572
TM
ROUND
BALER
Operating Instructions
and Parts Reference
PO B
1940, J
, nD 58402-1940
Ox
amestOwn
MAY 2013
0500145

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Haybuster 572 and is the answer not in the manual?

Questions and answers

Summary of Contents for DuraTech Industries Haybuster 572

  • Page 1 ROUND BALER Operating Instructions and Parts Reference PO B 1940, J , nD 58402-1940 amestOwn MAY 2013 0500145...
  • Page 2 A Tradition of Innovation Since 1966...
  • Page 3 572 Round Baler as of the date of publication. DuraTech Industries reserves the right to make updates to the machine from time to time. Even in the event of such updates, you should still find this manual to be appropriate for the safe operation and maintenance of your unit.
  • Page 4 A Tradition of Innovation Since 1966...
  • Page 5 F O R E W O R D Foreword All personnel must read and understand the following sections before operating the 572 Round Baler. • Foreword and Section 1, important safety information. • Section 2.1, “Pre-Operation Inspection”. • Section 3, “Machine operation,” which explains normal operation of the ma- chine.
  • Page 6 A Tradition of Innovation Since 1966 5 7 2 R O U N D B A L E R O P E R A T I N G I N S T R U C T I O N S...

  • Page 7: Table Of Contents

    T A B L E O F C O N T E N T S Part 1: Operating Instructions ........1 Introduction ................. 2 Purpose ..................2 Section 1: Safety ................. 4 1.1 Safety-alert symbols ..................4 1.2 Operator - personal equipment ..............6 1.3 Machine safety labels ..................
  • Page 8 T A B L E O F C O N T E N T S Section 4: Baler Adjustment ............. 24 4.1 Bale Density Gauge ..................24 4.2 Adjusting Bale Density .................. 24 4.3 Adjusting twine tension ................. 25 4.4 Adjusting gauge wheels ................. 25 4.5 Gate Locking Procedure ................
  • Page 9 T A B L E O F C O N T E N T S 6.3 Gearbox Lubrication ..................49 6.4 Hydraulic Cylinders and Valves ..............49 Section 7: Maintenance ............50 7.1 General Appearance ..................50 7.2 Welding Procedure ..................50 Section 8: Options..............
  • Page 10 LOWER DRIVE ROLLER ASSEMBLY ............108 SHORT IDLER ROLLER ASSEMBLY .............. 110 STARTER ROLLER ASSEMBLY ............... 112 UPPER DRIVE ROLLER ASSEMBLY .............. 114 HYDRAULIC CYLINDER SEALS AND OTHER ITEMS ....... 116 BALE KICKER (OPTIONAL) ................118 NET WRAP (OPTIONAL) .................. 120 HYDRAULIC VALVE - 4000497 ...............

  • Page 11: Part 1: Operating Instructions

    ROUND BALER Part 1: Operating Instructions 5 7 2 R O U N D B A L E R O P E R A T I N G I N S T R U C T I O N S...

  • Page 12: Introduction

    Introduction The 572 Round Baler is designed to produce round bales. To avoid possible damage to the machine and risk of injury to the operator, consult with a DuraTech Industries International, Inc. (DuraTech Industries) representative if you have any questions.
  • Page 13 Decals are illustrated in Part 2: Parts Reference. • Complete and return the Warranty Registration postcard. DuraTech Industries must receive this form before activating the warranty. Appendix A provides details of the warranty.

  • Page 14: Section 1: Safety

    Section 1: Safety The safety of the operator is of great importance to DuraTech Industries/Haybuster. We have provided decals, shield and other safety features to aid you in using your machine safely. In addition, we ask you to be a careful operator who will properly use and service your Haybuster equipment.
  • Page 15 DuraTech Industries uses industry accepted ANSI standards in labeling its products for safety and operational characteristics. Safety-Alert Symbol Read and recognize safety information. Be alert to the potential for personal injury when you see this safety-alert symbol. DANGER: Indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury.

  • Page 16: Operator - Personal Equipment

    1.2 Operator - personal equipment THE OPERATOR Physical Condition You must be in good physical condition and mental health and not under the influence of any substance (drugs, alcohol) which might impair vision, dexterity or judgment. Do not operate a 572 Round Baler when you are fatigued. Be alert - If you get tired while operating your 572 Round Baler, take a break.

  • Page 17: Machine Safety Labels

    Machine safety labels The safety decals located on your machine contain important information that will help you operate your equipment. Become familiar with the decals and their locations. DANGER: ROTATING PARTS WITHIN CAN KILL OR DISMEMBER. WAIT FOR ALL MOVEMENT TO STOP BEFORE SERVICING, UNLOADING, OR INSPECTING MACHINE.
  • Page 18 DANGER: STAND CLEAR OF SIDES AND REAR OF MACHINE. TAILGATE OPENS FASTER THATN YOU CAN MOVE AWAY. FAILURE TO COMPLY WILL RESULT IN DEATH OR SERIOUS INJURY. 6500469 DANGER: TO AVOID INJURY OR DEATH BY BEING PULLED INTO THE MACHINE: DISENGAGE PTO AND SHUT OFF ENGINE.
  • Page 19 WARNING: FOR YOUR PROTECTION AND SAFETY OF OTHERS, READ AND UNDERSTAND OPERATORS MANUAL BEFORE OPERATING MACHINE. READ AND UNDERSTAND OPERATORS MANUAL BEFORE OPERATING MACHINE. PLACE ALL CONTROLS IN NEUTRAL, STOP ENGINE, REMOVE IGNITION KEY, LOCK OUT POWER SOURCE, AND WAIT FOR ALL 6500208 MOVEMENT TO STOP BEFORE SERVICING, ADJUSTING, REPAIRING, OR UNPLUGGING.

