Panasonic TC-50PS24 Operating Instructions Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Plasma hdtv
  5. Viera TC-50PS24
  6. Operating instructions manual
Panasonic TC-50PS24 Operating Instructions Manual

Panasonic TC-50PS24 Operating Instructions Manual

50” class 1080p plasma hdtv (49.9 inches measured diagonally)
Hide thumbs Also See for TC-50PS24:
Table of Contents

Advertisement

Quick Links

Download this manual
Customer's Record
The model number and serial number of this product can be found on its back cover. You should note this serial number in
the space provided below and retain this book, plus your purchase receipt, as a permanent record of your purchase to aid
in identification in the event of theft or loss, and for Warranty Service purposes.
Model Number
Anotación del cliente
El modelo y el número de serie de este producto se encuentran en su panel posterior. Deberá anotarlos en el espacio
provisto a continuación y guardar este manual, más el recibo de su compra, como prueba permanente de su adquisición,
para que le sirva de ayuda al identificarlo en el caso de que le sea sustraído o lo pierda, y también para disponer de los
servicios que le ofrece la garantía.
Modelo
Panasonic Consumer Electronics Company,
Division of Panasonic Corporation of North America
One Panasonic Way, Secaucus
New Jersey 07094 U.S.A.
© 2010 Panasonic Corporation of North America. All Rights Reserved.
© 2010 Panasonic Corporation of North America. Todos los Derechos Reservados.
Serial Number
Número de serie
Panasonic Canada Inc.
5770 Ambler Drive
Mississauga, Ontario
L4W 2T3 CANADA
Printed in U.S.A.
Impreso en EE.UU.
M0110-0

Advertisement

Table of Contents
loading

Related Manuals for Panasonic TC-50PS24

Summary of Contents for Panasonic TC-50PS24

  • Page 1 One Panasonic Way, Secaucus Mississauga, Ontario New Jersey 07094 U.S.A. L4W 2T3 CANADA © 2010 Panasonic Corporation of North America. All Rights Reserved. Printed in U.S.A. © 2010 Panasonic Corporation of North America. Todos los Derechos Reservados. Impreso en EE.UU. M0110-0...
  • Page 2 Please read these instructions before operating your set and retain them for future reference. The images shown in this manual are for illustrative purposes only. Gracias por su decisión de comprar este producto marca Panasonic. Español Lea estas instrucciones antes de utilizar su televisor y guárdelas para consultarlas en...
  • Page 3 DVD player/ Blu-ray Disc recorder Blu-ray Disc player VIERA Link™ is a trademark of SDHC Logo is a trademark Panasonic Corporation. of SD-3C, LLC. HDMI, the HDMI logo and High- Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United Manufactured under license from Dolby States and other countries.

  • Page 4: Table Of Contents

    Contents Please read before using the unit ● Safety Precautions ·········································· 4 ● Notes ······························································· 7 Quick Start Guide ● Accessories/Optional Accessory ····················· 8 ● Basic Connection ·········································· 11 ● Identifying Controls ········································ 13 ● First Time Setup ············································ 14 Enjoy your TV! SD memory card Basic Features...

  • Page 5: Safety Precautions

    The following Do not climb or allow children to climb on the Plasma TV accessories are manufactured by Panasonic Corporation. Place or install the Plasma TV where it cannot be • Wall-hanging bracket (Angled) pushed, pulled over or knocked down.
  • Page 6 Do not place any objects on top of the Plasma TV. If water or an object gets inside the Plasma TV, if the If water spills onto the Plasma TV or foreign objects get Plasma TV is dropped, or if the enclosure becomes inside it, a short-circuit may occur which could result in damaged, unplug the power supply cord immediately.
  • Page 7 MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. For at least three (3) years from delivery of products, Panasonic will give to anyone who contacts us at the address provided below, for a charge of no more than our cost of physically performing source code distribution, a complete machine-readable copy of the corresponding source code covered under GPL v2/LGPL.

  • Page 8: Notes

    To assure continued compliance, follow the attached installation instructions and use only shielded interface cables when connecting to computer or peripheral devices. Any changes or modifications not expressly approved by Panasonic Corp. of North America could void the user’s authority to operate this device. FCC Declaration of Conformity Model No.

  • Page 9: Accessories/Optional Accessory

    VIERA Concierge and Quick start guide Product Registration Card (U.S.A.) How to assemble (p. 9) Optional Accessory Please contact your nearest Panasonic dealer to purchase the recommended wall-hanging bracket. For additional details, please refer to the wall-hanging Wall-hanging bracket bracket installation manual.
  • Page 10 Otherwise the TV may fall over and become damaged, and personal injury may result. Do not use the pedestal if it becomes warped or physically damaged. If you use the pedestal when it is physically damaged, personal injury may result. Contact your nearest Panasonic Dealer immediately.
  • Page 11 Accessories/Optional Accessory (Continued) AC cord connection To attach To remove Keep pushing both sides until they snap Insert it firmly until the and pull. tabs on both sides click into place. Reference of connection Antenna terminal Pin terminals HDMI terminal blue green green...

