Summary of Contents for Halex Q-3200
- Page 1 Halex 3200-Q Electronic Dartboard Q-3200 ELECTRONIC DARTBOARD With Wood Cabinet Owner’s Manual & Game Instructions...
-
Page 2: Limited 1-Year Warranty
Halex 3200-Q Electronic Dartboard LIMITED-1 YEAR WARRANTY This Halex product is warranted to be free from defects in workmanship or materials at the time of purchase for a period of 1 (one) year. Should any evidence of defects appear within the limited warranty period after the date of purchase, Regent Sports will either send replacement parts or advise another course of action. - Page 3 Halex 3200-Q Electronic Dartboard Setup / Mounting Instructions Choose a location to hang the dartboard where there is about 10 feet of open space in front of the board. The “toe-line” should be 7’ 9 1/4” from the face of the dartboard. Since this dartboard can be powered with the included AC adapter, you may want to mount it close to an electric outlet for convenience.
- Page 4 Halex 3200-Q Electronic Dartboard Dartboard Functions (see page 23 for diagram) POWER button - Located on the lower right corner on the side of the dartboard. Be sure the AC Adapter is plugged into the jack on the right side of the dartboard. Press the POWER switch to turn game on or off.
- Page 5 Halex 3200-Q Electronic Dartboard GAME button - Press to page through the on-screen game menu and select game. QuickPick buttons – These four game buttons launch you directly into the indicated games (See page 7 for instructions). RESET button – Press to clear display and reset dartboard to opening sound.
- Page 6 Halex 3200-Q Electronic Dartboard ™ CyberMatch Feature This exciting feature allows single player to play against the computer at one of five different levels of skill! Only 1 player can compete against the CyberMatch competitor at a time. The CyberMatch feature adds a level of competition to normally routine practice sessions.
- Page 7 Halex 3200-Q Electronic Dartboard ™ QuickPick Game Buttons These buttons launch you directly into the game indicated below the button. With the large selection of available games included in this dartboard, these buttons are a convenient way to jump directly into a game. The default setting is for 2 players. The following games have been set up for QuickPick: •...
-
Page 8: Game Rules
Halex 3200-Q Electronic Dartboard Caring for your Electronic Dartboard Never use metal tipped darts on this dartboard. Metal tipped darts will seriously damage the circuitry and electronic operation of this dartboard. Do not use excessive force when throwing darts. Throwing darts too hard will cause frequent tip breakage and cause excess wear on the board. - Page 9 Halex 3200-Q Electronic Dartboard Dart-Out Feature (“01” games only) This electronic dartboard has a special “Dart Out” feature. When a player requires less than 160 to reach zero, the estimate feature becomes active. The player can press the DART OUT button to view the darts necessary to throw to finish the game (reach zero exactly).
- Page 10 Halex 3200-Q Electronic Dartboard No-Score Cricket (Press SELECT button when Cricket is displayed) Same rules as standard Cricket except there is no point scoring. The object of this version is to be the first to simply “close” all the appropriate numbers (15 through 20 and the bullseye).
- Page 11 Halex 3200-Q Electronic Dartboard Only those points over 40 are counted toward the cumulative score. Player 1 must also exhibit precision dart throwing and avoid hitting any bullseyes during this first round because any hits scored by player 1 in the bullseye area will be subtracted from player 2’s needed total of 9 bullseyes.
- Page 12 Halex 3200-Q Electronic Dartboard will lose one life. When a player “equals” the previous three dart total, a life will also be lost. The LED screen on the right will light up once for each life taken away. The last player with...
- Page 13 Halex 3200-Q Electronic Dartboard Unders (G10) This game is the opposite of “Overs” Players must score less (“Under”) than their own previous three-dart total. The game begins with 180 (highest total possible) when the player shoots higher than his or her own previous three-dart total, they will lose a life. Each dart that hits outside the scoring area, including bounce outs will be penalized with 6o points added to your score.
