Summary of Contents for Chauvet Rogue R1 Beam
- Page 1 User Manual...
- Page 2 Copyright Notice CHAUVET® owns the content of this User Manual in its entirety, including but not limited to pictures, logos, trademarks, and resources. © Copyright 2014 CHAUVET®. All rights reserved.
-
Page 3: Table Of Contents
Table of Contents Table of Contents 1. Before You Begin ............................1 What Is Included ................................1 Claims ......................................1 Manual Conventions ..................................1 Symbols ....................................... 1 Product At A Glance ..............................2 Safety Notes ................................. 2 Personal Safety .................................... 2 Mounting And Rigging .................................. - Page 4 Table of Contents Pan and Tilt Movement BlackOut ............................... 17 Color Movement BlackOut ................................. 17 Gobo Movement BlackOut ................................. 17 Lamp Settings .................................... 18 Maintenance Timer ..................................19 Reset Function ................................... 19 Factory Reset Function ................................19 System Information ..............................20 Offset Mode ................................
-
Page 5: Before You Begin
If the box or the contents (the product and included accessories) appear damaged from shipping or show signs of mishandling, notify the carrier immediately, not CHAUVET®. Failure to report damage to the carrier immediately may invalidate your claim. In addition, keep the box and contents for inspection. -
Page 6: Product At A Glance
This product contains no user-serviceable parts. Any reference to servicing in this User Manual will only apply to properly trained CHAUVET® certified technicians. Do not open the housing or attempt any repairs. -
Page 7: Introduction
Introduction 2. I NTRODUCTION The Rogue™ R1 Beam is a compact, electronic, moving yoke beam product equipped with a Description 132-watt HRI lamp. It includes a color wheel with 14 colors plus white. It also includes 2 separate 5- and 8-facet rotating prisms, remote focus, and one gobo wheel with 17 static gobos plus open. ·... -
Page 8: Overview
Introduction Overview Fuse Power Switch DMX In Data In Data Power In Control Panel Front View Rear View Handle Top View Side View Rogue™ R1 Beam User Manual Rev. 2... -
Page 9: Dimensions
Introduction 14.17 in Dimensions 360 mm 13.39 in 340 mm 8.27 in 210 mm 7.52 in 191 mm 11.10 in 282 mm 10.87 in 276 mm 11.26 in 286 mm 17.52 in 445 mm 4.53 in 115 mm Rogue™ R1 Beam User Manual Rev. 2... -
Page 10: Setup
The listed current rating indicates the maximum current draw during normal operation. For more information, you may download Sizing Circuit Breakers from the CHAUVET® website: www.chauvetlighting.com/download/pro. Always connect this product to a protected circuit with an appropriate electrical ground to avoid the risk of electrocution or fire. -
Page 11: Gobo Wheel
Setup The Rogue™ R1 Beam includes one gobo wheel with 17 fixed gobos plus open. The diagram Gobo Wheel shows the gobo number on the wheel, as numbered in the DMX Values tables. Open The Rogue™ R1 Beam includes one color wheel with 14 fixed colors plus open (white), as Color Wheel indicated below. -
Page 12: Lamp Replacement
Setup The Rogue™ R1 Beam is equipped with an Osram Sirius 132-W lamp. Follow the Lamp Replacement procedure below to safely change the lamp. Disconnect the product from power before opening. Procedure 1. Turn the product off and disconnect it from power. Wait at least 15 minutes for the lamp to cool down. -
Page 13: Procedure (Cont.)
Setup Procedure 4. Remove the 2 Phillips-head screws on the sides of the fan assembly. (Cont.) 5. Roll the fan assembly to the right to expose the lamp. 6. Using the lamp base, push the lamp down against the spring clips located on the bottom, then roll the lamp out the top. -
Page 14: Increasing The Lamp's Life
· DO NOT power cycle the product unless it is necessary. · DO NOT re-strike the lamp immediately after turning it off. CHAUVET® recommends waiting 5 minutes before trying to re-strike the lamp. -
Page 15: Mounting
2 included omega brackets. Make sure the clamps (such as CLP-15 from CHAUVET®) are capable of supporting the weight of this product. Use two mounting points per product. In addition, use a safety cable to link the product to the structure. -
Page 16: Operation
Operation 4. O PERATION Control Panel Button Function Description <MENU> Exits from the current menu or function <ENTER> Enables the currently displayed menu or sets the currently selected value in to the current function <UP> Navigates upward through the menu list or increases the numeric value when in a function <DOWN>... -
Page 17: Menu Map
Operation Menu Map Main Level Programming Levels Description Address 001–512 Sets the DMX starting address 15CH Selects the DMX mode 19CH Auto Test Runs the product’s test sequence Pan Fine Tilt Tilt Fine P/T Speed Dimmer Dimmer Fine Shutter Run Mode Color Allows manual control of all settings from the Gobo... -
Page 18: Menu Map (Cont.)
Operation Menu Map (Cont.) Main Level Programming Levels Description Reverse pan operation Pan Reverse Normal pan operation Reverse tilt operation Tilt Reverse Normal tilt operation Rotates control screen view 180° Screen Reverse Normal control screen view Selects the 540° pan angle range Pan Angle Selects the 360°... -
Page 19: Menu Map (Cont.)
