- Page 1 VOZROZHDENIE LLC OKPD 27.90.40.190 ТУ 27.90.40-001-33120038-2018 APPROVED BY ВЗР.2499-00.00.000LU GATE MODELK-17 ВЗР.2499-00.00.000IM INSTALLATION MANUAL 27 sheets 2020...
-
Page 2: Table Of Contents
5.5 Access control and management system connection (optional) ..........16 5.6 Control panel connection to the ACS controller ..............19 Comprehensive inspection ......................22 6.1 Visual inspection and verification of the product readiness for use ........22 Acceptance of the installed product .................... 23 Gate K-17 Installation Manual... - Page 3 ВЗР.2499-00.00.000IM This Installation Manual (IM) applies to Oxgard gate K-17 and its modifications (hereinafter referred to as the product). IM defines rules and a procedure for installation and commissioning of the product. Before installing the product, please read the Operation Manual ВЗР.2499- 00.00.000 (OM) as well.
-
Page 4: General Provisions
AS IT MAY RESULT IN ELECTRIC SHOCK TO PERSONS. INSTALL PRODUCT NOT IN DRY AND HEATED ROOMS, EXCEPT FOR MODIFICATIONS WITH INDEX A. APPLY PASTES AND LIQUIDS CHEMICALLY AGGRESSIVE TO MATERIALS OF THE HOUSING WHEN CLEANING THE PRODUCT. Gate K-17 Installation Manual... -
Page 5: Safety Precautions
FOR DEATH AND DAMAGE TO HEALTH, COMPLETE OR PARTIAL LOSS OF PERFORMANCE OF THE PRODUCT AND/OR AUXILIARY EQUIPMENT IF USER FAILS TO COMPLY WITH THE SAFETY REQUIREMENTS SPECIFIED IN THIS SECTION, AND ALSO VOIDS THE PRODUCT WARRANTY. Gate K-17 Installation Manual... -
Page 6: Preparing The Product For Installation
Rules for visual inspection of the product 3.3.1 Check completeness of the product. Completeness shall be checked according to the Logbook ВЗР.2499- 00.00.000 (LB). 3.3.2 Visually inspect the product. There shall not be visible damage on the product. Gate K-17 Installation Manual... -
Page 7: Product Installation Site Requirements
Figure 1 – overall product dimensions Product installation site requirements ATTENTION: TO AVOID SWING AND/OR OVERTURN DURING OPERATION, INSTALL THE PRODUCT SECURELY. IN CASE OF PRODUCT INSTALLATION ON LOW STRENGTH FLOOR, TAKE MEASURES FOR INSTALLATION SITE FLOOR STRENGTHENING. Gate K-17 Installation Manual... -
Page 8: Product Installation And Dismantling
Attach gate flap to post using set screws. Make sure that gate flap is securely attached to post. Figure 2 – mark out and drill 3 holes of 16mm in diameter in the floor 4.2.4 for the gate post anchors. Gate K-17 Installation Manual... - Page 9 Check that installed gate is vertical in 2 planes, use steel shims of required thickness for the correct gate installation, where necessary. 4.2.9 Fasten gate base flange with three screws M10 by screwing these into the proper anchors using the S6 wrench. Gate K-17 Installation Manual...
-
Page 10: Product Dismantling
4.3.2 Before packing, clean the product from dust and dirt. 4.3.3 Put the product in a packing box. Gate K-17 Installation Manual... -
Page 11: Gate Connection And Setting
Figure 3 – gate diagram and diagram of PSU and control panel connection to gate control board. LED strip / Motor/ Red / Orange / Blue / Green / Solenoid / Encoder / Control panel / Socket / Plug Figure 3 – Gate connection diagram Gate K-17 Installation Manual... -
Page 12: Setting Of Gate Operations Modes
- when gate is in the pulse mode, blue indicator lights up, and while in potential mode, white indicator lights up; - “ANTI-PANIC” LED is flashing, when gate switches to “ANTI-PANIC” mode with corresponding ACS contacts closed, or “ANTI-PANIC” and ”STOP” LEDs are Gate K-17 Installation Manual... - Page 13 - After this, gate is restarted; it switches to the calibration mode, and indicators light up blue (pulse mode) or white (potential mode). Gate K-17 Installation Manual...
