Summary of Contents for Alfa Romeo 4C SPIDER 2018

  • Page 1 SPIDER 2 0 1 8 O W N E R ’ S M A N U A L...
  • Page 2 VEHICLES SOLD IN CANADA This manual illustrates and describes the operation of With respect to any Vehicles Sold in Canada, the name FCA features and equipment that are either standard or op- US LLC shall be deemed to be deleted and the name FCA tional on this vehicle.
  • Page 3 TABLE OF CONTENTS SECTION PAGE INTRODUCTION ............. . . 3 GRAPHICAL TABLE OF CONTENTS .

  • Page 5: Table Of Contents

    INTRODUCTION CONTENTS INTRODUCTION ..... . .4 WARNINGS AND CAUTIONS ... . .6 HOW TO USE THIS MANUAL .

  • Page 6: Introduction

    4 INTRODUCTION INTRODUCTION This Owner’s Manual describes all versions of this vehicle. Options and equipment dedicated to specific Dear Customer, markets or versions are not expressly indicated in the Congratulations on selecting your new vehicle. Be text. Therefore, you should only consider the informa- assured that it represents precision workmanship, dis- tion which is related to the trim level, engine, and tinctive styling, and high quality.

  • Page 7: How To Use This Manual

    INTRODUCTION 5 HOW TO USE THIS MANUAL The detailed index at the back of this Owner’s Manual contains a complete listing of all subjects. Essential Information Symbols Consult the Table of Contents to determine which section contains the information you desire. Consult the following table for a description of the symbols that may be used on your vehicle or through- Since the specification of your vehicle depends on the...

  • Page 8: Warnings And Cautions

    6 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against operating procedures that could result in a collision, bodily injury and/or death. It also contains CAU- TIONS against procedures that could result in damage to your vehicle. If you do not read this entire Owner’s Manual, you may miss important information.
  • Page 9 GRAPHICAL TABLE OF CONTENTS CONTENTS FRONT VIEW ......8 INTERIOR ......11 REAR VIEW .
  • Page 10 8 GRAPHICAL TABLE OF CONTENTS FRONT VIEW Front View 1 — Headlights 4 — Exterior Mirrors 2 — Windshield 5 — Doors 3 — Wheels/Tires...
  • Page 11 GRAPHICAL TABLE OF CONTENTS 9 REAR VIEW Rear View 1 — Rear Lights 2 — Decklid...
  • Page 12 10 GRAPHICAL TABLE OF CONTENTS INSTRUMENT PANEL Instrument Panel 1 — Air Vents 4 — Instrument Cluster 2 — Multifunction Lever 5 — Windshield Wiper Lever 3 — Steering Wheel 6 — Radio...
  • Page 13 GRAPHICAL TABLE OF CONTENTS 11 INTERIOR Interior 1 — Seats 4 — Door Locks/Window Switches 2 — Gear Selector 5 — Passenger Front Air Bag Location 3 — Climate Controls...
  • Page 15 GETTING TO KNOW YOUR VEHICLE CONTENTS KEYS .......15 DOORS ......22 ▫...
  • Page 16 14 GETTING TO KNOW YOUR VEHICLE EXTERIOR LIGHTS .....30 CLIMATE CONTROLS ....36 ▫...

  • Page 17: Keys

    GETTING TO KNOW YOUR VEHICLE 15 KEYS To Unlock The Doors Push and release the unlock button on the key fob to Key Fob unlock the doors. The park lights and turn signal lights The key fob contains the key fob with an integrated will flash to acknowledge the signal and the illuminated mechanical key.
  • Page 18 16 GETTING TO KNOW YOUR VEHICLE When a speed of more than 12 mph (20 km/h) is Replacing The Battery In The Key Fob reached, the doors will be locked automatically if the NOTE: Perchlorate Material – special handling may Autoclose function was selected.

  • Page 19: Ignition Switch

    GETTING TO KNOW YOUR VEHICLE 17 Replace the key fob battery with the following proce- General Information dure: The following regulatory statement applies to all radio frequency (RF) devices equipped in this vehicle: 1. Push release button and move the mechanical key to opening position.
  • Page 20 18 GETTING TO KNOW YOUR VEHICLE 3. Remove the key from the ignition switch lock cylinder. WARNING! (Continued) brake, turn the engine OFF, remove the key fob from the ignition and lock your vehicle. • Never leave children alone in a vehicle, or with access to an unlocked vehicle.

  • Page 21: Key-In-Ignition Reminder

    GETTING TO KNOW YOUR VEHICLE 19 Key-In-Ignition Reminder CAUTION! Opening the driver’s door when the key is in the • Always remove the Sentry Key from the vehicle ignition and the ignition switch position is in the STOP and lock all doors when leaving the vehicle (OFF/LOCK) position, sounds a signal to remove the unattended.

  • Page 22: General Information

    20 GETTING TO KNOW YOUR VEHICLE General Information Operation The following regulatory statement applies to all radio The alarm activates in the following cases: frequency (RF) devices equipped in this vehicle: 1. Wrongful opening of one of the doors or the decklid This device complies with Part 15 of the FCC Rules and (perimeter protection);...

  • Page 23: To Arm The System

    GETTING TO KNOW YOUR VEHICLE 21 To Arm The System To Disarm The System With the doors and decklid closed and the ignition key Deactivation either turned to STOP (OFF/LOCK) or removed, point Push the unlock button. the key towards the vehicle then push and release the The following operations are performed: lock button.

  • Page 24: Doors

    22 GETTING TO KNOW YOUR VEHICLE NOTE: If the batteries of the key fob run out or there is Locking Doors From The Outside a fault in the system, the alarm can be switched off by With the doors closed, push the lock button on the key inserting the key in the ignition switch and turning it to fob or turn the metal insert (located inside the key fob) MAR (ON/RUN).

  • Page 25: Emergency Door Locking Device

    GETTING TO KNOW YOUR VEHICLE 23 Unlocking Doors From The Outside Door Opening/Closing Mechanism Reset Push the unlock button on the key fob or turn the metal If the battery is disconnected or the protection fuse insert (located inside the key fob) in the driver side door blows, the door opening/closing mechanism must be lock.

  • Page 26: Seats

    24 GETTING TO KNOW YOUR VEHICLE SEATS Seats are a part of the Occupant Restraint System of the vehicle. WARNING! • It is dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed.

  • Page 27: Manual Front Seats

    GETTING TO KNOW YOUR VEHICLE 25 Manual Front Seats Seat Height Adjustment In order to achieve the ideal driving position, the height Forward And Rearward Adjustment of the seats can also be adjusted. Tools are required to The adjusting bar is at the front of the driver seat, near make this height adjustment.

  • Page 28: Head Restraints

    26 GETTING TO KNOW YOUR VEHICLE WARNING! (Continued) • Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt, which could result in serious injury or death. HEAD RESTRAINTS Non-Adjustable Head Restraints The non-adjustable head restraints are form fitted into...

  • Page 29: Steering Wheel

    GETTING TO KNOW YOUR VEHICLE 27 WARNING! (Continued) head restraints are placed in their proper posi- tions in order to minimize the risk of neck injury in the event of a crash. • Be certain that the seatback is securely locked into position.

  • Page 30: Mirrors

    28 GETTING TO KNOW YOUR VEHICLE mirror should be adjusted while the small control under WARNING! the mirror is set in the day position (toward the windshield). Do not adjust the steering column while driving. Adjusting the steering column while driving or driving with the steering column unlocked, could cause the driver to lose control of the vehicle.
  • Page 31 GETTING TO KNOW YOUR VEHICLE 29 WARNING! Vehicles and other objects seen in the passenger side convex mirror will look smaller and farther away than they really are. Relying too much on your passenger side convex mirror could cause you to collide with another vehicle or other object.

  • Page 32: Heated Mirrors

    30 GETTING TO KNOW YOUR VEHICLE Folding Mirrors EXTERIOR LIGHTS The exterior mirrors are hinged to allow the mirror to Multifunction Lever pivot forward or rearward to help avoid damage. The The multifunction lever, located on the left side of the mirror has three detent positions: full forward, full steering wheel, controls the operation of the headlights, rearward and normal.

  • Page 33: Headlights

    GETTING TO KNOW YOUR VEHICLE 31 Headlights NOTE: The low beams and side/tail lights will not be on with DRL. Rotate the end of the multifunction lever High Beams upward to the first detent for headlight operation. With the low beams activated, pull the multi- function lever towards the steering wheel to turn on the high beams.

  • Page 34: Follow Me Home/Headlight Delay

    32 GETTING TO KNOW YOUR VEHICLE Follow Me Home/Headlight Delay NOTE: If either light remains on and does not flash, or there is a very fast flash rate, check for a defective When this feature is selected, the driver can choose to outside light bulb.
  • Page 35 GETTING TO KNOW YOUR VEHICLE 33 Interior Light Timing (Center Position) CAUTION! There are four different modes of operation that can be Before getting out of the vehicle be sure that the activated in this position: Overhead Dome Lamp is in the center position or •...

  • Page 36: Windshield Wipers And Washers

    34 GETTING TO KNOW YOUR VEHICLE Dimmer Controls The dimmer controls are located on the left side of the instrument panel below the instrument cluster. Windshield Wiper/Washer Lever Windshield Wiper Operation Rotate the end of the lever upward, to the first detent past the intermittent settings for low-speed wiper op- Dimmer Controls eration.
  • Page 37 GETTING TO KNOW YOUR VEHICLE 35 the first delay interval setting. Continue to rotate the WARNING! end of the lever to the other detents for the other delay intervals that depend on the vehicle speed. Sudden loss of visibility through the windshield could lead to a collision.

  • Page 38: Climate Controls

    36 GETTING TO KNOW YOUR VEHICLE CLIMATE CONTROLS Climate Controls Overview The Climate Control System allows you to regulate the temperature, air flow, and direction of air circulating throughout the vehicle. The controls are located on the instrument panel below the radio. Climate Controls...
  • Page 39 GETTING TO KNOW YOUR VEHICLE 37 Climate Control Descriptions Icon Description A/C Button Push and release to change the current setting, the indicator illuminates when A/C is on. Performing this function again will cause the A/C operation to switch into manual mode and the A/C indicator will turn off.
  • Page 40 38 GETTING TO KNOW YOUR VEHICLE Icon Description Demist/Defrost Button Push and release the Demist/Defrost button to turn on the outside mirror defroster. An indicator will illuminate when the outside mirror defroster is on. The outside mirror de- froster automatically turns off after 20 minutes. Temperature Control Knob Temperature control is used to regulate the temperature of the air forced through the cli- mate system.
  • Page 41 GETTING TO KNOW YOUR VEHICLE 39 Icon Description Bi-Level Mode Bi-Level Mode Air comes from the instrument panel outlets and floor outlets. A slight amount of air is directed through the defrost and side window demister outlets. NOTE: Bi-Level mode is designed under comfort conditions to provide cooler air out of the panel outlets and warmer air from the floor outlets.

