EGT -300 User Manual

Hydrogen rich water purifier
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Hydrogen Rich Water Purifier
EGT-300
User's Manual
Precaution for safe use.
Be sure to read the product to make it more secure.
•
The advantages of Hydrogen water generator
•
Precautions for safe use.
•
Name of each part.
•
Product configuration.
•
How to install before use.
•
Installation overview.
•
How operate the system.
•
How to replace filter.
•
How to remove remained electrolytic water.
•
Filter configuration.
•
Trouble shooting chart
•
Specifications
•
Certificate of warranty
..............................
....................................
....................................
...........................
....................................
..............................
....................................
.........
.................................
.................................
.................................
.................................
...
2p
4p
5p
6p
7p
8p
12p
13p
14p
15p
16p
17p
18p

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EGT-300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EGT EGT-300

Summary of Contents for EGT EGT-300

  • Page 1 Hydrogen Rich Water Purifier User’s Manual EGT-300 Precaution for safe use. Be sure to read the product to make it more secure. … • The advantages of Hydrogen water generator ………………………… • Precautions for safe use. ……………………………… • Name of each part.
  • Page 2 ・ The characteristic of EGT Hydrogen Water Purifier Generation of High-Concentrated Hydrogen-Rich Water • With system control from automatic control program, hydrogen water with more than a certain concentration is always provided by controlling generation of hydrogen, dissolution timing, concentration control of hydrogen water etc.

  • Page 3: Precautions For Safe Use

    Precautions for Safe Use. Before using a product, please make sure to read "Precautions for Safe Use" carefully and use it appropriately. • After reading, please keep it in a place where anyone can see at any time. • Appearance may be subject to change without notice in order to improve the quality of a product. Warning In the event that serious injury or death may occur in violation of instructions given.
  • Page 4 Precautions for Safe Use. CAUTION Do not wipe with thinners, benzene, alcohol etc. Please use it in a safe place with no slope. Do not connect to a hot water pipe, only cold water taps line. Connect only to a cold water supply. Do not move machine when operating.
  • Page 5 • Name of each part Water Spigot Water Lever Drip Tray Grill Drip Tray Side Panel Side Panel Fixing Screw Middle valve Feed Water Supply Power Supply...

  • Page 6: Inside Structure

    • Product configuration Inside Structure LED Light Carbon Filter Water Spigot UF Membrane Filter Hydrogen Generator Module Drip Tray Drain Cap Hydrogen Generator Module PCB Cover Device Filter Head Pressure Regulator(Reducer)

  • Page 7: Package Content

    • How to install before use Package content Please check the components received against your packing slip to make sure you have all the parts Tubing (1/4 Inch) Electric adapter and plug (AC 100~240V,DC 12V 5A) User’s manual Adapter valve Diverter ( Optional ) ⑥...
  • Page 8 • Precaution for safe installation 1. Do not use warm or hot water, as may this damage the machine. 2. Please be sure to turn o adater valve when connecting water supply. 3. Check for any sign of leakage all tubing connections. 4.
  • Page 9 • Installation Overview Counter Top Type Sink Inlet water tubing Cold Adater valve Adater valve ※ For the first time use, please press and hold dispenser and flush 2 liter water over. Connect Water Lines ① Insert the inlet water tubing to water inlet collar located on the rear of the unit. ②...
  • Page 10 • Installation Overview Making Tubing Connections (Tubing is not performance - tested or certified by NSF) ① Measure 3/4” from the ends of tubing ( inlet end) and mark with a pencil. ( Check for roundness, smoothness, cut, nicks, flat spots, and sharp edges.) CORRECT INCORRECT ②...
  • Page 11 • Installation Overview • Tube Outlet Deco Mounting Installation ( Optional ) ① Insert base cover and gasket onto mounting bolt tube outlet deco. ② Insert mounting bolt through the drilled hole in the fixture. ③ Place washer and lock washer and fixing nut onto the mounting bolt. Position tube outlet deco on fixture, then tighten nut securely.
  • Page 12 • How to operate the system • How to use When push dispensing water lever to machine, Water comes out from water spigot. Push When leave the dispensing lever, water will not come out to water spigot.
  • Page 13 • How to replace filter Shut o the adapter valve and the middle valve. Make sure the water has been completely drained from the system. Remove the screw at the rear of the unit and slide the right-hand panel to open cover. Turn the cartridge to the left (counterclockwise) and pull the cartridge straight down to remove it.
  • Page 14 • How to remove remained electrolytic water Shut o the adapter valve and the middle valve. Make sure the water has been completely drained from the system. Remove the screw at the rear of the unit and slide the right-hand panel to open cover. Remove the plug from the end of the drain hose on the right side of the electrolyzer.

  • Page 15: Filter Configuration

    ・ Filter Configuration Outlet Water Inlet Water Filtration Pre Carbon Filter UF Membrane Filter Housing material polypropylene Filter component Carbon Block Polysulfone Capacity( Liter/ Gallon) 1,800L/475 gallon 3,600L/951 gallon Dimension 67( )×203(H) Weight 270g/6lb 240g/5lb...

  • Page 16: Troubleshooting Chart

    ・ Trouble Shooting Chart ※ Check out before requesting help and reporting product failure. ※ Before calling customer’s support, check the following and if you still need help please contact customer support. Symptoms Causes Measures to Be Taken Cold water shut o valve •...

  • Page 17: Specifications

    Specifications • 119 mm 363 mm Hydrogen Rich water Purifier EGT - 300 Model Power Requirement(Volt) 100 ~ 240 V, DC 12 ( 50/60 Hz ) Power Consumption 65 W Water Intake Mechanical Filtration System Quick-Changing Filtration Pressure Limit 0.2 MPa ~ 0.4 MPa (29 psi ~ 58 psi )
  • Page 18 Memo •...
  • Page 19 Memo •...

  • Page 20: Product Warranty

    Product warranty Hydrogen rich water Name of the EGT-300 Name of model. purifier product. Manufacturing number. The date of purchase. Contact information A sales agent. of sales office Customer name. Contact information. Address. This product has been passed the comprehensive inspection through the strict quality control at the factory.
