Atlantis Land NetCamera 800NV A02-OIPCAM1 Quick Start Manual

NetCamera 800NV
A02-OIPCAM1
QUICK START GUIDE
A02-OIPCAM1_GE01

System requirements

Before proceed with product installation, please make sure your system is in
compliance with the following requirements:
-Windows 98, ME, 2000, 2003, XP or Vista
-Internet Explorer 6.0 or later

Package contents

Before proceed with the product usage please check the package contents:
-IP Camera
-PoE Injector with power cord
-Mounting screws
-Quick Start Guide
-CD-ROM

Connectors

Green: Audio output
Red: Microphone input
- 1 -
1 .Click " Yes " to proceed with the installation procedure
2. Select desired language an click "Next"
3. Click "Next" to go to the next step
- 3 -
Audio output:
Audio input: connect here a microphone.
Video output: analog video output
Power: use this connector to use an external power supply (12V,1 A not included).
Network: ethernet 802.3 af port, to provide power and ethernet signal to the
NetCamera.

Configuration

Turn on your PC and put the provided CD-Rom in your CD-Rom reader. A welcome
page will appear. Select the purchased NetCamera and click on "Intelligent IP
Installer" link, then follow the next steps.
Video output
Power
Network (PoE)
4 .Click "Next"
6 .Click "Next"
connect here an external speaker.
.
-2 -
to go to the next step 5 .Click "Next" to go to the next step
to go to the next step 7 .Click " Install " then "Finish"
the installation procedure.
- 4 -
to complete
