PSC Console PC-2
for Distributed Programmable Servo Controller
Operation Manual
Instruction Manual 23005-2E
Reliance Electric Limited

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSC PC-2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Reliance electric PSC PC-2

  • Page 1 PSC Console PC-2 for Distributed Programmable Servo Controller Operation Manual Instruction Manual 23005-2E Reliance Electric Limited...
  • Page 2 The information in this instruction manual is subject to change without notice. Reliance Electric assumes no responsibility for errors that may appear in this manual. Throughout this manual, the following notes are used to alert you to safety considerations: ATTENTION: Identifies information about practices or circumstances that can lead to personal injury or death, property damage, or economic loss.

  • Page 3: Table Of Contents

    ONTENTS Chapter 1 General Information ..................1-1 1.1 Receiving Inspection .................. 1-1 1.2 Storing ......................1-1 Chapter 2 Description of the PSC Console ..............2-1 2.1 Functions of the PSC Console ..............2-1 2.2 Appearance and Components of the PSC Console ........2-2 2.3 Description of Main Components ..............
  • Page 4 Appendix A Error Messages ....................A-1 Appendix B Hardware Basic Specifications ............... B-1 Appendix C Items to be Purchased Separately ..............C-1 Appendix D Key Codes ......................D-1 Appendix E Pin Arrangement of Connector ............... E-1 Appendix F Outline Dimensions ..................F-1 PSC Console PC-2...
  • Page 5 List of Figures Figure 2.1 – Appearance and Main Components of the PSC Console ..2-2 Figure 2.2 – Key Arrangement and Effective Keys ........2-3 Figure 3.1 – Conversion Adapter for Connection between the PSC Console and the PSC3000/PSC4000/PSC5000 System ..3-1 Figure 4.1 –...
  • Page 6 PSC Console PC-2...

  • Page 7: Chapter 1 General Information

    General Information The products described in this Operation Manual are manufactured or distributed by Reliance Electric Limited. The PSC Console PC-2 (hereinafter called "PSC Console) is used for monitoring, setting and modifying various data to be required for the PSC3000/PSC4000/ PSC5000 Programmable Servo Control System.
  • Page 8 PSC Console PC-2...

  • Page 9: Chapter 2 Description Of The Psc Console

    HAPTER Description of the PSC Console This chapter describes the functions that can be performed by the PSC Console, and the components of the PSC Console. ATTENTION: Only qualified personnel who have read and understood all applicable PSC3000, PSC4000 or PSC5000 manuals and are fully familiar with the particular application can set and/or modify the attribute data of the PSC3000, PSC4000 or PSC5000 controller.

  • Page 10: Appearance And Components Of The Psc Console

    Appearance and Components of the PSC Console Figure 2.1 shows the appearance and the main components of the PSC Console. These components will be described in Section 2.3. Hand Strap Connecting Portion Rubber Pad Name Plate Display PC-2 Power Supply +5 VDC MONI PROG...

  • Page 11: Description Of Main Components

    Description of Main Components This section describes the main components of the PSC Console shown in Figure 2.1. 2.3.1 Display The display consists of 20 characters x 4 lines and each character consists of 5 x 7 dots. 2.3.2 Keyboard Figure 2.2 shows the key arrangement of the PSC Console keyboard.

  • Page 12: Reset Switch

    2.3.3 Reset Switch As shown in Figure 2.1, there is a switch called "Reset Switch" at the left lower corner on the rear side of the PSC Console. Pushing the Reset Switch with a thin bar like needle will initialize the PSC Console. 2.3.4 Interface Cable and Connectors Communication between the PSC Console and the PSC3000, PSC4000 or PSC5000 System is performed through the interface cable and the connectors.

  • Page 13: Chapter 3 Preparation Before Using The Psc Console

    HAPTER Preparation before Using the PSC Console This chapter describes connection of the PSC Console to the PSC3000, PSC4000 or PSC5000 System and the standard setting for operation of the PSC Console. Connection of the PSC Console to the PSC3000/ PSC4000/PSC5000 System The interface cable connector on the PSC3000, PSC4000 or PSC5000 System side must be connected to the PORT-A of the PSC Power Supply Card or PSC Power...

  • Page 14: Standard Settings For Operation Of The Psc Console

    Standard Settings for Operation of the PSC Console ATTENTION: Changing the settings of the PSC Console may cause malfunction of the system. Exercise extreme caution when the setting of the PSC Console must be changed. Note that the settings of the PSC Console will be maintained even when the power to the Console is disconnected.

  • Page 15: Chapter 4 Operation Of The Psc Console

    HAPTER Operation of the PSC Console This chapter describes operation modes of the PSC Console, how to select each operation mode and how to operate the PSC Console in each operation mode. Operation Modes of the PSC Console There are the following three operation modes: "RUN", "MONITOR" and "PROGRAM"...

  • Page 16: Operation Of The Psc Console In The Run Mode

    Operation of the PSC Console in the RUN Mode The RUN Mode must be selected for normal operation of the PSC3000, PSC4000 or PSC5000 System. This section describes the selection method of the RUN Mode and the keys that can be used in the RUN Mode. 4.2.1 Selection of the RUN Mode To select the RUN Mode of the PSC Console, press the RUN key.

  • Page 17: Operation Of The Psc Console In The Monitor Mode

    Operation of the PSC Console in the MONITOR Mode The MONITOR Mode must be selected to monitor the values of the control variables. This section describes how to select the MONITOR Mode and how to operate the PSC Console in the MONITOR Mode. 4.3.1 Selection of the MONITOR Mode To select the MONITOR Mode of the PSC Console, press the MONITOR key.

