Please follow the installation steps below to set up your B5110 Outdoor 15M IR IP Camera.
Check the package contents against the list below. See P.1
Physical overview. See P.1
Install the hardware and connect all cables. See P.2
Use the software CD to install Intelligent IP Installer.
Access to Internet via Static IP, Dynamic IP or both. See P.8
For more information, please check the User Manual available in the Software CD or you can download the latest
software from
http://www.zavio.com
Package Contents
Camera
Quick Installation Guide
Software CD
Mounting Bracket
Adaptor
Physical overview
Reset: When the device is empowered, press the Reset Button to reboot the device, or hold the Reset Button for 10
seconds to set the settings back to factory default.
Zavio B5110 Quick Installation Guide
B5110 Outdoor 15M IR IP Camera
Brief product information and quick installation
IP Surveillance Software
Intelligent IP Installer
User Manuals
Language Packs
Three screws, Lock ring, Brace, and Base plate
12V DC, max 6W
Infrared LEDs
IR Houisng
Audio In
Network Connector
Video Out
See P.2
1
Alarm Out
Alarm In
I/O Terminal Block
Reset button
Audio Out
12V Power
