  • Page 1 Operator’s Manual Vibroplate VPH70 5000403284 0811...
  • Page 2 Copyright notice © Copyright 2011 by Wacker Neuson Corporation. All rights, including copying and distribution rights, are reserved. This publication may be photocopied by the original purchaser of the machine. Any other type of reproduction is prohibited without express written permission from Wacker Neuson Corporation.

  • Page 3: Table Of Contents

    Table of Contents VPH70 Foreword Emission Control System Information Safety Information Laws Pertaining to Spark Arresters ............5 Operating Safety ...................6 Operator Safety while using Internal Combustion Engines ....7 Service Safety ..................8 Label Locations ..................9 Warning and Informational Labels ............10 Technical Data Engine Data ..................12...
  • Page 4 VPH70 Table of Contents Maintenance Maintaining the Emission Control System ........... 19 Periodic Maintenance Schedule ............19 Spark Plug ..................21 Air Cleaner ..................22 Engine Oil ................... 23 Adjusting Engine Speed ..............23 Carburetor Adjustment ............... 24 Cleaning Sediment Cup ..............24 Cleaning Plate ..................
  • Page 5 Foreword This manual provides information and procedures to safely operate and maintain this Wacker Neuson model. For your own safety and protection from injury, carefully read, understand and observe the safety instructions described in this manual. Keep this manual or a copy of it with the machine. If you lose this manual or need an additional copy, please contact Wacker Neuson Corporation.
  • Page 6 Emission Control System Information Emission Control Systems Information and Warranty The Emission Control Warranty and associated information is valid only for the U.S.A., its territories, and Canada. Emission Control Systems Warranty Statement See the supplied engine owner’s manual for the applicable exhaust and evaporative emission warranty statement.

  • Page 7: Safety Information

    Safety Information VPH70 Safety Information This manual contains DANGER, WARNING, CAUTION, NOTICE, and NOTE signal words which must be followed to reduce the possibility of personal injury, damage to the equipment, or improper service. This is the safety alert symbol. It is used to alert you to potential personal injury hazards.

  • Page 8: Operating Safety

    These areas get hot and may cause burns. 2.2.3 Do not use accessories or attachments that are not recommended by Wacker Neuson. Damage to equipment and injury to the user may result. 2.2.4 NEVER operate the machine with the beltguard missing. Exposed drive belt and pulleys create potentially dangerous hazards that can cause serious injuries.

  • Page 9: Operator Safety While Using Internal Combustion Engines

    Safety Information VPH70 Operator Safety while using Internal Combustion Engines Internal combustion engines present special hazards during operation and fueling. Read and follow the warning instructions in the engine owner’s manual and the safety guidelines below. Failure to follow the WARNING warnings and safety standards could result in severe injury or death.

  • Page 10: Service Safety

    A hot muffler could ignite the debris and start a fire. 2.4.6 Replace worn or damaged components with spare parts designed and approved by Wacker Neuson. 2.4.7 Disconnect the spark plug on machines equipped with gasoline engines, before servicing, to avoid accidental start-up.

  • Page 11: Label Locations

    Label Locations wpm_si000594gb.fm...

  • Page 12: Warning And Informational Labels

    Warning and Informational Labels Wacker Neuson machines use international pictorial labels where needed. These labels are described below. Label Meaning WARNING! Always wear hearing and eye protection when operating this machine. WARNING! Hot surface Guaranteed sound power level in dB(A).
  • Page 13 Safety Information VPH70 Label Meaning DANGER! Engines emit carbon monoxide; operate only in well-ventilated area. Read the Operator’s Manual. No sparks, flames, or burning objects near the machine. Shut off the engine before refueling. Company logo Company label A nameplate listing the model number, item number, revision number, and serial number is attached to each unit.

  • Page 14: Technical Data

    VPH70 Technical Data Technical Data Engine Data Engine Power Rating Net power rating per SAE J1349. Actual power output may vary due to conditions of specific use. VPH70 0006907 Engine Engine Make Honda Engine Model GX 160 UT1 SWX2 3.6 (4.8)

  • Page 15: Machine Data

    Technical Data VPH70 Machine Data VPH70 0006907 Plate Weight kg (lbs.) 77 kg (169) Exciter Speed 7000 Exciter Lubrication ml (oz.) 240 (8) Automatic transmission fluid Dextron III/Mercon or equivalent Dimensions mm (in.) 1100 ( 44 ) x 460 ( 18 ) x 1660 ( 26 ) Sound and Vibration Measurements The required sound specification, Paragraph 1.7.4.f of 89/392/EEC...

  • Page 16: Dimensions

    VPH70 Technical Data Dimensions mm (in.) 1120 (44) 460 (18) 610 (24) wpm_gr008416 wpm_td000450gb.fm...

