Easy
Leak
EP Easy Leak detector consists of the following:
www.elektropartner.dk/en - tlf.: +45 75 31 09 06
LEAK
LEAK
DETECTOR
DETECTOR
User´s manual
1 Smoke box unit
1 2.7 metres of battery cable
1 Oil level dipstick
1 2.7 metres of smoke hose
2 Smoke injectors
7 Centralizing rings for smoke injectors
42 Blind plugs
½ litre of smoke oil
Advertisement
Table of Contents
Summary of Contents for ELEKTRO PARTNER Easy Leak
- Page 1 LEAK Easy DETECTOR DETECTOR Leak User´s manual EP Easy Leak detector consists of the following: 1 Smoke box unit 1 2.7 metres of battery cable 1 Oil level dipstick 1 2.7 metres of smoke hose 2 Smoke injectors 7 Centralizing rings for smoke injectors 42 Blind plugs ½...
- Page 2 Field of application: Easy Leak detector is primarily designed to search for leaks in the intake and exhaust systems of vehicles with diesel or petrol engines. The device can emit a dense smoke, which clearly reveals bad sealing, cracks, and chinks, which allow air to leave and enter, as well as leaking gaskets and joints.
- Page 3 Safety instructions: Always abide by the below rules when working with Easy Leak detector. Preconditions at the workplace: Place the system or vehicle you are about to test on a level surface. The device must always stand horizontally during use, oil filling as well as during storage.
- Page 4 Filling of smoke oil and oil level control: OIL DIPSTICK 1. Place Easy Leak detector horizontally on the work table. 2. The oil screw is located on top of the device and is removed with a 6 mm hexagon key.