  • Page 20: Shielding

    WARNING: NEVER PLACE BALES WHERE THEY COULD ROLL DOWNHILL. BALES ARE HEAVY, LARGE AND ROUND. FAILURE TO COMPLY WILL RESULT IN DEATH OR INJURY. 6500470 CAUTION: ADJUST TRACTOR DRAWBAR SO THAT THE DISTANCE FROM THE END OF THE P.T.O. SHAFT ON THE TRACTOR TO THE CENTER OF THE DRAWBAR HITCH PIN IS 16”.

  • Page 21: Safety Review Section

    Safety review Section BEFORE OPERATING • Read and follow all instructions contained in: This 572 Round Baler operator’s manual Tractor operator’s manual Decals placed on the 572 Round Baler. NOTE: Additional copies of the above mentioned materials can be obtained from your dealer. •...

  • Page 22: Towing/Road Transport

    Check periodically and tighten any loose bolts or connections. • Use only replacement parts that are recommended by DuraTech Industries. • If it is necessary to operate the tractor engine indoors for more than a few seconds, be sure to provide enough ventilation to remove the tractor exhaust fumes.

  • Page 23: Fire Prevention

    1.7 Fire prevention Baling hay can produce large amounts of potentially combustible materials during the process. The risk of fire can be significantly reduced with proper operating and maintenance procedures. This does include frequent removal of dust, debris, and combustible materials. Most products baled can produce fine dusty material.

  • Page 24: Section 2: Pre-Operating

    Section 2: Pre-Operating There is no substitute for a sound preventive maintenance program and a well trained operator. To insure the long life and economical operation, learn how to operate the 572 Round Baler and how to use the controls properly.
  • Page 25 Check condition of decals. Replace if excessively worn. Check lug nuts for tightness. A minimum of 120 ft.‑lbs. Check conditions of the tire rims. Check tires for proper air pressure of 25 psi. Remove any buildup of material on the pickup and rotating parts. Make sure the SMV sign is installed.

  • Page 26: Section 3: Baler Operation

    Section 3: Baler Operation When operating the 572 Round Baler make sure that everyone is clear and/or at a safe distance from the tractor and baler. No one other than the operator should ride the tractor or baler. NO RIDERS! 3.1 Normal shutdown procedure For your safety and the safety of others, you must use the following normal shut‑down procedure before leaving the tractor controls unattended for any reason, including servicing, cleaning, or inspecting the 572 Round Baler.

  • Page 27: Hitching To Tractor

    3.2.2 Hitching to Tractor Adjust jack for tractor height. Position tractor so hitch pin can be installed, and install pin. The hitch pin should be sized to prevent excessive movement and should extend through all components of the hitch. The pin should be secured with a hairpin clip or suitable device to prevent loss of pin.

  • Page 28: Adjusting Hydraulic Outlets

    3.2.4 Adjusting Hydraulic Outlets The tractor must be equipped with 2 double acting control valves, 1 valve for control valve, and 1 valve to lift the pickup. Recommended hydraulic flow is 8 to 12 gallons per minute. The round baler has a hydraulic control system that requires locking one of the tractors hydraulic control valves continuously.

  • Page 29: Twine Routing

    3.3.3 Twine Routing The routing for the twine is depicted in the following pictures. Left-Hand side twine Right-Hand side twine 5 7 2 R O U N D B A L E R O P E R A T I N G I N S T R U C T I O N S...
  • Page 30 Routing through dual twine arms right twine arm left twine arm 5 7 2 R O U N D B A L E R O P E R A T I N G I N S T R U C T I O N S...

  • Page 31: Wheel Nut Torque (Lug Bolts)

    3.3.4 Wheel Nut Torque (lug bolts) Wheel nuts need to have a torque minimum of 120 ft.‑lbs. 3.3.5 Tires and rims Tires should be inflated to 25 PSI and should be free of cuts or cracks. There should also be adequate tread and no visible cords, wires or tread separation.

  • Page 32: Road Transport

    3.7 Road Transport 3.7.1 Preparing baler for transport Empty bale chamber. Close tailgate completely Raise pickup fully. Clean SMV, reflectors, warning lights and make sure they operate with the tractor. Check that safety chain is attached to the drawbar of the tractor or towing vehicle. If transporting with another vehicle, remove PTO driveline assembly and secure machine half of PTO to hitch of baler.

  • Page 33: Storing The 572 Round Baler

    3.9 Storing the 572 Round Baler WARNING: When preparing machine for storage, use normal shut-down procedure. To prepare the unit for storage, perform the following steps: Clean the machine thoroughly to prevent rust and to make inspections easier. Check for loose or worn chains, belts, sprockets and pulleys. Check condition of the bearings.

  • Page 34: Section 4: Baler Adjustment

    Section 4: Baler Adjustment 4.1 Bale Density Gauge The bale density gauge is a visual reading of the pressure being exerted by the tension circuit which determines the amount of hay being put into the bale. The lower the reading, the less hay and softer bale you will make. The higher the reading, the more hay and harder bale will be made.

  • Page 35: Adjusting Twine Tension

    4.3 Adjusting twine tension The tension put on the twine as it is pulled off the ball will determine how tightly it is applied to the bale. Adjust the tension by tightening the bolts on the tension springs to create resistance as shown in the pictures below. 4.4 Adjusting gauge wheels To adjust pickup tooth to ground clearance, adjust gauge wheel height on each end of pickup.

