- Page 1 W.MACHINE/WASHER-DRYER 31001354 HNL7126-80 Service Manual...
- Page 6 31001354 HNL7126-80 0615 (12/04/2006) Ricambio Inizio Fine Part No. Beginning Ending Piece Debut E-Teil Begin Ref. Descrizione - Description - Beschreibung - Descripcion Pieza Inicio Timer/select. knob 09200509 Timer knob support 41009496 Knob 97923599 Cam disc 03850313 Control panel 40004331...
- Page 7 31001354 HNL7126-80 0615 (12/04/2006) Ricambio Inizio Fine Part No. Beginning Ending Piece Debut E-Teil Begin Ref. Descrizione - Description - Beschreibung - Descripcion Pieza Inicio Hose clip 92470020 Hose 41013620 Hose clip 92470012 Solenoid valve 41013615 Drain hose 92693373 138a...
- Page 8 31001354 HNL7126-80 0615 (12/04/2006) Ricambio Inizio Fine Part No. Beginning Ending Piece Debut E-Teil Begin Ref. Descrizione - Description - Beschreibung - Descripcion Pieza Inicio 225a Gasket 92445626 Tub gasket clip 91750458 230a Tub gasket clip 90488603 Heater holder 97910301 Support spring.
- Page 9 31001354 HNL7126-80 0615 (12/04/2006) Ricambio Inizio Fine Part No. Beginning Ending Piece Debut E-Teil Begin Ref. Descrizione - Description - Beschreibung - Descripcion Pieza Inicio Circlip 91941775 Plug 09086935 Clip 92470038 Commutator motor 41002725 479i Coreboard 32K programmed 09200764 479m...
- Page 10 31001354 HNL7126-80 0615 (12/04/2006) - Modifications History - Ricambio Inizio Fine Part No. Beginning Ending Piece Debut E-Teil Begin Ref. Descrizione - Description - Beschreibung - Descripcion Pieza Inicio NEW TUB 97920615 0627 (03/07/2006) 40004248 0627 (03/07/2006) 204a Front flange...
-
Page 11: Wiring Diagram
2006 Nextra Washing Machines WIRING DIAGRAM WHITE GREEN BLUE BLUE GREEN YELLOW WHITE WHITE BLUE BLACK BLUE BLACK GREEN GREEN GREEN YELLOW BLUE BROWN BROWN BLUE BLUE 40002880 - COLD VALVE (2 POTS) © PAGE 12 2006 GIAS U.K. / Hoover Ltd. -
Page 12: Circuit Diagram
2006 Nextra Washing Machines CIRCUIT DIAGRAM © PAGE 13 2006 GIAS U.K. / Hoover Ltd. - Page 13 Legenda componenti lavaggio - Washing components list Liste composantes lavage - Waschung komponenten liste Leyenda componentes lavado – Yıkayıcılar parça listesi Versione 22/04/2009 Centrifuga lenta - Slow speed spin - Essorage lent - Langsame Zentrifuge - Centrifugado bajo – Dü ük hızda sıkma Centrifuga veloce - Fast speed spin - Essorage vite - Schnelle Zentrifuge - Centrifugado rapido –...
- Page 14 DT Dinamo tachimetrica - Tachometric dynamo - Bobine tachymetrique - Regel Dynamo - Dinamo taquimetrica – Takometrik dinamo EA Elettrovalvola asciugatura - Drying solenoid valve - Electrovanne sechage - Trochen - Elektroventil - Electrovalvula secado – Kurutucu solenoid valfi EC Elettrovalvola acqua calda - Solenoid valve for hot water - Electrovanne eau chaude - Warmes Wasser Elektroventil - Electrovalvula agua caliente –...
- Page 15 GT Morsetto generale di terra - Earth connection - Serre cable de sol - Erdklemme - Toma general tierra – Topraklama ba lantısı GV Morsetto messa a terra vasca - Tub earth connection - Serre cable de sol cuve - Waschbottich Erdklemme - Toma tierra cuba L1 Lampada spia alimentazione elettrica - Net pilot lamp - Lampe temoin - Kontrollampe - Piloto alimentacion electrica –...
- Page 16 MD Motore centrifuga - Spin motor - Moteur essorage - Schleuderung Motor - Motor secado – sıkma motoru ML Motore lavaggio - Washing motor - Moteur lavage - Waschung motor - Motor lavado – Yıkama motoru MP Elettropompa di scarico - Discharge electric pump - Pompe de vidange - Auslauf pumpe - Electrobomba vaciado –...
- Page 17 Potenziometro velocità centrifuga - Potentiometer adj spin speed - Potentiometre vitesse essorage - Schleuderung geschwindigkeit potentiometer - Potenciometro velocidad centrifugado – Sıkma hızı ayar potansiyometresi PV Pressostato variabile - Adjustable pressure switch - Pressostat variable - Varierbarer pressostat - Presostato variable – Ayarlanabilir basınç alteri RA Resistenza asciugatura - Drying heating element - Resistance sechage - Trockenheizung - Resistencia secado –...
- Page 18 Resistenza con consenso termostato - Heater with thermostatic consent - Resistan ce avec consentement thermostatique - Heizung mit Thermostat Erlaubnis - Resistencia con paso termostato – Termostatlı ısıtıcı TA Termostato di sicurezza asciugatura - Drying cycle safety thermostat - Thermostat de securitè...
- Page 19 VB Tasto bassa temperatura (60°C) - Low temperature (60°C) button - Touche basse temperature (60°C) - Niedrige Temperatur (60°C) Taste - Tecla baja temperatura (60°C) – Dü ük sıcaklık (60°C) butonu VC Tasto ciclo freddo - Cold washing button - Bouton lavage froid - Taste Kaltes Wasche - Tecla lavado frio –...
- Page 20 VR Tasto economia - Economic washing pushbutton - Poussoir lavage economique - Billigwasche Taste - Tecla economico – Ekonomik yıkama fonksiyonu VS Tasto fermo con acqua in vasca (spull stop) - Stop with water in tub button (spull stop) - Poussoir arret avec eau dans la cuve (spull stop) - Spull stop taste - Tecla flot –...
- Page 21 TABELLA CORRISPONDENZA CONTATTI PRESSOSTATO E BLOCCAPORTA REFERENCE LIST FOR CONNECTIONS TO PRESSURE SWITCH AND DOOR INTERLOCK TABLEAU DE CORRESPONDENCE POUR LES CONTACTS DU PRESSOSTAT ET RETARDATEUR OVERTURE REFERENZEN LISTE FÜR DIE DRUCHWÄCHTER KONTAKTS UND OEFFNUNGS VERSPATER TABLA DE CORRESPONDENCIA DE LOS CONTACTOS DEL PRESOSTATO Y BLOCAPUERTA BASINÇ...
- Page 22 ll contatto L della versione "A" corrisponde al contatto 3 della versione "B". Contact L of "A" version corresponds to contact 3 of "B" version. Le contact L de la version "A" corre- spond au contact 3 de la version "B". El contacto L de la version "A"...
