6D125E-5 ENGINE This material is proprietary to Komatsu America Corp. and is not to be reproduced, used, or disclosed except in accordance with written authorization from Komatsu America Corp. It is our policy to improve our products whenever it is possible and practical to do so. We reserve the right to make changes or improvements at any time without incurring any obligation to install such changes on products sold previously.
Page 2
DIAGRAMS AND SCHEMATICS..........90-1 00-2 WA470-6, WA480-6 Find manuals at https://best-manuals.com...
Page 19
Decide a place in the repair workshop to keep tools and removed parts. Always keep the tools and parts in their WA470-6, WA480-6 00-3...
Page 20
15. When jump starting the machine, only use a machine of similar size and voltage. Never use a arc welder or other electrical generating equipment to jump start the machine. Carefully review the safety and procedures for jump starting the machine. 00-4 WA470-6, WA480-6...
Page 21
DIAGRAMS AND SCHEMATICS This section has the foldout drawings for the machine. NOTICE The specifications contained in this shop manual are subject to change at any time and without any advance notice. Contact your distributor for the latest information. WA470-6, WA480-6 00-5...
Page 22
(-) and numbered after the page number. File as drained. in the example. Example: 10-4 10-4-1 Added pages 10-4-2 10-5 REVISED EDITION MARK When a manual is revised, an edition mark (bcd…) is recorded on the bottom outside corner of the pages. 00-6 WA470-6, WA480-6...
Page 23
Sling wire ropes from the middle portion of the hook. Slinging near the edge of the hook may cause the rope to slip off the hook during hoisting, and a serious accident WA470-6, WA480-6 00-7...
Page 24
The tightness of fit is decided by the tolerance. • Indication of size of rotating shaft and hole and relationship drawing of them. • Example: Tolerance Standard size Shaft Hole –0.030 +0.046 –0.076 00-8 WA470-6, WA480-6...
Page 25
The allowable maximum interference between the hole of a part and the shaft of another part to be assembled is called the “interference limit”. • The interference limit shows the repair limit of the part of smaller tolerance. • If the interference between the parts exceeds the interference limit, they must be replaced or repaired. WA470-6, WA480-6 00-9...
Page 26
The pins of the male and female connectors are in contact at the crimped terminal or soldered portion, but if there is excessive force brought to bear on the wiring, the plating at the joint will peel and cause improper connection or breakage. 00-10 WA470-6, WA480-6...
Page 27
★ If there is oil or water in the compressed air, the contacts will become even dirtier, so remove the oil and water from the compressed air completely before cleaning with com- pressed air. WA470-6, WA480-6 00-11...
Page 28
★ If the machine is left disassembled for a long time, it is particu- larly easy for improper contact to occur, so always cover the connector. 00-12 WA470-6, WA480-6...
Page 29
★ If the connector cannot be plugged in easily, remove the clamp and adjust the position. ★ If the connector clamp has been removed, be sure to return it to its original position. Check that there are no loose clamps. WA470-6, WA480-6 00-13...
Page 30
(2) while moving it up and down until the locks are set normally. Arrows: 1), 2), 3) ★ Right figure: Lock (a) is pulled down (not set completely) and lock (b) is set completely. (1): Male connector (2): Female connector (a), (b): Locks 00-14 WA470-6, WA480-6...
Page 31
After drying, leave the wiring harness disconnected and carry out a continuity test to check for any short circuits between pins caused by water. ★ After completely drying the connector, blow it with contact restorer and reassemble. WA470-6, WA480-6 00-15...
Page 32
D. When carrying out troubleshooting of circuits (measuring the voltage, resistance, continuity, or current), move the related wiring and connectors several times and check that there is no change in the reading of the tester. ★ If there is any change, there is probably defective contact in that circuit. 00-16 WA470-6, WA480-6...
Page 33
Always keep the oil filler and the area around it clean, and also use clean pumps and oil containers. If an oil cleaning device is used, it is possible to filter out the dirt that has collected during storage, so this is an even more effective method. WA470-6, WA480-6 00-17...
Page 34
The oil cleaning equipment is used to remove the ultra fine (about 3 m) particles that the filter built in the hydraulic equipment cannot remove, so it is an extremely effective device. 00-18 WA470-6, WA480-6...
Page 35
A does not float. In this case, float part A with a small screwdriver while pressing lock (L2), and then pull out connector (1) toward you. Pull Lock Type PACKARD-2 ★ 95 – 170, 12V140 engines WA470-6, WA480-6 00-19...
Page 36
★ If the lock is on the underside, use flat-head screwdriver [1] since you cannot insert your fingers. While pressing up lock (C) of the connector with flat-head screwdriver [1], pull out connector (3) in the direction of the arrow. 00-20 WA470-6, WA480-6...
Page 37
Connector Sensor Fuel pressure sensor in common rail: AMP-3 PFUEL, etc. ★ Injection pressure control valve of fuel supply pump: PCV (SUMITOMO-2) ★ Speed sensor of fuel supply pump: G (SUMITOMO-3) ★ Pull the connector straight up. WA470-6, WA480-6 00-21...
Page 38
★ Housing (H1) is left on the wiring harness side. Connect the connector according to the following procedure. A. Insert the connector to the end, while setting its groove. B. Turn housing (H1) in the direction of the arrow until it clicks. 00-22 WA470-6, WA480-6...
Page 40
Next, operate the hydraulic cylinder three to four times to the end of its stroke. After doing this, run the engine at normal speed. ★ When using the machine for the first time after repair or long storage, do the same procedure. 00-24 WA470-6, WA480-6...
Page 41
• Check the muffler for abnormal sound and sound different from that of a new muffler. • If any abnormal sound is heard, repair the muffler. Refer to both the Troubleshooting and the Disassembly and Assembly sections. WA470-6, WA480-6 00-25...
Page 42
After inserting the hose in the mating adapter, pull it back to check its connecting condition. When the hose is pulled back, the rubber cap portion moves toward the hose about 3.5 mm. This does not indicate an abnormality. 00-26 WA470-6, WA480-6...
Page 43
(2) to disconnect it. CONNECTION Hold the mouthpiece of the tightening portion and push body (2) in straight until sliding prevention ring (1) contacts surface (a) of the hexagonal portion at the male end to connect it. WA470-6, WA480-6 00-27...
Page 44
(2) to disconnect it. CONNECTION Hold the mouthpiece of the tightening portion and push the body (2) in straight until the slide prevention ring (1) contacts surface (a) of the hexagonal portion at the male end to connect it. 00-28 WA470-6, WA480-6...
Page 45
Used as sealant for flange surfaces and bolts Gasket at high temperature locations; used to sealant LG-3 790-129-9070 1 kg prevent seizure. ● Used as sealant for heat resistant gasket for at high temperature locations such as engine pre-combustion chamber, exhaust pipe. WA470-6, WA480-6 00-29...
Page 46
Used for normal temperature, light load SYG2-400CA-A G2-CA Various Various bearing at places in contact with water or SYG2-160CA Grease steam. SYG2- 160CNCA 400 g (10 per ● SYG2-400M Belows type Used for places with heavy load. case) 00-30 WA470-6, WA480-6...
Page 50
White & Red & Yellow & Green & Blue & Color — — Green Green Blue Black Black Code — — — — Yellow & Green & Color — — — Red & Blue — White Blue 00-34 WA470-6, WA480-6...
Page 51
