Page 1 Instruction Manual Body Composition MONITOR with Scale HBF-500CAN Model...
Page 2: Table Of Contents
TABLE OF CONTENTS Before Using the Monitor Introduction ..........3 Safety Information .
Page 3: Introduction
The personal memory function can be used to store data for up to four personal profiles. The memory function stores the measurement results for each personal profile from 1 day, 7 days, 30 days and 90 days ago. Your HBF-500CAN comes with the following components: • Main Unit • Instruction Manual •...
Page 4: Safety Information
SAFETY INFORMATION To assure the correct use of the product, basic safety measures should always be followed including the warnings and cautions listed in this instruction manual. SAFETY SYMBOLS USED IN THIS INSTRUCTION MANUAL Indicates a potentially hazardous situation which, if not avoided, could WARNING result in death or serious injury.
Page 5 This unit does not support the standards required for professional use. CARE AND MAINTENANCE Do not disassemble or modify the unit. Changes or modifications not approved by Omron Healthcare will void the user warranty. Do not subject the monitor to strong shocks, such as dropping the unit on the floor.
Page 6: Useful Information
BMI = weight (lb) / height (inch) / height (inch) × 703 The OMRON HBF-500CAN uses the height information stored in your Personal Profile Number to calculate your BMI classification. Let’s look at an example...
Page 7: Body Fat
USEFUL INFORMATION BODY FAT Examples of hidden fat Hidden Fat Not Revealed by BMI Although BMI calculates a simple obesity CaseA CaseB level, there is also hidden fat that not revealed by a BMI designation. Gender Although both cases are for people of similar height and weight, and their BMI 5' 7 7/8"...
Page 8: Visceral Fat
, 1 inch=2.54 cm) VISCERAL FAT distribution with 30 levels. CLASSIFICATION Level Classification 0: 1 - 9 level Example of display: +: 10 - 30 level • Visceral Fat Classification: * The data referenced by Omron Healthcare. • Visceral Fat:...
Page 9: Resting Metabolism & Skeletal Muscle
USEFUL INFORMATION RESTING METABOLISM & SKELETAL MUSCLE Skeletal muscle is muscle that is connected to bone and used to move parts of the body. The maintenance and increase of this skeletal muscle is closely linked to resting metabolism. What is resting metabolism? Regardless of your activity level, a minimum level of energy is required to sustain the body's everyday functions.
Page 10 USEFUL INFORMATION What is skeletal muscle? Muscle is divided into two types, muscle in internal organs, such as the heart, and muscle attached to bones that is used to move the body. Skeletal muscle can be increased through exercise and other activity.
Page 11: Long-Term Planning For Successful Weight Loss
USEFUL INFORMATION LONG-TERM PLANNING FOR SUCCESSFUL WEIGHT LOSS Ignoring a balanced diet and simply reducing food intake to lose weight can lead to a decline in muscle and bone. This may result in weight loss but not in reduction of fat levels. So even though your weight goes down, your resting metabolism is reduced making the body more prone to putting on fat.
Page 12: Principle Of Body Composition Calculation
The ratios of the water in your upper body and lower body may change through the day. This means that the electrical impedance of the body also varies. Since the HBF-500CAN uses electrodes for both the hands and feet to take measurements, it can reduce the influence of water movement on...
Page 13: Recommended Measurement Times
USEFUL INFORMATION RECOMMENDED MEASUREMENT TIMES Understanding the normal changes in your body fat percentage can help you in preventing or reducing obesity. Being aware of the times when the body fat percentages shift within your own daily schedule will assist you in obtaining an accurate trending of your body fat. It is recommended to use this unit in the same environment and daily circumstances.
Page 14 USEFUL INFORMATION The reason calculated results may differ from actual body fat percentage There are certain conditions when significant differences may occur between the estimated and the actual body fat values. These differences may be related to changing ratios of body fluid and/or body composition.
Page 15: Know Your Unit
KNOW YOUR UNIT Display Unit Display Grip Electrodes Grip Electrodes Personal Profile Number Button Personal Profile Number Button Skeletal Muscle Button Body Fat Button DOWN Button SET Button Resting Metabolism Button BMI Button Guest/Memory Button Cord Display Unit Holder Main Unit (Measurement Platform) Foot Electrodes...
