SERVICE MANUAL
Ver 1.0 2002. 04
Revision History
Revision History
Link
Link
SPECIFICATIONS
SPECIFICATIONS
SERVICE NOTE
SERVICE NOTE
DISASSEMBLY
DISASSEMBLY
• For INSTRUCTION MANUAL, refer to SERVICE MANUAL, LEVEL 1 (992997341.pdf).
• This service manual contains information for Japanese model as well.
• Note in Lens Frame Installation.
On the JK-226, JK-227, SY-77 boards
This service manual procides the information that is premised
the circuit board replacement service and not intended repair
inside the JK-226, JK-227, SY-77 boards.
Therefore, schematic diagram, printed wiring board and
electrical parts list of the JK-226, JK-227, SY-77 boards are not
shown.
The following pages are not shown.
BLOCK DIAGRAMS
BLOCK DIAGRAMS
FRAME SCHEMATIC DIAGRAMS
FRAME SCHEMATIC DIAGRAMS
SCHEMATIC DIAGRAMS
SCHEMATIC DIAGRAMS
SY-77 board
Schematic diagram ......................... Pages 4-9 to 4-28
Printed wiring board ........................ Pages 4-43 to 4-46
Electrical parts list ........................... Pages 6-9 to 6-13
JK-226, JK-227 boards
Schematic diagram ......................... Pages 4-33 to 4-34
Printed wiring board ........................ Pages 4-49 to 4-50
Electrical parts list ........................... Pages 6-6
The above-described information is shown in service
manual Level 3.
DSC-P9
US Model
Canadian Model
AEP Model
UK Model
Hong Kong Model
Australian Model
Chinese Model
Korea Model
Tourist Model
Japanese Model
PRINTED WIRING BOARDS
PRINTED WIRING BOARDS
ADJUSTMENTS
ADJUSTMENTS
REPAIR PARTS LIST
REPAIR PARTS LIST
DIGITAL STILL CAMERA
2
LEVEL
E Model

Advertisement

Table of Contents
loading

Related Manuals for Sony Cybershot DSC-P9

Summary of Contents for Sony Cybershot DSC-P9

  • Page 1 DSC-P9 SERVICE MANUAL LEVEL US Model Ver 1.0 2002. 04 Canadian Model Revision History Revision History AEP Model UK Model E Model Hong Kong Model Australian Model Chinese Model Korea Model Tourist Model Japanese Model Link Link SPECIFICATIONS BLOCK DIAGRAMS PRINTED WIRING BOARDS SPECIFICATIONS BLOCK DIAGRAMS...
  • Page 2 DSC-P9 COVER COVER SPECIFICATIONS System Output connectors AC-LS1A AC power adaptor Image device 8.98 mm (1/1.8 type) color A/V OUT (MONO) jack Power requirements Minijack AC 100 – 240 V, 50/60 Hz Primary color filter Video: 1 Vp-p, 75 Ω , unbalanced, Rated output voltage sync negative Total pixels number of camera...
  • Page 3 CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU PUBLISHED BY SONY.

  • Page 4: Table Of Contents

    DSC-P9 TABLE OF CONTENTS Section Title Page Section Title Page SERVICE NOTE 1-2-2. Initialization of B, E, F, 7, 9 Page Data ··························· 5-9 ························································ 1-1 Initializing B, E, F, 7, 9 Page Data ·································· 5-9 Self-diagnosis Display ····················································· 1-3 Modification of B, E, F, 7, 9 Page Data.
  • Page 5 DSC-P9 Section Title Page REPAIR PARTS LIST 6-1. Exploded Views ······························································· 6-1 6-1-1. Cabinet (Front) Section ··················································· 6-1 6-1-2. Cabinet (Rear) Assembly ················································· 6-2 6-1-3. Lens Block and LCD Section ·········································· 6-3 6-1-4. Battery Holder Assembly ················································ 6-4 6-2. Electrical Parts List ························································· 6-5 * The color reproduction frame is shown on page 113.

  • Page 6: Service Note

    DSC-P9 SECTION 1 COVER COVER SERVICE NOTE • NOTE FOR REPAIR When remove a connector, don’t pull at wire of connector. Make sure that the flat cable and flexible board are not cracked of It is possible that a wire is snapped. bent at the terminal.
  • Page 7 DSC-P9 [Precaution on Replacing the Video Lens or the SY-77 [Note in Lens Frame Installation] Board] When tightening a screw, have both sides of the lens block assembly so as not for the load to depend. The DSC-P9 uses the position sensor to detect the zoom position. Accordingly, the zoom position will vary if the position data changes due to the replacement of the video lens or the SY-77 board, thus causing the video lens to collide against the mechanism end when...

