- Page 1 Industrial Monochrome CCD Camera CV-A50 IR Operation Manual Revision 0 Manual: Version- 1.0 A50Manualnov25.doc JPT 25-11-03...
-
Page 2: Table Of Contents
10. Appendix ....................23 10.1. CV-A50 IR emulating CV-M50 IR interfacing ..............23 10.2. WEN out on pin 6 on 6 pin connector ...............24 10.3. CV-A50 IR without sync on video output..............24 10.4. Precautions ......................25 10.5. Typical CCD Characteristics...................25 11. Users Record ....................26... -
Page 3: General
CV-A50 IR 1. General The CV-A50 IR is a monochrome CCIR and EIA interlaced 1/2” CCD cameras with enhanced near IR response, designed for a wide range of automated imaging application. The camera features a compact housing and a wide range of unique functions. -
Page 4: Camera Housing And Dimensions
CV-A50 IR 4. Camera Housing and Dimensions Fig. 1. Locations and dimensions. 12-pin Hirose connector for frame grabber interfacing and power (12V DC). BNC connector for video output. VS 1.0 Vpp 75 Ohm. 6-pin Hirose connector for trigger input and RS-232C control interface. -
Page 5: Pin Assignment
CV-A50 IR 5. Pin Assignment 5.1. 12-pin Multi-connector (DC-IN/VIDEO OUT, EXT.HD/VD IN) Type: HR10A-10R-12PB-01 (Hirose) male Seen from rear. Pin configuration is compatible with EIAJ standard Pin no. Signal Remarks +12 V DC input Video output Parallel with the BNC connector. -
Page 6: Input And Output Circuits
In the following schematic diagrams the input and output circuits for video and timing signals are shown. Jumper settings are shown as for factory default. For alternative connections refer to “10.1. CV-A50 IR emulating CV-M50 IR interfacing.” 5.3.1. Video output... -
Page 7: Functions And Operations
CV-A50 IR 6. Functions and Operations Apart from the standard continuous operation, the CV-A50 IR features three external asynchronous trigger modes (edge pre-select, pulse width controlled and start/stop) and a special frame-delay readout mode. Long integration time mode is also supported. -
Page 8: Input-Output Of Hd/Vd Signals
CV-A50 IR 6.2. Input-output of HD/VD Signals In the default setting the camera will accept external HD/VD signals on pin 6 and 7 of the 12 pin Hirose connector. If external HD/VD is applied, the camera will synchronize to it. If no external sync signals are applied, the camera will operate with its internal x-tal controlled sync. - Page 9 CV-A50 IR Fig. 10. Horizontal timing details and pixel numbering for the CCD array. CCIR Fig. 11. Horizontal timing details and pixel numbering for the CCD array. EIA - 8 -...
- Page 10 CV-A50 IR Fig. 12. Vertical timing details for interlaced. CCIR Fig. 12A. Vertical timing details for non-interlaced. CCIR - 9 -...
- Page 11 CV-A50 IR Fig. 13. Vertical timing details for interlaced. EIA Fig. 13A. Vertical timing details for non-interlaced. EIA - 10 -...