  • Page 36: Gate Locking Procedure

    4.5 Gate Locking Procedure DANGER: Make sure no one is near the tailgate before opening it. DANGER: Engage tailgate lock and install cylinder stop before working on or around baler with tailgate in raised position. When servicing baler with tailgate in raised position, always lock tailgate up hydraulically and install cylinder stop. The lockout valve is conveniently located by the left hand baler tire.

  • Page 37: Adjusting Main Drive Chain Tension

    4.7 Adjusting Main Drive Chain Tension Periodic drive chain adjustment is necessary to extend chain life. Adjust tension bolt so there is 1/8” of clearance between the bushing and the mounting channel. tension adjustment bolt 4.8 Adjusting pickup drive chain Remove gauge wheels and end shields on both ends of pickup.

  • Page 38: Adjusting Belt Tracking

    4.9 Adjusting belt tracking The lower rear roller on the tailgate can be adjusted up and down to adjust belt tracking. Adjusting the roller down on the right or up on the left will move the belts to the left. bolt (B) Adjusting the roller up on the right or down on the left will move the belts to the right.

  • Page 39: Material Trap Cleanout And Inspection

    4.11 Material Trap Cleanout and Inspection WARNING: Use normal shut down procedure (Section 3.1) before inspection and cleanout of material trap. DANGER: Engage tailgate lock and install cylinder stop before working on or around baler with tailgate in raised position. The 572 Round Baler is equipped with a material catch pan to feed valuable feed that falls through the belts during the baling process back into the baler.

  • Page 40: Belt Installation And Routing

    4.14 Belt Installation and Routing WARNING: Use normal shut down procedure (Section 3.1) before inspection and cleanout of material trap. DANGER: Engage tailgate lock and install cylinder stop before working on or around baler with tailgate in raised position. Install belts with rough top side of belt to outside of machine. Open tailgate.

  • Page 41: Twine Pincher Adjustment

    4.15 Twine Pincher Adjustment To adjust the twine pincher, turn clevis counter clockwise to lengthen and to shorten turn clevis clockwise. Figure 4.5 Twine pincher adjustment location clevis 5 7 2 R O U N D B A L E R O P E R A T I N G I N S T R U C T I O N S...

  • Page 42: Section 5: Monitor

    Section 5: Monitor 5.1 Monitor Operation 5.1.1 Bale Monitor Screen The bale monitor screen is the default screen. This screen displays most of the operational machine data. By pressing button 1 from this screen the operator can access the Bale Count Screen. Button 2 will reset a tie sequence. Button 3 initiates an auto tie sequence at any bale size as long as the system is set to “Auto”.

  • Page 43: Calibration Of The 572 Baler - General

    5.2 CALIBRATION OF THE 572 BALER – General Connect the PTO. Connect the pickup lift hoses. Connect the baler hoses. Connect monitor. Connect monitor to power outlet. 1. TWINE ARM CALIBRATION With the tractor running and the hydraulic lever locked in detent allowing oil flow through the valve body, press button #6 and check fault screen.
  • Page 44 3. BALE SHAPE CALIBRATION With the tractor running and the hydraulic lever locked in detent allowing oil flow through the valve body, the tailgate fully closed and the chamber empty. Engage PTO and run baler for a brief period and then disengage PTO. Check fault screen.

  • Page 45: Other Diagnosis

    5.3 Other Diagnosis 1. Slip Clutch Warning • “Slip Clutch” will be displayed on the monitor screen if the PTO is engaged but the pickup isn’t rotating. • If the pickup is rotating with the PTO engaged, shut the machine down and remove the access cover to the proximity switch for the pickup located on the right side of the machine.

  • Page 46: Menu Screen

    5.4 Menu Screen 5.4.1 Misc. Setup Screen This is the misc. setup screen. It can be accessed by pushing button 3 on the menu screen. This screen allows the operator to toggle the twine buzzer, backlight, gate manual or auto and reset the bale size calibration by pressing the corresponding button.

  • Page 47: Misc Setup Screen

    5.4.4 Misc Setup Screen This is the misc setup screen. It can be accessed by pushing button 3 on the menu screen. This screen allows the operator to toggle the twine buzzer, backlight, gate manual or auto, and calibrate the bale shape indicators by pressing the corresponding button.

  • Page 48: Twine Dispensing Indicators

    5.4.8 Twine Dispensing Indicators Twine indicators are illuminated when the twine is being fed in to the baler. They will blink with an audible alarm when they are not spinning during a tie sequence. For example, twine ball goes empty during tying sequence, this will notify the operator.

  • Page 49: Baling Sequence

    5.4.13 Baling sequence • All operational set values are entered. • Directional valve on tractor is engaged. • Gate closed icon is illuminated on Plus‑1. • If twine arm is not home, bring it home. • Start baling. • Watch bale shape indicators when baling, keep level. •...