  • Page 12: Basic Connection

    For more details on the external equipment’s connections, please refer to the operating manuals for the equipment. When disconnecting the power cord, be absolutely sure to disconnect the power cord plug from the wall outlet first. For additional assistance, visit us at: www.panasonic.com www.panasonic.ca...
  • Page 13 Basic Connection (Continued) AV cable connections To use HDMI terminals AV Equipment HDMI AV OUT e.g. Blu-ray Disc player Connecting to HDMI terminals will enable you to enjoy high-definition digital images and high-quality sound. The HDMI connection is required for a 1080p signal. For “VIERA Link connections”, please refer to p.

  • Page 14: Identifying Controls

    Identifying Controls TV controls/indicators Front of the TV Back of the TV SD card slot Selects channels in sequence Volume up/down Displays the Main menu. Remote control HDMI Input 3 connector sensor within about 23 feet (7 meters) in Changes the input Video Input 2 connector front of the TV set.

  • Page 15: First Time Setup

    First Time Setup First time setup screen is displayed only when the TV is turned on for the first time after the power cord is inserted into a wall outlet and when “Auto power on” (p. 29) is set to “No”. Turn the TV On with the POWER button (TV) (Remote)
  • Page 16 Auto channel setup (ANT/Cable setup) Select the connected Antenna in terminal Not used: Go to ANT/Cable setup Step 3 of 6 Cable Antenna Not used (Label inputs) select ANTENNA Cable In ANTENNA Cable In Select “Not used” when viewing TV via Select Satellite receiver or Cable box.
  • Page 17 Change RETURN following operations. Complete the First time setup Completion message is displayed when you successfully completed the First time setup. Setup is complete. Enjoy your Panasonic VIERA TV. Press OK to exit. RETURN Note About broadcasting systems Analog (NTSC):...

  • Page 18: Watching Tv

    Watching TV Basic connection (p. 11-12) To watch TV and other functions Turn power on (Remote) (TV) Note If the mode is not TV, press and select TV. (p. 26) Select a channel number (Remote) down (TV) To directly enter the digital channel number When tuning to a digital channel, press the button to enter the minor number in a compound...
  • Page 19 Watching TV (Continued) (Operate after Other Useful Functions Select the Audio mode for watching TV Digital mode Press SAP to select next audio track (if available) when receiving a digital Listen channel. with SAP Audio track 1 of 2 (Secondary (English) Audio Program) Analog mode...
  • Page 20 Favorite Feature Set the Favorite Feature Use the Favorite Feature Display the SUB MENU. Display “Favorite channels” MENU Select “Set favorite” Select the channel select select Setup SUB MENU Favorite channels Channel surf mode 26-1 Set favorite Edit CH caption Signal meter Set the displayed channel Set a Favorite channel...

  • Page 21: Using Viera Tools

    Using VIERA TOOLS VIERA TOOLS is the easy way to access frequently-used menu items. They are displayed as shortcut icons on the TV screen. Unlike a conventional menu, you can enjoy using, playing or setting a function quickly. Display VIERA TOOLS Select the item select next...
  • Page 22 VIERA Link Setting If you connect equipment that has the “HDAVI Control” function to the TV using an HDMI cable, you will find it easier to use. Please refer to p. 30-35. Before using these functions, you need to set “VIERA Link” setting to “On” as shown below. Display the menu Select “Setup”...

  • Page 23: Viewing With Viera Image Viewer

    Viewing with VIERA IMAGE VIEWER The VIERA Image Viewer is a function that lets you easily view still images on a VIERA television by simply inserting an SD card into the VIERA SD card slot. (Media other than SD Cards will not work.) Photo viewer Insert the SD card * This setting will be skipped next time unless you select “Set later”.
  • Page 24 Insert the card Remove the card Compliant card type (maximum capacity): SDHC Card (32 GB), microSDHC Card Gently insert the SD Card label (16 GB), SD Card (2 GB), miniSD Card surface facing front. (2 GB), microSD Card (2 GB) (requiring microSDHC Card/miniSD Card/microSD Label surface SD Card...

  • Page 25: Displaying Pc Screen On Tv

    Displaying PC Screen on TV The screen of the PC connected to the unit can be displayed on the TV. You can also listen to PC sound with the audio cable connected. To connect PC (p. 43) Display the Input select menu Input select HDMI 1 HDMI 2...
  • Page 26 PC menu setting (change as desired) Making settings “How to Use Menu Functions” (p. 27) Menu Item Adjustments/Configurations (options) Reset to Resets PC adjustments. Confirmation screen is displayed. Select “Yes” and press OK to reset. defaults H & V: The H and V sync signals are input from the HD/VD connector. (p. 49) Sync On green: Uses a synchronized signal on the Video G signal, which is input from the G connector.

