- Page 1 H.R.UV-C SPA - PRO Installation and Operating Manual HRP-30-SPA ENGLISH...
-
Page 2: Table Of Contents
CONTENTS IMPORTANT SAFETY INSTRUCTIONS ................... 3 PRODUCT OVERVIEW ........................3 GENERAL INSTALLATION INSTRUCTION ..................5 3.1 Mounting instructions ........................5 Pipe work ........................... 6 Flow direction ..........................6 3.4 Connection ............................. 7 3.5 Electrical connection ........................8 OPERATING INSTRUCTIONS ......................9 4.1 Flow requirements .......................... -
Page 3: Important Safety Instructions
Introduction Thank you for purchasing the H.R.UV-C SPA pool sanitising system, the latest in high reflection UV technology, manufactured to the highest standards in England. To ensure years of trouble-free service, please read and follow these instructions for proper installation, maintenance and use. - Page 4 Fig. 1 Dimensions:...
-
Page 5: General Installation Instruction
3. GENERAL INSTALLATION INSTRUCTION 3.1 Mounting instructions The H.R.UV-C SPA should be either installed horizontally or vertically allowing enough space for the pipe connections, wiring and Maintenance of lamps/Quartz sleeve. It should be firmly secured, using the fixing kit provided, to a Solid wall. NOTE: When mounting the UV, it is essential to leave a clearance space of at least 1 metre from one side of the unit to allow access to replace the lamp(s) and/or quartz... -
Page 6: Pipe Work
3.2 Pipe work The H.R.UV-C SPA should be placed downstream (after) of any pumps, filters and heating devices but upstream (before) of any chemical dosing or similar water treatment (see Figs. 4 and 5). Fig. 4 3.3 Flow direction H.R.UV-C SPA is factory set to accept input water flow entering on the left and exiting on the right,... -
Page 7: Connection
The Flow can be reversed by rotating the flow switch 180 degrees (i.e. ½ turn - see Fig. 6). WARNING: The flow switch paddle can be damaged when reversing the flow direction if it is lifted by more than 5mm from its housing and turned with force. If the flow switch has been rotated it is important to ensure that it is finally locked in the correct orientation perpendicular (at right angles) to the flow of water. -
Page 8: Electrical Connection
For pipework 50-mm or 1½“ in diameter. Fig. 7 All factory unions are made from ABS plastic, when gluing connections to ABS pipe an ABS cement must be used or when using a PVC pipe, a Transition cement must be used (See Fig. 7). There is no need to use mastic or PTFE tape to connect unions to the H.R.UV-C SPA, use the O-rings provided to put in the groove on the end of the Manifold Assembly. -
Page 9: Operating Instructions
4. OPERATING INSTRUCTIONS 4.1 Flow requirements Minimum flow rate: • /hour (1,000 litres per hour) Maximum flow rate: • 30W (Mini) = 12m /hour (12,000 litres per hour) • A higher flow rate will require the installation of a bypass to prevent damage to the unit. This unit is a plug and play device so as long as the minimum flow rate is achieved the unit will work as soon as the power is switched on. - Page 10 STEP ONE Components required. STEP TWO Unscrew securing cap anti-clockwise. STEP THREE Thread tube through the securing cap (1) and component (2), then push the pipe onto component (3) STEP FOUR Once all components are looped through the tubing tighten securing cap. STEP FIVE Lastly unscrew the retaining gland and insert tube over the connection point.
- Page 11 The language menu is displayed on each power up of the unit. The factory default setting for the language is English. To change to another language, press the buttons until the desired language appears, press OK to select and save. The digital controller has four programmable functions: •...
- Page 12 The controller is pre-programmed to dose two chemical types: A. Hydrogen Peroxide / Active Oxygen / H₂O₂ Liquid Chlorine Part 1 buttons until “DOSE CHEMICAL” is displayed, press the To set the type of chemical: use the O.K. button and then use the buttons to choose: A.
- Page 13 For a concentration of 12% the above dosing amount should be multiplied by 3 (i.e. the dose for a 50m³ pool would need to be increased to 960ml/day when the H₂O₂ strength is 12%). For any other concentration strengths, the dose amount should be adjusted pro-rata as required. The digital controller will automatically sense the temperature of your water and adjust the required dose accordingly.
-
Page 14: Maintenance
• NOTE: the time must be entered in the 24-Hour format. • The display will now revert to showing the UV lamp life remaining and the current time. Shock Dose The shock dose feature enables the operator to shock dose the pool immediately with a chosen volume of the dispensing chemical. - Page 15 Unclamping the clip from body 1. Pull the clip in shown direction to Unscrew all the highlighted fasteners unlock from body 2. Pull the second side after unlocking the 1 side Remove Lamp holder Clip from Hard cap Unmount the Hard cap from Blue lamp Holder Carefully remove the blue lamp holder shroud white plastic electrical end caps from...
- Page 16 Gently slide the lamp out ensuring that no Unscrew the blue quartz sleeve locking nut pressure is applied to the glass quartz anticlockwise. Both ends must be sleeve. unscrewed before the quartz sleeve can be removed. Slide the O-ring off the quartz sleeve The quartz sleeve can now be removed.
-
Page 17: Intelligent Dosing Pump Routine Maintenance
NOTE: Pinch the blue lamp holder shroud as you reassemble the unit to release any trapped air. Failure to release the trapped air may cause the lamp holder to disconnect from the lamp end. Turn on the water supply to check for leaks before reconnecting the electric supply. - Page 18 STEP THREE Cut the two black securing ties at either end of the tube. This will then release the tube, which can be discarded. STEP FOUR Take replacement tube re-attach connection points. Loop securing ties in place in order to seal to the connection points. Once securely in place cut the excess tie and dispose of.
-
Page 19: Disposal Of Electrical/Electronic Equipment
6. DISPOSAL OF ELECTRICAL/ELECTRONIC EQUIPMENT DO NOT dispose of this product as an unsorted municipal waste. This symbol on the product or on the packaging indicates that this product should not be treated as household waste. Instead it should be handed over to the applicable collection point for the recycling of electrical and electronic equipment. - Page 20 Rectangle and Square Pools Volume = Length (L) x Width (W) x Depth (D) or Average Depth Circular Volume = π (3.142) x Radius2 x Depth (D) OR Average Depth Radius = Diameter divided by 2 Ellipses Volume = π (3.142) x A x B x Depth (D) OR Average Depth Irregular Shapes For irregular shapes, calculating the area is less accurate.
- Page 21 Notes: ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ………………………………………………………………………………………………. ……………………………………………………………………………………………….
- Page 22 Elecro Engineering Ltd Repairs Department Unit 11 Gunnels Wood Park Gunnels Wood Road Stevenage Hertfordshire SG1 2BH United Kingdom __________________________________________________________________________________ Customer Information: (ATTACH TO HEATER) ………………………………………………………………………………. Company Name: ………………………………………………………………………………. Contact Name: Daytime Telephone Number: ………………………………………………………………………………. ……………………………………………………………………………….. Email Address: ……………………………………………………………………………….. ………………………………………………………………………………..
- Page 24 Unit 11, Gunnels Wood Park, Stevenage, Herts SG1 2BH Sales@elecro.co.uk www.elecro.co.uk +44 (0) 1438 749474 © Copyright MANE321-EN- H.R.UV-C SPA PRO Manual V1-29.09.2021-Elecro...