  • Page 8: Self-Diagnosis Display

    [Description on Self-diagnosis Display] Self-diagnosis display • C: ss: ss You can reverse the camera malfunction yourself. (However, contact your Sony dealer or local authorized Sony service facility when you cannot recover from the camera malfunction.) • E: ss: ss Contact your Sony dealer or local authorized Sony service facility.

  • Page 9: Disassembly

    DSC-P9 SECTION 2 COVER COVER DISASSEMBLY • This set can be disassembled in the order shown below. 2-1. BT LID DSC-P9 (Page 2-2) 2-2. CABINET (FRONT) 2-3. CABINET (REAR) 2-4. LCD MODULE ASSEMBLY (Page 2-2) ASSEMBLY (Page 2-3) (Page 2-3) 2-7.

  • Page 10: Bt Lid

    DSC-P9 Note: Follow the disassembly procedure in the numerical order given. 2-1. BT LID 1 Open the BT lid. 4 BT lid 2 Screw (1.7 × 3) 3 Two claws 2-2. CABINET (FRONT) ASSEMBLY 6 Screw (M1.7) 1 Screw (M1.7) 2 Screw (M1.7) 7 Center cabinet...

  • Page 11: Cabinet (Rear) Assembly

    DSC-P9 2-3. CABINET (REAR) ASSEMBLY 2 Screw 5 Cabinet (rear) (M1.7) assembly 1 Screw (M1.7) 3 Two screws (M1.7) 2-4. LCD MODULE 1 Flexible board (CN102) 6 LCD module 2 Flexible board (CN101) 3 Two screws (M1.7) 4 Four claws 5 Back light unit...

  • Page 12: Cabinet (Bottom) Assembly

    DSC-P9 2-5. CABINET (BOTTOM) ASSEMBLY 1 Claw Rear side 2 Cabinet (bottom) assembly 2-6. LENS BLOCK ASSEMBLY 2 Two claws 3 Lens block assembly 1 Two flexible board (CN001, 301)

  • Page 13: Service Position (Sy-77 Board: Side A)

    DSC-P9 [SERVICE POSITION (SY-77 BOARD: SIDE A)] Note 1: Don’t use the 12 pin flexible board of CPC-9 jig. It causes damage to the unit. Note 2: The old CPC-9 jig (Parts code: J-6082-393-B) cannot be used, because it cannot operate the adjustment remote commander.

  • Page 14: Board

    DSC-P9 2-8. SY-77 BOARD 5 Claw 1 Connector (CN351) 7 SY-77 board 4 Screw (M1.7 × 4) 2 Flexible board (CN703) 6 Flexible board 3 Three flexible boards (CN701) (CN001, 301, 702) 2-9. MEMORY STICK CONNECTOR 1 Two screws (M1.7 × 4) 2 Claw 3 Memory stick connector...

  • Page 15: Board

    DSC-P9 2-10.ST-70 BOARD Note: High-voltage cautions (See page 1-1). 3 ST-70 board Note: When installing ST-70 board, the claw is put into the bottom 1 Connector the BT main frame. (CN351) BT main frame 2 Claw 2-11.SW-368 BOARD 1 Two screws (M1.7 ×...

  • Page 16: Service Position (Sy-77 Board: Side B)

    DSC-P9 2-12.JK-227 BOARD 6 Claw 2 Claw 7 JK-227 board (including JK-226) 5 Screw (M1.7) 1 Screw 3 Claw (M1.7 × 4) 4 DD sheet metal [SERVICE POSITION (SY-77 BOARD: SIDE B)] Adjusting remote commander Note 1: Don’t use the 12 pin flexible board of CPC-9 jig. It causes damage to the unit.

  • Page 17: Circuit Boards Location

    DSC-P9 2-13.CIRCUIT BOARDS LOCATION SW-368 ST-70 CD-397 SY-77 JK-227 (including JK-226) Board Name Function CD-397 CCD IMAGER SY-77 CAMERA MODULE, CAMERA DSP, VIDEO, MEMORY, LENS DRIVE, SH DSP, FLASH MEMORY, FRONT CONTROL, AUDIO, CLOCK GENERATOR, FLASH CONTROL, DC/DC CONVERTER, CAMERA PROCESS ST-70 FLASH DRIVE SW-368...

  • Page 18: Block Diagrams

    DSC-P9 COVER COVER 3. BLOCK DIAGRAMS Link Link OVERALL BLOCK DIAGRAM POWER BLOCK DIAGRAM 2 OVERALL BLOCK DIAGRAM POWER BLOCK DIAGRAM 2 POWER BLOCK DIAGRAM 1 POWER BLOCK DIAGRAM 1...
  • Page 19 DSC-P9 SECTION 3 3. BLOCK DIAGRAMS 3. BLOCK DIAGRAMS COVER COVER BLOCK DIAGRAMS 3-1. OVERALL BLOCK DIAGRAM ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located. SY-77 BOARD CD-397 BOARD (1/2) PANEL UNIT LENS IRIS...