  • Page 17: Operation

    Before using an oxygenated fuel, confirm the fuel's contents. Some states / Provinces require this information to be posted on the fuel pump. The following are Wacker Neuson approved percentages of oxygenates: ETHANOL - (ethyl or grain alcohol) 10% by volume. You may use gasoline containing up to 10% ethanol by volume (commonly referred to as E10).

  • Page 18: Before Starting

    VPH70 Operation Before Starting 4.3.1 Read and understand the safety and operating instructions at the beginning of this manual. 4.3.2 Check: • Oil level in the engine • Fuel level • Condition of the air cleaner • Tightness of the external fasteners •...

  • Page 19: To Start

    Operation VPH70 To Start See Graphic: wc_gr000014 4.4.1 Open fuel valve by moving lever to the right (a1). Note: If engine is cold, move choke lever to close position (b1). If engine is hot, set choke to open position (b2).

  • Page 20: Operation

    VPH70 Operation Operation Run the engine at full throttle and allow the plate to pull itself along at its normal speed. When operating on an incline it may be necessary to assist the plate by pushing it forward slightly. When operating downhill hold the plate back slightly, if it begins to pick up speed.

  • Page 21: Maintenance

    Normal maintenance, replacement, or repair of emission control devices and systems may be performed by any repair establishment or individual; however, warranty repairs must be performed by a dealer/service center authorized by WACKER NEUSON. The use of service parts that are not equivalent in performance and durability to authorized parts may impair the effectiveness of the emission control system and may have a bearing on the outcome of a warranty claim.
  • Page 22 VPH70 Maintenance Machine Maintenance The chart below lists basic machine maintenance. Daily After Every Every Every before first 2 weeks month year starting 20 hrs. 50 hrs. 100 hrs. 300 hrs. Check external hardware. Check and adjust drive belt. Inspect shockmounts for damage.

  • Page 23: Spark Plug

    Maintenance VPH70 Spark Plug See Graphic: wc_gr000028 Clean or replace the spark plug as needed to ensure proper operation. Refer to your engine operator’s manual. The muffler becomes very hot during operation and remains hot for a while after stopping the engine. Do not touch the muffler while it is hot.

  • Page 24: Air Cleaner

    VPH70 Maintenance Air Cleaner See Graphic: wc_gr000025 The engine is equipped with a dual element air cleaner. Service air cleaner frequently to prevent carburetor malfunction. NOTICE: NEVER run engine without air cleaner. Severe engine damage will occur. NEVER use gasoline or other types of low flash point solvents for cleaning the air cleaner.

  • Page 25: Engine Oil

    Maintenance VPH70 Engine Oil See Graphic: wc_gr000022 5.5.1 Drain the oil while the engine is still warm. 5.5.2 Remove the oil filler plug (a) and the drain plug (b) to drain the oil. Note: In the interests of environmental protection, place a plastic sheet and a container under the machine to collect any liquid that drains off.

  • Page 26: Carburetor Adjustment

    VPH70 Maintenance Carburetor Adjustment See Graphic: wc_gr000032 5.7.1 Start the engine and allow it to warm up to operating temperature. 5.7.2 Set the pilot screw (a) two turns out. See Note. 5.7.3 With the engine idling, turn the pilot screw (a) in or out to the setting that produces the highest rpm.

  • Page 27: Cleaning Plate

    Maintenance VPH70 Cleaning Plate Clean plate after use to remove dirt, stones, and mud caught under the engine console. If plate is being used in a dusty area, check engine cylinder cooling fins for heavy dirt accumulation. Keep engine cylinder fins clean to prevent engine from overheating.

  • Page 28: Lifting Machine

    VPH70 Maintenance 5.10 Lifting Machine See Graphic: wpmgr008417 See Technical Data for weight of the machine. To lift machine manually: 5.10.1 Stop the engine. 5.10.2 Obtain help from a partner and plan the lift. To avoid burns or fire hazards, let the engine cool before transporting the machine or storing it indoors.

  • Page 29: Transporting Machine

    Maintenance VPH70 5.11 Transporting Machine See Graphic: wpmgr008418 To avoid burns or fire hazards, let engine cool before transporting machine or storing indoors. WARNING 5.11.1 Turn fuel valve to the off position and keep the engine level to prevent fuel from spilling.

  • Page 30: Troubleshooting

    VPH70 Maintenance 5.13 Troubleshooting Problem / Symptom Reason / Remedy Plate does not develop full • Engine throttle control not completely open. speed. Poor compaction. • Throttle control not adjusted correctly. • Ground too wet, plate sticking. Allow soil to dry before compacting.
