Summary of Contents for Minix NEO X5
- Page 1 Android™ is a trademark of Google Inc.
- Page 3 Thank you for purchasing MINIX NEO X5. Follow this guide to setup your device. MINIX NEO X5 is a revolutionary smart media hub based on a dual- core ARM Cortex-A9 processor with quad-core Mali-400 GPU and the latest Android™ 4.0.4 OS. Sign into Google Play Store to download the favorite applications and install them directly into NEO X5.
-
Page 4: Table Of Contents
Content Chapter 1: Connect ............5 What's in the box ..................6 MINIX NEO X5 at a glance ..............7 What you need ..................11 Setting up MINIX NEO X5 ..............12 Chapter 2: Basic Setup ..........13 Language setup ..................14 Time zone setup ...................14 Wi-Fi setup (basic) ................14 Chapter 3: Google Play Store ........15... -
Page 5: Chapter 1: Connect
Chapter 1 Connect. - 5 -... -
Page 6: What's In The Box
What’s in the box MINIX NEO X5 x 1 MINIX remote x 1 5V Power adapter x 1 Micro-USB OTG cable x 1 HDMI cable x 1 Setup guide x 1 - 6 -... -
Page 7: Minix Neo X5 At A Glance
MINIX NEO X5 at a glance 4 5 6 9. Recover button (for 1. IR receiver service and upgrade) 2. Power LED 10. HDMI port 3. Power button 11. Optical audio port 4. Earphone jack 12. USB 2.0 port 3 5. - Page 8 The LED glows when the MINIX NEO X5 is on. Power button To power on MINIX NEO X5, press and hold the power button for 2-3 seconds until the power LED glows. To power off MINIX NEO X5, press and hold the power button and the display will prompt out the confirmation dialogue for power off, select OK to confirm;...
- Page 9 USB port and release it once MINIX NEO X5 is powered on. HDMI port Connect MINIX NEO X5 to the HDMI port of a high-definition TV or PC monitor using an HDMI cable. Optical audio port Connect to the optical audio input of an external sound processing unit, such as an amplifier.
- Page 10 PPPoE dial-up, go into the setting page at: Settings ->More… While connected with the Ethernet cable, MINIX NEO X5 can be used as a router and also a Wi-Fi hotspot; if you need to use the Wi-Fi hotspot feature, please make sure that the Wi-Fi feature is OFF before you enable the Wi-Fi hotspot service at: Settings ->More…...
-
Page 11: What You Need
A high-definition TV or PC monitor that can display 720p or 1080p video with at least one HDMI input. Cable An HDMI cable to connect MINIX NEO X5 to your TV. Wireless network A wired network cable or an 802.11 a, b, g, or n Wi-Fi wireless network (wireless video streaming requires 802.11g or n), your wireless network... -
Page 12: Setting Up Minix Neo X5
1. Connect one end of the HDMI cable to the HDMI port of your TV/ PC monitor. 2. Connect the other end of the cable to the HDMI port of MINIX NEO Step 2: Connecting the power Connect the 5V power adapter supplied in the package to this port. -
Page 13: Chapter 2: Basic Setup
Chapter 2 Basic Setup. - 13 -... -
Page 14: Language Setup
Language setup You may choose the desired system language by the following steps: Launcher Home Screen > Settings > Language & input > Language The default language is English, you may choose your desired language and confirm. Time zone setup You should adjust the time zone according to your current location by the following steps: Launcher Home Screen >... -
Page 15: Chapter 3: Google Play Store
Chapter 3 Google Play Store. - 15 -... - Page 16 Sign-in to your Google Account Launch the Google Play Store by the following steps: Launcher Home Screen -> Google Play Store, hit and confirm. To use Google Play Store you need a Google Account. If you already had a Google Account, select “Sign in” and login with your Google Account.
-
Page 17: Chapter 4: Control
Chapter 4 Control. - 17 -... -
Page 18: Different Control Methods
4.) MINIX infrared remote control (included) Using your MINIX remote Read on to learn about using your MINIX remote with MINIX NEO X5. This remote will be 100% functional when working with our customized user interface - the GridShow launcher Note: The MINIX remote will still function if you are not using the GridShow launcher, however, some keys might become useless, e.g the... -
Page 19: Functions Of The Minix Remote
Functions of the MINIX remote POWER - To wake up from or put the MINIX NEO X5 into sleep mode VOLUME DOWN - Adjust the system volume down VOLUME UP - Adjust the system volume up HOME - Bring you back to the Home Screen (choose of launcher... - Page 20 ZOOM IN - Allow you to zoom in when an application supports this function UP - Move upward ZOOM OUT - Allow you to zoom out when an application supports this function LEFT - Move left OK - To confirm a particular action, and as an “Enter” key RIGHT - Move right SEARCH - Pop up the search interface when an application supports this function...
- Page 21 MINIX. This clause does not apply to such software which is licensed under the General Public License (“GPL”) or other Free Open Source Licenses.
- Page 22 - 22 -...