  • Page 42: Climate Control Functions

    40 GETTING TO KNOW YOUR VEHICLE Climate Control Functions 4. Move the Recirculation Control to Heating After demisting/defrosting, operate the controls as normal to restore the required comfort conditions. To heat the passenger compartment, proceed as follows: NOTE: The climate control system is very useful for 1.
  • Page 43 GETTING TO KNOW YOUR VEHICLE 41 Ventilation recirculation function on rainy/cold days to avoid the possibility of the windows misting. To ventilate the passenger compartment properly, pro- ceed as follows: Climate Control 1. Fully open the vents and direct them appropriately. Proceed as follows: 2.

  • Page 44: Windows

    42 GETTING TO KNOW YOUR VEHICLE Door Mirror Demisting System Maintenance In winter, the climate control system must be turned on at least once a month for about ten minutes. Have the system inspected at an authorized dealer before the summer.
  • Page 45 GETTING TO KNOW YOUR VEHICLE 43 Continuous Automatic Operation This is activated by pushing one of the two buttons for longer than half a second. The window will stop when it is fully opened, or when the button is pushed again. It can be used on both the driver side and passenger side, only for lowering the window.

  • Page 46: Removable Soft Top

    44 GETTING TO KNOW YOUR VEHICLE 4. Make sure that the reset is correct by checking that Removing The Soft Top the windows work automatically. To remove the soft top, proceed as follows: 1. Turn the front locking handles located near the sun WARNING! visors to the left one quarter turn.
  • Page 47 GETTING TO KNOW YOUR VEHICLE 45 2. From the passenger side with the door open, move 3. Roll up the soft top to the center of the vehicle, repeat the two side locking handles towards each other and the procedure on the driver’s side of the vehicle. lift the top from the retainers.

  • Page 48: Installing The Soft Top

    46 GETTING TO KNOW YOUR VEHICLE 5. Place the pin buffer over the front locking handle Installing The Soft Top pins to prevent damage to the soft top during To install the soft top, proceed as follows: storage. 1. With the doors open, take the soft top and place it in center of the vehicle.
  • Page 49 GETTING TO KNOW YOUR VEHICLE 47 3. As the side beam is unrolled, engage the two fixed 4. Move the side locking handles inward. locating pins (1 front, 1 rear) into their retainers. Unlocking The Side Beam Locating Pins Seating In The Vehicle...
  • Page 50 48 GETTING TO KNOW YOUR VEHICLE 5. Rotate down the side beam. 6. Release the handles and complete the rotation to lock the soft top. Rotating The Side Beam Down Soft Top In Locking Position...
  • Page 51 GETTING TO KNOW YOUR VEHICLE 49 7. Check to make sure that the handles are locked in place. Handles In Locked Position NOTE: Handles In Locked Position • Do not attach a roof rack on the soft top. 8. Repeat this procedure on both sides of the vehicle. •...
  • Page 52 50 GETTING TO KNOW YOUR VEHICLE • With the top open and the vehicle travelling, the • When using steam washers or high-pressure power speech recognition system along with the dial num- washers, maintain a suitable distance and do not ber command, may not be recognized because of the exceed a maximum temperature of 140 °F (60 °C).

  • Page 53: Decklid

    GETTING TO KNOW YOUR VEHICLE 51 • The rubber seals of the top must be washed with To open the decklid: water only. Apply talcum power or use specific 1. Open the driver’s side door. rubber care products (silicone spray) if the seals are dry or partially stuck.
  • Page 54 52 GETTING TO KNOW YOUR VEHICLE 3. Move to the rear of the vehicle and lift the decklid. 4. Lift upward on the decklid prop rod to release it from the stowage retainer. Decklid Lift Point Location Decklid Prop Rod Location 1 —...

  • Page 55: To Close The Decklid

    GETTING TO KNOW YOUR VEHICLE 53 5. Place the decklid prop rod in the decklid slot to WARNING! (Continued) secure the decklid in the open position. • Access the luggage compartment only with the vehicle stationary. Before exiting the vehicle, you should always place the vehicle into FIRST gear or REVERSE, apply the parking brake, and re- move the key from the ignition.

  • Page 56: Internal Equipment

    54 GETTING TO KNOW YOUR VEHICLE NOTE: Always check that the decklid is closed correctly INTERNAL EQUIPMENT to prevent it from opening while the vehicle is travel- Storage ling. Seatback Storage WARNING! Located in the back of both the driver and passenger front seats are pockets that can be used for storage.
  • Page 57 GETTING TO KNOW YOUR VEHICLE 55 Console Storage CAUTION! (Continued) There is a cargo pouch storage area located between the • During normal vehicle operation, the luggage driver and passengers seat. compartment (located rear of the engine) can reach temperatures above 149 °F (65 °C). Do not transport objects in the luggage compartment that may be damaged at such temperatures.
  • Page 58 56 GETTING TO KNOW YOUR VEHICLE WARNING! Do not allow children to have access to rear storage compartment. Always close the decklid when your vehicle is unattended. Once in the rear storage compartment, young children may not be able to escape.

  • Page 59: Cupholder

    GETTING TO KNOW YOUR VEHICLE 57 Cupholder WARNING! (Continued) A cupholder is located in the rear of the center console. • Access the luggage compartment only with the vehicle stationary. Before exiting the vehicle, you should always place the vehicle into FIRST gear or REVERSE, apply the parking brake, and re- move the key from the ignition.

  • Page 60: Power Outlets

    58 GETTING TO KNOW YOUR VEHICLE Power Outlets Your vehicle is equipped with a 12 Volt (13 Amp) power outlet that can be used to power cellular phones, small electronics and other low powered electrical accesso- ries. Power Outlet Fuse Location WARNING! To avoid serious injury or death: •...
  • Page 61 GETTING TO KNOW YOUR VEHICLE 59 CAUTION! CAUTION! (Continued) accessories still plugged in), the vehicle must be • Many accessories that can be plugged in draw driven a sufficient length of time to allow the power from the vehicle’s battery, even when not generator to recharge the vehicle’s battery.
  • Page 63 GETTING TO KNOW YOUR INSTRUMENT PANEL CONTENTS INSTRUMENT CLUSTER ....62 ▫ Exit Trip ......76 ▫...

  • Page 64: Instrument Cluster

    62 GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER Instrument Cluster...

  • Page 65: Instrument Cluster Descriptions

    GETTING TO KNOW YOUR INSTRUMENT PANEL 63 Instrument Cluster Descriptions WARNING! (Continued) 1. Temperature Gauge for service if your vehicle overheats. If you decide • The temperature gauge shows engine coolant tem- to look under the hood yourself, see “Servicing And perature.

  • Page 66: Instrument Cluster Display

    64 GETTING TO KNOW YOUR INSTRUMENT PANEL • The fuel pump symbol points to the side of the main menus and submenus. You can access the the vehicle where the fuel door is located. specific information you want and make selections and adjustments.
  • Page 67 GETTING TO KNOW YOUR INSTRUMENT PANEL 65 The system allows the driver to select information by pushing the following buttons mounted on the instru- ment panel to the left of the steering column: Instrument Cluster Display The instrument cluster display features a driver- interactive display that is located in the instrument cluster.

  • Page 68: Change Engine Oil Indicator System

    66 GETTING TO KNOW YOUR INSTRUMENT PANEL • Down Arrow Button Reset the Oil Change Reminder message as follows: Push and release the down arrow button to 1. Without pushing the brake pedal, cycle the ignition scroll downward through the main menu and to the MAR/ON/RUN position (do not start the submenus or to decrease the displayed value.
  • Page 69 GETTING TO KNOW YOUR INSTRUMENT PANEL 67 • Speed Buzzer 3. Briefly push the SET/BACK button to store the new setting and go back to the main menu option previ- • Trip B/Data ously selected. • Set Time Selecting An Option Of The Main Menu With Sub- •...
  • Page 70 68 GETTING TO KNOW YOUR INSTRUMENT PANEL Speed Buzzer (Speed Limit) Briefly push the SET/BACK button to go back to the menu screen, or push and hold the SET/BACK button With this function, it is possible to set the vehicle speed (approximately one second) to go back to the main limit (MPH or km/h) to immediately alert the driver screen without storing the settings.
  • Page 71 GETTING TO KNOW YOUR INSTRUMENT PANEL 69 2. Push and release the up or down arrow button to 5. Push and release the up or down arrow button for select the setting and once selected a beep will occur setting. to signal the setting is saved.
  • Page 72 70 GETTING TO KNOW YOUR INSTRUMENT PANEL BACK button (approximately one second) to go back to NOTE: The setting will increase or decrease by one the main screen without storing the settings. unit each time the up or down arrow button is pushed. Push and hold the up or down arrow button to Set Date increase/decrease the setting rapidly.
  • Page 73 GETTING TO KNOW YOUR INSTRUMENT PANEL 71 3. Briefly push the SET/BACK button to go back to the 6. Briefly push the SET/BACK button to return to the menu screen, or push and hold the SET/BACK submenu. button (approximately one second) to go back to the 7.
  • Page 74 72 GETTING TO KNOW YOUR INSTRUMENT PANEL 5. Briefly push the SET/BACK button to return to the Buzzer Volume (Adjusting The Failure/Warning submenu. Buzzer Volume) With this function, the volume of the buzzer accompa- When you have made the required settings, briefly nying any failure/warning indication can be adjusted push the SET/BACK button to go back to the submenu to one of eight volume levels.
  • Page 75 GETTING TO KNOW YOUR INSTRUMENT PANEL 73 To obtain this information, proceed as follows: Daytime Running Lamps This function may be used to activate/deactivate the Push the SET/BACK button briefly. The display shows daytime running lamps. the service interval in miles (mi) or kilometers (km) according to the previous setting (see the Unit Of Proceed as follows to switch this function on or off: Measurement paragraph).

  • Page 76: Values Displayed

    74 GETTING TO KNOW YOUR INSTRUMENT PANEL Push and release the down arrow button to return to the After a few seconds, the name of the selected value is last menu option (Daylights). replaced by the corresponding icon. Values Displayed Range This indicates the distance which may be traveled with Indications On Display...

  • Page 77: Trip Computer

    GETTING TO KNOW YOUR INSTRUMENT PANEL 75 Trip Button Current Fuel Consumption This indicates the fuel consumption. The value is con- The TRIP/RESET button, located on the right steering stantly updated. The message “----” will appear on the column stalk, can be used to display and to reset the trip display if the vehicle is parked with the engine running.

  • Page 78: Trip Functions

    76 GETTING TO KNOW YOUR INSTRUMENT PANEL Trip Functions New Trip Both trip functions are resettable (reset — start of new To reset: trip). • Push and hold the TRIP button to reset the system manually. “Trip A” can be used to display the figures relating to: •...

