV A 5.4 Analog and digital inputs (DVI-D, VGA) 15-pin Sub-D connector Connect VGA cable with 15-pin Sub-D connector (male) for the analog input to the 15-pin Sub-D connector (female). With DVI-I analog signal (connected with DVI-I to VGA converter) DVI socket With DVI digital signal.

  • Page 17: Adjustments

    19INCH LCD MONITOR REV A 6. Adjustments 6.1 Picture adjustment This section describes the settings for operation of the flat panel display with a video source. The most important settings are: Adjusting the graphics memory of the video source As with all monitors, the flat panel display also has certain limits, e.g. maximum resolution and vertical frequency.

  • Page 18: Optimum Picture Quality

    19INCH LCD MONITOR REV A slightly until the display is just above the absolute lowest black level (one step is generally sufficient). Similarly, set the white level using a 100%-white test pattern and the measurement device. Only the contrast level should be adjusted to ensure that the black level remains unchanged.

  • Page 19: Osd Menu

    19INCH LCD MONITOR REV A 6.3 OSD menu 6.3.1 Keys assignment and operation LED A “dynamic help for keypad function” is available for each menu: it explains the role of each key depending on the OSD menu window, which is currently active.

  • Page 20: Submenu Calls

    19INCH LCD MONITOR REV A Selection point To previous selection Command "Enter key" Slide controller Decrease value Down Selection point To subsequent selection Except "Exit OSD" menu One menu level upwards (settings are Exit retained) In "Exit OSD" menu Return to main menu (settings are retained) 6.3.4 Submenu calls Press the “Menu”...

  • Page 21: Description Of The Menus

    19INCH LCD MONITOR REV A 6.4 Description of the menus Adjustment Main Menu Function Description range Adjustment of contrast This allows the brighter area to be seen more distinctly. The center point is in 128 Contrast 0…255 position. Note: for DVI-D signals the Contrast setting is optimized.
  • Page 22 19INCH LCD MONITOR REV A another. The auto functions are used to assist the automatic setting of parameters. The quality of settings depends on the picture contents and the type of synchronization. Corresponding items in the OSD can adjust all settings finely. The selected auto functions are executed.
  • Page 23 19INCH LCD MONITOR REV A Status Current display settings can be called here in the respective picture mode: Operate hours of display, firmware version, OSD version, configuration version, current source, current temperature, current timing of input signal, current LUT inside the monitor.

  • Page 24: Fault Diagnostics

    19INCH LCD MONITOR REV A 7. Fault diagnostics Fault Cause Remedy No picture appears on Broken fuse Inform servicing department the display, operation LED off Power cable not inserted Insert power cable or incorrectly inserted No picture appears on No video signal Check video cable the display, operation Video...

  • Page 25: Technical Data

    19INCH LCD MONITOR REV A 8. Technical data All technical data are valid after a warming-up period of 2 hours. 8.1 Display Type TFT,color active matrix Display area 376.32 mm x 301.056 mm Picture diagonal 19" or 48 cm Native resolution 1280 x 1024 (full-screen format) Pixel organization 3 vertical sub pixels Pixel pitch...

  • Page 26: Electronics

    19INCH LCD MONITOR REV A 8.3 Electronics Multi-standard technology Video modes with resolutions less than 1280 x 1024 can be expanded to the TFT resolution, and thus utilize the full display area (like multi-sync CRTs). In the same way, resolutions higher than 1280 x 1024 can be reduced and then displayed.

  • Page 27: Serial Interface

    19INCH LCD MONITOR REV A 8.4.3 Serial interface RS232 Via D-sub 9pin 8.4.4 Timing Input Analog Digital Horizontal frequency 31kHz -82kHz 31kHz -82kHz 50.0Hz - 85.0 50.0Hz - 85.0 Hz Vertical frequency (Non-Interlaced) (Non-Interlaced) Input Video Signal Analog RGB Digital RGB Signals Separate Sync.

  • Page 28: Mechanical Design

    19INCH LCD MONITOR REV A 8.6 Mechanical design Housing components Aluminum Protective screen Visible screen surface Approx. 376 mm x 301 mm Ventilation slots In rear panel Degree of protection (front) IP20 to DIN 40 050 Connection panel At rear, covered Weight: Without stand 5.0 kg (approximate) With stand...

  • Page 29: Mechanical Requirements

    19INCH LCD MONITOR REV A 8.8 Mechanical requirements Operation Vibration According to EN 60068-2-6 10 ... 58 Hz with ± 0.075 mm deflection 58 ... 500 Hz at 10 m/s² Shock According to EN 60068-2-27 (single shock) 150 m/s², 6 ms No permanent shock allowed in operating conditions Packed unit Vibration...

  • Page 30: Electromagnetic Compatibility

    19INCH LCD MONITOR REV A 8.10 Electromagnetic compatibility IEC6061-1-2 FCC Class B...

  • Page 31: Dimensional Drawings

    19INCH LCD MONITOR REV A 9. Dimensional drawings All dimensions in mm. 9.1 Front 、Platform and Side view...

  • Page 32: Remarks And Contact Address

    Environmental protection When disposing of the device, the requirements and laws in the respective country must be observed. Name of Manufacture: Shenyang Torch-Bigtide Digital Technology Co., Ltd. Address: No. 18-6B，Yaoyang Road, Huishan Economic Development Area, Shenbei New District, Shenyang, China 110164 Person to be contacted: Mr.

This manual is also suitable for:

Hl1916n