  • Page 20: Power Block Diagram 1

    DSC-P9 3. BLOCK DIAGRAMS 3. BLOCK DIAGRAMS COVER COVER ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located. 3-8. POWER BLOCK DIAGRAM 1 SY-77 BOARD (1/2) CN706 JK-227 BOARD HI UNREG JK-226 BOARD J001...

  • Page 21: Power Block Diagram 2

    DSC-P9 3. BLOCK DIAGRAMS 3. BLOCK DIAGRAMS COVER COVER 3-9. POWER BLOCK DIAGRAM 2 ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located. SW-368 BOARD PANEL UNIT CN701 Q002, 003 CN102 SY-77 BOARD (2/2) Q105, 108...

  • Page 22: Printed Wiring Boards And Schematic Diagrams

    DSC-P9 DSC-P9 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS COVER COVER SECTION 4 PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS 4-1. FRAME SCHEMATIC DIAGRAMS FRAME (1/2) CONTROL PANEL UNIT SWITCH BLOCK D901 LCD901 S004 BACK 1.5INCH POWER...
  • Page 23 DSC-P9 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS COVER COVER FRAME (2/2) CN001 25P LENZ UNIT PRE_LAMP M_5V ST-70 BOARD CN351 15P OPTICAL VIEW VL_3V FINDER STB_ON1 LENZ CCD_OUT STB_FULL ST_UNREG D101 ST_UNREG SELF TIMER/ ST_UNREG AF ILLUMINATOR...

  • Page 24: Schematic Diagrams

    DSC-P9 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS COVER COVER 4-2. SCHEMATIC DIAGRAMS THIS NOTE IS COMMON FOR SCHEMATIC DIAGRAMS (In addition to this, the necessary note is printed in each block) (For schematic diagrams) 1. Connection • All capacitors are in µF unless otherwise noted. pF : µ Link Pattern box µF.

  • Page 25: Ccd Imager)

    DSC-P9 COVER COVER 4-2. SCHEMATIC DIAGRAMS Link Link CD-397 BOARD CD-397 BOARD (CCD IMAGER) ST-70 BOARD (FLASH DRIVE) (CCD IMAGER) ST-70 BOARD (FLASH DRIVE) CONTROL SWITCH BLOCK SW-368 BOARD (1/2) CONTROL SWITCH BLOCK SW-368 BOARD (1/2) (CONTROL SWITCH) (CONTROL SWITCH) SW-368 BOARD (2/2) SW-368 BOARD (2/2) (LCD DRIVE, TIMING GENERATOR)
  • Page 26 DSC-P9 DSC-P9 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS CD-397 PRINTED WIRING BOARD CD-397 PRINTED WIRING BOARD COVER COVER For Schematic Diagram 4-2. SCHEMATIC DIAGRAMS • Refer to page 4-41 for printed wiring board. CD-397 BOARD Note: voltage and waveform of mounted on CD-397 board can not be measured, because they are (mounted) CCD IMAGER(CCD BLOCK) by the side of the lens.
  • Page 27 DSC-P9 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS SW-368 PRINTED WIRING BOARD SW-368 PRINTED WIRING BOARD COVER COVER For Schematic Diagram • Refer to page 4-47 for printed wiring board. SW-368 BOARD (1/2) CONTROL SWITCH(KEY BLOCK) S004 CONTROL XX MARK:NO MOUNT NO MARK:REC/PB MODE RIGHT CL001...
  • Page 28 DSC-P9 DSC-P9 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS SW-368 PRINTED WIRING BOARD SW-368 PRINTED WIRING BOARD COVER COVER For Schematic Diagram • Refer to page 4-47 for printed wiring board. • Refer to page 4-54 for waveforms. SW-368 BOARD (2/2) LCD DRIVE,TIMING GENERATOR(RGB/TG BLOCK) Q107 MCH3310-TL-E...

  • Page 29: Flash Drive

    DSC-P9 DSC-P9 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS ST-70 PRINTED WIRING BOARD ST-70 PRINTED WIRING BOARD COVER COVER For Schematic Diagram • Refer to page 4-51 for printed wiring board. ST-70 BOARD D002 FLASH DRIVE(FL BLOCK) HAU160C030TP LND016 NO MARK:REC/PB MODE XE_A T001 R007...
  • Page 30 DSC-P9 DSC-P9 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS COVER COVER COVER COVER For Schematic Diagram CONTROL SWITCH BLOCK CONTROL SWITCH BLOCK is replaced as a block, so that PRINTED WIRING BOARD is omitted. S005 MODE DIAL SET_UP R002 MOVIE 4000 R003 PLAY P_AUTO...
  • Page 31 DSC-P9 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS COVER COVER 4-3. PRINTED WIRING BOARDS THIS NOTE IS COMMON FOR WIRING BOARDS (In addition to this, the necessary note is printed in each block) (For printed wiring boards) • Chip parts. •...

