Summary of Contents for Supoin S20 Series
- Page 1 User Manual Supoin S20 Series Products Shenzhen Supoin Technology Corp. Addr ：Room2401-2408,Block A, World Trade Square, No.9 Fuhong Rd, Futian District, Shenzhen, China ：+0086-755-25828560 82178516 ：+0086-0755-82281509 www.supoin.net...
-
Page 2: Table Of Contents
Table of Contents User Manual of S30 Series Products Chapter 4 Precautions and Troubleshooting Chapter 1 Introduction 4.1.1 To ensure that the Supoin S20 does not fail, follow the following ................................. precautions during use of the Supoin S20: Overview ....... -
Page 3: Chapter 1 Introduction
TFT-LCD TFT-LCD 1.1 Overview Camera(Optional) 5.0 mega pixels, auto focus S20 series products are industrial grade handheld terminals independently Scanner 1D Laser Scanner 2D CMOS laser scanner researched, developed, designed and produced according to the characteristics of each industr y, and feature ergonomic design, compact size, anti-shock and... -
Page 4: Battery Life (Hours)
1.4 Battery Life (hours) Weight 320 g (standard battery included) Test Item S3C2416 PXA310 Battery 3.7V 3200 mAh polymer lithium batteries Continuous 1D scan+sound 12.04 Expansion Slot Mini SD card, up to 32 GB, Micro SD slot Continuous 1D scan +WI-FI（powermode=1）... -
Page 5: Chapter 2 Appearance And Hardware
TF card slot Components inside after removing rear cover: charge jack and USB interface SIM card slot Figure 1-1 Front view of Supoin S20 Top view、Front view、Bottom view Figure 1-4 Inserting an SD card/ a SIM card Page 06 Page 07... -
Page 6: Functions Of Button
ESC key, with the decimal key value 27 Delete key: It functions the same as the Backspace button when you are typing a Then we will introduce the software function of S20 series devices in detail, mainly barcode and characters. Its decimal key value is 8. -
Page 7: Use Instructions For Pda Tools
3.2.1 Main Menu of PDA Device Of all the three indicating lights in the top right corner, the one in the leftmost will light after turning on, the middle one will turn to red after plugging in power, and turn to green after the batter y is filled. For example, the red marker box in the above picture displays batter y level and signal strength. -
Page 8: And Gprs Test (Optional)
3.2.3 3G and GPRS Test (Optional) 3.2.4 Bluetooth Setting(Optional) AT instruction test is usually used in 3G or GPRS module dial test. Turning On/Off Bluetooth A) Obtain current signal value A) Open or close the window of Bluetooth Manager B) If “Run on Startup”... -
Page 9: Camera Setting(Optional)
3.2.5 Camera Setting(Optional) 3.2.6 Barcode 1D Setting Activate camera program Open/close and various parameter setting of barcode 1D auto scanning tools A) “Take OK”: Focus and take pictures. A) “Open scan head”: open the autoscan function, input barcode in the focal position B) “Show F3”: Preview the photos. -
Page 10: Barcode 2D Setting
3.2.7 Barcode 2D Setting 3.2.8 USB Setting Set data synchronization or USB disc loading (note: this item is only existed in Open/close and various parameter setting of Barcode 2D auto scanning tools 2416 plan device, remember not to connect with the USB line before setting, or the A)“Open scan head”: open the autoscan function, input barcode in the focal position... -
Page 11: Screen Setting
3.2.11 Sound Setting B) “Output debugging information”: output the debugging information of the application program to PC through serial. C)“Connect other serial devices”: use the customized serial tool wire to Set the volume and sounds connect other serial devices. -
Page 12: Dormancy Setting
3.2.12 Dormancy Setting 3.2.13 Lock Setting Set dormancy and wake up parameter of the system Set relevant parameter when locking the screen A)“Lock screen”: if the choice is selected, the screen will be locked A)“Auto close screen” time: the screen will close automatically when the automatically if you press * and # key in order, a picture of a lock will appear in system is in idle status, and the time inter val reaches. -
Page 13: On And Off Setting Of The Modular
3.2.14 On and off Setting of the Modular 3.2.15 Autorun Setting Set on or off of each hardware modular in PDA Set the operating programs and shortcuts of autorun. A) WI-FI: turn on or turn off WI-FI modular, WI-FI Manager icon will appear A)”Desktop shortcut”: set up shortcut in the desktop. -
Page 14: Input Method Setting
3.2.16 Input Method Setting 3.2.17 Setting Information Set ”#” to change the input method Display all informatin of the current device. A) “Soft keyboard”: allow”#” key to activate the input panel of soft keyboard B) “Keyboard input letter ”: allow”#” to activate keyboard to input letter. -
Page 15: Chapter 4 Precautions And Troubleshooting
Do not try to disassemble the Supoin S20. Otherwise, the Supoin S20 may be damaged. Do not touch the screen surface of the Supoin S20 by using a pen, a pencil or other sharp articles in case the screen may be scratched. -
Page 16: Troubleshooting
No sound can be Adjust the volume. disabled. heard. After being inactive for a period The Supoin S20 is in the of time, the Supoin S20 is closed. inactive state. The Supoin S20 is closed. The battery is used up. Replace the battery.