  • Page 79: Warning Lights And Messages

    GETTING TO KNOW YOUR INSTRUMENT PANEL 77 Briefly push and release the MENU button to go back to brake is applied, that the brake fluid level is low, or that the menu screen or push and hold the MENU (approxi- there is a problem with the anti-lock brake system mately one second) to go back to the main screen reservoir.
  • Page 80 78 GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: The light may flash momentarily during sharp is detected. If the light does not illuminate, have the cornering maneuvers, which change fluid level condi- light inspected by your authorized dealer. tions. The vehicle should have service performed, and The light also will turn on when the parking brake is the brake fluid level checked.
  • Page 81 GETTING TO KNOW YOUR INSTRUMENT PANEL 79 or flash depending on the nature of the problem. Cycle detected, it will stay on until the fault is cleared. If the the ignition when the vehicle is safely and completely light comes on intermittently or remains on while stopped and the transmission is placed in the PARK driving, have an authorized dealer service the vehicle position.

  • Page 82: Yellow Warning Lights

    80 GETTING TO KNOW YOUR INSTRUMENT PANEL may be a malfunction with the charging system. Con- the recommended value and/or that slow pressure loss tact your authorized dealer as soon as possible. This is occurring. In these cases, optimal tire duration and indicates a possible problem with the electrical system fuel consumption may not be guaranteed.
  • Page 83 GETTING TO KNOW YOUR INSTRUMENT PANEL 81 As an added safety feature, your vehicle has been subsequent vehicle start-ups as long as the malfunction equipped with a tire pressure monitoring system exists. When the malfunction indicator is illuminated, (TPMS) that illuminates a low tire pressure telltale the system may not be able to detect or signal low tire when one or more of your tires is significantly under- pressure as intended.
  • Page 84 82 GETTING TO KNOW YOUR INSTRUMENT PANEL — Electronic Stability Control (ESC) Warning CAUTION! (Continued) Light — If Equipped sensor to become inoperable. After using an after- The “ESC Indicator Light” in the instrument cluster will market tire sealant it is recommended that you take come on when the ignition is placed in the ON/RUN or your vehicle to your authorized dealer to have your MAR/ON/RUN position, and when ESC is activated.
  • Page 85 GETTING TO KNOW YOUR INSTRUMENT PANEL 83 — Electronic Stability Control (ESC) Off When the engine is running, the MIL may flash to alert Warning Light — If Equipped serious conditions that could lead to immediate loss of power or severe catalytic converter damage. The vehicle This light indicates the Electronic Stability Control should be serviced as soon as possible if this occurs.

  • Page 86: Green Indicator Lights

    84 GETTING TO KNOW YOUR INSTRUMENT PANEL — Generic Warning Light — Cruise Control Set Indicator Light — If Equipped The Generic Warning Light will illuminate if there is an Engine Oil Pressure Sensor Failure. This light will turn on when the speed control is set to the desired speed.

  • Page 87: Onboard Diagnostic System - Obd Ii

    GETTING TO KNOW YOUR INSTRUMENT PANEL 85 ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! Your vehicle is equipped with a sophisticated onboard • Prolonged driving with the MIL on could cause diagnostic system called OBD II. This system monitors further damage to the emission control system. It the performance of the emissions, engine, and Alfa could also affect fuel economy and driveability.

  • Page 88: Emissions Inspection And Maintenance Programs

    86 GETTING TO KNOW YOUR INSTRUMENT PANEL EMISSIONS INSPECTION AND MAINTENANCE WARNING! PROGRAMS • ONLY an authorized service technician should In some localities, it may be a legal requirement to pass connect equipment to the OBD II connection port an inspection of your vehicle’s emissions control sys- in order to diagnose or service your vehicle.
  • Page 89 GETTING TO KNOW YOUR INSTRUMENT PANEL 87 • The MIL will not flash at all and will remain fully Your vehicle has a simple ignition actuated test, which you can use prior to going to the test station. To check illuminated until you place the ignition in the off if your vehicle’s OBD II system is ready, you must do position or start the engine.
  • Page 91 SAFETY CONTENTS SAFETY FEATURES .....90 ▫ Child Restraints .....123 ▫...

  • Page 92: Safety Features

    90 SAFETY SAFETY FEATURES WARNING! (Continued) Four-Wheel Anti-Lock Brake System (ABS) you will brake in the shortest distance possible, depending on the current road conditions. The Four-Wheel ABS is designed to aid the driver in • For maximum efficiency of the braking system, a maintaining vehicle control under adverse braking condi- bedding-in period of about 311 miles (500 km) is tions.

  • Page 93: Esc (Electronic Stability Control System)

    SAFETY When you are in a severe braking condition involving WARNING! the use of the ABS, you will experience some pedal drop as the vehicle comes to a stop. This is the result of the • Electronic Stability Control (ESC) cannot prevent system reverting to the base brake system.
  • Page 94 92 SAFETY AntiSlip Regulation System (ASR), Hill Start Assist WARNING! (Continued) (HSA), Hydraulic Brake Assistant System (HBA), inflated and unevenly worn tires may also de- ELECTRONIC Q2 system (E-Q2) and Ready Alert Brake grade ESC performance. Any vehicle modifica- (RAB). All of the systems work together to enhance tion or poor vehicle maintenance that reduces the vehicle stability and control in various driving condi- effectiveness of the ESC system can increase the...
  • Page 95 SAFETY Cornering Brake Control System (CBC) WARNING! (Continued) The system acts when braking on corners, optimizing by prevailing road conditions. ESC cannot pre- the distribution of brake pressure on the four wheels: vent all collisions, including those resulting from the system prevents the wheels on the inside of the excessive speed in turns, driving on very slippery corner (less affected by the weight of the vehicle) from surfaces, or hydroplaning.
  • Page 96 94 SAFETY This is an integral part of the ESC system and automati- Hill Start Assist (HSA) cally operates in the event of one or both drive wheels This is an integral part of the ESC system and facilitates slipping, loss of grip on wet roads (hydroplaning) and starting on slopes, activating automatically in the fol- acceleration on slippery, snowy or icy roads, etc.
  • Page 97 SAFETY NOTE: WARNING! (Continued) • HSA is not a parking brake; therefore, never leave the way as to compromise the safety of the driver, the vehicle without having engaged the parking brake, other occupants of the vehicle or any other road turned the engine off and engaged first gear, so that user.

  • Page 98: Auxiliary Driving Systems

    96 SAFETY Electronic Q2 System (E-Q2) the outside temperature decreases, the tire pressure will decrease. Tire pressure should always be set based on The Electronic Q2 system intervenes during accelera- cold inflation tire pressure. This is defined as the tire tion on corners, braking the inner drive wheel and thus pressure after the vehicle has not been driven for at least increasing the traction of the outer wheel (which bears...
  • Page 99 SAFETY automatically update and the TPM Telltale Light will CAUTION! (Continued) turn off once the system receives the updated tire equipped on your vehicle. Undesirable system pressures. The vehicle may need to be driven for up to operation or sensor damage may result when 20 minutes above 15 mph (24 km/h) in order for the using replacement equipment that is not of the TPMS to receive this information.
  • Page 100 98 SAFETY • Driving on a significantly under-inflated tire causes The TPMS uses wireless technology with wheel rim the tire to overheat and can lead to tire failure. mounted electronic sensors to monitor tire pressure Under-inflation also reduces fuel efficiency and tire levels.
  • Page 101 SAFETY Tire Pressure Monitoring Light will extinguish once the 5. Using wheels/tires not equipped with TPM sensors. updated tire pressures have been received. The vehicle NOTE: Your vehicle may be equipped with a compact may need to be driven for up to 20 minutes above spare wheel and tire assembly.

  • Page 102: Occupant Restraint Systems

    100 SAFETY 5. Once you repair or replace the original road tire and OCCUPANT RESTRAINT SYSTEMS reinstall it on the vehicle in place of the compact Some of the most important safety features in your spare tire, the TPMS will update automatically and vehicle are the restraint systems: the Tire Pressure Monitoring Telltale Light will turn Occupant Restraint Systems Features...
  • Page 103 SAFETY 2. If a child from 2 to 12 years old (not in a rear-facing 7. The driver and front passenger seats should be child restraint) must ride in the front passenger seat, moved back as far as practical to allow the front air move the seat as far back as possible and use the bags room to inflate.

  • Page 104: Seat Belt Systems

    102 SAFETY Seat Belt Systems Initial Indication Buckle up even though you are an excellent driver, even If the driver is unbuckled when the ignition switch is on short trips. Someone on the road may be a poor first in the START or ON/RUN position, a chime will driver and could cause a collision that includes you.
  • Page 105 SAFETY based on vehicle speed until the driver and occupied NOTE: If BeltAlert has been deactivated and the driver or outboard front seat passenger (if equipped with outboard front seat passenger seat belts are buckled. outboard front passenger seat BeltAlert) is unbuckled The driver should instruct all occupants to buckle their the Seat Belt Reminder Light will turn on and remain on seat belts.
  • Page 106 104 SAFETY WARNING! (Continued) WARNING! (Continued) • In a collision, you and your passengers can suffer slide out of the seat belt. Follow these instructions much greater injuries if you are not properly to wear your seat belt safely and to keep your buckled up.
  • Page 107 SAFETY WARNING! (Continued) WARNING! (Continued) vehicle, take it to your authorized dealer immedi- do not wear your shoulder belt. The lap and ately and have it fixed. shoulder belt are meant to be used together. • A seat belt that is buckled into the wrong buckle •...
  • Page 108 106 SAFETY 2. The seat belt latch plate is above the back of the front seat, and next to your arm in the rear seat (for vehicles equipped with a rear seat). Grasp the latch plate and pull out the seat belt. Slide the latch plate up the webbing as far as necessary to allow the seat belt to go around your lap.
  • Page 109 SAFETY Lap/Shoulder Belt Untwisting Procedure Use the following procedure to untwist a twisted lap/ shoulder belt. 1. Position the latch plate as close as possible to the anchor point. 2. At about 6 to 12 inches (15 to 30 cm) above the latch plate, grasp and twist the seat belt webbing 180 degrees to create a fold that begins immediately above the latch plate.
  • Page 110 108 SAFETY Seat Belts And Pregnant Women Seat Belt Pretensioner The front seat belt system is equipped with pretension- ing devices that are designed to remove slack from the seat belt in the event of a collision. These devices may improve the performance of the seat belt by removing slack from the seat belt early in a collision.
  • Page 111 SAFETY Switchable Automatic Locking Retractor (ALR) If the passenger seating position is equipped with an ALR and is being used for normal usage, only pull the The seat belt in the passenger seating position is seat belt webbing out far enough to comfortably wrap equipped with a Switchable Automatic Locking Retrac- around the occupant’s mid-section so as to not activate tor (ALR) which is used to secure a child restraint...