-
Page 12: External Trigger Modes
CV-A50 IR 6.4. External Trigger Modes This camera has 5 external asynchronous trigger modes, which can be set by RS-232C commands. Edge Pre-select Mode.TR=1 Pre-selected exposure. (SM=0, SM=1) Pulse Width Control Mode. TR=2 Pulse width controlled exposure. Frame Delay read out mode. TR=3 PWC exposure read out by ext. -
Page 13: Edge Pre-Select Mode
CV-A50 IR 6.5. Edge Pre-select Mode The leading edge of the trigger pulse initiates the exposure. The exposure time (accumulation time) is governed by the pre-defined shutter speed set by RS-232C. The resulting video is output as “odd field” for EIA and “even field” for CCIR, and appear 9H (EIA9 or 10H (CCIR) after the leading edge of WEN (polarity is user selectable). -
Page 14: Pulse Width Control Mode
CV-A50 IR 6.6. Pulse Width Control Mode The leading edge of the trigger pulse initiates the exposure. The exposure time (accumulation time) is governed by duration of the trigger pulse. The resulting video is output as “odd field” for EIA and “even field” for CCIR, and appear 9H (EIA9 or 10H (CCIR) after the leading edge of WEN (polarity is user selectable). -
Page 15: Frame-Delay Read Out Mode
CV-A50 IR 6.7. Frame-delay read out Mode This mode allows simultaneous capture of multiple camera using a common external trigger pulse subsequent multiplexed (sequential) readout using a single input frame grabber, as the user has control over when the image is read out from the CCD sensor. The exposure starts at the falling edge of the ext. -
Page 16: Long Time Exposure Mode
CV-A50 IR 6.8. Long Time Exposure Mode The exposure time is the interval between 2 ext. VD pulses sent to the VD input of the camera (Pin No. 7 of the 12-pin Hirose connector). The exposure starts after input of the first ext. VD pulse, and ends after the next input of the next ext. -
Page 17: Start/Stop Mode
CV-A50 IR 6.9. Start/Stop Mode The exposure time is controlled by the interval between the ext. trigger and the ext. VD signal. The exposure starts at the first HD pulse after the falling edge of the ext. trigger, and stops 14.5 H after the falling edge of the VD pulse. -
Page 18: Other Functions
CV-A50 IR Important notes on using this mode:- • As the start of exposure will be synchronized with the internal H signal, the start of exposure may be shifted by max 1H. • To avoid this shift (jitter), synchronize the camera with an external HD and make sure that the trigger pulse aligns to the HD signal as shown in Fig. -
Page 19: Configuring The Camera
All configuration of the A50/60 camera is done via the RS-232C port. The camera can be set up from a PC running terminal emulator software, or using JAI´s camera control software. Below is the description of the ASCII based short command protocol. -
Page 20: Cv-A50 Ir Rs-232C Command List
CV-A50 IR 7.2. CV-A50 IR RS-232C command list. Command Name Format Parameter Remarks A – General settings and useful commands Echo Back 0=Echo off 1=Echo on EB=[Param.]<CR><LF> Off at power up Camera Status request ST?<CR><LF> Actual setting Online Help request HP?<CR><LF>... -
Page 21: Camera Control Tool For Cv-A50/60
CV-A50 IR 7.3. Camera Control Tool for CV-A50 IR (CV-A50/60 software) From www.jai.com CV-A50/60 Camera Control Tool for Windows 98/NT/2000 can be downloaded. The control tool contents a camera control program and tools for making your own program. Below the different windows are shown. -
Page 22: Hd/Vd Input-Output Selection
CV-A50 IR 7.4. Internal Switch and Jumper Settings. 7.4.1 HD/VD input-output selection In the default setting the camera will accept external HD/VD signals on pins 6 and 7 of the 12 pin Hirose connector. The composite video signal from the camera will be synchronized to an external HD/VD source connected to the camera. -
Page 23: Specifications
CV-A50 IR 8. Specifications Specifications CV-A50 IR C CV-A50 IR E Scanning system CCIR, 25 frames/sec. EIA. 30 frames/sec. 625 lines, 2:1 Interlaced 525 lines, 2:1 Interlaced Frame rate (Full frame) 50 Hz 59.94 Hz Line frequency 15.625 kHz 15.734 kHz Pixel frequency 14.1875 MHz... -
Page 24: Spectral Sensitivity
The CV-A50 IR has a slightly different pin configuration on the 12-pin Hirose connector, compared to the CV-M50 IR. This new configuration is compliant to the EIA-J standard. This means, however, that the CV-A50 IR is not completely backward compatible with the CV- M50 IR, in all cases (depending on the cable configuration). -
Page 25: Wen Out On Pin 6 On 6 Pin Connector
Configuration shown in Bold+Italic is factory default setting Fig. 32. PK8275B main board 10.3. CV-A50 IR without sync on video output. For applications where the video output signal should be without the composite sync signal, it is possible to remove the sync signal by removing an internal resistor. -
Page 26: Precautions
CV-A50 IR 10.4. Precautions Personnel not trained in dealing with similar electronic devices should not service this camera. The camera contains components sensitive to electrostatic discharge. The handling of these devices should follow the requirements of electrostatic sensitive components. Do not attempt to disassemble this camera. -
Page 27: Users Record
Company and product names mentioned in this manual are trademarks or registered trademarks of their respective owners. JAI A-S cannot be held responsible for any technical or typographical errors and reserves the right to make changes to products and documentation without prior notification.
