Replacement Parts And Adjustment Items; Adjustment Tools; Operation Inspection - Samsung Digimax 230 Manual

Ⅲ . . A A D D J J U U S S T T M Ⅲ
1 1 . . R R e e p p l l a a c c e e m m e e n n t t P P a a r r t t s s a a n n d d A A d d j j u u s s t t m m e e n n t t I I t t e e m m s s
Digimax 230 requires electrical adjustments when certain parts are replaced.
The table below indicates the adjustments required for the respective part replacements.
Main board
Power board
Top board
CCD F PCB
Barrel ass'y
TFT LCD
※ When Main board is replaced, adjust certainly at the procedure as below.
AE Adjustment → AWB Adjustment → AF Adjustment → Flash Adjustment
2 2 . . A A d d j j u u s s t t m m e e n n t t T T o o o o l l s s
The following tools are required for electrical adjustment.
Program
Equipment
Chart
▶ Program
Please contact to our website (www.ssa.net) and download the each programs.
▶ Equipment
- Light source box : Adjust AE at LV 12 and check at LV 15.
- AWB light box : Adjust AWB at Daylight/Fluorescen/Tungsten position.
▶ Chart
- AF chart : Please contact to our website (www.ssa.net) and print the AF Chart on the A3 size
paper from the "AFCHART.pdf "
- Gray chart : Standard 31% Gray Chart.
3 3 . . O O p p e e r r a a t t i i o o n n I I n n s s p p e e c c t t i i o o n n
a. Contact to our website www.ssa.net.
b. Connect the card reader to PC and format the CF card.(Please use the CF card unber the 16MB.)
c. Download the program[sktest03.bin] to CF card.
※ It will be changed the file name after downloading, please rename to the sktest03.bin.
d. Set the mode dial to PC mode.
e. Turn on the power of the camera after inserting the CF card.
It will be inspect every function of a camera as below sequence.
WIDE SHOT(FLASH OFF) → MACRO SHOT → NORMAL SHOT(FLASH OFF) → TELE SHOT(FLASH OFF)
→ WIDESHOT(FLASH ON) → SINGLE SHOT→ VOICE REC. → MOVE CLIP → SLIDE SHOW → DELET
M E E N N T T
AF
Adjustment Adjustment
③
X
X
③
③
X
AF AE
Adjustment Adjustment
sktest09.bin sktest03.bin
Light source box AWB light box
(LV12,15)
AF Charrt
AE AWB
Adjustment
① ②
X X
X X
① ②
① ②
X X
AWB
Adjustment
sktest05.bin
Daylight
Fluorescen
Tungsten
16
Flash Operation
Adjustment Inspection
④
X
X
④
④
X
Flash Operation
Adjustment Inspection
sktest06.bin sktest16.bin
AC Adaptor
Gray reflection
chart(31%).
●
●
●
●
●
●