  • Page 27: Watching Videos And Dvds

    Watching Videos and DVDs If you have an applicable equipment connected to the TV, you can watch videos and DVDs on the TV screen. Input Select You can select the external equipment to access. With the connected equipment turned On Display the Input select menu Select the input mode Press the corresponding NUMBER...

  • Page 28: How To Use Menu Functions (Picture, Sound Quality, Etc.)

    How to Use Menu Functions Various menus allow you to make settings for the picture, sound, and other functions so that you can enjoy watching TV best suited for you. Display the menu Shows the functions that can be adjusted. Some functions will be disabled depending on the type of input signal.
  • Page 29 How to Use Menu Functions Menu list Menu Item Adjustments/Configurations (alternatives) Reset to defaults* Resets all picture adjustments to factory default settings except for “Advanced picture”. Picture mode Basic picture mode (Vivid/Standard/Cinema/Custom) (p. 47) Adjusts the color, brightness, etc. for each picture mode to suit your taste •...
  • Page 30 (Continued) Menu list Menu Item Adjustments/Configurations (alternatives) Sets the mode to select the channel with the Channel up/down button. (All/Favorite/Digital only/Analog only) Channel surf mode • Favorite: Only channels registered as FAVORITE. (p. 18) Language Selects the screen menu language. Clock Adjusts the clock.

  • Page 31: Viera Link Tm "Hdavi Control Tm

    VIERA Link “HDAVI Control ” Simultaneously control all Panasonic “HDAVI Control” equipped components using one button on the TV remote. Enjoy additional HDMI Inter-Operability with Panasonic products which have the “HDAVI Control” function. This TV supports “HDAVI Control 5” function.
  • Page 32 When audio from other equipment connected to this unit via HDMI is output using “DIGITAL AUDIO OUT” of this unit, the system switches to 2CH audio. (When connecting to an AV amp via HDMI, you can enjoy higher sound quality.) For details about HDMI cables for connecting a Panasonic HD camcorder, read the manual for the equipment.
  • Page 33 VIERA Link “HDAVI Control ” Display the menu Automatic Input Switching Power on link Select “Setup” Power off link Menu Setup VIERA Link settings select ECO / energy saving Advanced setup Energy First time setup saving mode About next Reset to defaults (for “HDAVI Control 4 or later”...
  • Page 34 “TV” to “Theater”. Sound will be output from the Home Theater whenever the TV is powered on. If the “ONE TOUCH PLAY” key is pressed on the remote control for a Panasonic Home Theater system, the following sequence of operations is performed automatically.
  • Page 35 VIERA Link “HDAVI Control ” You can enjoy more convenient operation with the “HDAVI Control” function in the “VIERA Link” menu. For more details on the “HDAVI Control” function, refer to p. 30 Display the VIERA Link menu Speaker control select next VIERA Link...
  • Page 36 You can select the Home theater or TV speakers for audio Adjustment for the equipment output. Control the theater speakers with the TV’s remote control. Volume up / down This function is available only when a Panasonic Amplifier or Player theater is connected. Mute Select “Speaker output” •...

  • Page 37: Lock

    Lock You can lock specified channels or shows to prevent children from watching objectionable content. Display the menu Channel lock Select “Lock” next Menu Password Enter password. - - - - select You will be asked to enter your password Game lock each time you display the Lock menu.
  • Page 38 To select the channel or the rating of the program to lock Select up to 7 (1-7) channels to block. These channels will be blocked regardless of the program rating. Select “Mode” and set to “Custom” Select a channel to lock To lock/unlock all channels: select Menu...

  • Page 39: Editing And Setting Channels

    Editing and Setting Channels The current channel settings can be changed according to your needs and reception conditions. Display the menu Auto program automatically Select “Setup” Menu Setup Channel surf mode next Language select Clock ANT/Cable setup Input labels Anti image retention Adjusts Surf mode, Language, Clock, Channels, Inputs, and other settings.
  • Page 40 Automatically searches and adds available channels to the memory. Select “ANT in” Select a scanning mode (p. 15) Select “Cable” or “Antenna” Menu Auto program Or select “Not used” (p. 15). All channels Analog only Select “Auto program” Digital only select Menu ANT/Cable setup...

  • Page 41: Closed Caption

    Closed Caption Display the menu Select “Closed caption” Menu Closed caption Reset to defaults next Mode Analog select Primary Digital Digital setting Press to exit from a menu screen Display broadcast TV’s Closed Caption (CC) text when available. The television includes a built-in decoder that is capable of providing a text display of the audio. The program being viewed must be transmitting the Closed caption (CC) information.