  • Page 50: Section 6: Lubrication

    Section 6: Lubrication The operator should make a check of all grease fittings on the unit before beginning to operate it so as to become familiar with their location and the correct service schedule. WARNING: Use normal shut down procedure (Section 3.1) before lubricating machine. 6.1 Lubrication Use only high quality, #2 multi‑purpose grease when lubricating the unit.
  • Page 51 Figure 6.1 Roller bearing (1 & 2 of 9) roller bearings Figure 6.2 Roller bearing (3 of 9) roller bearing Figure 6.3 PTO (1 & 2 of 7) 5 7 2 R O U N D B A L E R O P E R A T I N G I N S T R U C T I O N S...
  • Page 52 Figure 6.4 PTO (3 of 7) Figure 6.5 PTO (4 of 7) Figure 6.6 Main drive chain Roller bearing (4 of 9) main drive chain roller bearing 5 7 2 R O U N D B A L E R O P E R A T I N G I N S T R U C T I O N S...
  • Page 53 Figure 6.7 Roller bearing (5 of 9) roller bearing Figure 6.8 Secondary drive roller chain Roller bearing (6 of 9) roller bearings secondary drive roller chain Figure 6.9 Pickup drive chain Drum roller bearing (7 of 9) roller bearing pickup drive chain 5 7 2 R O U N D B A L E R O P E R A T I N G I N S T R U C T I O N S...
  • Page 54 Figure 6.10 Tailgate pivots (All) tailgate pivots Figure 6.11 Tailgate latches (All) tailgate latches Figure 6.12 12” RH drum drive Drum roller bearing (8 of 9) roller bearing 12” RH drum drive 5 7 2 R O U N D B A L E R O P E R A T I N G I N S T R U C T I O N S...
  • Page 55 Figure 6.13 Tension arm pivot (All) tension arm pivots Figure 6.14 Pickup jackshaft (1 on each end of pickup) Pickup lift (1 of 2) pickup jackshaft pickup lift Figure 6.15 Pickup end drives (All) pickup end drives 5 7 2 R O U N D B A L E R O P E R A T I N G I N S T R U C T I O N S...
  • Page 56 Figure 6.16 Pickup lift (2 of 2) pickup lift Figure 6.17 Twine arm pivots (1 & 2 of 3) twine arm pivots Figure 6.18 Twine arm pivots (3 of 3) twine arm pivot 5 7 2 R O U N D B A L E R O P E R A T I N G I N S T R U C T I O N S...

  • Page 57: Chain Oiler

    6.2 Chain Oiler The 572 Round Baler is equipped with and automatic oiler. reservoir The automatic oiler cycles oil to lubrication points each time the tailgate is opened. The reservoir holds two quarts of oil and will last approximately eight hours. The rate will vary depending on how the pumps dispensing rate is adjusted and the number of cycles the tailgate is used.
  • Page 58 LubeMinder System Parts Break Down 5 7 2 R O U N D B A L E R O P E R A T I N G I N S T R U C T I O N S...

  • Page 59: Gearbox Lubrication

    6.3 Gearbox Lubrication The oil level should be approximately half the depth of the gear drive, for the parting line for horizontal mounting, or to the shaft centerlines if mounted other than horizontally. To change the oil, remove the drain plug and let the oil drain out. Then replace the drain plug and add 28 oz. of 80W‑90 API GL5 gear lube.

  • Page 60: Section 7: Maintenance

    Section 7: Maintenance 7.1 General Appearance Clean all mud, dirt, grease and other foreign material from the exterior of the machine. Wash the entire machine. If washing the 572 Round Baler with a high-pressure washer, keep nozzle away from sealed bearings. Repaint places where bare metal is exposed 7.2 Welding Procedure Precautions are required for welding on machines welding on machines with electric components.

  • Page 61: Section 8: Options

    Section 8: Options 8.1 Net wrap 8.1.1 Loading the net wrap To load a new roll of net wrap into the machine, first ensure that the PTO is disengaged on the machine and all movement has stopped. Access the NET WRAP SETUP SCREEN and press LOAD NET WRAP (button #6) to move the net wrap feed bar into the load position.
  • Page 62 Figure 8.1 Net wrap in loading position After the roll of net has been loaded ensure that everyone is clear of the machine. Press (button #2) LOADING COMPLETE to signify that the net wrap has been loaded into the machine. When button #2 is pressed it will move the net wrap feed bar and knife into the cut position and hold the loose end of the net in place until the first bale is formed and wrapped.

  • Page 63: Feeding The Net

    support rollers before the roll of net has support rollers with threaded net roll been added 8.1.2 Feeding the net To feed the net, retract the hydraulic cylinder pulling the guillotine net cutter up into the feed position. This causes the net to be pinched between the bale forming belts and the feed bar feeding the net into the bale forming chamber.

  • Page 64: Cutting The Net

    magnetic sensor 8.1.3 Cutting the net To cut the net, extend the hydraulic cylinder pushing the guillotine net cutter down into the cut position. As the net cutter moves down, the spring loaded breaks comes into contact with the support rollers causing the support rollers to stop.

  • Page 65: Bale Kicker Option

    8.2 Bale Kicker option When the bale is wrapped, open the tailgate to let the bale out. As the tailgate opens it pulls the bale back off the floor roll and onto the bale kicker. The weight of the bale on the bale kicker will lower the kicker to the ground. The bale then rolls down the bale kicker to the ground.

