XX151-01-00

SURVEYOR4A MINIATURE

FIXED-POSITION CAMERA DOMES

Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet

your requirements or that the operation will be entirely error free or perform precisely as

described in the documentation. This system has not been designed to be used in life-critical

situations and must not be used for this purpose.

WARNING: To reduce a risk of fire or electric shock, do not expose this product to rain or

moisture.

Product specifications subject to change without notice.

Vicon and its logo are registered trademarks of Vicon Industries Inc.

VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788

TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116

24-Hour Technical Support: 800-34-VICON (800-348-4266)

UK: +44 (0) 1489 566300

WEB: www.vicon-cctv.com

Vicon part number 8009-8151-01-00

Rev 605 Section 3

Table of Contents

Need help?

Do you have a question about the Surveyor4A SeriesS4AVF-CA and is the answer not in the manual?

Questions and answers

Summary of Contents for Vicon Surveyor4A SeriesS4AVF-CA

Page 1 SURVEYOR4A MINIATURE FIXED-POSITION CAMERA DOMES Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed to be used in life-critical situations and must not be used for this purpose.
Page 3 FCC Notice Note: Complies with Federal Communications Commission Rules & Regulations Part 15, Subpart B for a Class A digital device. WARNING This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer’s instruction, may cause interference to radio and television reception.
Page 4 The product shows a significant change in performance. 6. Attachments - Use only Vicon recommended attachments to 20. Replacement Parts - Use only Vicon specified replacement prevent unit damage and personal injury.
Page 5: Table Of Contents
Contents Quick Installation .......................iv Introduction .........................1 Installation ...........................3 Unpacking and Inspection..........................3 Inspection for Visible Damage ........................3 Inspection for Concealed Damage .......................3 Surveyor4A Dome Components ........................3 Mounting the Unit ............................4 Camera/Lens Adjustments ..........................7 Final Installation .............................9 Operation ...........................10 Maintenance ........................10 Care and Cleaning of Lower Dome......................10 Shipping Instructions .......................11 Reference...........................12 Technical Information .......................14...
Page 6: Quick Installation
Quick Installation iv • Quick Installation XX151-01-00 Rev 605 Surveyor4A Fixed-Position Camera Dome...
Page 7: Introduction
Read this manual through completely before attempting installation. Vicon’s Surveyor4A Series of Fixed-Position Camera Domes offers a compact indoor domed housing incorporating a fixed camera and lens combination. They are configured for in-ceiling installation. The domes include a standard or high-resolution color or day/night camera with a choice of fixed-focal-length or varifocal autoiris lenses.
Page 8 Table 1 Models, Product Codes and Descriptions Model Product Code Description S4AVF-CA 8399-00 1/3-in. color camera and 2.6 - 6 mm autoiris varifocal lens; 24 VAC; isolated power input, 4-inch smoked lower dome; NTSC; coaxial cable video S4AVF-CA-C 8399-01 1/3-in. color camera and 2.6 - 6 mm autoiris varifocal lens; 24 VAC;...
Page 9: Installation
Installation Unpacking and Inspection All Vicon equipment is tested and inspected before leaving the factory. It is the carrier’s responsibility to deliver the equipment in the same condition as it left the factory. Inspection for Visible Damage Immediately inspect the cartons upon delivery. Make a note of any visible damage on all copies of the carrier’s freight bill.
Page 10: Mounting The Unit
Mounting the Unit The Surveyor4A is intended for in-ceiling installation. It can be installed in either a dropped ceiling or a hard ceiling. Installation is done with a 4 x 4 electrical box, which is included. All mounting hardware is provided. The ceiling material must provide suitable strength to support the weight of the Surveyor4A dome (3.0 lb, 1.4 kg).
Page 11 The power supply for the camera must be 24 VAC. Refer to Figure 5. Note: Vicon systems and components, like most electronic equipment, require a clean, stable power source. Voltage irregularities such as surges, drops, and interruptions can affect the operation of your equipment and, in severe cases, damage certain components.
