Instruction Manual
Battery crimping tool HL-300B
Instruction Manual
Battery crimping tool HL-300B
Due to continuing improvements, actual product may differ slightly from
the product described here in.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL
Advertisement
Table of Contents
Summary of Contents for Hewlee HL-300B
- Page 1 Instruction Manual Battery crimping tool HL-300B Instruction Manual Battery crimping tool HL-300B Due to continuing improvements, actual product may differ slightly from the product described here in. Read this material before using this product. Failure to do so can result in serious injury.
-
Page 2: Limited 1 Year Warranty
SAVE THIS MANUAL LIMITED 1 YEAR WARRANTY Keep this manual for the safety warnings and precautions, assembly, operating, We make every effort to assure that its products meet high quality and durability inspection, maintenance and cleaning procedures. Write the month and year of standards, and warrants to the original purchaser that this product is free from purchase. -
Page 3: Please Read The Following Carefully
PLEASE READ THE FOLLOWING CAREFULLY GENERAL SAFETY RULES THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A TO WORK IN SAFE CONDITIONS WITH THIS TOOLING, IT IS IMPERATIVE TO REFERENCE TOOL ONLY. NEITHER MANUFACTURER READ CARFULLY THE DIRECTIONS FOR USE AND TO FOLLOW THE DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY... -
Page 4: Personal Safety
Standard hexagonal die size: 10.16.25.35.50.70.95.120.150.185.240.300 mm The best temperature for charging is between 10℃ - 40℃. Make sure the air hole of the battery and charger are uncovered during charging. Please pull out the plug when meet a bad weather. Please do not burn the battery or make it being short-circuited, it may cause explosion. -
Page 5: Understand Your Tool
UNDERSTAND YOUR TOOL HL-300B is a tool for crimping Cu/Al lugs with cables from 10-300mm It is powered by Li-ion, actuated by motor and controlled by MCU. With a high pressure hydraulic system, it is a perfect tool to be used in electrical construction site. -
Page 6: Description Of Components
2. Description of components: The crimping process can be interrupted at any moment by releasing the trigger. Do not put your fingers into the head of the tool during operating. Your fingers could be pinched very severely. Parts No. Description Function Die holder For fixing die... -
Page 7: Function Description
3. Function description The battery can be used for hundreds of times, when the life span reduced obviously, change to a new battery please. MCU - automatically detect the pressure during operation and provide security protect, shut off the motor and reset automatically after Please charging the battery in time to avoid it to be used up absolutely;... - Page 8 In addition we see a lower power weight ratio with 50% more capacity and OPERATING INSTRUCTION shorter charging cycles compare to Ni-MH batteries. Please check carefully before operating. Make sure the tool is complete and has no A Temperature sensor makes the tool stop working automatically damage part.