  • Page 66: Section 9: Troubleshooting

    Section 9: Troubleshooting Problem Cause Remedy Driveline will not Lack of Lubrication Increase Lubrication telescope Drawbar interference Adjust drawbar Driveline bent Repair/Replace Splines damaged Repair/Replace Vibrating Driveline Bent/Twisted driveline Replace Worn bearings Repair bearings Drive Chain failure Lack of lube Increase lubrication Incorrect operating tension Adjust tension...
  • Page 67 Problem Cause Remedy Gate will not stay open Incorrect counterbalance Adjust valve setting Pickup will not turn Slip clutch is slipping Repair Drive chain broken Repair Cam broken/jammed Repair/Replace Not Picking Clean Ground speed too high Reduce ground speed Windrow too light Increase windrow density Too much float Decrease pickup float...
  • Page 68 Problem Cause Remedy Uneven bale formation Faulty shape indicator Repair/Replace Shape Indicator not Recalibrate Bale Shape calibrated Loose bales Density set too low Increase density setting Tension cylinder leakage Fix cylinder Incorrect weaving Correct weave pattern Windrows too heavy Lighten windrow RPM too low Increase tractor RPM Low twine tension...

  • Page 69: Appendix A: Warranty

    This warranty is limited to the replacement of any defective part or parts if DuraTech Industries is notified within thirty (30) days of failure.

  • Page 70: Appendix B: 572 Haybuster Round Baler Specifications

    Appendix B: 572 Haybuster Round Baler Specifications BALE SIZE Diameter ....................36” to 72” Width ........................61” Bale weight ..................1000 - 1600 lbs BALER, GENERAL Base Weight, w/bale ramp, no net wrap ............6950 lbs Tongue Weight ....................1400 lbs Length With bale ramp .....................
  • Page 71 Control ..................Hydraulic standard Twine Arms ................2, Dual arm dual strand Twine ball capacity ....................6 MONITOR Type ..................Sauer Plus 1 Automatic Bale forming ................Dual graph, outer belt Gate Open .....................Yes, icon Gate Closed ....................Yes, icon Bale Size ................
  • Page 72 A Tradition of Innovation Since 1966 5 7 2 R O U N D B A L E R O P E R A T I N G I N S T R U C T I O N S...

  • Page 73: Part 2: Parts Reference

    ROUND BALER Part 2: Parts Reference...

  • Page 74: Main Frame Assembly

    M A I N F R A M E A S S E M B L Y 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 75 M A I N F R A M E A S S E M B L Y ITEM PART QTY. PART DESCRIPTION 2600054 TIRE\21.5LX16.1\10PLY 2600650 WHL\8-BOLT\16.1X18\6K 2900026 HUB/WHEEL HUB(811)COMPLET 4800003 BOLT\HEX\3/8X1 4800024 BOLT\HEX\1/4X3/4 4800041 BOLT\HEX\1/2X5 4800139 BOLT\HEX\3/4X4-1/2 4800334 BOLT\CRG\1/2X2\NC 4900001 NUT\HEX\1/2\NC 4900002 NUT\HEX\3/8\NC...

  • Page 76: Main Frame Assembly Details

    M A I N F R A M E A S S E M B L Y D E T A I L S 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 77 M A I N F R A M E A S S E M B L Y D E T A I L S ITEM PART QTY. PART DESCRIPTION 2600054 TIRE\21.5LX16.1\10PLY 2600650 WHL\8-BOLT\16.1X18\6K 2900026 HUB/WHEEL HUB(811)COMPLET 4800003 BOLT\HEX\3/8X1 4800024 BOLT\HEX\1/4X3/4 4800041 BOLT\HEX\1/2X5 4800139...

  • Page 78: Hitch

    H I T C H 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 79 H I T C H ITEM PART QTY. PART DESCRIPTION 4800003 BOLT\HEX\3/8X1 4800018 BOLT\HEX\1/2X1-1/4 4800034 BOLT\HEX\3/8X1-1/2 4900001 NUT\HEX\1/2\NC 4900002 NUT\HEX\3/8\NC 4900023 NUT\TPLCK\3/8\NC 4900076 NUT\FLG\SERR\3/8\NC 5000001 WASH\FLAT\3/8 5000004 WASH\FLAT\1/2 5000006 WASH\LOCK\1/2 5000019 WASH\LOCK\3/8 5800632 JACK\5000LB\15”\SWIVEL-STYLE 7200390 HITCH-08 7200581 PIN\HITCH 7200582 PL\RETNG 7200659 BRKT\HOSE\MINDER\HITCH 7200854...

  • Page 80: Tension Arm Assembly

    T E N S I O N A R M A S S E M B L Y 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 81 T E N S I O N A R M A S S E M B L Y ITEM PART QTY. PART DESCRIPTION 3800043 FTG\LUB\1/8MPXZRK\SHORT 4100030 PIN 1” X 3-1/2” HYD. CYL. 4500380 BOLT\SPRING\FOLD 4800010 BOLT\HEX\5/8X2 4800164 BOLT\HEX\3/8X3/4 4800196 BOLT\HEX\5/8X2-3/4 4800481 BOLT\CRG\1/2X1-1/4\NC 4800524...

  • Page 82: Rock Trap

    R O C K T R A P 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 83 R O C K T R A P ITEM PART QTY. PART DESCRIPTION 4800003 BOLT\HEX\3/8X1 4800041 BOLT\HEX\1/2X5 4800139 BOLT\HEX\3/4X4-1/2 4900002 NUT\HEX\3/8\NC 4900014 NUT\TPLCK\1/2\NC 4900139 NUT\TPLCK\3/4\GR8\NC 5000019 WASH\LOCK\3/8 7200461 ROD\SPRING\ROCKTRAP\BALE 7200462 END\SPRING\ROCKTRAP 7200463 BRKT\SPRING 7200543 TRAP\ROCK\BALER 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...