  • Page 112: Supplemental Restraint Systems (Srs)

    110 SAFETY WARNING! WARNING! • Never place a rear-facing child restraint in front of • The seat belt assembly must be replaced if the an air bag. A deploying passenger front air bag switchable Automatic Locking Retractor (ALR) can cause death or serious injury to a child 12 feature or any other seat belt function is not years or younger, including a child in a rear- working properly when checked according to the...
  • Page 113 SAFETY The air bag system must be ready to protect you in a Air Bag Warning Light collision. The Occupant Restraint Controller (ORC) The ORC monitors the readiness of the electronic parts monitors the internal circuits and interconnecting wir- of the air bag system whenever the ignition ing associated with the electrical Air Bag System Com- switch is in the AVV/START or MAR/ACC/ ponents.
  • Page 114 112 SAFETY The diagnostics also record the nature of the malfunc- WARNING! tion. While the air bag system is designed to be main- tenance free, if any of the following occurs, have an Ignoring the Air Bag Warning Light in your instru- authorized dealer service...
  • Page 115 SAFETY WARNING! (Continued) extending your arms to reach the steering wheel or instrument panel. • Never place a rear-facing child restraint in front of an air bag. A deploying passenger front air bag can cause death or serious injury to a child 12 years or younger, including a child in a rear- facing child restraint.
  • Page 116 114 SAFETY This vehicle may be equipped with a driver and/or WARNING! (Continued) front passenger seat belt buckle switch that detects • Relying on the air bags alone could lead to more whether the driver or front passenger seat belt is severe injuries in a collision.
  • Page 117 SAFETY Because air bag sensors measure vehicle deceleration WARNING! over time, vehicle speed and damage by themselves are not good indicators of whether or not an air bag should • Do not drill, cut, or tamper with the knee impact have deployed.
  • Page 118 116 SAFETY impacts, in addition to the injury reduction potential provided by the seat belts and body structure. The SABICs are located in the door trim below the side windows. The trim covering the SABICs is labeled “SRS AIRBAG” or “AIRBAG.” The SABICs deploy upward, covering the side win- dows.
  • Page 119 SAFETY Side Impacts Side Air Bags are a supplement to the seat belt restraint system. Side Air Bags deploy in less time than it takes to The Side Air Bags are designed to activate in certain blink your eyes. side impacts. The Occupant Restraint Controller (ORC) determines whether the deployment of the Side Air WARNING! Bags in a particular impact event is appropriate, based...
  • Page 120 118 SAFETY • Steering Wheel and Column WARNING! • Instrument Panel • Side Air Bags need room to inflate. Do not lean • Knee Impact Bolsters against the door or window. Sit upright in the center of the seat. • Driver and Front Passenger Air Bags •...
  • Page 121 SAFETY If you do have a collision which deploys the air bags, Do not drive your vehicle after the air bags have any or all of the following may occur: deployed. If you are involved in another collision, the air bags will not be in place to protect you. •...
  • Page 122 120 SAFETY Enhanced Accident Response System compartment and on the ground near the engine com- partment and fuel tank before resetting the system and In the event of an impact, if the communication net- starting the engine. work remains intact, and the power remains intact, depending on the nature of the event, the ORC will Depending on the nature of the event the left and right determine whether to have the Enhanced Accident...
  • Page 123 SAFETY Customer Action Customer Will See Customer Action Customer Will See NOTE: Each step MUST BE held for at least two NOTE: Each step MUST BE held for at least two seconds seconds 4. Place turn signal in Right turn light is OFF. 11.
  • Page 124 122 SAFETY Maintaining Your Air Bag System WARNING! (Continued) be serviced in any way (including removal or WARNING! loosening/tightening of seat attachment bolts), • Modifications to any part of the air bag system take the vehicle to your authorized dealer. Only could cause it to fail when you need it.

  • Page 125: Child Restraints

    SAFETY • How far (if at all) the driver was depressing the Child Restraints accelerator and/or brake pedal; and, Everyone in your vehicle needs to be buckled up at all • How fast the vehicle was traveling. times, including babies and children. Every state in the United States, and every Canadian province, requires These data can help provide a better understanding of that small children ride in proper restraint systems.
  • Page 126 124 SAFETY There are different sizes and types of restraints for NOTE: children from newborn size to the child almost large • For additional information, refer enough for an adult safety belt. Always check the child www.safercar.gov/parents/index.htm or call: 1–888– seat Owner’s Manual to make sure you have the correct 327–4236 seat for your child.
  • Page 127 SAFETY Child Size, Height, Weight Or Recommended Type Of Child Re- straint Larger Children Children who have outgrown their Belt Positioning Booster Seat and forward-facing child restraint, but the vehicle seat belt, seated in the are too small to properly fit the rear seat of the vehicle vehicle’s seat belt Children Too Large for Child...
  • Page 128 126 SAFETY Older Children And Child Restraints WARNING! Children who are two years old or who have outgrown • Improper installation can lead to failure of an their rear-facing convertible child seat can ride forward- infant or child restraint. It could come loose in a facing in the vehicle.
  • Page 129 SAFETY Children Too Large For Booster Seats If the child is using the lap/shoulder belt, check seat belt fit periodically and make sure the seat belt buckle is Children who are large enough to wear the shoulder latched. A child’s squirming or slouching can move the belt comfortably, and whose legs are long enough to belt out of position.
  • Page 130 128 SAFETY Lap/Shoulder Belt Systems For Installing Child WARNING! Restraints In This Vehicle • Improper installation or failure to properly secure a child restraint can lead to failure of the restraint. The child could be badly injured or killed. • Follow the child restraint manufacturer’s direc- tions exactly when installing an infant or child restraint.
  • Page 131 SAFETY Frequently Asked Questions About Installing Child Restraints With Seat Belts What is the weight limit (child’s Weight limit of the Child Restraint Always use the tether anchor when weight + weight of the child re- using the seat belt to install a for- straint) for using the Tether Anchor ward facing child restraint, up to with the seat belt to attach a for-...
  • Page 132 130 SAFETY 2. Pull enough of the seat belt webbing from the 8. If the child restraint has a top tether strap and the retractor to pass it through the belt path of the child seating position has a top tether anchorage, connect restraint.

  • Page 133: Transporting Pets

    SAFETY 3. Attach the tether strap hook of the child restraint to the top tether anchorage as shown in the diagram. 4. Remove slack in the tether strap according to the child restraint manufacturer’s instructions. WARNING! An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child.

  • Page 134: Safety Tips

    132 SAFETY SAFETY TIPS Exhaust Gas Transporting Passengers WARNING! NEVER TRANSPORT PASSENGERS IN THE CARGO Exhaust gases can injure or kill. They contain AREA. carbon monoxide (CO), which is colorless and odor- less. Breathing it can make you unconscious and WARNING! can eventually poison you.

  • Page 135: Safety Checks You Should Make Inside The Vehicle

    SAFETY Whenever a change is noticed in the sound of the Air Bag Warning Light exhaust system, when exhaust fumes can be detected The Air Bag warning light will turn on for four to inside the vehicle, or when the underside or rear of the eight seconds as a bulb check when the ignition vehicle is damaged, have a competent mechanic inspect switch is first turned to ON/RUN.
  • Page 136 134 SAFETY operation of the accelerator, brake or clutch pedals. WARNING! (Continued) Only use a floor mat that is securely attached using the • ONLY install floor mats designed to fit your floor mat fasteners so it cannot slip out of position and vehicle.

  • Page 137: Periodic Safety Checks You Should Make

    SAFETY Periodic Safety Checks You Should Make WARNING! (Continued) Outside The Vehicle • NEVER place any objects under the floor mat Tires (e.g., towels, keys, etc.). These objects could change the position of the floor mat and may Examine tires for excessive tread wear and uneven wear cause interference with the accelerator, brake, or patterns.
  • Page 139 STARTING AND OPERATING CONTENTS STARTING THE ENGINE ....139 ALFA DNA SYSTEM (DYNAMIC VEHICLE CONTROL SYSTEM) ....148 ▫...
  • Page 140 138 STARTING AND OPERATING PARKING SENSORS — IF EQUIPPED ..156 ADDING FUEL/SMART FUEL ... .159 ▫ Acoustic Signal ..... .156 TRAILER TOWING .

  • Page 141: Starting The Engine

    STARTING AND OPERATING 139 STARTING THE ENGINE Automatic Transmission Before starting your vehicle, adjust your seat, adjust To start the engine, press the brake pedal. The system both inside and outside mirrors, and fasten your seat engages NEUTRAL (N) automatically. belts.

  • Page 142: Normal Starting

    140 STARTING AND OPERATING Normal Starting If Engine Fails To Start NOTE: Normal starting of either a cold or a warm WARNING! engine is obtained without pumping or pressing the accelerator pedal. Never pour fuel or other flammable liquids into the throttle body air inlet opening in an attempt to start Turn the ignition switch to the AVV (START) position the vehicle.

  • Page 143: After Starting

    STARTING AND OPERATING 141 After Starting Additionally, for the first 200 miles (300 km), following these few simple guidelines is all that is necessary for a The idle speed is controlled automatically, and it will good break-in. decrease as the engine warms up. •...
  • Page 144 142 STARTING AND OPERATING The parking brake lever is located in the central tunnel. should always be applied whenever the driver is not in To apply the parking brake, pull the parking brake lever the vehicle. up as firmly as possible. To release the parking brake, pull the parking brake lever up slightly, push the center WARNING! button, then lower the parking brake lever completely.

  • Page 145: Six-Speed Alfa Twin Clutch

    STARTING AND OPERATING 143 CAUTION! WARNING! (Continued) • Before exiting the vehicle, always come to a If the Brake Warning Light remains on with the complete stop, then apply the parking brake, shift parking brake released, a brake system malfunction the transmission into FIRST gear or REVERSE, is indicated.
  • Page 146 144 STARTING AND OPERATING When the ignition is in the OFF position, the transmis- Operating Modes sion controls (shift paddles on the steering wheel, and The transmission has two normal operating modes gear selector buttons on the center console) are dis- (except when the “Race”...
  • Page 147 STARTING AND OPERATING 145 If a requested gear shift is not allowed (typically, Accelerating From A Stop because it would cause engine overspeed or lugging), FIRST (1) and REVERSE (R) can only be engaged (at a an acoustic signal will sound and the transmission will stop) when the brake pedal is pressed.
  • Page 148 146 STARTING AND OPERATING speeds below 6 mph (10 km/h), attempts to shift Pressing a shift paddle will only shift the transmission from 1 to R (or R to 1) will only be allowed if the one gear at a time. Holding a paddle depressed will not vehicle speed drops below the 2 mph (3 km/h) command multiple shifts;...
  • Page 149 STARTING AND OPERATING 147 • The driver’s door is opened and the accelerator pedal WARNING! or the brake pedal are not operated for at least one and a half seconds. Do not coast in NEUTRAL and never turn off the ignition to coast down a hill.

  • Page 150: Alfa Dna System

    148 STARTING AND OPERATING General Notes For uphill departures, accelerate gradually but fully, immediately after releasing the parking brake or the When the vehicle is stopped and in gear, always keep brake pedal; this allows the engine speed to increase to the brake pedal pressed until you decide to set off, then provide more torque at the wheels.

