Norcross D10DX.06T Installation And Operation Manual

Digital depth sounder with air & water temperature, thru-hull transducer

Advertisement

Quick Links

D10D
Model No.
INSTALLATION AND OPERATION MANUAL
D10DX.06T – Digital Depth Sounder with Air & Water Temperature, Thru-Hull Transducer
SAFETY INFORMATION:
Periodically wipe the face with a dry cloth. Do not use abrasives or solvents
on this device.
Only qualified personnel should perform repairs or servicing not covered in
this manual.
The LCD used in the product is made of glass. Therefore, it can break
when the product is dropped or impacted.
Keep this product away from heat sources such as radiators, heaters,
stoves and other heat generating sources.
temperatures above 150° F (65° C).
Shade the LCD during storage. Do not expose LCD to direct sunlight for
extended periods of time.
storage.
NOTES, NOTICES, AND CAUTIONS
WARNING: Indicates a potential for property damage, personal injury or
death.
IMPORTANT: Indicates potential damage to the device and tells you how to
avoid it.
NOTICE: Indicates important information that helps you make better use of
the device and tells you how to correct a performance problem.
INFORMATION: Indicates resources to obtain the proper information to help
you make the most of your device.
Read this manual completely before attempting to use or
install your device. Visit our Customer Service Center on our
website for advanced troubleshooting and technical support.
This depth sounder should not be used as a navigational aid
to prevent grounding, boat damage, or personal injury. Always
operate the boat at slow speeds in unfamiliar water, or if you
suspect shallow water or submerged objects.
w w w . h a w k e y e e l e c t r o n i c s . c o m
To ensure safety and many years of trouble-free
operation of your product, please read this
manual carefully before using this product.
Use the supplied cover at all times during
I
:
NFORMATION
W
:
ARNING
Do not store in extreme

Advertisement

loading
Need help?

Need help?

Do you have a question about the D10DX.06T and is the answer not in the manual?

Questions and answers

Summary of Contents for Norcross D10DX.06T

  • Page 1 D10D Model No. INSTALLATION AND OPERATION MANUAL D10DX.06T – Digital Depth Sounder with Air & Water Temperature, Thru-Hull Transducer To ensure safety and many years of trouble-free operation of your product, please read this manual carefully before using this product.
  • Page 2 Transducer that can ONLY be thru hull mounted and requires a hole to be drilled in the bottom of your boat. . The Thru Hull Transducer (D10DX.06T) is suitable for the following vessels: • Outboard, inboard/outboard, single or dual inboard, or jet-drive propulsion.
  • Page 3 to contact us or to complete a transducer exchange request to exchange the transducer for one that is specialized for your vessel. You may also call 888- 766-7276 to inquire about exchanging the transducer. INSTALLING THE DISPLAY Tools & Supplies Required for Installation •...
  • Page 4 OTICE The display can also be surface mounted using the Adjustable Surface Mount Bracket (1000-10). Please visit our website or contact us by phone for purchase information. You must attach the extension rod to the mounting stud on the back of the display housing before inserting the display into the Surface Mount Bracket.
  • Page 5 STEP 3 Connecting of the Power Cable The display has no ON/OFF switch. Therefore, you will need to connect the power harness to a power source that will turn the unit on as power is applied. The key switch or an ON/OFF power switch will be suitable for powering the unit.
  • Page 6: Display Mode Selection

    3. Remove the fuse and check for 12 volt power at the spring located inside the fuse housing that is connected to the vessel’s power source. If 12 volt power is present continue to the next step. If power is not present, return to Step 1. 4.
  • Page 7 To Change the Mode: 1. Press the “UP” Button to change the mode to the Right (The display will change modes from Depth to Water Temperature to Air Temperature) 2. Press the “DOWN” Button to change the mode to the Left (The display will change modes from Depth to Air Temperature to Water Temperature) OTICE When a Temperature Mode is selected the Water or...
  • Page 8: Keel Offset

    DEEP WATER ALARM The deep alarm function can be set for depths ranging from 3 to 200 feet and triggers an alarm when the depth is more than the setting. You must be in the “Depth Sounder” mode to adjust this setting. To set the DEEP ALARM (lower alarm): 1.
  • Page 9: Units Of Measure

    The maximum Keel Offset setting is 20 FT (6.1 M), and can be set in .1 (1/10th) Feet or Meter increments. The unit will read “---” when a negative value occurs due to the Keel Offset subtraction. To set the Keel Offset: 1.
  • Page 10 MOUNTING THE TRANSDUCER OTICE The included transducer needs to be installed in a thru- hull configuration. It CANNOT be glued in-hull. We also offer the option to trade-in the included transducer for a customized transducer. Please visit our website for details. Does the Installation Vessel Have These Characteristics? •...
  • Page 11 STEP 1 Test Before Installation 1. Connect the sensor to the instrument as per the instructions supplied with the instrument. 2. Place the sensor in the water with the transducer face in the horizontal position and aimed towards the sea bottom. 3.
  • Page 12 STEP 2 Choosing a Mounting Location To obtain the best performance, the transducer should be mounted in a location where the water flow beneath the hull is aeration and turbulence-free. Try to mount the transducer as close to the centerline of the boat as possible.
  • Page 13 Mounting Location “DONT’s” OTICE deliver consistent, accurate readings, the transducer must have a continuous supply of non-turbulent water. O NOT MOUNT THE TRANSDUCER IN AN AREA OF TURBULENCE OR BUBBLES Never install the transducer where the boat may be supported during trailering, launching, hauling, or storage. OTICE To Get a Good “View”...
  • Page 14 STEP 3 Drilling the Hole 1. After selecting the mounting location based on STEP 2, place the rubber gasket inside the hull against the mounting location. (illustration A) 2. Ensure that there is at least 1/2” (12 mm) of flat surface area around the rubber gasket.
  • Page 15 STEP 5 Cable Routing & Connection to the Depth Sounder Display Route the cable to the mounting location of the depth sounder transducer plug. • To reduce electrical interference, separate the transducer cable from other electrical wiring. • Coil any excess cable and secure it in place using tie-wraps. •...
  • Page 16 CARE AND MAINTENANCE Aquatic growth can accumulate rapidly on the transducer’s surface. This will greatly reduce its performance. If you notice a degradation in performance of your depth sounder, you may need to clean the transducer. • Clean minor marine growth from the surface with a soft cloth and mild household detergent.
  • Page 17 (F) 407-370-6880, (E) customerservice@norcrossmarine.com (I) www.norcrossmarine.com ARNING © 2010 NorCross Marine Products Inc., All Rights Reserved. ALL unauthorized copying of the content of this document without the expressed written consent of NorCross Marine Products, Inc is strictly forbidden. w w w . h a w k e y e e l e c t r o n i c s . c o m...
  • Page 18 NOTES w w w . h a w k e y e e l e c t r o n i c s . c o m...