  • Page 84: Main Drive

    M A I N D R I V E 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 85 M A I N D R I V E 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 86 A Tradition of Innovation Since 1966 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 87 M A I N D R I V E ITEM PART QTY. PART DESCRIPTION 1000007 SPKT\15\5/8\IDLER 1000194 SPKT\80\12\3/4\IDLER 1000260 SPKT\60\B\14\1-3/8\5/16KW 1000261 SPKT\60\B\14\1-1/2\5/16KW 1000269 SPKT\B\80\SK\15 1000270 SPKT\B\80\SF\23 1000271 SPKT\B\80\SF\32 1000296 SPKT\60\B\18\2\1/2KW 1000297 SPKT\60\B\25\1-3/4\3/8KW 1100062 CHAIN\60\CL 1100064 CHAIN\60DBL\CL 1100162 CHAIN\80H\CL 1100263 CHAIN\60DBL\13 1100289 CHAIN\80\ 1100291...

  • Page 88: Secondary Drive

    S E C O N D A R Y D R I V E 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 89 S E C O N D A R Y D R I V E ITEM PART QTY. PART DESCRIPTION 1000007 SPKT\15\5/8\IDLER 1000272 SPKT\B\60\SF\42 1000298 SPKT\60\B\15\1-5/8\3/8 1100290 CHAIN\60\121 1400554 BUSH\QD\SF\1-3/4 4800098 BOLT\HEX\3/8X1-1/4\NC 4801232 BOLT\CRG\5/8X2-1/2 4900070 NUT\HEX\5/8\GR8\NC 5000002 WASH\FLAT\5/8 5000003 WASH\LOCK\5/8 5000005 WASH\FLAT\3/4 5000019 WASH\LOCK\3/8...

  • Page 90: Pick Up Lift Assembly

    P I C K U P L I F T A S S E M B L Y 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 91 P I C K U P L I F T A S S E M B L Y ITEM PART QTY. PART DESCRIPTION 4100030 PIN 1” X 3-1/2” HYD. CYL. 4100252 CYL\HYD\3X24\1-1/2RD\WELD 4800068 BOLT\HEX\1/2X3 4800082 BOLT\HEX\1/2X1-1/2 4800085 BOLT\HEX\1/2X1 4900001 NUT\HEX\1/2\NC 4900014 NUT\TPLCK\1/2\NC 4900133...

  • Page 92: Compression Rack Assembly

    C O M P R E S S I O N R A C K A S S E M B L Y 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 93 C O M P R E S S I O N R A C K A S S E M B L Y ITEM PART QTY. PART DESCRIPTION 4800098 BOLT\HEX\3/8X1-1/4\NC 4800158 BOLT\HEX\5/8X4-1/2 4801207 BOLT\HEX\3/8X2\FULL_THD 4900001 NUT\HEX\1/2\NC 4900002 NUT\HEX\3/8\NC 4900023 NUT\TPLCK\3/8\NC 5000001 WASH\FLAT\3/8 5000002...

  • Page 94: Dual Twine Tie

    D U A L T W I N E T I E 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 95 D U A L T W I N E T I E ITEM PART QTY. PART DESCRIPTION 1400092 SHVE\A\4\IDLER\34-037 2000809 CLLOR\SHFT\1\(SET) 4100283 CYL\HYD\1-1/2X8X3/4MLRT 4800012 BOLT\CRG\3/8X1-1/4\NC 4800029 BOLT\HEX\3/8X2-1/2 4800043 PIN\COT\1/4X2-1/2 4800068 BOLT\HEX\1/2X3 4800071 BOLT\HEX\5/16X1-1/4 4800098 BOLT\HEX\3/8X1-1/4\NC 4800114 BOLT\HEX\1/2X2 4800127 PIN\COT\1/8X1 4800135 BOLT\HEX\1/2X3-1/2 4800142 BOLT\HEX\3/8X1-3/4...

  • Page 96: Belt Guide

    B E L T G U I D E 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 97 B E L T G U I D E ITEM PART QTY. PART DESCRIPTION 4800029 BOLT\HEX\3/8X2-1/2 4800098 BOLT\HEX\3/8X1-1/4\NC 4900002 NUT\HEX\3/8\NC 5000019 WASH\LOCK\3/8 7200433 BRKT\GUIDE\BELT 7200594 BRKT\BAR\GUIDE\BELT 7200483 GUIDE\BELT 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...

  • Page 98: Belt Guide - Tailgate

    B E L T G U I D E - T A I L G A T E 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 99 B E L T G U I D E - T A I L G A T E ITEM PART QTY. PART DESCRIPTION 4800029 BOLT\HEX\3/8X2-1/2 4800098 BOLT\HEX\3/8X1-1/4\NC 4800533 PIN\COT\3/16X1 4900002 NUT\HEX\3/8\NC 5000019 WASH\LOCK\3/8 7200434 BRKT\GUIDE\BELT 7200656 BRKT\BAR\GUIDE\BELT 7200657 ROD\GUIDE\BELT 7200484 GUIDE\BELT 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...

  • Page 100: Tailgate Assembly

    T A I L G A T E A S S E M B L Y 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 101 T A I L G A T E A S S E M B L Y ITEM PART QTY. PART DESCRIPTION 4800070 BOLT\HEX\1/2X2-1/2 4800082 BOLT\HEX\1/2X1-1/2 4800098 BOLT\HEX\3/8X1-1/4\NC 4800146 BOLT\HEX\3/8X2 4800160 BOLT\HEX\7/16X1-1/4 4800178 BOLT\HEX\1/2X1-3/4 4800277 BOLT\HEX\1/4X1 4800469 BOLT\HEX\3/4X1-3/4 4801202 SCR\CSK\3/4X1-1/2 4900001 NUT\HEX\1/2\NC 4900002 NUT\HEX\3/8\NC...