- Page 14 Halex 3200-Q Electronic Dartboard Since this game does not utilize point scoring, the double and triple rings count as single numbers. ROUND-THE-CLOCK Double - Player must score a Double in each segment from 1 through 20 in order. ROUND-THE-CLOCK Double 5 - Game starts at double segment 5 •...
- Page 15 Halex 3200-Q Electronic Dartboard 15 16 D 17 18 19 20 B TOTAL Player 1 Player 2 Any Double Any Triple Forty One (G16) This game follows similar rules as standard Double Down as described above with two exceptions. First, instead of going from 15 through 20 and bullseye, the sequence is reversed which will be indicated on the LED display.
- Page 16 Halex 3200-Q Electronic Dartboard Shanghai (G18) Each player must progress around the board from 1 through 20 in order. Players start at number 1 and throw 3 darts. The object is to score the most points possible in each round of 3 darts.
- Page 17 Halex 3200-Q Electronic Dartboard Double 20 ... Outer Single 20 ... Triple 20 ... Inner Single 20 ... Outer Bullseye ... Inner Bullseye ... Outer Bullseye ... Inner Single 3 ... Triple 3 ... Outer Single 3 ... and finally a Double 3.
- Page 18 Halex 3200-Q Electronic Dartboard The object of the game is to “Eliminate” your opponents. The rules are very simple. Each player must score higher total points with 3 darts than the opponent before them. Each player starts with 3 lives. If the player fails to score higher total points than the previous opponents score, they lose one life.
- Page 19 Halex 3200-Q Electronic Dartboard Adjustable difficulty settings are as follows: BATTLEGROUND DOUBLES: • Players shoot for double segments only to eliminate opponent’s armies BATTLEGROUND TRIPLES: • Players shoot for triple segments only to eliminate opponent’s armies BATTLEGROUND with GENERALS This variation of the game includes one more obstacle to accomplish to win the game.
- Page 20 Halex 3200-Q Electronic Dartboard BATTLEGROUND SCOREBOARD Army Player 1’s Player 2’s Army The top cricket scoring display on the dartboard shows player 1’s army segments. Player 2’s army segments are in the second row. Each time a segment is hit, the corresponding light will shut off.
- Page 21 Halex 3200-Q Electronic Dartboard ADVANCED BATTLEGROUND The rules are the same as standard Battleground except now there are land mines on the battlefield! Players must be careful to avoid the land mines located in the Triple and Double rings of opponents segment numbers.
- Page 22 Halex 3200-Q Electronic Dartboard 301 – 901 ⊕ ⊕ Cricket * ⊕ ⊕ Scram Cut-Throat Cricket English Cricket Advanced Cricket Shooter ⊕ ⊕ Big Six ⊕ ⊕ Overs ⊕ ⊕ Unders ⊕ ⊕ Count-Up ⊕ ⊕ High Score ⊕ ⊕...
-
Page 23: Important Notes
Cleaning your Electronic Dartboard Your Halex electronic dartboard will provide many hours of competition if cared for properly. Regular dusting of the cabinet is recommended using a damp cloth. A mild detergent can be used if necessary. - Page 24 Halex 3200-Q Electronic Dartboard Player Indicator Singles Ring Scoring Displays 10. Triples ring Hold, Double In/Out, 11. Built-in Dart Holders Master Out indicators 12. Adapter Jack (on side) Active Score Display 13. Start/Hold Button Built-in Speakers 14. Quick Pick Buttons Doubles Ring 15.
-
Page 25: Accessories/Spare Parts
$ 7.95 Prices include shipping and handling. To place order: MasterCard/Visa You can place your order on our website at www.regent-halex.com Mail Make check payable to: Regent Sports Corporation and send to the following address: 45 Ranick Road Hauppauge, NY 11788 Attn: Customer Service Please do not send cash. - Page 26 Halex 3200-Q Electronic Dartboard...
