Summary of Contents for Kramer VM-2UX
- Page 1 USER MANUAL MODEL: VM-2UX 12G SDI 1:2 DA P/N: 2900-300711 Rev 3 www.KramerAV.com...
-
Page 4: Table Of Contents
Contents Introduction Getting Started Achieving the Best Performance Safety Instructions Recycling Kramer Products Overview Connecting the VM-2UX Technical Specifications Figures Figure 1: VM-2UX 12G SDI 1:2 DA Figure 2: Connecting to the VM-2UX VM-2UX – Content... -
Page 5: Introduction
Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio; and GROUP 14: Collaboration. Congratulations on purchasing your Kramer VM-2UX 12G SDI 1:2 DA, which is ideal for the following typical applications: ... -
Page 6: Getting Started
Avoid interference from neighbouring electrical appliances that may adversely influence signal quality Position your VM-2UX away from moisture, excessive sunlight and dust This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building. -
Page 7: Recycling Kramer Products
Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at www.kramerav.com/support/recycling/. -
Page 8: Overview
Extended-reach Input Extension – Input signal equalization and output signal reclocking to gain extended-reach signal extension. Using Kramer high-quality coaxial SDI cables, supports extension of up to 80m (260ft) for 12G 4K signals. Reach depends on signal resolution, and quality of copper cable used. For further details, go to our website at www.kramerav.com/product/VM-2UX. -
Page 9: Figure 1: Vm-2Ux 12G Sdi 1:2 Da
This section defines the VM-2UX. Figure 1: VM-2UX 12G SDI 1:2 DA Feature Function 12G/6G LED (Blue) Lights when the SDI Signal is 12G or 6G 12G means a 2160p60 progressive video format and 6G means a 2160p30 progressive video format HD 1.5/3G LED... -
Page 10: Connecting The Vm-2Ux
Connecting the VM-2UX Always switch off the power to each device before connecting it to your VM-2UX. After connecting your VM-2UX, connect its power and then switch on the power to each device. You do not have to connect all the inputs and outputs, connect only those that are required. -
Page 11: Technical Specifications
0.52kg (1.15lbs) approx. Included Accessories: Power supply, mounting bracket RK-4PT 19” rack adapter Options: Specifications are subject to change without notice at www.kramerav.com For optimum range and performance use the recommended Kramer cables available at www.kramerav.com/product/VM-2UX VM-2UX – Technical Specifications... - Page 13 SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our Web site to find updates to this user manual. We welcome your questions, comments, and feedback.