  • Page 32: Printed Wiring Boards

    DSC-P9 COVER COVER 4-3. PRINTED WIRING BOARDS Link Link CD-397 BOARD ST-70 BOARD CD-397 BOARD ST-70 BOARD SW-368 BOARD SW-368 BOARD COMMON NOTE FOR PRINTED WIRING BOARDS WAVEFORMS COMMON NOTE FOR PRINTED WIRING BOARDS WAVEFORMS MOUNTED PARTS LOCATION CIRCUIT BOARDS LOCATION MOUNTED PARTS LOCATION CIRCUIT BOARDS LOCATION...
  • Page 33 DSC-P9 DSC-P9 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS MOUNTED PARTS LOCATION MOUNTED PARTS LOCATION COVER COVER CD-397 (CCD IMAGER) • For Printed Wiring Board. • :Uses unleaded solder. • There are a few cases that the part isn't mounted in this model is printed on this diagram.
  • Page 34 DSC-P9 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS MOUNTED PARTS LOCATION MOUNTED PARTS LOCATION COVER COVER SW-368 (FRONT CONTROL, LCD DRIVE, TIMING GENERATOR, CONTROL SWITCH) • For Printed Wiring Board. • :Uses unleaded solder. •...
  • Page 35 DSC-P9 4-2. SCHEMATIC DIAGRAMS 4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS MOUNTED PARTS LOCATION MOUNTED PARTS LOCATION COVER COVER ST-70 (FLASH DRIVE) • For Printed Wiring Board. • :Uses unleaded solder. • There are a few cases that the part isn't mounted in this model is printed on this diagram.
  • Page 36 DSC-P9 SW-368 BOARD SW-368 BOARD COVER COVER SW-368 BOARD 340 mVp-p 7.8 Vp-p IC101 w; REC/PB IC101 rj REC/PB 460 mVp-p 7.8 Vp-p IC101 ws REC/PB IC101 rk REC/PB 3.0 Vp-p 7.8 Vp-p IC101 wf REC/PB IC102 1 REC/PB 4.1 Vp-p 5.1 Vp-p 11.28 MHz IC101 wj REC/PB...
  • Page 37 DSC-P9 4-3. PRINTED WIRING BOARDS 4-3. PRINTED WIRING BOARDS COVER COVER SW-368 BOARD C002 R111 C101 R112 C102 R113 C103 R114 C104 R115 C105 R116 C106 R117 C107 R118 C108 R119 C109 R120 C110 R121 C111 R122 C112 R123 C113 R124 C114 R125...

  • Page 38: Adjustments

    DSC-P9 SECTION 5 COVER COVER ADJUSTMENTS Before starting adjustment EVR Data Re-writing Procedure When Replacing Board The data that is stored in the repair board, is not necessarily correct. Perform either procedure 1 or procedure 2 or procedure 3 when replacing board. Procedure 1 Save the EVR data of the machine in which a board is going to be replaced.

  • Page 39: Main Parts And Boards

    DSC-P9 1-1. Adjusting items when replacing main parts and boards When replacing main parts and boards, adjust the items indicated by z in the following table. Replaced parts Block Mounted parts Board replacement replacement replacement Adjustment section Adjustment Initialization of A, D page data Initialization of A, B, D, E, F, 7, 9 page data Initialization of B, E, F, 7, 9, page data...

  • Page 40: Camera Section Adjustments

    DSC-P9 5-1. CAMERA SECTION ADJUSTMENT 1-1. PREPARATIONS BEFORE ADJUSTMENT 1-1-1. List of Service Tools • Oscilloscope • Color monitor • Vectorscope • Regulated power supply • Digital voltmeter Ref. No. Name Parts Code Usage Auto white balance adjustment/check Filter for color temperature correction (C14) J-6080-058-A White balance adjustment/check Pattern box PTB-450...

  • Page 41: Preparations

    DSC-P9 1-1-2. Preparations Note 1: For details of how remove the cabinet and boards, refer Pattern box to “2. DISASSEMBLY”. Note 2: When performing only the adjustments, the lens block and boards need not be disassemble. 1) Connect the equipment for adjustments according to Fig. 5-1- 2) Connect the Adjusting remote commander to SY-77 board CN706 via CPC-9 jig (J-6082-393-C).
  • Page 42 DSC-P9 CONTROL SWITCH BLOCK Must be connected when the MIC UNIT is used. Illumination LENS UNIT CN351 CN704 ST-70 BOARD CN705 CN001 SY-77 BOARD CN701 CN703 CN301 CN706 CN702 JK-227 BOARD Must be connected SPEAKER JK-226 BOARD when the Memory Stick is used.