Operation Menu Map (Cont.) Main Level Programming Levels Description Defines amount of hours between Interval 10–250 maintenance Maintenance Shows amount of time remaining in Timer Remaining maintenance cycle Time RESET Resets the time back to the beginning Pan/Tilt Resets pan/tilt functions to the home position Prism Resets all prism functions to the home position Setup... -
Page 20: Address
Operation This programming level sets the DMX starting address. Address · Starting from the Main Level screen, select Address, press <ENTER>. Set the In this mode, each product will respond to a unique starting address from the DMX controller. All products with the same starting address will respond in unison. This option DMX Address sets the products DMX address. -
Page 21: Setup
Operation This programming level controls the product’s head movement, lamp adjustments, and Setup maintenance timer. · Starting from the Main Level screen, select Setup, press <ENTER>. Reverses the operation of the pan attribute. Pan Reverse 1. Highlight Pan Reverse, press <ENTER>. 2. -
Page 22: Lamp Settings
· DO NOT power cycle the product unless it is necessary. · DO NOT re-strike the lamp immediately after turning it off. CHAUVET® recommends waiting 5 minutes before trying to re-strike the lamp. -
Page 23: Maintenance Timer
Operation Maintenance This programming level allows the user to change a range of options that control the action of the maintenance timer. Timer · Starting from the Setup screen level, select Maintenance Timer, press <ENTER>. Maintenance Timer This option defines the amount of time (hours) that the maintenance timer will count down to. Interval 1. -
Page 24: System Information
Operation This programming level shows standard information regarding the product’s operating status. System · Starting from the Main Level screen, select Sys Info, press <ENTER>. Information · Ver: The current software version is displayed on the screen. · Running Mode: The current Running mode is displayed on the screen. ·... -
Page 25: Dmx Values
Operation DMX Values 19CH Channel Function Value Percent/Setting 000ó255 0–100% Fine Pan 000ó255 0–100% Tilt 000ó255 0–100% Fine Tilt 000ó255 0–100% Pan/Tilt Speed 000ó255 0–100% Dimmer 000ó255 0–100% Fine Dimmer 000ó255 0–100% 000ó007 Closed 008ó015 Open 016ó131 Slow to fast 132ó167 Fast close, slow open (slow to fast) Shutter... -
Page 26: Dmx Values (Cont.)
Operation DMX Values (Cont.) 19CH Channel Function Value Percent/Setting (Cont.) 000ó003 Open 004ó006 Gobo 1 007ó009 Gobo 2 010ó012 Gobo 3 013ó015 Gobo 4 016ó018 Gobo 5 019ó021 Gobo 6 022ó024 Gobo 7 025ó027 Gobo 8 028ó030 Gobo 9 031ó033 Gobo 10 Gobo Wheel 034ó036... -
Page 27: Dmx Values (Cont.)
Operation DMX Values (Cont.) 19CH Channel Function Value Percent/Setting (Cont.) 000ó007 No function 008ó015 Effect 1 016ó023 Effect 2 024ó031 Effect 3 032ó039 Effect 4 040ó047 Effect 5 048ó055 Effect 6 056ó063 Effect 7 064ó071 Effect 8 072ó079 Effect 9 080ó087 Effect 10 088ó095... -
Page 28: Dmx Values (Cont.)
Operation DMX Values (Cont.) 19CH Channel Function Value Percent/Setting (Cont.) Movement Macro 000ó255 0–100% Speed 000ó029 No function 030ó039 Dimmer conventional mode 040ó049 Dimmer linear mode 050ó059 Pan/Tilt fast mode 060ó069 Pan/Tilt normal mode 070ó079 Blackout during pan/tilt (3 sec hold) 080ó089 Disable pan/tilt blackout (3 sec hold) 090ó099... -
Page 29: Dmx Values (Cont.)
Operation DMX Values (Cont.) 15CH Channel Function Value Percent/Setting (Cont.) 000ó004 Open (white) 005ó008 Red (1) 009ó012 Deep yellow (2) 013ó016 Turquoise (3) 017ó020 Green (4) 021ó024 Light green (5) 025ó028 Light purple (6) 029ó032 Pink (7) 033ó036 Light yellow (8) Color Wheel 037ó040 Magenta (9) -
Page 30: Dmx Values (Cont.)
Operation DMX Values (Cont.) 15CH Channel Function Value Percent/Setting (Cont.) 000ó004 No function Prism 2 005ó255 Prism insert 000ó127 Prism index 128ó189 Counter-clockwise rotation, fast to slow Prism 2 Rotate 190ó193 Stop 194ó255 Clockwise rotation, slow to fast Focus 000ó255 0–100% 000ó029 No function 030ó039... -
Page 31: Technical Information
Technical Information 5. T ECHNICAL NFORMATION To maintain optimum performance and minimize wear, you should clean this product Product frequently. Usage and environment are contributing factors in determining the cleaning Maintenance frequency. As a rule, clean this product at least twice a month. Dust build-up reduces light output performance and can cause overheating. -
Page 32: Technical Specifications
Technical Information 6. T ECHNICAL PECIFICATIONS Dimensions and Length Width Height Weight Weight 11.1 in (282 mm) 14.2 in (360 mm) 17.5 in (445 mm) 38.8 lb (17.6 kg) Note: Dimensions in inches rounded to the nearest decimal digit. Power Power Supply Type Range Voltage Selection... -
Page 33: Returns
Be prepared to provide the model number, serial number, and a brief description of the cause(s) for the return. Clearly label the package with an RMA number. CHAUVET® will refuse any product returned without an RMA number.