  • Page 102: Tailgate Assembly Details

    T A I L G A T E A S S E M B L Y D E T A I L S 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 103 T A I L G A T E A S S E M B L Y D E T A I L S ITEM PART QTY. PART DESCRIPTION 4800070 BOLT\HEX\1/2X2-1/2 4800082 BOLT\HEX\1/2X1-1/2 4800098 BOLT\HEX\3/8X1-1/4\NC 4800146 BOLT\HEX\3/8X2 4800160 BOLT\HEX\7/16X1-1/4 4800178 BOLT\HEX\1/2X1-3/4 4800277 BOLT\HEX\1/4X1 4800469...

  • Page 104: Tailgate Latch Assembly

    T A I L G A T E L A T C H A S S E M B L Y 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 105 T A I L G A T E L A T C H A S S E M B L Y ITEM PART QTY. PART DESCRIPTION 3800043 FTG\LUB\1/8MPXZRK\SHORT 4100030 PIN 1” X 3-1/2” HYD. CYL. 4100241 CYL\HYD\2X24\1-1/4ROD 4800022 PIN\RLLD\3/8X2 4800082 BOLT\HEX\1/2X1-1/2 4800176 BOLT\HEX\5/8X4\FULL THRD...

  • Page 106: Shield Assembly

    S H I E L D A S S E M B L Y 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 107 S H I E L D A S S E M B L Y ITEM PART QTY. PART DESCRIPTION 4703577 HINGE\FAB\3\BASE 4800003 BOLT\HEX\3/8X1 4800024 BOLT\HEX\1/4X3/4 4800029 BOLT\HEX\3/8X2-1/2 4800089 BOLT\HEX\3/8X4 4800098 BOLT\HEX\3/8X1-1/4\NC 4800164 BOLT\HEX\3/8X3/4 4800657 SCR\RD\PHL\#10-24X5/8 4900002 NUT\HEX\3/8\NC 4900009 NUT\HEX\1/4\NC 4900023 NUT\TPLCK\3/8\NC 4900072 NUT\HEX\#10\NC...

  • Page 108: Pick Up Assembly

    P I C K U P A S S E M B L Y 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 109 P I C K U P A S S E M B L Y ITEM PART QTY. PART DESCRIPTION 1000007 SPKT\15\5/8\IDLER 1000284 SPKT\60\B\24\1-3/8\5/16 1000287 SPKT\B\60\SDS\20 1000288 SPKT\B\60\SDS\24 1000289 SPKT\B\60\SH\14 1100062 CHAIN\60\CL 1100286 CHAIN\60\67 1100288 CHAIN\60\40 1400643 BUSH\QD\SH\1-1/4 1400644 BUSH\QD\SDS\1-3/8 2000333 BRG\FLG\CAST\1-1/4\3-BOLT 2000334 BRG\FLG\CAST\1-3/8\3BOLT...

  • Page 110: Pick Up Assembly Details

    P I C K U P A S S E M B L Y D E T A I L S 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 111 P I C K U P A S S E M B L Y D E T A I L S ITEM PART QTY. PART DESCRIPTION 1000007 SPKT\15\5/8\IDLER 1000284 SPKT\60\B\24\1-3/8\5/16 1000287 SPKT\B\60\SDS\20 1000288 SPKT\B\60\SDS\24 1000289 SPKT\B\60\SH\14 1100062 CHAIN\60\CL 1100286 CHAIN\60\67 1100288 CHAIN\60\40 1400643...

  • Page 112: Pick Up Wheel And Hub Assembly

    P I C K U P W H E E L A N D H U B A S S E M B L Y 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 113 P I C K U P W H E E L A N D H U B A S S E M B L Y ITEM PART QTY. PART DESCRIPTION 2600007 TIRE\4.80X8 2600609 WHL\4-BOLT\8 2600805 WHL\ASSY\4-BOLT\4X8-INCLUDES ITEMS 1, 2 2900031 SEAL\WHEEL HUB 2900032 CONE/WHEEL HUB(44643...

  • Page 114: Drum Roller

    D R U M R O L L E R 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 115 D R U M R O L L E R ITEM PART QTY. PART DESCRIPTION 2000311 BRG\FLG\CAST\1-3/4\4BOLT 4800070 BOLT\HEX\1/2X2-1/2 5000006 WASH\LOCK\1/2 7200302 ROLLER\SUPPORT\BALER 7200458 MNT\PAN\RECLAIMER\GUIDE\MATERIAL 7200554 RING\BRG\PICKUP 7200665 PL\PIVOT\PICKUP 7200298 ASSEMBLY\RLLR\DRUM 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...

  • Page 116: Long Idler Roller Assembly

    L O N G I D L E R R O L L E R A S S E M B L Y 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 117 L O N G I D L E R R O L L E R A S S E M B L Y ITEM PART QTY. PART DESCRIPTION 2000088 BRG\SPHCL\1-1/2\RA108RRB 2000803 CLLR\LOCK\1-1/2 4800469 BOLT\HEX\3/4X1-3/4 5000012 WASH\LOCK\3/4 7200200 SHFT\RLLR\IDLR\LONG 7200201 RLLR\IDLER\LONG 7501135 SEAL\BRG\RLLR\4.5”X2.25”X.75”...

