Realtek Gigabit LAN chip
(for -UL series)
Realtek 10/100 Mbps LAN chip
(for -UN series)
4Mb Flash ROM BIOS
Onboard AC'97 CODEC
Front Audio Connector
32-bit PCI Expansion Slots x5
COM2 Connector
USB 2.0 Connectors x2
Game Port Connector
IrDA Connector
S/PDIF Connector
AUX-IN Connector
CD-IN Connector
Case Open Connector
SYSFAN2 Connector
Serial ATA Ports x2
Supports 150 MB/s Transfer Rate
JP14 CMOS Data Clear Jumper
Front Panel Connector
IDE Connectors x 2
(ATA33/66/100 supported)
FDD Connector
AOpen reserves the right to revise all the specifications and information contained in this document, which are subject to change without notice.
SPP/EPP/ECP Parallel Port
PS/2 Mouse
Connector
USB 2.0
Ports
PS/2 Keyboard
COM 1 Port
Connector
(for AX4SG series only)
RJ45 10/100/1000 LAN Jack
(for –UL and –UN
Series Motherboards)
Line-In
Speaker
Out
MIC-In
VGA Port
USB 2.0 Ports
Resetable Fuse
JP28 PS2 KB/Mouse Wakeup Jumper
ATX Power Connector
4-pin 12V ATX Power Connector
Low ESR Capacitors
SYSFAN1 Connector
AGP Protection LED
478-pin CPU socket with Voltage and
Frequency Auto-detection that supports
®
®
Intel
Pentium
4 1.6~3.20GHz+ CPU
AGP 8X Expansion Slot
supports 8X AGP card(2.1GB/s)
(for AX4SG series, it also supports ADD card)
CPUFAN Connector
®
Intel
865G/865PE/848P Chipsets that support
400/533/800 MHz FSB, DDR 400/333/266 and
AGP 8X
184-pin DIMMsx4 support 128bit Dual channel
DDR400/333/266 Max. To 4GB
(for AX4SG and AX4SPE series)
184-pin DIMMsx2 support 128bit Single channel
DDR400/333/266 Max. To 2GB
(for AX4SPB series)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AOpen AX4SG-U
Summary of Contents for AOpen AX4SG-U
- Page 1 DDR400/333/266 Max. To 2GB Front Panel Connector (for AX4SPB series) IDE Connectors x 2 (ATA33/66/100 supported) FDD Connector AOpen reserves the right to revise all the specifications and information contained in this document, which are subject to change without notice.
- Page 2 1. JP14 Clear CMOS You can clear CMOS to restore system default setting. To clear the CMOS, follow the procedure below. 1. Turn off the system and unplug the AC power. Everything you need to boot this 2. Remove ATX power cable from connector PWR2. motherboard is included in this 3.
- Page 3 3. Connecting ATX Power Connector 5. Setting CPU Voltage & Frequency Full-range Adjustable CPU Core Voltage This motherboard comes with a 20-pin and 4-pin ATX power connector as shown below. Make sure you plug in the right direction. We strongly recommend you to insert the 4-pin This motherboard supports CPU VID function.
- Page 4 6. Memory Module (128-Bit DDR Dual Channel) 8. AGP 8X Expansion Slot This model provides an AGP 8X slot that is the latest AGP specification. The AGP 8X calls In the past, we used to have 64-bit memory bandwidth for memory access. No matter how for the bus to operate at the basic AGP 66-MHz clock frequency and the bandwidth are many memory modules have been installed, though capacity added, the speed of access 2.1Gbytes/s.
- Page 5 12. S/PDIF (Sony/Philips Digital Interface) Connector 10. Connecting IrDA Connector The IrDA connector can be configured to support wireless infrared module, with this S/PDIF (Sony/Philips Digital Interface) is a newest audio transfer file format, which provides module and application software such as Laplink or Windows 98 Direct Cable Connection, impressive audio quality through optical fiber and allows you to enjoy digital audio instead of the user can transfer files to or from laptops, notebooks, PDA devices and printers.
- Page 6 BIOS Setup, press <Del> during POST (Power On Self Test). upgrading. Choose "Load Setup Defaults" for recommended optimal performance. Download the new version of BIOS package zip file from AOpen official web site. (ex: http://english.aopen.com.tw) Unzip download...
- Page 7 It is very possible that your keyboard press Del to see if the is defective. system reboots. AX4SG-UL R1.00 Sep. 01. 2003 AOpen Inc. During system rebooting, press Del to enter BIOS Setup. Choose Award Plug and Play BIOS Extension v1.0A “Load Setup Default".
- Page 8 Online Manual: To download manual, please log on and then select your preferred language. Under “Type” directory, choose “Manuals” to go to our manual database. You can also find the manual and EIG in AOpen Bonus Pack. http://download.aopen.com.tw/downloads Dear Customer, Thanks for choosing AOpen products.