  • Page 43: Precautions

    DSC-P9 1-1-4. Precautions 1. Setting the Switch Unless otherwise specified, set the switches as follows and per- form adjustments. 1. Mode Dial .......... CAMERA 2. ZOOM switch (SW-368 board S001, S002) ....WIDE end 3. EV (Menu display) ......0EV 4.

  • Page 44: Preparing The Flash Adjustment Box

    DSC-P9 4. Preparing the Flash Adjustment Box A dark room is required to provide an accurate flash adjustment. If it is not available, prepare the flash adjustment box as given below; 1) Provide woody board A, B and C of 15 mm thickness. woody board A (2) woody board B (2) woody board C (1)

  • Page 45: Initialization Of A, B, D, E, F, 7, 9 Page Data

    DSC-P9 1-2. INITIALIZATION OF A, B, D, E, F, 7, 9 PAGE 3. A Page table Note 1: Fixed data-1: Initialized data. DATA (Refer to “1. Initializing the A Page Data”) 1-2-1. Initialization of A, D Page Data Note 2: Fixed data-2: Modified data. 1.

  • Page 46: Initializing B, E, F, 7, 9 Page Data

    DSC-P9 1-2-2. Initialization of B, E, F, 7, 9 Page Data 3. B Page Table 1. Initializing B, E, F, 7, 9 Page Data Note 1: Fixed data-1: Initialized data. Note: If the B, E, F, 7, 9 Page data has been initialized, (Refer to “1.
  • Page 47 DSC-P9 5. F Page Table Note 1: Fixed data-1: Initialized data. (Refer to “1. Initializing the B, E, F, 7, 9 Page Data”) Note 2: Fixed data-2: Modified data. (Refer to “2. Modification of B, E, F, 7, 9 Page Data”) Address Initial value Remark Address Initial value...
  • Page 48 DSC-P9 Address Initial value Remark Address Initial value Remark Color reproduction adj. AWB 3200K standard data input 2 AWB 3200K standard data input 1 AWB 5800K standard data input 1 AWB 3200K standard data input 1 AWB 5800K standard data input 1 AWB 3200K standard data input 1 AWB 3200K standard data input 3 Fixed data-1 (Initialized data)

  • Page 49: B Page Table

    DSC-P9 6. 7 Page Table Address Initial value Remark Note 1: Fixed data-1: Initialized data. (Refer to “1. Initializing B, E, F, 7, 9 Page Data”) Note 2: Fixed data-2: Modified data. (Refer to “2. Modification of B, E, F, 7, 9 Page Data”) Address Initial value Remark 00 to FF...

  • Page 50: Video System Adjustments

    DSC-P9 1-3. VIDEO SYSTEM ADJUSTMENTS 2. Video Burst Level Check Adjust the burst level of the composite video signal output. 1. Video Sync Level Adjustment Adjust the sync level of the composite video signal output. Mode PLAY Mode PLAY Signal Arbitrary Signal Arbitrary...

  • Page 51: Camera System Adjustments

    DSC-P9 1-4. CAMERA SYSTEM ADJUSTMENTS After completing the camera system adjustments, release the data setting: Before perform the camera system adjustments, check that the specified values of “VIDEO SYSTEM ADJUSTMENTS” are sat- Order Page Address Data Procedure isfied. Press PAUSE button. Note: For “CAMERA SYSTEM ADJUSTMENTS”, perform in order of item numbers.

  • Page 52: Picture Frame Setting

    DSC-P9 Picture Frame Setting How to reset the zoom and focus when they deviated: Order Page Address Data Procedure Mode CAMERA Subject Color bar chart (Standard picture frame with the zoom lens at WIDE end) Set the following data. Measurement Point Video terminal of A/V OUT jack 00: WIDE end (75 Ω...
  • Page 53 DSC-P9 1. Flange Back Adjustment Adjusting method: RadarW RadarW RadarW RadarW RadarW (Using the minipattern box) Order Page Address Data Procedure The flange back of inner focus lens is adjusted automatically. If Perform “Data setting during shifted, the auto focus is disordered. camera system adjustment”.

  • Page 54: Flange Back Adjustment

    DSC-P9 RadarW RadarW RadarW RadarW RadarW RadarW RadarW RadarW RadarW RadarW 2. Flange Back Adjustment 3. Flange Back Check (Using the flange back adjustment chart) Mode CAMERA The flange back of inner focus lens is adjusted automatically. If Subject Siemens star shifted, the auto focus is disordered.

  • Page 55: F No. Compensation

    DSC-P9 RadarW RadarW RadarW RadarW RadarW RadarW 4. F No. Compensation 5. Mechanical Shutter Adjustment Compensate the unevenness of the iris meter sensitivity. Adjust the period which the mechanical shutter is closed, and com- pensate the exposure. Mode CAMERA Mode CAMERA Subject Clear chart...

