Summary of Contents for Erskine Attachments Mount Height Adapter
- Page 1 Mount Height Adapter Skid Steer Loaders Operator’s Manual Maintenance Parts Information Read this Manual Before Use...
-
Page 2: Table Of Contents
Serial Number………….._____________ YOUR ATTACHMENT DEALER ADDRESS: PHONE: CONTACT: NOTE: Erskine Attachments LLC reserves the right to make improvements in design or changes in specifications at any time without notice and without incurring any obligations to install them on units previously sold. -
Page 3: Safety
Indicates potentially Erskine Attachments LLC cannot anticipate every hazardous situation which, if not avoided, possible circumstance that might involve potential will result in death or serious injury. hazard. The safety messages found in this manual ... - Page 4 Read the operator’s manuals for the “Skid Steer Maintenance Loader” and the “primary attachment” that the mount height adapter will be used with. NEVER NEVER make adjustments, lubricate, clean, or allow untrained people to operate. perform any service on the machine while it is in operation.
-
Page 5: Serial Number/Decal Location
SERIAL NUMBER AND SAFETY DECAL LOCATIONS Serial Number Location: It is important to refer to the serial number of the attachment when making repairs or ordering parts. Early or later models (identification made by serial number) may use different parts, or it may be necessary to use different procedures in doing a specific operation. -
Page 6: User's Mounting Instructions
USER’S MOUNTING INSTRUCTIONS After the initial set-up assembly is completed use the following procedure to mount the attachment to the loader. Coupler wedges or pins must extend through holes in attachment. Levers must be fully down and locked. Failure to secure wedges or pins can allow the attachment to come off and cause injury or death. -
Page 7: Routine Maintenance
ROUTINE MAINTENANCE Lower the attachment to rest flat on the ground, shut down the engine, set the park brake, and wait for all motion to stop before leaving the operator’s seat to perform service of any kind. It is the operator’s responsibility to make daily inspections of the loader and attachment for damage, loose bolts, fluid leaks, or anything else that could cause a potential service or safety problem. -
Page 8: Parts Information
PARTS INFORMATION ITEM PART NO. DESCRIPTION STOCK NO. 311204 MNT FRAME ADAPTER W/A 311203 FRAME ADAPTER W/A (311322 311231 PLATE HANDLE PAINTED UNPAINTED) 311225 PIN 1.25 X 6.5 W/ANG Z 311201 LATCH PIN LIFT W/A 311223 PIN ROTATING 300458 SPRING 1 1/2 OD X 3.50 COMP 311224 PIN LIFT LINKAGE 300460... -
Page 9: General Specifications
GENERAL SPECIFICATIONS Model Mount Height Adapter Load Limit 4,000 lbs. 8.6” Length 21.7” Height 45.2” Width Operating Weight 165 lbs. All dimensions are in INCHES. -
Page 10: Bolt Torque Information
BOLT TORQUE INFORMATION... -
Page 11: Warranty
Erskine Attachments LLC to improve its products whenever it is possible and practical to do so. Erskine Attachments LLC reserves the right to make changes and or add improvements at any time without incurring any obligation to make such changes or add such improvements to products previously sold. - Page 12 P/N 311232 Date Printed: 2/21/2018 Printed in U.S.A. Erskine Attachments LLC...
