General Operating Instructions
®
Measuring/Control Stations DULCOTROL
Cooling Water
These general operating instructions facilitate the installation and calibration of the measuring panel inclusive
of its individual component parts. All further processes such as for example the setting of specifi c limit and
control pa ram e ters are described in the individual operating instructions of the ProMinent
®
components.
®
The individual operating instructions are enclosed with the measuring/control station DULCOTROL
cooling water.
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
DULCOTROL
®
cooling water
Please enter the Identcode of your device
These general operating instructions apply only in conjunction
with the individual operating instructions of all supplied individual components.
Please completely read through all operating instructions! Do not discard!
The operator shall be liable for any damage caused by installation or operating errors!
Part no. 986419
ProMinent Dosiertechnik GmbH · 69123 Heidelberg · Germany
BA DR 002 02/09 GB
