Installation Guide

and Users Manual

VICTORY

198 Series Wall Mounted Range Hood

Model number: D/E/F/F4/L/N/Q2/Z

available size: 30", 36", 42"

IMPORTANT:

Read and save these instructions.

NOTICE:

Installer: Leave this guide with the homeowner

Homeowner: Keep this guide for future reference

Wall Mount Range Hood

Rev. 1016u.8a

Table of Contents

Need help?

Do you have a question about the 198 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Victory 198 Series

Page 1 Installation Guide and Users Manual VICTORY 198 Series Wall Mounted Range Hood Model number: D/E/F/F4/L/N/Q2/Z available size: 30”, 36”, 42” IMPORTANT: Read and save these instructions. NOTICE: Installer: Leave this guide with the homeowner Homeowner: Keep this guide for future reference Wall Mount Range Hood Rev.
Page 3 Important Safety Notice Read all Instructions before Installing and operating this appliance • The installation in this manual is intended for qualified installers, service technicians or persons with similar qualified background. Installation and electrical wiring must be done by qualified profession- als and in accordance with all applicable codes and standards, including fire-rated construction.
Page 4 Important Safety Notice Read all Instructions before Installing and operating this appliance • Clean ventilating fan frequently. • Always use appropriate cookware and utensils size. • Always use cookware appropriate for the size of the surface element. To reduce the risk of injury to persons in the event of a stove top grease fire: •...
Page 5: Table Of Contents
Table of Contents INSTALLATION USE AND CARE Tools needed............3 Troubleshooting..........13 Parts supplied...........4 Use and care information......14 Venting requirements........5 Specifications..........14 MAINTENANCE Mount heights & clearance......5-6 Calculating vent system length.......6 Cleaning..........15 Venting methods & ductless conversion..7 Replacing filter & light bulb.....15- WARRANTY Charcoal filters &...
Page 6: Parts Supplied
Parts supplied: Range Hood (vary with model) Flappers SS Panel, Baffle or Aluminum Filter(s) Mounting Bracket Lower standard chimney Upper standard chimney Charcoal Filter Air diverter Flexible Duct Tube (Optional) (Optional re-circulating kit) (Optional re-circulating kit) Description Quantity Toggle Bolts 2 Pcs Duct Set 1 Set...
Page 7: Venting Requirements
Venting Requirements Height & Clearance • Vent system must terminate to the outside Mounting (roof or side wall). Maximum* ceiling clearance Bracket • DO NOT terminate the vent system in an at- 110” at 31” hood mounting Standard tic or other enclosed area. height above countertop/stove Upper (may vary with different...
Page 8: Calculating Vent System Length
IMPORTANT: • A minimum of 6” round (standard for this range hood) or 3-1/4 x 10” rectangular duct (purchased separately) must be used to maintain maximum airflow efficiency. • Flexible 6” round duct provided for convenience, always use rigid type metal/aluminum ducts if available to maximize airflow when connecting to provided duct.
Page 9 Venting Methods • This range hood is factory set for venting through the roof or wall. For non-vented (re-circulating) installa- tions, see Recirculating (Non-Vented) Kit on Page 11. • Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed. IMPORTANT: •...
Page 10 Charcoal Filter Installation NOTE: The charcoal filters are preinstalled if you purchased the range hood with re-circulating kit from us. Remove aluminum filters on hood. Remove the safety filter under the aluminum filter by unscrewing two screws, then position the charcoal filter and align the screw holes, reinstall and fasten two screws.
Page 11: Preparation
Preparation Advanced Preparations: Read the entire installation guide and users manual thoroughly, understand instructions and warnings. Be familiar with the controls of the range hood by reading through Range Hood Operations, Page 13. Place the range hood on a flat, stable surface. Connect the range hood to a designated standard outlet (please refer the product label for the suitable voltage of this unit) and verify no debris has entered the vent openings, then turn on the range hood.
Page 12: Installation
Installation DO NOT INSTALL THE RANGE HOOD BEFORE TESTING IT. MECHAN- ICAL DAMAGE MIGHT HAVE OCCURRED DURING TRANSPORTION. Plug in the range hood to the USA/Canada 120V standard outlet (220V for Eu- rope and other countries), test the blower and the lights before installing it. Installations (refer to Page 4 for parts): Figure 1 Measure the distance between stove top and the bottom of...
Page 13: Installation
Installation (Continued) Figure 4 Figure 3 Figure 2 Store excess wires in the wiring box. Install both chimneys and tighten screws to secure the lower chimney to the range hood as shown in Figure To avoid scratching the chimney, extend the upper chimney slowly and carefully to the chimney-mount- ing bracket and tighten screws as shown in Figure 6.
Page 14 Range Hood Operations & Wiring Diagram SV168/198 Series Standard Class (3 Speed Mechanical Control) Low Speed High Speed Power Switch Medium Speed Light Switch Turn On: • Press the speed control (Low Speed, Medium Speed, High Speed) switch to select the desired level of power.
Page 15: Troubleshooting
Troubleshooting If the range hood or halogen light does not operate • Check if the range hood has been plugged in, make after installation: sure that all power has been turned back ON, fused not blown and all electrical wiring are properly con- nected.
Page 16: Use And Care Information
Use and Care Information Operations: • Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference. • Always leave safety grills and filters in place. Without these components, operating blowers could catch on to hair, fingers and loose clothing.
Page 17 WARNING Maintenance SAFETY WARNING: Never put your hand into area housing the Hazard of Burns! fan while the fan is operating! Light bulb become extremely hot when turned on. For optimal operation, clean range hood & all filter/oil container regu- DO NOT touch bulb until switched off and cooled.
Page 18 Maintenance (Continued) Replacing GU10 Type light bulb: • This range hood uses LED or halogen bulb (please refer to the actual specification of the hood purchased): USA/Canada: Halogen 35W Type GU10 120V (Europe : 220V) USA/Canada: LED 3W Type GU10 120V (Europe : 220V) •...
Page 19 Maintenance (Continued) Replacing the Light Bulb Using the Inner Ring Opener: • Make sure the range hood is unplugged or turn OFF breaker. • Make sure the lights are cool to touch, carefully align the arrow on the inner ring with the arrow on the outer ring where it says OPEN with the Inner Ring Opener as shown in Figure 1.
Page 20 Warranty TO OBTAIN SERVICE UNDER WARRANTY: You must present proof of original purchase date. Please provide an original dated proof of purchase (sales receipt / invoice) in order to obtain service under warranty. One Year Parts Warranty: For one year from the date of original purchase, your local reseller will provide free of charge, non-consumable replace- ment parts or components that failed due to manufacturing defects.
Page 21 Disclaimer Carefully inspect all items for damages before accepting delivery. note any damages on the freight bill or express receipt. request name and signature of the carrier’s agent and keep copy to support your claim. Upon acceptance of items, owner assumes responsibility for its safe arrival. Report damages to the carrier and file a claim immediately.
Page 22 VICTORY range hoods 7272 Buller Ave Burnaby ,BC V5J4S3 Canada...
