Please note:
This instruction manual provides detailed information and instructions that must be read, understood and
followed to ensure that the equipment is installed, operated and serviced in an appropriate manner.
Failure to do so before using may result in hazardous consequences and/or improper operation.
Manufactured by:
PRIMARY FLUID
SYSTEMS INC.
ECO Valve
Uses:
• Back Pressure valve
• Anti-Siphon valve
• Pressure Sustaining valve
• Pressure Relief valve
Instruction Manual
1/2", 3/4", and 1" ("B" Series)
ECO-55, ECO-75, ECO-100
1050 Cooke Blvd., Burlington, Ontario, L7T 4A8
Tel: (905) 333-8743
Call Toll Free: 1-866-324-6422
Fax: (905) 333-8746
E-Mail:
sales@ecovalve.ca
http:www.ecovalve.ca
10/2020
Rev. 9
Advertisement
Related Manuals for Primary fluid systems ECO-55
Summary of Contents for Primary fluid systems ECO-55
- Page 1 • Pressure Relief valve Instruction Manual 1/2”, 3/4”, and 1” (“B” Series) ECO-55, ECO-75, ECO-100 Please note: This instruction manual provides detailed information and instructions that must be read, understood and followed to ensure that the equipment is installed, operated and serviced in an appropriate manner.
- Page 2 Introduction The following instructions are to provide information on the Installation, operation and maintenance of ECO Valve, diaphragm style valves, manufactured by Primary Fluid Systems Inc. The valves are designed to help improve the performance and safe operation of most positive displacement pumps.
- Page 3 Back Pressure /Pressure Sustaining Valve: Reason for Selection and Use Metering pumps having an atmospheric discharge system pressure or less than 20 psi will benefit from the installation of a back pressure control valve. Metering pumps in general require downstream back pressure to ensure smoother function of the discharge check assemblies, which enhances the accuracy of the discharge flow.
- Page 4 The valve is supplied from the factory pre-set at 50 psig. To increase the pressure setting, back off the lock nut located beneath the colour coded bonnet cap. Turn the Allan bolt using a 5/16” or #8 hex key clockwise to increase pressure setting or counter clockwise to reduce pressure setting.
- Page 5 Manual Air Release The valve is shipped with a factory set pressure of 50 psig. The diagram to the left shows a cut away view of the position of the diaphragm on the seat. To adjust the valve to relieve air or gas downstream: 1.
- Page 6 Typical Installations The installations below are typical installation examples only. Consult your engineering department for the appropriate installation for your application or call the factory for advice Example A: Solenoid Driven Pumps Rated Under 150 psig Example B: System arrangement for solenoid driven (above 150 psig) or motor driven pumps.
- Page 7 Exploded View – Back Pressure / Pressure Relief Valve 1/2" High Flow (ECO-55), 3/4” (ECO-75), 1" (ECO-100) ECO Valves...
-
Page 8: Parts Ordering Information
Parts Ordering Information Connection: A= NPT B= BSPT C= S/W N.A. D= S/W Metric EVT-1CPVC- 51 E= Flg. ASME F= Flg. DIN G= Union Thr’d EVB -2* * * - * *- * * Size: 55= ½” valve 75= ¾” valve 100= 1”... -
Page 9: Flow Rates
The maximum pressure rating for valves regardless 1.00 1.00 of size is 150 PSIG (1034 kPa) at 73° F (22°C) 1.00 1.00 1.00 NR = not recommended 1.00 1.00 Primary Fluid Systems, Inc. takes no responsibility for the enclosed data. -
Page 11: Limited Warranty
LIMITED WARRANTY Primary Fluid Systems Inc. (Primary) warrants its products against defects in workmanship or materials for one (1) year under normal use. Three-(3) year available when application card is completed and returned to factory. Primary’s obligations and liabilities under this warranty shall be limited to replacement of the product, or a refund of an amount not to exceed the purchase price of the product(s) to which such warranty claim is made. - Page 12 Notes...