  • Page 56: Light Value Adjustment

    DSC-P9 RadarW RadarW RadarW RadarW RadarW RadarW RadarW RadarW 6. Light Value Adjustment 7. Mixed Color Cancel Adjustment Adjust the standard LV value. To perform mixed color cancel adjustment based on data of each color in color bar. Mode CAMERA Mode CAMERA Subject...

  • Page 57: Auto White Balance 3200K Standard Data Input 1

    DSC-P9 8. Auto White Balance 3200K Standard Data Input 1 Processing after Completing Adjustment: RadarW RadarW RadarW Order Page Address Data Procedure Adjust the white balance standard data at 3200K. Press PAUSE button. Mode CAMERA Subject Clear chart Set data noted down at step 3, (Standard picture frame with the and press PAUSE button.

  • Page 58: Auto White Balance 3200K Standard Data Input 2

    DSC-P9 9. Auto White Balance 3200K Standard Data Input 2 10. Auto White Balance 3200K Standard Data Input 3 RadarW RadarW RadarW RadarW RadarW RadarW RadarW RadarW RadarW RadarW Adjust the white balance standard data at 3200K. Adjust the white balance standard data at 3200K. Mode CAMERA Mode...

  • Page 59: Auto White Balance 3200K Check

    DSC-P9 RadarW RadarW RadarW RadarW RadarW Processing after Completing Adjustment: 11. Auto White Balance 3200K Check Order Page Address Data Procedure Mode CAMERA Press PAUSE button. Subject Clear chart (Standard picture frame with the Set data noted down at step zoom lens at WIDE end) 5, and press PAUSE button.

  • Page 60: Auto White Balance 5800K Standard Data Input 1

    DSC-P9 12. Auto White Balance 5800K Standard Data Input 1 Order Page Address Data Procedure RadarW RadarW RadarW RadarW RadarW Press PAUSE button. (Note 3) Adjust the white balance standard data at 5800K. Check the data changes to “01”. Mode CAMERA Note 3: The adjustment data will be automatically input to page: Subject...

  • Page 61: Auto White Balance 5800K Standard Data Input 2

    DSC-P9 13. Auto White Balance 5800K Standard Data Input 2 14. Auto White Balance 5800K Standard Data Input 3 RadarW RadarW RadarW RadarW RadarW RadarW RadarW RadarW Adjust the white balance standard data at 5800K. Adjust the white balance standard data at 5800K. Mode CAMERA Mode...

  • Page 62: Auto White Balance 5800K Check

    DSC-P9 RadarW RadarW RadarW RadarW RadarW 15. Auto White Balance 5800K Check Order Page Address Data Procedure Mode CAMERA Check that the displayed data (Note 2) satisfied the B ratio Subject Clear chart 2 specified value. (Standard picture frame with the zoom lens at WIDE end) Processing after Completing Adjustment: Filter...

  • Page 63: Ccd Linearity Check

    DSC-P9 RadarW RadarW RadarW 16. CCD Linearity Check Processing after Completing Adjustment: Check that CCD output keeps being straight even ISO sensitivity Order Page Address Data Procedure is changed. Mode CAMERA Set data noted down at step Subject Clear chart 11, and press PAUSE button.

  • Page 64: Color Reproduction Adjustment

    DSC-P9 RadarW RadarW RadarW RadarW RadarW 17. Color Reproduction Adjustment Adjust the color separation matrix coefficient so that proper color reproduction is produced. Mode CAMERA Subject Color bar chart (Standard picture frame with the zoom lens at WIDE end) Measurement Point Video terminal of A/V OUT jack (75 Ω...

  • Page 65: Ccd White Defect Compensation

    DSC-P9 RadarW RadarW RadarW RadarW RadarW 18. CCD White Defect Compensation Mode CAMERA Subject Not required Measurement Point Displayed data of page: 6, address: 55 Measuring Instrument Adjusting remote commander Note 1: Check that the data of page: 6, address: 02 is “00”. If not, turn the power of unit OFF/ON.

  • Page 66: Ccd Black Defect Compensation

    DSC-P9 RadarW RadarW RadarW RadarW RadarW Processing after Completing Adjustment: 19. CCD Black Defect Compensation Order Page Address Data Procedure Mode CAMERA Press PAUSE button. Subject Clear chart (Standard picture frame with the zoom lens at WIDE end) Measurement Point Displayed data of page: 6, address: 55 Set data noted down at step...

