- Page 1 SB-5644 HDTV Component/Digital/Audio Matrix Routing Switcher w/ IR + RS-232...
- Page 2 SAFETY INFORMATION To ensure the best results from this product, please read this manual and all other documentation before operating your equipment. Retain all documentation for future reference. Follow all instructions printed on unit chassis for proper operation. To reduce the risk of fire, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid. Make sure power outlets conform to the power requirements listed on the back of the unit.
-
Page 3: Table Of Contents
Component Matrix Switcher Series Thank you for purchasing the SB-5644 Component-Audio Matrix Switcher. You will find this unit easy to install and highly reliable but it is essential that you read this manual thoroughly before attempting to use the 4x4 Component-Audio Matrix Switcher. -
Page 4: Features & Specifications
FEATURES & SPECIFICATIONS FEATURES • Supports (4) Inputs to (4) Outputs Component Video (YPBPR) Matrix Switcher • Input/Output signals via Component Video (YPBPR), Digital (PCM), Stereo Audio (AR/AL) • Higher video bandwidth 325MB each signal path • Supports HDTV high definition resolutions 480p, 576i/p, 720p, 1080i/1080p •... -
Page 5: Front Panel
If the input signals to the SB-5644 are appropriate, switch the power switch to <ON> and you should see and hear the signals on the devices you have connected to the various output connectors of the SB-5644. -
Page 6: Back Panel
Please study the panel drawings and become familiar with the signal input-output, power requirements plus any controls present. Before using the SB-5644, please take the time to make certain that the device you wish to connect to its inputs is functioning properly in all respects. -
Page 7: Remote Control
REMOTE CONTROL Before making any connections observe the following: • Ensure the main voltage supply matches the label on the supplied plug-pack (+/-10%). • Ensure that the power switch is OFF. • Ensure that all system grounds (earth) are connected to a common point. •... -
Page 8: Rs-232 Serial Interface
RS-232 SERIAL INTERFACE RS-232 SERIAL INTERFACE CONNECT a PC or CONTROL SYSTEM RS-232 SERIAL CONNECT RS-232 The switcher can be controlled via the RS-232 serial control port to allow for Pin RS-232 Definition interfacing to a PC or similar third party control system. ------ Not used Transmitter... -
Page 9: Rs-232 Protocol Commands
RS-232 SERIAL COMMANDS MORE STUFF FOR SB-5644 Note: Turning the unit system power off over RS-232 will distinguish the LED display leaving only the power switch LED on. The video and audio outputs will also mute. While the unit is turned off by RS-232 it will continue to accept and act upon switching commands. -
Page 10: Typical Hook-Up & Operation
COMPONENT VIDEO - Component Video (YPBPR), connector with RCA DIGITAL - Digital Audio (PCB), connector with RCA AUDIO - Stereo Audio (AR/AL), connector with RCA SB-5644 SUPPORTS (4) COMPONENT INPUTS MATRIXED TO (4) SWITCH OUTPUTS. SUPPORTS IR & RS-232 INTERFACE CONTROL SYSTEM PORTS. - Page 11 LIMITED WARRANTY PLEASE READ THE FOLLOWING TERMS AND CONDITIONS CAREFULLY BEFORE USING THIS HARDWARE, COMPONENTS AND SOFTWARE PROVIDED BY, THROUGH OR UNDER SHINYBOWUSA, INC (COLLECTIVELY, THE “PRODUCT”). By using or installing the product, you unconditionally signify your agreement to these Terms and Conditions. If you do not agree to these Terms and Conditions, do not use the product and return the product to SHINYBOWUSA, Inc.