  • Page 151: Driving Modes

    STARTING AND OPERATING 149 This also acts on the dynamic vehicle control systems Dynamic Mode (engine, gearbox/transmission, ESC system). Activation Move the Alfa DNA system lever upwards (to the letter “D”) and hold in this position for half a second, until the corresponding LED lights up and the Dynamic mode activation indicator appears on the display.
  • Page 152 150 STARTING AND OPERATING Engine And Gearbox/Transmission: When Race mode is activated, the longitudinal/lateral accelerometer indicator screen (G-meter information) is The system adjusts the transmission shift calibration for displayed automatically. This considers gravitational sportier shifting. acceleration (G). NOTE: In Dynamic mode, the engine response to the Electronic Stability Control (ESC) and Anti-Slip accelerator pedal position increases considerably.
  • Page 153 STARTING AND OPERATING 151 In Race mode, the transmission only works in MANUAL All Weather Mode mode. Activation Deactivation Move the Alfa DNA system lever downwards (to the letter “A”) and hold in this position for half a second, To deactivate Race mode and return to Dynamic mode, until the corresponding LED lights up and the All move the Alfa DNA system lever downwards (to letter Weather mode activation indicator appears on the dis-...

  • Page 154: System Failure

    152 STARTING AND OPERATING NOTE: This strategy can be activated with vehicle at a stand- still, Race mode selected and FIRST (1st) gear engaged. • When the engine is next started, All Weather mode or Natural mode will be retained when the vehicle is The sequence of operations to perform is as follows: restarted.

  • Page 155: Speed Control - If Equipped

    STARTING AND OPERATING 153 The Speed Control Lever is located on the left side of the WARNING! (Continued) steering column. vehicle as measured by the performance pages must NOTE: In order to ensure proper operation, the Speed never be exploited in a reckless or dangerous man- Control system has been designed to shut down if ner, which can jeopardize the user’s safety or the multiple speed control functions are operated at the...

  • Page 156: To Activate

    154 STARTING AND OPERATING To Activate NOTE: The vehicle should be traveling at a steady speed, and on level ground before setting the speed Rotate the end of the multifunction lever upward to the control. first detent, indicated by the speed control icon, to activate the Speed Control.

  • Page 157: To Accelerate For Passing

    STARTING AND OPERATING 155 Metric Speed (km/h) Metric Speed (km/h) • Tapping the speed control lever up (+) once will • Tapping the speed control lever down (-) once will result in a two km/h increase in set speed. Each result in a two km/h decrease in set speed.

  • Page 158: Parking Sensors - If Equipped

    156 STARTING AND OPERATING memory. Rotating the end of the multifunction lever to Acoustic Signal the O (off) position, or turning the ignition switch to When REVERSE gear is engaged, and there is an OFF, erases the set speed memory. obstacle behind the vehicle, an acoustic signal is emitted which varies according to the distance of the bumper PARKING SENSORS —...

  • Page 159: Indications On Display - If Equipped

    STARTING AND OPERATING 157 Indications On Display — If Equipped If an obstacle is detected in the rear central area, the instrument cluster display shows all the arcs in the rear When the sensors are activated, the parking sensor central area, up to the one that corresponds to the display screen appears in the instrument cluster.

  • Page 160: Fault Indication

    158 STARTING AND OPERATING Fault Indication • The variation in sensor position, caused by variation in ride (due to suspension component wear), chang- Parking sensor failures, if any, will be indicated when ing tires, overloaded vehicle, or tuning that lowers REVERSE gear is engaged by the switching on of the the vehicle, for example, may affect parking sensor warning light in the instrument cluster display.

  • Page 161: Adding Fuel/Smart Fuel

    STARTING AND OPERATING 159 ADDING FUEL/SMART FUEL WARNING! (Continued) NOTE: and must continue to pay attention while backing up. Failure to do so can result in serious injury or • The Smart Fuel is a device placed on the top of the death.
  • Page 162 160 STARTING AND OPERATING 2. There is no fuel filler cap. A flap door inside the pipe Emergency Gas Can Refueling: seals the system. Most gas cans will not open the flapper door. A funnel is provided to open the flapper door to allow emergency refueling with a gas can.

  • Page 163: Trailer Towing

    STARTING AND OPERATING 161 TRAILER TOWING 4. Pour fuel into funnel opening. Trailer towing with this vehicle is not recommended. 5. Remove funnel from filler pipe, clean off prior to putting back in the storage area. RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) WARNING! Towing This Vehicle Behind Another Vehicle •...

  • Page 164: Driving Tips

    162 STARTING AND OPERATING Towing Condition Wheels OFF The Ground Alfa Twin Clutch Transmis- sion Flat Tow None Transmission in NEUTRAL Dolly Tow Front NOT ALLOWED Rear NOT ALLOWED On Trailer DRIVING TIPS WARNING! Driving On Slippery Surfaces Rapid acceleration on slippery surfaces is danger- Information in this section will aid in safe controlled ous.

  • Page 165: Driving Through Water

    STARTING AND OPERATING 163 Driving Through Water Traction When driving on wet or slushy roads, it is possible for Driving through water more than a few inches/ a wedge of water to build up between the tire and road centimeters deep will require extra caution to ensure surface.
  • Page 166 164 STARTING AND OPERATING WARNING! CAUTION! (Continued) • Do not exceed 5 mph (8 km/h) when driving • Driving through standing water limits your vehi- through standing water. This will minimize wave cle’s traction capabilities. Do not exceed 5 mph effects.
  • Page 167 IN CASE OF EMERGENCY CONTENTS HAZARD WARNING FLASHER ..166 JUMP STARTING .....187 ▫...

  • Page 168: Hazard Warning Flasher

    166 IN CASE OF EMERGENCY HAZARD WARNING FLASHER BULB REPLACEMENT The Hazard Warning flasher switch is located on the Replacement Bulbs center console. Interior Bulbs Push the switch to turn on the Hazard Warn- ing flasher. When the switch is activated, all Bulb Number directional turn signals will flash on and off to Overhead Lamp...

  • Page 169: Replacing Exterior Bulbs

    IN CASE OF EMERGENCY 167 Replacing Exterior Bulbs Bulb Number Dipped/Main Beam D5S (See Authorized NOTE: Lens fogging can occur under certain atmo- Headlights (Versions Dealer) spheric conditions. This will usually clear as atmo- With Bi-Xenon Head- spheric conditions change to allow the condensation to lights) —...
  • Page 170 168 IN CASE OF EMERGENCY Low/High Beam Bi-Halogen Headlights To change the bulb, proceed as follows: 1. Turn the steering wheel completely. 2. Open the protective flap by rotating the screw. Headlight 1 — Daytime Running Lights 2 — Direction Indicator 3 —...
  • Page 171 IN CASE OF EMERGENCY 169 3. Remove protective cover from headlamp assembly. Bulb Holder Protective Cover 1 — Electrical Connector 4. Remove the electric connector (1) and then rotate the 2 — Bulb Holder bulb holder (2) clockwise and remove it. 5.
  • Page 172 170 IN CASE OF EMERGENCY 3. Remove protective cover from headlamp assembly. Low/High Beam HID & LED Headlights For the replacement, contact an authorized dealer. Direction Indicators Front: 1. Turn the steering wheel completely. 2. Open the protective flap by rotating the screw. Protective Cover 4.
  • Page 173 IN CASE OF EMERGENCY 171 Side: 4. Install the cluster making sure that the internal clip clicks into position. 1. Compress the retaining clip, then pull the side marker assembly outwards. Front Side Marker To change the bulb, proceed as follows: 1.
  • Page 174 172 IN CASE OF EMERGENCY 3. Remove bulb from bulb housing then remove and Direction Indicators replace bulb and reinstall. To change the bulb, proceed as follows: 1. Remove the protective cap (one for each side) on the side cover of the luggage compartment. Front Side Marker Bulb Rear Light Clusters These contain the bulbs for the side lights, direction...
  • Page 175 IN CASE OF EMERGENCY 173 2. Remove the second protective cap insert a hand Tail Lights/Brake Lights inside the opening. These are LEDs. For the replacement, contact an autho- rized dealer. Reversing Light WARNING! The reverse lights are located close to the exhaust pipes;...
  • Page 176 174 IN CASE OF EMERGENCY Rear Of Vehicle Reversing Light Bulb Holder 1 — Reverse Light Location 2 — Reverse Light Location...
  • Page 177 IN CASE OF EMERGENCY 175 Third Brake Lights 2. Turn bulb holder counterclockwise, remove bulb and replace it. These are LEDs. For the replacement, contact an autho- rized dealer. License Plate Lights To replace the bulbs proceed as follows: 1. Compress the retaining clip, then pull the license plate light cluster out.
  • Page 178 176 IN CASE OF EMERGENCY Roof Light To change the bulb, proceed as follows: 1. Remove roof light working at the points indicated by the arrows. 1 — Bulb 2 — Protective Flap 3. Close protective flap (2) and install roof light in its housing, making sure that it is locked in place.

  • Page 179: Fuses

    IN CASE OF EMERGENCY 177 FUSES WARNING! • When replacing a blown fuse, always use an appropriate replacement fuse with the same amp rating as the original fuse. Never replace a fuse with another fuse of higher amp rating. Never replace a blown fuse with metal wires or any other material.

  • Page 180: General Information

    178 IN CASE OF EMERGENCY General Information The fuses protect electrical systems against excessive current. When a device does not work, you must check the fuse element inside the blade fuse for a break/melt. Also, please be aware that when using power outlets for extended periods of time with the engine off may result in vehicle battery discharge.

  • Page 181: Engine Compartment Fuses

    IN CASE OF EMERGENCY 179 Engine Compartment Fuses The engine compartment fuse box is located on the left side of the engine compartment, next to the battery. To access the fuses, remove screws, and then remove the cover. Engine Compartment Fuse Box 1 —...
  • Page 182 180 IN CASE OF EMERGENCY Cavity Maxi Fuse Mini Fuse Description 70 Amp Tan – Body Controller 20 Amp Yellow – Ignition Switch 40 Amp Orange – Anti-Lock Brake Pump 20 Amp Yellow – Anti-Lock Brake Valve 40 Amp Orange –...

  • Page 183: Dashboard Fuse Box

    IN CASE OF EMERGENCY 181 Cavity Maxi Fuse Mini Fuse Description – 10 Amp Red Water Pump, HVAC 30 Amp Green – Headlamp Washer – If Equipped 40 Amp Orange – Alfa Twin Clutch Transmission Pump – 5 Amp Tan After Run Pump –...

  • Page 184: Tire Service Kit

    182 IN CASE OF EMERGENCY Vehicle Fuse Num- Cavity Mini Fuse Description 7.5 Amp Brown Stop Light Switch, Instrument Panel Node 5 Amp Tan Transmission Shifter Module, Cigar Lighter Light, Drive Style Unit, Heated Mirrors Relay 5 Amp Tan Climate Control, Body Controller 20 Amp Yellow Driver Power Window TIRE SERVICE KIT...