  • Page 67: Strobe White Balance Adjustment

    DSC-P9 RadarW RadarW RadarW RadarW RadarW 20. Strobe White Balance Adjustment Order Page Address Data Procedure Adjust the white balance when the strobe light flashed. Check that the displayed data Mode CAMERA satisfies the Y level specified value. Subject Flash adjustment box (Note 3) Paper which reflection rate is Press PAUSE button.
  • Page 68 DSC-P9 Processing after Completing Adjustment: Order Page Address Data Procedure Press PAUSE button. Set data noted down at step 3, and press PAUSE button. Release the data setting performed at step 1. (Refer to page 5-14) 5-31...

  • Page 69: Af Illumination Check

    DSC-P9 RadarW RadarW RadarW RadarW RadarW 21. AF Illumination Check Check the deviation of optical axis of AF illuminator. Mode CAMERA Subject Flash adjustment box (Note 3) (50 cm or 1 m from the front of lens) Measurement Point Check operation on monitor TV Measuring Instrument Note 1: Perform checking by making the shooting surface of the Flash adjustment box perpendicular to the optical axis of...

  • Page 70: Lcd System Adjustments

    DSC-P9 1-5. LCD SYSTEM ADJUSTMENTS [Adjusting connector] Most of the measuring points for adjusting the LCD system are Before perform the camera system adjustments, check that the concentrated in CN706 of the SY-77 board. specified values of “VIDEO SYSTEM ADJUSTMENTS” are sat- Connect the Measuring Instruments via the CPC-9 jig (J-6082- isfied.

  • Page 71: Lcd Initial Data Input

    DSC-P9 1. LCD Initial Data Input 2. VCO Adjustment (SW-368 Board) Set the VCO free-run frequency. If deviated, the LCD screen will Mode PLAY be blurred. Signal Arbitrary Mode PLAY Adjustment Page Signal Arbitrary Adjustment Address 84, 8D Measurement Point Pin 7 of CN706 on SY-77 board (HSY) Adjusting method:...

  • Page 72: Black Limit Adjustment (Sw-368 Board)

    DSC-P9 3. Black Limit Adjustment (SW-368 Board) 4. Bright Adjustment (SW-368 Board) Set the maximum amplitude of the RGB decoder for driving the Set the amplitude of the RGB decoder for driving the LCD to the LCD to the specified value. specified value.

  • Page 73: Contrast Adjustment (Sw-368 Board)

    DSC-P9 5. Contrast Adjustment (SW-368 Board) 6. VG Center Adjustment (SW-368 Board) Set the level of the VIDEO signal for driving the LCD to the speci- Set the center of VG signal for driving the LCD to the specified fied value. value.

  • Page 74: Psig Gray Adjustment (Sw-368 Board)

    DSC-P9 7. PSIG Gray Adjustment (SW-368 Board) 8. V-COM Adjustment (SW-368 Board) Set the common electrode drive signal level of LCD to the speci- Set the DC bias of the common electrode drive signal of LCD to fied value. the specified value. If deviated, the LCD display will be move, producing flicker and Mode PLAY...

  • Page 75: White Balance Adjustment (Sw-368 Board)

    DSC-P9 9. White Balance Adjustment (SW-368 Board) Correct the white balance. If deviated, the LCD screen color cannot be reproduced. Mode PLAY Signal Arbitrary Measurement Point Check on the LCD screen Measuring Instrument Adjustment Page Adjustment Address 88, 89 Specified Value LCD screen must not be colored Note 1: Check the white balance only when replacing the fol- lowing parts.

  • Page 76: Service Mode

    DSC-P9 5-2. SERVICE MODE • Changing the address The address increases when the FF (M) button is pressed, 2-1. ADJUSTING REMOTE COMMANDER and decreases when the REW (M) button is pressed. There The adjusting remote commander is used for changing the calcu- are altogether 256 addresses, from 00 to FF.

  • Page 77: Data Process

    DSC-P9 2-2. DATA PROCESS The calculation of the adjusting remote commander display data (hexadecimal notation) are required for obtaining the adjustment data of some adjustment items. In this case, after converting the hexadecimal notation to decimal notation, calculate and convert the result to hexadecimal notation, and use it as the adjustment data.

  • Page 78: Service Mode

    DSC-P9 2-3. SERVICE MODE 3. Mode Dial Check (1) 1. Setting the Test Mode Page 2 Address 90 Page D Address 21 Data Function Data Function 00 to 14 MOVIE Normal 15 to 3D Forced MOVIE mode power ON 3E to 67 CAMERA Forced CAMERA mode power ON Using method:...

  • Page 79: Switch Check (2)

    DSC-P9 6. Switch Check (2) Page 2 Addresses 91, 92, 94 Using method: 1) Select page: 2, addresses: 91, 92 and 94. 2) By discriminating the dispaly data, the pressed key can be discriminated. Data Address 00 to 0C 0D to 27 28 to 48 49 to 73 74 to A5...

