User Guide (English)
Introduction
Congratulations on purchasing the M-Audio Keystation 49 keyboard. The 49 key velocity-sensitive USB
keyboard is designed to easily integrate with your PC or Macintosh computer. Keystation 49 offers semi-
weighted keys that give you the feel of a piano in a compact MIDI controller. Ideal for a multitude of music
creation and education applications, Keystation 49 offers a pitch bend wheel, directional and transport
buttons for software control, plus an assignable modulation wheel and a slider for hands-on control. Though
Keystation 49 is class compliant and features true plug-and-play operation under Windows XP, Windows
Vista, Windows 7, Windows 8, and Mac OS X, we recommend that you spend a few minutes reviewing this
manual to learn about proper operation, advanced functionality, and programmability.
Box Contents
Keystation 49, USB Cable, Ableton Live Lite, User Guide, Safety & Warranty Manual
Support
For the latest information about this product (system requirements, compatibility information, etc.) and
product registration, visit m-audio.com/keystation49.
For additional product support, visit m-audio.com/support.

Quick Start

Connecting Your Keyboard
Keystation 49 is powered through a USB connection to a computer. It is recommended that you connect
Keystation 49 to a computer's onboard USB port or to a powered USB hub. The single USB cable not only
powers the keyboard but also sends MIDI data to and from your computer system.
You can also use Keystation 49 with your iPad to control supported music creation apps.
Connecting your Keystation 49 to an iPad requires the iPad Camera Connection Kit, which is available from
the Apple Store.
Connection Diagram
COMPUTER*
ON/OFF ON/OFF
POWER POWER
SUSTAIN
PEDAL*
2
*SOLD
SEPARATELY
