CONSUMER: READ AND SAVE THESE INSTRUCTIONS
IMPORTANT: Read and understand all of the directions in this manual before assembling,
starting, or servicing the heater. Improper use of this heater can cause serious injury. Keep
this manual for future reference. The requirements of local authorities having jurisdiction
shall be followed.
DANGER
of fire, explosion, burn,asphyxiation, and carbon monoxide poisoning can result.
Only persons who can follow and understand these instructions should use or service this
heater. If you need heater information such as an instruction manual, labels, etcetera,
contact the manufacturer.
DANGER
under construction, alteration or repair.
Model Number
MH-600T-KFA
GENERAL HAZARD WARNING: Be sure to comply with the
instructions and warnings provided with this heater, or death,
serious bodily injury and property loss, damage from the hazards
Not for use in residential living areas or in non-adequately ventilated
enclosed spaces. For outdoor use. Indoor use permitted for: The
temporary heating of adequately ventilated buildings or structures
Fax: 320-251-2922 • Web: www.masterindustrialproducts.com • Email: info@pinnacleclimate.com
KEROSENE FORCED AIR
User's Manual &
Operating Instructions
1 Industrial Blvd #101, Sauk Rapids, MN 56379 USA • Toll Free (800) 779-3267
© 2017 Pinnacle Climate Technologies, Inc. MAKB-410
HEATER
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Master MH-600T-KFA
Summary of Contents for Master MH-600T-KFA
- Page 1 User’s Manual & Operating Instructions Model Number MH-600T-KFA CONSUMER: READ AND SAVE THESE INSTRUCTIONS IMPORTANT: Read and understand all of the directions in this manual before assembling, starting, or servicing the heater. Improper use of this heater can cause serious injury. Keep this manual for future reference.
-
Page 2: Table Of Contents
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE Table of Contents Safety Information Indicates an imminently hazardous DANGER Safety Information ..............2-3 situation which, if not avoided, WILL Features ..................3 result in death or serious injury. Unpacking.................. -
Page 3: Safety Information
Front Features Handle Frame Front Handle Rear Shell Front Shell Rear Handle Lower Shell Fan Guard Fuel Tank Control Panel Power Cord Figure 1. Features of Model MH-600T-KFA © 2017, Pinnacle Climate Technologies, Inc. Kerosene Forced Air Heater User’s Manual... -
Page 4: Unpacking
Fuel Tank Flange Fan Guard Wheel Support Frame Wheel (Pneumatic) Axle Wheel Tube Valve Flat Washer (L) Flat Washer (S) Cotter Pin Bushing Figure 2. Assembly of Model MH-600T-KFA © 2017, Pinnacle Climate Technologies, Inc. Kerosene Forced Air Heater User’s Manual... - Page 5 NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE Assembly Model MH-600T-KFA Wheel support frame Wheels and Axle Wheel Caps Front and Rear Handle Handle Frame Cord Wraps Screws, Nuts, and Washers Cotter Pins and Bushings...
-
Page 6: Operation
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE Operation KEROSENE (K-1) Electrical System Protection: This heater’s electrical system is For optimal performance of this heater, it is strongly suggested protected by a fuse that protects it and other electrical components from that K-1 kerosene be used. - Page 7 NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE Operation (Continued) Fuse Barrel Motor Model MH-600T-KFA Combustion Chamber Internal Shut- 176°F / 80°C Room Temperature off Temp. +/-10 Degrees Fuse Power Lamp Reset Temp. 149°F / 65°C...
- Page 8 NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE Operation (Continued) LONG-TERM STORAGE OF HEATER 1. Remove drain nut from rear bottom side of fuel tank by un- screwing nut and drain. See Figure 6. 2. Using a small amount of kerosene, swirl and rinse the inside of the tank.
-
Page 9: Maintenance
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE Maintenance Never service heater while it is WARNING plugged in or while hot! Nozzle NOTE: USE ORIGINAL EQUIPMENT REPLACEMENT PARTS. Use of third-party or other alternate components will void warranty and may cause unsafe operating conditions. - Page 10 NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE Maintenance (Continued) Burner Assembly Fuel Filter Fuel Cover Photocell Figure 10. Removing Fuel Filter Figure 9. Photocell Fuel Cap PHOTOCELL CLEAN PHOTOCELL ANNUALLY OR AS NEEDED. Fuel Gasket 1.
-
Page 11: Wiring Diagram
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE Maintenance (Continued) PUMP PRESSURE ADJUSTMENT (Continued) 8. Stop heater (See OPERATION, page 7). 9. If accessory pressure gauge is being used, remove pressure gauge. 10. Replace fuel line, and plug in end of filter cover. NOTE: Use only original equipment replacement parts. -
Page 12: Exploded View
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE Exploded View © 2017, Pinnacle Climate Technologies, Inc. Kerosene Forced Air Heater User’s Manual... -
Page 13: Parts List
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE Parts List Description MH-400T-KFA PCB Assembly 70-027-0800 Fuel Cap Assembly 70-006-0200 Pneumatic Wheel 70-041-0110 Photocell 70-016-0150 Nozzle 70-015-0750 Fan Motor Assembly 70-021-0800 © 2017, Pinnacle Climate Technologies, Inc. Kerosene Forced Air Heater User’s Manual... -
Page 14: Troubleshooting Guide
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE Troubleshooting Guide Problem Possible Cause Solution Heater Ignites, but main PCB shuts 1. Incorrect pump pressure. 1. Adjust pump pressure (see page 10). off after a short period of time. 2. -
Page 15: Warranty
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE Limited Warranty Pinnacle Climate Technologies, Inc. warrants this heater If Pinnacle Climate Technologies, Inc. finds the item to to the original retail purchaser only, to be free from defects be in normal operating condition, or not defective the item in material and workmanship for a period of one (1) year will be returned freight collect.