  • Page 185: Tire Service Kit Components And Operation

    IN CASE OF EMERGENCY 183 Tire Service Kit Components And Operation WARNING! (Continued) • A loose Tire Service Kit thrown forward in a WARNING! collision or hard stop could endanger the occu- • Do not attempt to seal a tire on the side of the pants of the vehicle.
  • Page 186 184 IN CASE OF EMERGENCY Tire Service Kit Components (Bottom View) Tire Service Kit Components (Top View) 1 — Power Plug 2 — Air Pump Hose (Black) 1 — Sealant Cartridge Receptacle 2 — Pressure Gauge 3 — Deflation Button 4 —...
  • Page 187 IN CASE OF EMERGENCY 185 positioning of the kit when injecting the sealant into the deflated tire and running the air pump. Move the vehicle as necessary to place the valve stem in this position before proceeding. 3. Place the transmission in PARK and place the igni- tion in the OFF position.
  • Page 188 186 IN CASE OF EMERGENCY NOTE: Do not remove foreign objects (e.g., screws or NOTE: nails) from the tire. • If the tire does not inflate to at least 26 psi (1.8 Bar) pressure within 15 minutes the tire is too badly Injecting Sealant Into The Tire damaged.

  • Page 189: Tire Service Kit Usage Precautions

    IN CASE OF EMERGENCY 187 • When the Tire Service Kit sealant is in a liquid form, WARNING! (Continued) clean water, and a damp cloth will remove the Failure to follow this warning can result in injuries material from the vehicle or tire and wheel compo- that are serious or fatal to you, your passengers, and nents.

  • Page 190: Preparations For Jump Start

    188 IN CASE OF EMERGENCY CAUTION! Do not use a portable battery booster pack or any other booster source with a system voltage greater than 12 Volts or damage to the battery, starter motor, alternator or electrical system may occur. NOTE: When using a portable battery booster pack, follow the manufacturer’s operating instructions and precautions.

  • Page 191: Jump Starting Procedure

    IN CASE OF EMERGENCY 189 4. If using another vehicle to jump start the battery, park the vehicle within the jumper cables reach, set the parking brake and make sure the ignition is OFF. WARNING! Do not allow vehicles to touch each other as this could establish a ground connection and personal injury could result.
  • Page 192 190 IN CASE OF EMERGENCY discharged battery (exposed metal part of the en- 2. Disconnect the negative end (-) of the jumper cable gine) away from the battery and the fuel injection from the negative (-) post of the booster battery. system.

  • Page 193: If Your Engine Overheats

    IN CASE OF EMERGENCY 191 IF YOUR ENGINE OVERHEATS WARNING! In any of the following situations, you can reduce the You or others can be badly burned by hot engine potential for overheating by taking the appropriate coolant (antifreeze) or steam from your radiator. If action.

  • Page 194: Towing A Disabled Vehicle

    192 IN CASE OF EMERGENCY TOWING A DISABLED VEHICLE Front Tow Eye Usage Your vehicle is equipped with a tow eye that can be used to tow a disabled vehicle. The front tow eye receptacle is located on the lower right side of the front fascia.
  • Page 195 IN CASE OF EMERGENCY 193 • The tow eye is recommended for use with an ap- When using a tow eye, be sure to follow the “Tow Eye Usage Precautions” in this section. proved tow bar and or rope. • Do not use the tow eye to pull the vehicle onto a flatbed truck.
  • Page 196 194 IN CASE OF EMERGENCY CAUTION! • The tow eye must be used exclusively for road- side assistance operations. Only use the tow eye with an appropriate device in accordance with the highway code (a rigid bar or rope) to flat tow the vehicle for a short distance to the nearest service location.

  • Page 197: Fire Extinguisher - If Equipped

    IN CASE OF EMERGENCY 195 FIRE EXTINGUISHER — IF EQUIPPED EVENT DATA RECORDER (EDR) The fire extinguisher is located under the dashboard in This vehicle is equipped with an Event Data Recorder front of the passenger side seat. (EDR). The main purpose of an EDR is to record data that will assist in understanding how a vehicle’s sys- tems performed under certain crash or near crash-like situations, such as an air bag deployment or hitting a...
  • Page 199 SERVICING AND MAINTENANCE CONTENTS SCHEDULED SERVICING ....199 ▫ Body Lubrication ....215 ▫...
  • Page 200 198 SERVICING AND MAINTENANCE ▫ Tire Chains (Traction Devices) ...250 ▫ Protection From Atmospheric Agents ..253 ▫ Tire Rotation Recommendations ..251 ▫...

  • Page 201: Scheduled Servicing

    SERVICING AND MAINTENANCE 199 SCHEDULED SERVICING NOTE: The actual interval for changing the oil and replacing the engine oil filter depends on the vehicle Your vehicle is equipped with an automatic oil change usage conditions and is signalled by the warning light indicator system.
  • Page 202 200 SERVICING AND MAINTENANCE • Check front and rear disc brake pad condition and Change engine oil at 4,000 miles (6,500 km) if the wear. vehicle is operated in a dusty and off road environment. This type of vehicle use is considered Severe Duty. •...

  • Page 203: Maintenance Plan

    SERVICING AND MAINTENANCE 201 Maintenance Plan At Every Oil Change Interval As Indicated By Oil Change Indicator System: Required Maintenance Intervals Change oil and filter. Refer to the maintenance plan on the following page for Inspect battery and clean and tighten terminals as the required maintenance intervals.
  • Page 204 202 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Months: Or Kilometers: Check battery charge sta- tus and possibly recharge Check tire condition/wear and adjust pressure if re- quired Check lighting system op- eration (headlights, direc- tion indicators, hazard lights, passenger compart- ment lights, boot lights, instrument panel warning...
  • Page 205 SERVICING AND MAINTENANCE 203 Mileage or time passed (whichever comes first) Or Months: Or Kilometers: Check cleanliness of hood and deck lid locks, as well as cleanliness and lubrica- tion of associated linkages Visually inspect condition of: exterior bodywork, car- bon monocoque, aerody- namic bottom, pipes and hoses (exhaust, fuel sup-...
  • Page 206 204 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Months: Or Kilometers: Check condition and wear of rear brake pads and discs, and operation of pad wear indicator Check and top off, if re- quired, fluid levels (engine coolant, brake/hydraulic clutch fluid, windscreen washer fluid, battery fluid,...
  • Page 207 SERVICING AND MAINTENANCE 205 Mileage or time passed (whichever comes first) Or Months: Or Kilometers: Check engine control sys- tem operation (via diag- nostic tool) Check and, if necessary, top off oil level of twin clutch transmission Replace accessory drive belt(s) Replace spark plugs * Replace toothed timing...
  • Page 208 Do only service work for which replacement. you have the knowledge and the right equipment. • Contact your Alfa Romeo Dealer if you have ques- If you have any doubt about your ability to tions. perform a service job, take your vehicle to a competent mechanic.

  • Page 209: Engine Compartment

    SERVICING AND MAINTENANCE 207 ENGINE COMPARTMENT 1750 Turbo Engine 1 — Fuse Box 3 — Engine Oil Dip Stick 5 — Coolant Reservoir 2 — Battery 4 — Engine Oil Fill...

  • Page 210: Checking Oil Level

    208 SERVICING AND MAINTENANCE Checking Oil Level CAUTION! To assure proper engine lubrication, the engine oil must Do not overfill the engine with oil. Overfilling the be maintained at the correct level. Check the oil level at engine with oil will cause oil aeration, which can regular intervals.
  • Page 211 SERVICING AND MAINTENANCE 209 To check the windshield washer solvent level, proceed as follows: 1. To avoid any interference during the procedure, lift the windshield wiper blade. 2. Loosen the four screws using the supplied screw- driver. Remove the washer solvent protection panel. Washer Solvent Plug 1 —...
  • Page 212 210 SERVICING AND MAINTENANCE 5. After the check, reinsert the plug with the control pipe in the initial position. 6. Reposition the washer solvent protection panel and tighten the four self-tapping screws. If the level is not sufficient, namely if there is no washer solvent inside the pipe, proceed as follows: 1.

  • Page 213: Maintenance-Free Battery

    SERVICING AND MAINTENANCE 211 WARNING! (Continued) WARNING! (Continued) you. Care must be exercised when filling or work- an output greater than 12 Volts. Do not allow ing around the washer solution. cable clamps to touch each other. • Battery posts, terminals, and related accessories Maintenance-Free Battery contain lead and lead compounds.

  • Page 214: Dealer Service

    212 SERVICING AND MAINTENANCE DEALER SERVICE CAUTION! (Continued) The pages that follow contain the required maintenance your engine, transmission, or air conditioning. services determined by the engineers who designed Such damage is not covered by the New Vehicle your vehicle. Limited Warranty.

  • Page 215: Engine Oil Filter

    SERVICING AND MAINTENANCE 213 engine oils that are API Certified and meet the require- station or governmental agency for advice on how and ments of FCA Material Standard MS-12991. where used oil and oil filters can be safely discarded in your area.

  • Page 216: Engine Cover

    214 SERVICING AND MAINTENANCE To reassemble the cover back onto the engine, first make WARNING! sure it is properly aligned, the oil cap is centered, and that all four studs are lined up with their couplers. Then The air induction system (air cleaner, hoses, etc.) gently push on the four corners of the engine cover to can provide a measure of protection in the case of snap the stud back into position.

  • Page 217: Body Lubrication

    SERVICING AND MAINTENANCE 215 recommends that air conditioning service be performed WARNING! (Continued) by an authorized dealer using recovery and recycling to Warranty Information Book, for further war- equipment. ranty information. NOTE: Use only manufacturer approved A/C system • The air conditioning system contains refrigerant PAG compressor oil, and refrigerants.

  • Page 218: Wiper Blades

    216 SERVICING AND MAINTENANCE Wiper Blades Blade Lifting Clean the rubber edges of the wiper blades, the wind- If it is necessary to lift the blade from the windshield (In shield, and rear window periodically with a sponge or the event of snow or blade replacement) Proceed as soft cloth and a mild nonabrasive cleaner.
  • Page 219 SERVICING AND MAINTENANCE 217 3. After turning the ignition to the STOP, within two 2. Push the release button on the arm of the wiper minutes move the right stalk upward, into the un- blade. stable (“anti-panic”) position, for at least half of a 3.

  • Page 220: Windshield Washer Nozzles

    218 SERVICING AND MAINTENANCE Windshield Washer Nozzles broken, damaged, deteriorated, or mispositioned parts. Open seams or loose connections could permit exhaust The windshield washer nozzles are adjustable. They fumes to seep into the passenger compartment. In originally adjusted at the factory. Should it be necessary addition, have the exhaust system inspected each time to adjust them again, contact your authorized Alfa the vehicle is raised for lubrication or oil change.
  • Page 221 SERVICING AND MAINTENANCE 219 NOTE: Intentional tampering with emissions control CAUTION! systems can result in civil penalties being assessed against you. • The catalytic converter requires the use of un- leaded fuel only. Leaded gasoline will destroy the In unusual situations involving grossly malfunctioning effectiveness of the catalyst as an emissions con- engine operation, a scorching odor may suggest severe trol device and may seriously reduce engine per-...