  • Page 80: Repair Parts List

    DSC-P9 SECTION 6 REPAIR PARTS LIST COVER COVER 6-1. EXPLODED VIEWS The components identified by mark 0 or dotted line with mark 0 are NOTE: critical for safety. • -XX and -X mean standardized parts, so they may • Accessories are given in the last of the electrical Replace only with part number speci- fied.

  • Page 81: Cabinet (Rear) Assembly

    DSC-P9 6-1-2. CABINET (REAR) ASSEMBLY ns: not supplied Ref. No. Part No. Description Ref. No. Part No. Description 1-477-235-11 SWITCH BLOCK, CONTROL 3-075-821-01 LCD WINDOW (1.5) 3-075-824-01 COVER, MODE DIAL 3-075-822-01 SHEET (1.5), ADHESIVE X-3952-494-1 CABINET (REAR) ASSY X-3952-492-1 CABINET (LOWER) ASSY 3-075-831-01 COVER, JACK 3-070-999-01 FOOT (UN), RUBBER 3-071-051-01 BUTTON, FUNCTION...

  • Page 82: Lens Block And Lcd Section

    DSC-P9 6-1-3. LENS BLOCK AND LCD SECTION ns: not supplied LCD901 D901 IC101 MIC901 (Note) : BT001 (BATTERY, LITHIUM SECONDARY) Board on the mount position. (See page 4-35.) (Note) Be sure to read “Precuations for Replacement of CCD Imager” on page 4-8 when changing the CCD imager. The components identified by Les composants identifiés par une mark 0 or dotted line with...

  • Page 83: Battery Holder Assembly

    DSC-P9 6-1-4. BATTERY HOLDER ASSEMBLY ns: not supplied BT901 (Note) (Note) Including the parts mounted on JK-226 board. Ref. No. Part No. Description Ref. No. Part No. Description 1-684-891-11 FP-478 FLEXIBLE BOARD 3-071-008-01 SP HOLDER 1-815-853-13 CONNECTOR, MEMORY STICK A-7078-258-A SW-368 BOARD, COMPLETE 3-075-839-01 LID, BT A-7078-257-A JK-227 BOARD, COMPLETE (Note) X-3952-491-1 HOLDER ASSY, BATTERY...

  • Page 84: Electrical Parts List

    DSC-P9 CD-397 6-2. ELECTRICAL PARTS LIST NOTE: The components identified by • Due to standardization, replacements in the • Items marked “*” are not stocked since they mark 0 or dotted line with mark parts list may be different from the parts speci- are seldom required for routine service.
  • Page 85 DSC-P9 ST-70 SW-368 Ref. No. Part No. Description Ref. No. Part No. Description A-7078-259-A ST-70 BOARD, COMPLETE C115 1-162-964-11 CERAMIC CHIP 0.001uF C116 1-125-838-11 CERAMIC CHIP 2.2uF 6.3V *********************** C117 1-125-838-11 CERAMIC CHIP 2.2uF 6.3V 1-477-329-11 FLASH UNIT C118 1-125-838-11 CERAMIC CHIP 2.2uF 6.3V C119...
  • Page 86 DSC-P9 SW-368 Ref. No. Part No. Description Ref. No. Part No. Description R006 1-216-845-11 METAL CHIP 100K 1/16W R007 1-216-818-11 METAL CHIP 1/16W R008 1-216-815-11 METAL CHIP 1/16W R009 1-216-820-11 METAL CHIP 1/16W R010 1-216-822-11 METAL CHIP 1.2K 1/16W R011 1-216-823-11 METAL CHIP 1.5K 1/16W...
  • Page 87 DSC-P9 Ref. No. Part No. Description Ref. No. Part No. Description ACCESSORIES ************ 1-476-332-11 ADAPTOR, AC (AC-LSI) (US, CND, KR, JE, J) 1-476-332-23 ADAPTOR, AC (AC-LSI) (CH) 1-476-332-43 ADAPTOR, AC (AC-LSI) (AEP, UK, E, HK) 1-569-007-11 ADAPTOR, CONVERSION (E, JE) 1-569-008-21 ADAPTOR, CONVERSION 2P (E) 1-696-819-11 CORD, POWER (AUS) 1-769-608-11 CORD, POWER (AEP, E)
  • Page 88 DSC-P9 FOR CAMERA COLOR REPRODUCTION ADJUSTMENT Take a copy of CAMERA COLOR For NTSC mode REPRODUCTION FRAME with a clear sheet for use. DSC-P9 — 113 —...
  • Page 89 DSC-P9 2002D0500-1 Sony EMCS Co. 9-929-973-31 ©2002.4 — 114 — Published by DI Customer Center...
  • Page 90 Reverse 992997331.pdf Revision History S.M. Rev. Ver. Date History Contents issued 2002.04 Official Release — —...
