PROPANE CONStRuCtION CONVECtION HEAtER
IMPORTANT: Read and understand this manual before
assembling, starting or servicing heater. Improper use
of heater can cause serious injury. Keep this manual for
future reference.
GENERAL HAZARD WARNING:
Failure to comply with the precautions and instructions
provided with this heater, can result in death, serious
bodily injury and property loss or damage from hazards
of fire, explosion, burn, asphyxiation, carbon monoxide
poisoning and/or electrical shock.
Only persons who can understand and follow the instruc-
tions should use or service this heater.
If you need assistance or heater information such as an in-
structions manual, labels, etc. contact the manufacturer.
Safety Informa ion ............................................... 2
Unpacking............................................................ 3
Theory of Operation............................................. 3
Product Identification ........................................... 3
Ventilation ........................................................... 3
Propane Supply ................................................... 4
Installation ........................................................... 4
Operation ............................................................. 5
Storage ................................................................ 7
OWNER'S MANuAL
VARIABLE 40-80,000 Btu/HR
75-200,000 Btu/HR
tABLE OF CONtENtS
Save this manual for future reference.
For more information, visit www.desatech.com
Maintenance ........................................................ 7
Troubleshooting ................................................... 8
Specifications ...................................................... 9
Replacement Parts .............................................. 9
Technical Services ............................................... 9
Accessories ......................................................... 9
Illustrated Parts Breakdown and Parts List........ 10
Warranty and Repair Service ............................ 14
Advertisement
Table of Contents
Related Manuals for Desa TC106
Summary of Contents for Desa TC106
-
Page 1: Table Of Contents
PROPANE CONStRuCtION CONVECtION HEAtER OWNER’S MANuAL VARIABLE 40-80,000 Btu/HR 75-200,000 Btu/HR IMPORTANT: Read and understand this manual before assembling, starting or servicing heater. Improper use of heater can cause serious injury. Keep this manual for future reference. GENERAL HAZARD WARNING: Failure to comply with the precautions and instructions provided with this heater, can result in death, serious bodily injury and property loss or damage from hazards... -
Page 2: Safety Informa Ion
SAFEty INFORMAtION Propane gas is odorless. An Propane Gas: odor-making agent is added to propane gas. The odor helps you detect a propane gas WARNING: This product leak. However, the odor added to propane contains and/or generates gas may fade. Propane gas may be present chemicals known to the State even though no odor exists. -
Page 3: Unpacking
SAFEty INFORMAtION PROduCt Continued IdENtIFICAtION 15. Check hose before each use of heater. If highly worn or cut, replace with hose speci- Outer fied by manufacturer before using heater. Shell 16. Do not alter heater. Keep heater in its original state. 17. -
Page 4: Propane Supply
PROPANE SuPPLy down position. Protect hands before lifting outer shell. Never grasp bare metal without You must provide propane gas and propane hand protection. tank(s). 1. Care must be taken to protect hands dur- Use this heater only with a propane vapor ing this step. -
Page 5: Operation
INStALLAtION OPERAtION Continued WARNING: Review and un- 4. Open propane supply valve on propane derstand the warnings in the tank(s) slowly. Note: If not opened slowly, Safety Information section, page excess-flow check valve on propane tank 2. They are needed to safely op- may stop gas flow. - Page 6 OPERAtION Continued 8. When burner remains lit, set heater at the desired heat level by slightly depressing Yellow the control knob and turning it counter- Flame clockwise to the MED or HI settings (see Figure 5, page 5). 9. If burner goes out, turn off gas. Slightly de- Blue Flame press and turn control knob fully clockwise...
-
Page 7: Storage
OPERAtION StORAgE Continued CAuTION: Disconnect heater 200,000 bTu/HR HEATER from propane supply tank(s). TO START HEATER 1. Before lighting pilot fully close the ball CAuTION: be careful not to valve (turn knob fully clockwise). locate fingers in groves on side 2. -
Page 8: Troubleshooting
tROuBLESHOOtINg WARNING: Never service heater while it is plugged in, connected to propane supply, operating or hot. Severe burns and electrical shock can occur. ObSERvED FAuLT REMEDy POSSIbLE CAuSE Burner fails to light 1. Open propane supply valve 1. Propane supply valve slowly closed on propane tank(s) 2. -
Page 9: Specifications
• Fuel Orifice Port Size: 0.032" (0.813 mm) REPLACEMENt PARtS tECHNICAL SERVICES You may have further questions about WARNING: use only original this heater. If so, contact DESA Heating replacement parts. This heater Products’ Technical Service Department at 1-866-672-6040. When calling, please must use design-specific parts. -
Page 10: Illustrated Parts Breakdown And Parts List
ILLuStRAtEd PARtS BREAkdOWN MODELS TC106, TC112, TC113, TC114 AND TC115 www.desatech.com 119588-01A... - Page 11 PARtS LISt MODELS TC106, TC112, TC113, TC114 AND TC115 This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 9 of this manual. NO. PART NO. DESCRIPTION qTy. 113785-01 Cap...
- Page 12 ILLuStRAtEd PARtS BREAkdOWN MODELS 200C, RCP200v(A), SPC-200C, TC107 AND TC200v(A) www.desatech.com 119588-01A...
- Page 13 PARtS LISt MODELS 200C, RCP200v(A), SPC-200C, TC107 AND TC200v(A) This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 9 of this manual. NO. PART NO. DESCRIPTION qTy. 113814-01 Pilot Assembly 113835-01 Hose/Regulator Assembly 113777-01 Burner Ring Assembly 113778-01 Ring Shield...
-
Page 14: Warranty And Repair Service
LIMItEd WARRANtIES FOR NEW ANd FACtORy RECONdItIONEd PROduCtS New Products: DESA Heating Products warrants this heater and any parts thereof, to be free of de- fects in materials and workmanship for one (1) year from the date of first purchase, when operated and maintained in accordance with the manufacturer's instructions.
