Rocco
Model No. FCFL**RN3
LOG EFFECT CONVENTIONAL FLUE
ROOM HEATER
User Instructions
These instructions should be read by the user before operating the
appliance and retained for future reference
Model No. FCFL**RN3 is for use on Natural Gas (G20) at a supply pressure
of 20 mbar in G.B. / I.E.
** Denotes trim & colour variant