Page 12 Figure 3 Enclosure/Camera Assembly Components (Inside View) Power Supplies Vicon recommends several power supplies, depending on the needs of the installation. Refer to the table below. For other multichannel power supplies, contact Altronix Corporation at 888-258-7669. Model Number Description VC24PS-1 Single channel indoor, 24 VAC V248-3.5PS...
Page 13: Camera/Lens Adjustments
Figure 4 Power Connections Camera Synchronization If there is more than one unit in a system, the cameras have to be synchronized to ensure there is no roll of video. If the camera will be used in a line lock video application, the camera interface board is already set in line lock mode by default.
Page 14 Lens/Autoiris Adjustment The manual iris lens can be manually adjusted for focus and angle of view. On the lens, focus (near to infinity) is the front ring and the telephoto/wide adjustment is the end ring; iris is fixed. On autoiris lenses, iris adjustment may be required if the picture appears dark or grainy or has poor color.
Page 15: Final Installation
Camera/Lens Positioning The camera position can be adjusted in four axes, horizontally (pan), vertically (tilt), vertical height of the camera/lens assembly in the enclosure and rotation about the lens axis (roll). Rotate the camera/lens assembly on the camera mounting (L) bracket to adjust the pan position; swivel the assembly for tilt position. The vertical height of the camera/lens assembly can be adjusted by loosening the lock nut, changing the vertical position of the camera mounting bracket within the slot in the mounting bracket and retightening the nut.
Page 16: Operation
Operation When power is applied to the camera, the Surveyor4A dome views the selected scene. Maintenance The Surveyor4A Miniature Fixed-Position Camera Dome requires no scheduled maintenance except for the occasional cleaning of the lower dome. Care and Cleaning of Lower Dome The inside surface of the smoked (gray-tinted) dome is easily scratched.
Page 17: Shipping Instructions
Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A.
Page 18: Reference
Caution: Careful selection of the proper cable is essential to obtain the best performance from this equipment. Vicon assumes no responsibility for poor performance when cables other than those recommended are installed. In all cases, coaxial cable impedance should be 75 ohms.
Page 19 Twisted-Pair Cable Caution: Careful selection of the proper cable is essential to obtain the best performance from this equipment. Vicon assumes no responsibility for poor performance when cables other than those recommended are installed. Materials Use a pure copper stranded or solid conductor with or without a tin plating to obtain a low DC resistance. Do not use cable with either steel or aluminum stranded conductor because these do not transfer signals effectively for long distances.
Page 20: Technical Information
Technical Information ELECTRICAL Input Voltage: 24 VAC ±20%, isolated. Current Rating: 250 mA. Power Consumption: 6 W Heat Equivalent: 0.34 btu/min (0.097 kg-cal/min). Note: These figures represent the conversion of 100% of the electrical energy to heat. Actual percentage of heat generated will be less and will vary from product to product .
Page 21 Dimensions: Height: 3.4 in. (86 mm), below ceiling; 4.1 in. (104 mm), above ceiling. Total Diameter: 6.44 in. (164 mm). Dome Diameter: 4.73 in. (120 mm). Total width of electrical box: 4.75 in. (121 mm). Weight: Approximately 2.25 lb (1.02 kg). Construction: Cast plastic, aluminum and steel.
Page 22 Table 3 Camera Specifications Model Image Color/ Resolution Sensitivity Electronic Iris Signal-to-Noise Device (sec) Ratio Mono (TV lines) fc (lux) S4AVF-CA/ 1/3 CCD, 2:1 interlace, Color 0.07 (0.8) 1/60 (1/50)– >48 dB (AGC off) S4AVF-CA-C NTSC/PAL at 40 IRE, /100,000 f/1.6.
Page 23 Software supplied either separately or in hardware is furnished on an “As Is” basis. Vicon does not warrant that such software shall be error (bug) free. Software support via telephone, if provided at no cost, may be discontinued at any time without notice at Vicon’s sole discretion.
Page 24 Vicon Industries Inc. Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 631-952-CCTV (2288) 800-645-9116 Fax: 631-951-CCTV (2288) Vicon Europe Headquarters Brunel Way Fareham, PO15 5TX United Kingdom +44 (0) 1489 566300 Fax: +44 (0) 1489 566322 Brussels Office Planet II - Unit E...