Page 16 KNOW YOUR UNIT Measurement Start Indicator Weight Indicator Height Indicator Guest Indicator Gender Indicator Low Battery Indicator Personal Profile Number Age Indicator Weight Results Display Mode Indicator Memory Indicator Body Composition Results Measurement Progress/ Body Fat Percentage and BMI Classification Bar Body Fat Percentage and BMI Classification Visceral Fat Classification...
Page 17 KNOW YOUR UNIT WARNING Contact your physician or healthcare provider before beginning a weight reduction or exercise program. USING THE DISPLAY UNIT Extend the cord as illustrated to the right. STORING THE DISPLAY UNIT Coil the cord into the Display Unit Holder. Make sure the cord is coiled evenly, and does not stick out of the Display Unit Holder.
Page 18: Battery Installation
BATTERY INSTALLATION Locate the Battery Cover on the back of the unit. Press the tab on the battery cover in the direction of the arrow to release the cover as Rear illustrated. Pull the tab of the cover upwards. INSTALL 4 “AA” SIZE BATTERIES so the + (positive) and –...
Page 19 BATTERY INSTALLATION BATTERY REPLACEMENT Measurement values and personal profiles stored in the memory will not be deleted during battery replacement. The date and time will need to be set when monitor is turned on. Low Battery Indicator When the Low Battery Indicator appears on the display screen remove all four worn batteries. Replace with four new batteries at the same time.
Page 20: Setting The Date And Time
SETTING THE DATE AND TIME When the power is turned on for the first time, it is necessary to set the date and time. Buttons Used in this Procedure SET Button Use this button to confirm the setting or move to the next item after confirming the set item.
Page 21 SETTING THE DATE AND TIME SETTING THE DAY Press the UP or DOWN button to change the day. Press the SET button. The day is set. The hour flashes on the display. SETTING THE HOUR Press the UP or DOWN button to change the hour. Press the SET button.
Page 22: Setting Personal Data
SETTING PERSONAL DATA To measure Body Composition, your personal data must be set. Your personal data includes your age, gender and height. The Body Composition Monitor with SCALE provides two options to enter your personal data. 1) Select a personal profile number to save your personal data. The monitor saves up to 4 personal profiles.
Page 23 SETTING PERSONAL DATA Select a Personal Profile or GUEST as your Personal Data Option. A. Personal Profile Press the desired Personal Profile Number button (1 through 4). Press the SET button. NOTE: 1) If no information has been entered for the Personal Profile Number you selected, the number and the symbols for gender, age and height blink on the display.
Page 24: Changing Personal Data
SETTING PERSONAL DATA SETTING THE GENDER Set the gender to MALE OR FEMALE Press the UP or DOWN button to change the gender. Press the SET button. The gender is set. The default value for height blinks on the display. SETTING THE HEIGHT Set the height between 3’4”...
Page 25 SETTING PERSONAL DATA Select the Personal Profile Number you want to change. Press the Personal Profile Number button (1 thorough 4). The selected Personal Profile Number flashes once on the display. Press the SET button. The Personal Profile Number is set. The current SETTING for age blinks on the display.
Page 26: How To Take A Measurement
HOW TO TAKE A MEASUREMENT YOUR PERSONAL DATA MUST BE ENTERED BEFORE TAKING A MEASUREMENT. CAUTION: Consult your physician before using this monitor when pregnant. CAUTION: Persons with disabilities or persons that are physicially frail should be assisted by another person when using this monitor or use a handrail, a walker, or other support device to prevent falling when stepping on and off the monitor.
Page 27 HOW TO TAKE A MEASUREMENT HOW TO MEASURE BODY COMPOSITION Press the Power Switch to turn the monitor ON. The CAL symbol blinks on the display, then the display changes to 0.0 lb. Wait until 0.0 lb appears on the display. NOTES: •...
Page 28 HOW TO TAKE A MEASUREMENT Select the Personal Profile Number button or the Guest/Memory button. A. Personal Profile Number Press the button for the Personal Profile Number you selected while holding the display unit. The Personal Profile Number will appear after blinking once. Ex.: To select Personal Profile Number “1”, press button NOTE:...