  • Page 42: Input Labels

    Input Labels Display the menu Select “Setup” next Menu Setup Channel surf mode Language select Clock ANT/Cable setup Input labels Anti image retention Adjusts Surf mode, Language, Clock, Channels, Inputs, and other settings. Select “Input labels” next Menu Setup Channel surf mode Language select Clock...

  • Page 43: Using Timer

    Using Timer The TV can automatically turn On/Off at the designated date and time. The Clock must be set before On time/Off time settings. (p. 16) The “Sleep” timer and “On / Off timer” will not work if the “Auto power on” (p. 29) is set. Display the menu Select “Timer”...

  • Page 44: Recommended Av Connections

    These diagrams show our recommendations or how to connect the TV unit to your various equipment. For other connections, consult the instructions for each piece of equipment and its specifications. For additional assistance, please visit our website at: www.panasonic.com www.panasonic.ca...

  • Page 45: Ratings List For Lock

    Ratings List for Lock “V-chip” technology enables you to lock channels or shows according to standard ratings set by the entertainment industry. (p. 37) U.S. MOVIE RATINGS (MPAA) NO RATING (NOT RATED) AND NA (NOT APPLICABLE) PROGRAMS. Movie which has not been rated or where rating does not apply.

  • Page 46: Technical Information

    Technical Information Closed Caption (CC) For viewing the CC of digital broadcasting, set the aspect to FULL (If viewing with H-FILL, JUST, ZOOM or 4:3; characters might be cut off). The CC can be displayed on the TV if the receiver (such as a set-top box or satellite receiver) has the CC set On using the Component or HDMI connection to the TV.
  • Page 47 Electrical interference, static electricity or erroneous operation may damage the data or card. Back up the recorded data at regular intervals in case of deteriorated or damaged data or erratic operation of the unit. (Panasonic is not liable for any deterioration or damage of recorded data.) 24 mm...
  • Page 48 “HDAVI Control ” HDMI connections to some Panasonic equipment allows you to interface automatically. (p. 30) This function may not work normally depending on the equipment condition. The equipment can be operated by other remote controls with this function on even if TV is in Standby mode.
  • Page 49 Technical Information (Continued) H size Aspect Ratio: 4:3 The width will be decreased on both sides to Size 1 Size 2 reduce noise. Aspect Ratio: FULL/JUST(H-FILL/ZOOM) The width will be increased on both sides to Size 1 Size 2 reduce noise. See page 28 for more information 4:3 side bars Do not display a picture in 4:3 mode for an extended period, as this can cause...

  • Page 50: Care And Cleaning

    PC Input Terminals Connection Computer signals which can be input are those with a horizontal scanning frequency of 15 to 110 kHz and vertical scanning frequency of 48 to 120 Hz. (However, the image will not be displayed properly if the signals exceed 1,200 lines.) Some PC models cannot be connected to the set.

  • Page 51: Faq

    Before requesting service or assistance, please follow these simple guides to resolve the problem. If the problem still persists, please contact your local Panasonic dealer or Panasonic Service Center for assistance. For details (p. 54, 55) For additional assistance, please contact us via the website at: www.panasonic.com/contactinfo...
  • Page 52 If there is a problem with your TV, please refer to the table below to determine the symptoms, then carry out the suggested check. If this does not solve the problem, please contact your local Panasonic dealer, quoting the model number and serial number (both found on the rear of the TV).

  • Page 53: Specifications

    Specifications TC-50PS24 Power Source AC 120 V, 60 Hz Maximum 353 W Standby condition 0.3 W Drive method AC type Aspect Ratio 16:9 Visible screen size 50 ” class (49.9 inches measured diagonally) (W × H × Diagonal) 43.5 ” × 24.4 ” × 49.9 ”...

  • Page 54: Limited Warranty (For U.s.a. And Puerto Rico Only)

    Limited Warranty Coverage If your product does not work properly because of a defect in materials or workmanship, Panasonic Consumer Electronics Company (referred to as “the warrantor”) will, for the length of the period indicated on the chart below, which starts with the date of original purchase (“Limited Warranty period”), at its option either (a) repair your product with new...

  • Page 55: Customer Services Directory

    ■ For hearing or speech impaired TTY users, TTY: 1-877-833-8855 Accessory Purchases (United States and Puerto Rico) Purchase Parts, Accessories and Instruction Books on line for all Panasonic Products by visiting our Web Site at: http://www.pstc.panasonic.com or, send your request by E-mail to: npcparts@us.panasonic.com...

  • Page 56: Limited Warranty (For Canada)

    This warranty is given only to the original purchaser, or the person for whom it was purchased as a gift, of a Panasonic brand product mentioned above sold by an authorized Panasonic dealer in Canada and purchased and used in Canada, which product was not sold “as is”, and which product was delivered to you in new condition in the original packaging.

Table of Contents
