T77DVTS/BK/GR/TN
7" CAR HEADREST
Notice to Customers
TOUCH SCREEN MULTI-MEDIA PLAYER
This unit is manufactured with precision
elements.
Pay attention to protection against dam-
pness.
Prevent the hard object from scratching
LCD suface.
LCD may have a few color dots,which is
common for the matrix display technol-
ogy,and doesn,t indicates defects of fault.
Touch Screen
Touch Screen
Dual Side
Dual Side
DVD Player
DVD Player
HEADREST DVD PLAYER
Advertisement
Table of Contents
Related Manuals for Tview T77DVTS
Summary of Contents for Tview T77DVTS
- Page 1 T77DVTS/BK/GR/TN 7" CAR HEADREST Notice to Customers TOUCH SCREEN MULTI-MEDIA PLAYER This unit is manufactured with precision elements. Pay attention to protection against dam- pness. Prevent the hard object from scratching LCD suface. LCD may have a few color dots,which is common for the matrix display technol- ogy,and doesn,t indicates defects of fault.
-
Page 2: Notice Before Operation
Notice before operation Safety Before operating the product,please check the voltage of your car and it should be consistent with the working voltage of the player. Do grasp the powerplug firmly in connecting or disconnecting to the power,do not pull the power line by force. The radium emitting light beam used by the product is harmful to eyes,do not permission and only the professional technicians dismantle the enclosure without... - Page 3 FEATURES -Screen Size: 7 Inch Digital panel -Display Profile Ratio: 16:9 -System: PAL/NTSC -Built-in: USB/SD/FM/IR/DVD -Built in dual channel IR transmitter Channel A:2.3MHZ(Left),2.8mhz(Right) Channel B:3.2MHZ (Left),3.8mhz(Right) -Operating Temperature: -20C To 50C -Storage Temperature: -10C~+70C -Display Method: TFT Color LCD -Resolution(HxV): 480x234 -Disc Format: MP3/DVD/VCD/CD/SVCD/CD-R/...
-
Page 4: Functions Of Keys
Functions of keys Basic description Press display key for the first time,the lcd shall display:DVD (state) (1) Disk for mat,current title number and total title number; (2) The current chapter and total title number; (3) The playing of current title. Title Chapter 1/29 00:00:12... -
Page 5: Basic Operations
Functions of keys Basic operations Power ON/OFF Basic description 1. Press the Power key and the indicator shall be turned on,after the screen appearance the player will begin read Power ON/OFF,press the “Power” key of the panel to turn ON/OFF the player,the power key Power key the disk,if no disk inside,the lcd will appear”no disk”. - Page 6 The operation of MP3 disk is same with playing mp4 disk,MP4 disk has video image and auto play is the Default setup for this player ,press stop/return key to return to the menu to facilitate the user to select the Menu. TVIEW CAR VIDEO AUTO VIDEO ACCESSORIES...