  • Page 222: Cooling System

    220 SERVICING AND MAINTENANCE Cooling System Coolant Checks Check engine coolant (antifreeze) protection every 12 WARNING! months (before the onset of freezing weather, where applicable). If the engine coolant (antifreeze) is dirty or • Turn vehicle off and disconnect the fan motor rusty in appearance, the system should be drained, lead before working near the radiator cooling fan.
  • Page 223 SERVICING AND MAINTENANCE 221 • This vehicle has not been designed for use with Selection Of Coolant propylene glycol-based engine coolant (antifreeze). Refer to “Fluids And Lubricants” in “Technical Specifi- Use of propylene glycolbased engine coolant (anti- cations” for further information. freeze) is not recommended.
  • Page 224 222 SERVICING AND MAINTENANCE Please review these recommendations for using Or- NOTE: ganic Additive Technology (OAT) engine coolant (anti- • It is the owner’s responsibility to maintain the proper freeze) that meets the requirements of FCA Material level of protection against freezing according to the Standard MS.90032.
  • Page 225 SERVICING AND MAINTENANCE 223 Cooling System Pressure Cap Disposal Of Used Coolant The cap must be fully tightened to prevent loss of Used ethylene glycol-based coolant (antifreeze) is a engine coolant (antifreeze), and to ensure that engine regulated substance requiring proper disposal. Check coolant (antifreeze) will return to the radiator from the with your local authorities to determine the disposal coolant expansion bottle/recovery tank if so equipped.

  • Page 226: Brake System

    224 SERVICING AND MAINTENANCE Points To Remember • Maintain engine coolant (antifreeze) concentration at a minimum of 50% OAT coolant (conforming to NOTE: When the vehicle is stopped after a few miles/ MS.90032) and distilled water for proper corrosion kilometers of operation, you may observe vapor coming protection of your engine which contains aluminum from the front of the engine compartment.
  • Page 227 SERVICING AND MAINTENANCE 225 Use only manufacturer’s recommended brake fluid. WARNING! Refer to “Fluids And Lubricants ” in “Technical Speci- fications” for further information. Riding the brakes can lead to brake failure and possibly a collision. Driving with your foot resting WARNING! or riding on the brake pedal can result in abnor- mally high brake temperatures, excessive lining...
  • Page 228 226 SERVICING AND MAINTENANCE Checking Brake Fluid WARNING! (Continued) • Overfilling the brake fluid reservoir can result in spilling brake fluid on hot engine parts, causing the brake fluid to catch fire. Brake fluid can also damage painted and vinyl surfaces, care should be taken to avoid its contact with these surfaces.
  • Page 229 SERVICING AND MAINTENANCE 227 Adding Brake Fluid If the fluid level in the reservoir is not sufficient, proceed as follows: 1. Take the black funnel for topping up the brake fluid and its extension pipe from the service kit in the luggage compartment.

  • Page 230: Alfa Twin Clutch Transmission

    228 SERVICING AND MAINTENANCE 3. After topping up, remove the funnel with the exten- CAUTION! sion pipe. Using a transmission fluid other than the manufac- 4. Tighten the reservoir plug. turer’s recommended fluid may cause deterioration 5. Reposition the brake fluid protection panel and in transmission shift quality.

  • Page 231: Raising The Vehicle

    SERVICING AND MAINTENANCE 229 RAISING THE VEHICLE Fluid Level Check The fluid level is preset at the factory and does not In the case where it is necessary to raise the vehicle, go require adjustment under normal operating conditions. to an authorized dealer or service station. Frequent fluid level checks are not required, but have TIRES your authorized dealer check the fluid level as specified...
  • Page 232 230 SERVICING AND MAINTENANCE Tire Markings NOTE: • P (Passenger) — Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. • European — Metric tire sizing is based on European design standards.
  • Page 233 SERVICING AND MAINTENANCE 231 Tire Sizing Chart EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 P = Passenger car tire size based on U.S. design standards, or ..blank..= Passenger car tire based on European design standards, or LT = Light truck tire based on U.S.
  • Page 234 232 SERVICING AND MAINTENANCE EXAMPLE: Service Description: 95 = Load Index – A numerical code associated with the maximum load a tire can carry H = Speed Symbol – A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index un- der certain operating conditions –...
  • Page 235 SERVICING AND MAINTENANCE 233 Tire Identification Number (TIN) tire. Look for the TIN on the outboard side of black sidewall tires as mounted on the vehicle. If the TIN is The TIN may be found on one or both sides of the tire; not found on the outboard side, then you will find it on however, the date code may only be on one side.
  • Page 236 234 SERVICING AND MAINTENANCE Tire Terminology And Definitions Term Definition B-Pillar The vehicle B-Pillar is the structural member of the body located behind the front door. Cold Tire Inflation Pressure Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least three hours, or driven less than 1 mile (1.6 km) after sitting for a minimum of three hours.
  • Page 237 SERVICING AND MAINTENANCE 235 Tire Loading And Tire Pressure NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver’s side door. Check the inflation pressure of each tire, including the spare tire (if equipped), at least monthly and inflate to the recommended pressure for your vehicle.
  • Page 238 236 SERVICING AND MAINTENANCE Tire And Loading Information Placard Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the Tire and Load- ing Information placard in “Vehicle Loading”...
  • Page 239 SERVICING AND MAINTENANCE 237 Steps For Determining Correct Load Limit— Consult this manual to determine how this reduces the available cargo and luggage load capacity of your (1) Locate the statement “The combined weight of vehicle. occupants and cargo should never exceed XXX kg or XXX lbs.”...
  • Page 240 238 SERVICING AND MAINTENANCE WARNING! Overloading of your tires is dangerous. Overload- ing can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them.

  • Page 241: Tires - General Information

    SERVICING AND MAINTENANCE 239 Tires — General Information WARNING! (Continued) Tire Pressure • Overinflated or underinflated tires can affect ve- hicle handling and can fail suddenly, resulting in Proper tire inflation pressure is essential to the safe and loss of vehicle control. satisfactory operation of your vehicle.
  • Page 242 240 SERVICING AND MAINTENANCE Fuel Economy CAUTION! Underinflated tires will increase tire rolling resistance After inspecting or adjusting the tire pressure, resulting in higher fuel consumption. always reinstall the valve stem cap. This will pre- Tread Wear vent moisture and dirt from entering the valve stem, which could damage the valve stem.
  • Page 243 SERVICING AND MAINTENANCE 241 inflation pressure should be increased by 3 psi (21 kPa), WARNING! (Continued) which equals 1 psi (7 kPa) for every 12°F (7°C) for this serious collision. Do not drive a vehicle loaded to outside temperature condition. the maximum capacity at continuous speeds above Tire pressure may increase from 2 to 6 psi (13 to 40 kPa) 75 mph (120 km/h).
  • Page 244 242 SERVICING AND MAINTENANCE Consult an authorized tire dealer for tire repairs and Tire Spinning additional information. When stuck in mud, sand, snow, or ice conditions, do not spin your vehicle’s wheels above 30 mph (48 km/h) Damaged Run Flat tires, or Run Flat tires that have or for longer than 30 seconds continuously without experienced a loss of pressure should be replaced stopping.
  • Page 245 SERVICING AND MAINTENANCE 243 Life Of Tire The service life of a tire is dependent upon varying factors including, but not limited to: • Driving style. • Tire pressure - Improper cold tire inflation pressures can cause uneven wear patterns to develop across the tire tread.
  • Page 246 244 SERVICING AND MAINTENANCE Keep dismounted tires in a cool, dry place with as little affect your vehicle’s handling. If you ever replace a exposure to light as possible. Protect tires from contact wheel, make sure that the wheel’s specifications match with oil, grease, and gasoline.

  • Page 247: Tire Types

    SERVICING AND MAINTENANCE 245 the tire sidewall. Use all season tires only in sets of four; WARNING! (Continued) failure to do so may adversely affect the safety and • Never use a tire with a smaller load index or handling of your vehicle. capacity, other than what was originally equipped Summer Or Three Season Tires —...

  • Page 248: Spare Tires - If Equipped

    246 SERVICING AND MAINTENANCE While studded tires improve performance on ice, skid WARNING! and traction capability on wet or dry surfaces may be poorer than that of non-studded tires. Some states Do not use Summer tires in snow/ice conditions. prohibit studded tires; therefore, local laws should be You could lose vehicle control, resulting in severe checked before using these tire types.
  • Page 249 SERVICING AND MAINTENANCE 247 tire rotation for your vehicle. If your vehicle has this WARNING! option, refer to an authorized tire dealer for the recom- mended tire rotation pattern. Compact and collapsible spares are for temporary emergency use only. With these spares, do not drive Compact Spare Tire —...
  • Page 250 248 SERVICING AND MAINTENANCE Inflate collapsible tire only after the wheel is properly worn to the tread wear indicators, the temporary use installed to the vehicle. Inflate the collapsible tire using full size spare tire needs to be replaced. Since it is not the electric air pump before lowering the vehicle.

  • Page 251: Wheel And Wheel Trim Care

    SERVICING AND MAINTENANCE 249 and mild soap to wipe away promptly. Do not use harsh WARNING! (Continued) chemicals or a stiff brush. They can damage the wheel’s wheel. Keep inflated to the cold tire inflation pres- protective coating that helps keep them from corroding sures listed on your Tire and Loading Information and tarnishing.

  • Page 252: Tire Chains (Traction Devices)

    250 SERVICING AND MAINTENANCE CAUTION! CAUTION! (Continued) the New Vehicle Limited Warranty. HAND WASH Do not use scouring pads, steel wool, a bristle ONLY USING MILD SOAP AND WATER WITH A brush, metal polishes or oven cleaner. These prod- SOFT CLOTH. Used on a regular basis; this is all ucts may damage the wheel’s protective finish.

  • Page 253: Tire Rotation Recommendations

    Remove the damaged parts of the device before guarantee high grip performance with little increase of further use. wear. Alfa Romeo, in collaboration with Pirelli, devel- • Install device as tightly as possible and then oped a specific high performance tire for the 4C model.

  • Page 254: Treadwear

    252 SERVICING AND MAINTENANCE All passenger vehicle tires must conform to Federal WARNING! safety requirements in addition to these grades. The traction grade assigned to this tire is based Treadwear on straight-ahead braking traction tests, and does The Treadwear grade is a comparative rating, based not include acceleration, cornering, hydroplan- on the wear rate of the tire when tested under ing, or peak traction characteristics.

  • Page 255: Vehicle Storage

    SERVICING AND MAINTENANCE 253 BODYWORK WARNING! Protection From Atmospheric Agents The temperature grade for this tire is established Vehicle body care requirements vary according to geo- for a tire that is properly inflated and not over- graphic locations and usage. Chemicals that make roads loaded.