- Page 14 5 seconds, only “ANTI-PANIC” LED lights up, and gate switches to “ANTI-PANIC” with closed ACS contacts, otherwise, “ANTI-PANIC” and “STOP” LEDs light up, and gate switches to “ANTI-PANIC” with broken ACS contacts. - Then release “ANTI-PANIC” button. Gate K-17 Installation Manual...
-
Page 15: Power Connection
USE THE POWER SUPPLY UNITS WITH AN OUTPUT CURRENT BELOW PRODUCT POWER CONNECTION USING THE CABLE WITH CROSS- SECTION LESS THAN 1.5MM IS PROHIBITED. WHEN POWER CABLE LENGTH EXCEEDS 10M, IT IS RECOMMENDED TO USE CABLE WITH CROSS-SECTION OF 2.5MM Gate K-17 Installation Manual... -
Page 16: Control Panel Connection
CP is connected through the telephone socket H16 on the gate control board TJ3-6P6C using the telephone connector RJ12(G)\6P6C. TJ3-6\6P6C RJ 12(G)\6P6C Access control and management system connection (optional) The ACS controller shall be connected to the gate control contact group Gate K-17 Installation Manual... - Page 17 To switch to the potential operation mode, follow the operation mode selection instructions in p. 5.2. In this case, left/right passage mode is only enabled as long as the control signal is delivered to LEFT/RIGHT inputs. Gate K-17 Installation Manual...
- Page 18 D23 indicates passage to the right and relay trip (PassOk1 - to the right). D22 indicates passage to the left and relay trip (PassOk2 - to the left). D24 is either constantly on indicating the "AP" command activation (in hold mode). Gate K-17 Installation Manual...
-
Page 19: Control Panel Connection To The Acs Controller
IO1, IO2, IO3, IO4 contacts of control board terminal blocks. (LEFT, RIGHT, STOP, AP) being uncommitted collector outputs. The contact assignment is shown in Table 2, Gate K-17 Installation Manual... - Page 20 "RIGHT" button (3) status STOP "STOP" button (2) status АР "AP" button (4) status LEFT, RIGHT, STOP and АР outputs represent current status of the CP buttons – the transistor opens when corresponding button is pressed. Gate K-17 Installation Manual...
- Page 21 ACS controller or via a relay. Figure 7 – When using the relay, it is MANDATORY(!) to connect a diode in parallel to the winding. U power Cross-board Figure 7 – Diagram for connecting a diode in parallel to the relay winding Gate K-17 Installation Manual...
-
Page 22: Comprehensive Inspection
Check that all cables are securely attached. 6.1.3 Turn the product on and perform functional check by carrying out several test passes. 6.1.4 If no any abnormal noises and operational disturbances are detected, the product is ready for operation. Gate K-17 Installation Manual... -
Page 23: Acceptance Of The Installed Product
"Product Service Record" Section of the Logbook ВЗР.2499-00.00.000 (LB); the "Installation Information” Section of the product Logbook ВЗР.2499-00.00.000 (LB) is filled in; the Commissioning Certificate is issued. Gate K-17 Installation Manual... - Page 24 ВЗР.2499-00.00.000IM Gate K-17 Installation Manual...
- Page 25 ВЗР.2499-00.00.000IM Gate K-17 Installation Manual...
- Page 26 ВЗР.2499-00.00.000IM Gate K-17 Installation Manual...
- Page 27 Vozrozhdenie LLC 192289 Saint-Petersburg 66, Sofiiskaya str. Telephone/Fax +7 (812) 366 15 94 www.oxgard.com info@oxgard.com...