  • Page 18: Key Operations And Displays In The Monitor Mode

    4.3.3 Key Operations and Displays in the MONITOR Mode This section describes various key operations in the MONITOR Mode and the displays obtained as a result of such key operations. 4.3.3.1 To Display Control Variable When you press the MON key, "M" will appear in the display as shown below. If it is followed by pressing the 0 to 9 ENTER keys, the control variable of the entered number will be shown in the Display Line 1 (for the Display Line 1, see the...

  • Page 19: To Display Additional Control Variables

    4.3.3.3 To Display Additional Control Variables To display other control variable(s) in addition to control variable already displayed, press the following keys in the following order. 0 to 9 ENTER The additional control variable(s) is (are) displayed in the Display Lines 2 and 3 (for the Display Lines 2 and 3, see the figure in Section 4.3.1).

  • Page 20: Operation Of The Psc Console In The Program Mode

    Operation of the PSC Console in the PROGRAM Mode The PROGRAM Mode is used for displaying, setting and modifying the attribute data. This section describes the selection method of the PROGRAM Mode and the operation of the PSC Console in this mode. 4.4.1 Selection of the PROGRAM Mode Press the PROGRAM key to select the PROGRAM Mode.

  • Page 21: Key Operations And Displays In The Program Mode

    4.4.3 Key Operations and Displays in the PROGRAM Mode This section describes various key operations in the PROGRAM Mode and the displays to be obtained as a result of such key operations. 4.4.3.1 To Display Attribute Data When you press the DATA key, "D" will appear in the System Line of the display as shown below (for the System Line, refer to the figure in Section 4.4.1).
  • Page 22 To modify an attribute data, first enter the desired figure. The entered figure will be shown in the Attribute Data Setting/Modifying Line of the display. After verifying that the entered figure is correct, press the ENTER key. If the entered figure is incorrect, press the CLR key and then enter the correct figure.
  • Page 23 Example: When you desire to set the attribute data No. 100 to "–100.1", use the following procedure. Press the following keys to display the present setting as follows. DATA ENTER P R O G R A M D 1 0 0 : 1 0 0 .

  • Page 24: To Discontinue Modification Of Attribute Data

    4.4.3.4 To Discontinue Modification of Attribute Data When you desire to discontinue modification of the attribute data, press the ENTER key without entering any number; i.e., pressing the CLR ENTER keys discontinues modification. 4.4.3.5 To Scroll Attribute Data When you desire to monitor the attribute data by scrolling, use the following procedure.

  • Page 25: Appendix A Error Messages

    PPENDIX Error Messages The following shows the error messages to be displayed on the PSC Console. When such error messages appear, take the corrective actions in accordance with the following instructions. Error Message: TRANSFER FAILED Causes • A communication error occurred when the PSC Console was connected to or disconnected from the PSC3000/PSC4000/PSC5000 System.
  • Page 26 PSC Console PC-2...

  • Page 27: Appendix B Hardware Basic Specifications

    PPENDIX Hardware Basic Specifications Display element : Model STN Liquid Crystal Number of characters that can be displayed : 20 characters x 4 lines Construction of characters displayed : 5 x 7 dots matrix Size of characters displayed : 2.45 mm W x 3.95 mm H Effective display area : 57.55 mm W x 17.15 mm H Kind of characters that can be...
  • Page 28 PSC Console PC-2...

  • Page 29: Appendix C Items To Be Purchased Separately

    PPENDIX Items to be Purchased Separately The following items are to be purchased by the user separately. • Dedicated Holder Case Part No. PHC810-00 (See the following figure) • Conversion Adaptor Part No. SM-9407 • Hand Strap Part No. PHS810-00 Dedicated Holder Case Wall or Equipment Case M4 Screws x 2...
  • Page 30 PSC Console PC-2...

  • Page 31: Appendix D Key Codes

    PPENDIX Key Codes The following figure shows the hexadecimal codes to be sent out when the keys of the PSC Console are pressed. The upper characters in each key show the legend of the key and the lower characters show the hexadecimal code of the key. MONITOR PROGRAM P-ROM...
  • Page 32 PSC Console PC-2...

  • Page 33: Appendix E Pin Arrangement Of Connector

    PPENDIX Pin Arrangement of Connector The following table shows the pin arrangement of the connector. Pin No. Symbol Signal Input/Output Frame Grounding Transmitting Data Output Receiving Data Input Request for Transmission Output Transmission OK Input Data Set Ready Input Signal Grounding PWR+ Power Supply 5 V (Vcc) Input...
  • Page 34 PSC Console PC-2...

  • Page 35: Appendix F Outline Dimensions

    PPENDIX Outline Dimensions M2.6, 4 pos. 68.5 7.6 dis., 4 pos. 6 dia., 4 pos. PC-2 Power Supply +5 VDC MONI PROG Interface Type RS232C SHIFT P-ROM Serial No. INTERNIX ALLCLR VRFY DATA PLAY POFF TEST 3 dia. hole ENTER RESET 76.8 71.5...
  • Page 36 PSC Console PC-2...
  • Page 38 Reliance Electric Limited 3-2, Fukuura 2-chome, Kanazawa-ku, Yokohama 236-8641 Phone 045 (701) 1770 FAX 045 (783) 7486 Yokohama Sales Office 3-2, Fukuura 2-chome, Kanazawa-ku, Yokohama 236-8641 Phone 045 (791) 3115 FAX 045 (785) 0276 Osaka Sales Office Shin-Osaka IN Bldg, 5-14-5 Nishi-nakajima, Yodogawa-ku, Osaka 532-0011...