Page 29 HOW TO TAKE A MEASUREMENT Start the measurement. 1) Step onto the measurement platform and place your feet on the foot electrodes with your weight evenly distributed. Remain still and do not move until the weight measurement is complete. The display will show your weight and then the weight result will blink twice.
Page 30 HOW TO TAKE A MEASUREMENT Check the measurement results. Press the appropriate button to view the measurement results. Weight Weight Body Fat Percentage Skeletal Muscle Percentage Body Fat Percentage Classification Visceral Fat Level/ Visceral Fat Level/ Visceral Fat Classification Visceral Fat Classification Weight Weight Resting Metabolism...
Page 31 Visceral fat area (0 - Approx. 300 cm , 1 inch=2.54 cm) distribution with 30 levels. * The data referenced by Omron Healthcare. Turn the monitor off. Press the Power Switch to turn the monitor off. Store the Display Unit in the Display Unit...
Page 32: How To Measure Weight Only
HOW TO MEASURE WEIGHT ONLY Press the Power Switch to turn the monitor ON. The CAL symbol blinks on the display, then the display changes to 0.0 lb. Wait until 0.0 lb appears on the display. NOTES: • If you step onto the monitor before 0.0 lb appears on the display, an error message “Err”...
Page 33: How To Use The Memory Function
HOW TO USE THE MEMORY FUNCTION Measurement results are automatically stored in memory when you take a measurement using a Personal Profile Number button. You can view results for 1 day, 7, 30, and 90 days before. The monitor automatically stores up to 97 measurement values for each Personal Profile Number. When 97 sets of measurement values are stored in the memory for that Personal Profile Number, its oldest record is deleted to save the most recent measurement values.
Page 34 HOW TO USE THE MEMORY FUNCTION NOTES: • If there are no results for a selected memory, “- - - -” is displayed for that item. • To view previous results for other items, press the button for the desired item. The results for the selected item are displayed.
Page 35 HOW TO USE THE MEMORY FUNCTION Viewing Previous Measurement Results Follow this procedure if you just want to view and compare previous measurement results, without taking a measurement. Press the Power Switch to turn the monitor ON. The CAL symbol blinks on the display, then the display changes to 0.0 lb.
Page 36 HOW TO USE THE MEMORY FUNCTION View the previous measurement results. 1) Press the Guest/Memory button once. The results for the previous day are displayed. [Example] 2) Press the Guest/Memory button to cycle through the results from “1 day”, “7 days”, “30 days”, and “90 days”...
Page 37: Error Indicators
ERROR INDICATORS ERROR DISPLAY CAUSE CORRECTION Make sure you are barefoot. Make sure your palms or the soles of your feet are clean and dry. Your palms or feet are not positioned Make sure your feet are correctly over the electrodes correctly. positioned.
Page 38: Troubleshooting Tips
TROUBLESHOOTING TIPS PROBLEM CAUSE AND SOLUTION Low Battery Indicator Check the battery installation for proper placement of No power the battery polarities. No display appears on the unit Replace all four worn batteries. The weight value is displayed abnormally low or Place the monitor on a hard, level floor.
Page 39: Care And Maintenance
Do not crease the cord when storing in the Display Unit Holder. Use the monitor consistent with the instruction provided in this manual. CAUTION: Do not disassemble or modify the unit. Changes or modifications not approved by Omron Healthcare will void the user warranty.
Page 40: Fcc Statement
FCC STATEMENT NOTE: POTENTIAL FOR RADIO/TELEVISION INTERFERENCE (for U.S.A. only) This product has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 41: Warranty
WARRANTY Limited Warranty Your HBF-500CAN Body Composition MONITOR with Scale, excluding the batteries, is warranted to be free from defects in materials and workmanship appearing within 1 year from the date of purchase, when used in accordance with the instructions provided with the unit. The above warranties extend only to the original retail purchaser.
Page 42: Specifications
SPECIFICATIONS Model OMRON Body Composition MONITOR with Scale - HBF-500CAN Display Weight display: 0 to 300 lb with 0.2 lb increments (0 to 135 kg with 0.1 kg increments) Body fat percentage: 5.0 to 60.0% with 0.1% increments Skeletal muscle percentage: 5.0 to 50.0% with 0.1% increments BMI: 7.0 to 90.0 with 0.1 increments...
Page 43: Notes
