MICROWAVE OVEN
SERVICE MANUAL
MODEL: MV-1345S
CAUTION
BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
P/NO : 3828W5S0439
All manuals and user guides at all-guides.com
Website http://biz.lgservice.com
April, 1997
Printed in Korea