  • Page 256: Body And Underbody Maintenance

    254 SERVICING AND MAINTENANCE What Causes Corrosion? Do not use abrasive cleaning components, solvents, steel wool or other aggressive material to clean the Corrosion is the result of deterioration or removal of lenses. paint and protective coatings from your vehicle. Preserving The Bodywork The most common causes are: Washing...
  • Page 257 SERVICING AND MAINTENANCE 255 • If you detect any stone chips or scratches in the paint, CAUTION! touch them up immediately. The cost of such repairs is considered the responsibility of the owner. • Do not use abrasive or strong cleaning materials such as steel wool or scouring powder that will •...

  • Page 258: Interiors

    256 SERVICING AND MAINTENANCE INTERIORS Replace the belts if they appear frayed or worn or if the buckles do not work properly. Seats And Fabric Parts NOTE: If the belts retract slowly, inspect the upper Use Mopar Total Clean to clean fabric upholstery and turning loop for soiling.

  • Page 259: Plastic And Coated Parts

    SERVICING AND MAINTENANCE 257 Plastic And Coated Parts Leather Parts Use Mopar Total Clean to clean vinyl upholstery. Mopar Total Clean is specifically recommended for leather upholstery. CAUTION! Your leather upholstery can be best preserved by regu- lar cleaning with a damp soft cloth. Small particles of •...

  • Page 260: Glass Surfaces

    258 SERVICING AND MAINTENANCE CAUTION! Do not use Alcohol and Alcohol-based and/or Ke- tone based cleaning products to clean leather seats, as damage to the seat may result. Glass Surfaces All glass surfaces should be cleaned on a regular basis with Mopar, or any commercial household-type glass cleaner.
  • Page 261 TECHNICAL SPECIFICATIONS CONTENTS VEHICLE IDENTIFICATION NUMBER ..260 ▫ CNG And LP Fuel System Modifications ..264 ▫ MMT In Gasoline ....264 WHEEL AND TIRE TORQUE SPECIFICATIONS .

  • Page 262: Vehicle Identification Number

    260 TECHNICAL SPECIFICATIONS VEHICLE IDENTIFICATION NUMBER WHEEL AND TIRE TORQUE SPECIFICATIONS The Vehicle Identification Number (VIN) is found on Proper lug nut/bolt torque is very important to ensure the left front corner of the instrument panel, visible that the wheel is properly mounted to the vehicle. Any through the windshield.
  • Page 263 TECHNICAL SPECIFICATIONS 261 Inspect the wheel mounting surface prior to mounting the tire and remove any corrosion or loose particles. Torque Patterns After 25 miles (40 km) check the lug nut/bolt torque to be sure that all the lug nuts/bolts are properly seated Wheel Mounting Surface against the wheel.

  • Page 264: Brake System

    262 TECHNICAL SPECIFICATIONS BRAKE SYSTEM Light spark knock at low engine speeds is not harmful to your engine. However, continued heavy spark knock Your vehicle is equipped with dual hydraulic brake at high speeds can cause damage and immediate ser- systems.

  • Page 265: Materials Added To Fuel

    TECHNICAL SPECIFICATIONS 263 Materials Added To Fuel Gasoline/Oxygenate Blends Besides using unleaded gasoline with the proper octane Some fuel suppliers blend unleaded gasoline with rating, gasolines that contain detergents, corrosion and oxygenates such as ethanol. stability additives are recommended. Using gasolines that have these additives will help improve fuel CAUTION! economy, reduce emissions, and maintain vehicle per-...

  • Page 266: E-85 Usage In Non-Flex Fuel Vehicles

    264 TECHNICAL SPECIFICATIONS E-85 Usage In Non-Flex Fuel Vehicles MMT In Gasoline Non-Flex Fuel Vehicles (FFV) are compatible with gaso- Methylcyclopentadienyl Manganese Tricarbonyl line containing up to 10% ethanol (E-10). Gasoline with (MMT) is a manganese-containing metallic additive higher ethanol content may void the New Vehicle that is blended into some gasoline to increase octane.

  • Page 267: Carbon Monoxide Warnings

    TECHNICAL SPECIFICATIONS 265 Carbon Monoxide Warnings CAUTION! (Continued) performance and damage the emissions control WARNING! system. Carbon monoxide (CO) in exhaust gases is deadly. • An out-of-tune engine or certain fuel or ignition Follow the precautions below to prevent carbon malfunctions can cause the catalytic converter to monoxide poisoning: overheat.

  • Page 268: Fluid Capacities

    266 TECHNICAL SPECIFICATIONS FLUID CAPACITIES U.S. Metric Fuel (Approximate) 1750 Turbo Engine 10.5 Gallons 40 Liters Reserve Fuel 1.1 Gallons 4 Liters Engine Oil with Filter 1750 Turbo Engine 6.1 Quarts 5.8 Liters Cooling System 1750 Turbo Engine (Mopar Antifreeze/Engine Coolant 11.2 Quarts 10.6 Liters 10 Year/150,000 Mile Formula).
  • Page 269 TECHNICAL SPECIFICATIONS 267 Component Fluid, Lubricant, or Genuine Part Engine Oil Filter – 1750 Turbo Engine We recommend you use Mopar Engine Oil Filter. Spark Plugs – 1750 Turbo Engine We recommend you use Mopar Spark Plugs. * Fuel Selection – 1750 Turbo Engine Use Only 91 Octane or higher, 0-10% Ethanol.

  • Page 270: Chassis

    268 TECHNICAL SPECIFICATIONS Chassis Component Fluid, Lubricant, or Genuine Part Alfa Twin Clutch Transmission • Gearbox: Full synthetic 75W-85 manual transmission fluid meeting MS.90021 or FPW9.55550–MZ3 or the API GL4 specification. • Control System: Use only Mopar C Series DDCT SAE 75W Hydraulic Fluid or equivalent.
  • Page 271 MULTIMEDIA CONTENTS CYBERSECURITY..... .270 RADIO OPERATION AND MOBILE PHONES ......272 RADIO SYSTEM.

  • Page 272: Cybersecurity

    270 MULTIMEDIA CYBERSECURITY WARNING! Your vehicle may be a connected vehicle and may be • It is not possible to know or to predict all of the equipped with both wired and wireless networks. possible outcomes if your vehicle’s systems are These networks allow your vehicle to send and receive breached.

  • Page 273: Radio System

    MULTIMEDIA • Two tweeter speakers with 1 inch (25 mm) diameter NOTE: and two mid-woofer speakers with 5 inch (130 mm) • FCA US or your dealer may contact you directly diameter, fitted on the doors regarding software updates. Hi Fi System — If Equipped •...

  • Page 274: Phones

    272 MULTIMEDIA RADIO OPERATION AND MOBILE PHONES General Information Under certain conditions, the mobile phone being on in The following regulatory statement applies to all Radio your vehicle can cause erratic or noisy performance Frequency (RF) devices equipped in this vehicle: from your radio.
  • Page 275 CUSTOMER ASSISTANCE CONTENTS SUGGESTIONS FOR OBTAINING SERVICE FOR ▫ Customer Assistance For The Hearing Or Speech YOUR VEHICLE ..... .274 Impaired (TDD/TTY).

  • Page 276: Suggestions For Obtaining Service For Your Vehicle

    274 CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE FOR IF YOU NEED ASSISTANCE YOUR VEHICLE The manufacturer and its authorized dealer are vitally interested in your satisfaction. We want you to be Prepare For The Appointment happy with our products and services. If you are having warranty work done, be sure to have the right papers with you.

  • Page 277: Fca Us Llc Customer Center

    CUSTOMER ASSISTANCE 275 In Mexico Contact Any communication to the manufacturer’s customer center should include the following information: Av. Prolongacion Paseo de la Reforma, 1240 • Owner’s name and address Sante Fe C.P. 05109 • Owner’s telephone number (home and office) Mexico, D.

  • Page 278: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)

    276 CUSTOMER ASSISTANCE Customer Assistance For The Hearing Or the manufacturer’s Service Contract National Customer Speech Impaired (TDD/TTY) Hotline at 1-800-521-9922 (Canadian residents, call (800) 465-2001 English / (800) 387-9983 French). To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- The manufacturer will not stand behind any service cation Devices for the Deaf) equipment at its customer contract that is not the manufacturer’s service contract.

  • Page 279: Warranty Information

    CUSTOMER ASSISTANCE 277 REPORTING SAFETY DEFECTS WARNING! In The 50 United States And Washington, D.C. Engine exhaust (internal combustion engines only), If you believe that your vehicle has a defect that some of its constituents, and certain vehicle compo- could cause a crash or cause injury or death, you nents contain, or emit, chemicals known to the State should immediately inform the National Highway of California to cause cancer and birth defects, or...

  • Page 280: In Canada

    278 CUSTOMER ASSISTANCE In Canada Diagnostic Procedure Manuals If you believe that your vehicle has a safety defect, Diagnostic Procedure Manuals are filled with diagrams, you should contact the Customer Service Depart- charts and detailed illustrations. These practical manu- als make it easy for students and technicians to find and ment immediately.
  • Page 281 INDEX...
  • Page 282 280 INDEX Adding Engine Coolant (Antifreeze) ...221 Alfa Twin Clutch Transmission ... .85, 143 Adding Fuel ......159 Fluid Type .
  • Page 283 INDEX 281 Brake System ......224, 262 Child Restraints Anti-Lock (ABS) ......90 Booster Seats .
  • Page 284 282 INDEX Radiator Cap ......223 Electrical Power Outlets ....58 Selection Of Coolant (Antifreeze) .
  • Page 285 INDEX 283 Oil Filter ......213 Folding Rear Seat ......24 Oil Selection .
  • Page 286 284 INDEX Hazard Intermittent Wipers (Delay Wipers) ... .34 Driving Through Flowing, Rising, Or Shallow Introduction ......4 Standing Water .
  • Page 287 INDEX 285 Lights ......31, 135 Maintenance Free Battery....211 Air Bag .
  • Page 288 286 INDEX New Vehicle Break-In Period ....141 Paint Care ......253 Parking Brake.
  • Page 289 INDEX 287 Remote Keyless Entry Seat Belt Pretensioner ....108 Unlock The Doors ..... .15 Seat Belt Reminder .
  • Page 290 288 INDEX Security Alarm ......20 Supplemental Restraint System - Air Bag..112 Sentry Key (Immobilizer) .
  • Page 291 INDEX 289 Sizes .......231 Uniform Tire Quality Grades ....251 Snow Tires .
  • Page 292 290 INDEX Windshield Defroster..... .133 Windshield Washers ..... . .34 Windshield Wiper Blades.
  • Page 293 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this The antenna cable should be as short as practical and vehicle’s electronic system to provide immunity to radio routed away from the vehicle wiring when possible. Use frequency signals. Mobile two-way radios and telephone only fully shielded coaxial cable.
  • Page 294 184CSPDR-126-AB ©2017 FCA US LLC. All Rights Reserved. ALFA ROMEO is a registered trademark of Second Edition FCA Group Marketing S.p.A., used with permission. Printed in U.S.A.

Table of Contents