  • Page 118: Lower Drive Roller Assembly

    L O W E R D R I V E R O L L E R A S S E M B L Y 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 119 L O W E R D R I V E R O L L E R A S S E M B L Y ITEM PART QTY. PART DESCRIPTION 2000311 BRG\FLG\CAST\1-3/4\4BOLT 4800085 BOLT\HEX\1/2X1 4800334 BOLT\CRG\1/2X2\NC 4800410 SCR\CSK\ALN\5/16X1-1/2\NC 4900001 NUT\HEX\1/2\NC 5000006 WASH\LOCK\1/2 7200584 RLLR\DRIVE\LOWER\BALER...

  • Page 120: Short Idler Roller Assembly

    S H O R T I D L E R R O L L E R A S S E M B L Y 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 121 S H O R T I D L E R R O L L E R A S S E M B L Y ITEM PART QTY. PART DESCRIPTION 2000088 BRG\SPHCL\1-1/2\RA108RRB 2000803 CLLR\LOCK\1-1/2 4801202 SCR\CSK\3/4X1-1/2 7200219 RLLR\IDLER\SHORT 7200220 SHFT\RLLR\IDLR 7501135 SEAL\BRG\RLLR\4.5”X2.25”X.75”...

  • Page 122: Starter Roller Assembly

    S T A R T E R R O L L E R A S S E M B L Y 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 123 S T A R T E R R O L L E R A S S E M B L Y ITEM PART QTY. PART DESCRIPTION 2000344 BRG\FLG\CAST\2S\4BOLT\3L 4800106 BOLT\HEX\5/8X1-1/2 4800334 BOLT\CRG\1/2X2\NC 4900001 NUT\HEX\1/2\NC 5000003 WASH\LOCK\5/8 5000006 WASH\LOCK\1/2 7200872 RLLR\STRTR\LCK\SHFT 7200689 PL\MNT\BRG 5 7 2 R o u n d B a l e r...

  • Page 124: Upper Drive Roller Assembly

    U P P E R D R I V E R O L L E R A S S E M B L Y 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 125 U P P E R D R I V E R O L L E R A S S E M B L Y ITEM PART QTY. PART DESCRIPTION 2000311 BRG\FLG\CAST\1-3/4\4BOLT 4800061 BOLT\CRG\1/2X1-1/2\NC 4800481 BOLT\CRG\1/2X1-1/4\NC 4900001 NUT\HEX\1/2\NC 5000006 WASH\LOCK\1/2 7200284 GUARD\BRG\RLLR\DRIVE 7200318 RLLR\DRIVE\UPPER\BALER...

  • Page 126: Hydraulic Cylinder Seals And Other Items

    H Y D R A U L I C C Y L I N D E R S E A L S A N D O T H E R I T E M S 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 127 H Y D R A U L I C C Y L I N D E R S E A L S A N D O T H E R I T E M S ITEM PART NO. DESCRIPTION 4100331 CYL\HYD\3X8\TIEROD\3000PSI 4100226 CYL\HYD\2X8\1-1/4RD\WLD>...

  • Page 128: Bale Kicker (Optional)

    B A L E K I C K E R ( O P T I O N A L ) 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 129 B A L E K I C K E R ( O P T I O N A L ) ITEM PART QTY. PART DESCRIPTION 4100030 PIN 1” X 3-1/2” HYD. CYL. 4100333 CYL\HYD\2X6\1-1/8RD\TIEROD 4800157 PIN\COT\3/16X2 4800158 BOLT\HEX\5/8X4-1/2 4900107 NUT\NYLCK\5/8\NC 7200537 RAMP\BALE\HYD 7200724...

  • Page 130: Net Wrap (Optional)

    N E T W R A P ( O P T I O N A L ) 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 131 N E T W R A P ( O P T I O N A L ) 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 132 N E T W R A P ( O P T I O N A L ) ITEM PART QTY. PART DESCRIPTION 2000083 BRG\CAM\RLLR\1/2 I.D.X1-1/2 O.D.X 7/16 THRU 4100030 PIN 1” X 3-1/2” HYD. CYL. 4100226 CYL\HYD\2X8\1-1/4RD\WELDE 4800003 BOLT\HEX\3/8X1 4800018 BOLT\HEX\1/2X1-1/4 4800034 BOLT\HEX\3/8X1-1/2...

  • Page 133: Hydraulic Valve - 4000497

    H Y D R A U L I C V A L V E - 4 0 0 0 4 9 7 ITEM PART QTY. PART DESCRIPTION 4000497 VALVE\HYD\BALER 4000509 VLV\SOL\POPPET\NC 4000513 VALVE\HYD\CART\CHECK\PILOT 4000514 VLV\SOL\POPPET\NO 4000515 VALVE\HYD\SOL\12V\300AA\DTZ 4000516 VALVE\HYD\CART\FLO;CNTRL\10GPM@1000PSI 4000517 VALVE\HYD\CART\SCREEN\20GPM 4000518 VALVE\HYD\CART\PRESS;COMP\80PSI...

  • Page 134: Hydraulic Schematic

    H Y D R A U L I C S C H E M A T I C 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...

  • Page 135: Hydraulics

    H Y D R A U L I C S 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...

  • Page 136: Tractor Connections

    T R A C T O R C O N N E C T I O N S 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...

  • Page 137: 4000497 Valve

    4 0 0 0 4 9 7 V A L V E 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...

  • Page 138: 4000269 Valve

    4 0 0 0 2 6 9 V A L V E 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...

  • Page 139: 4100226 Net Wrap Cylinder

    4 1 0 0 2 2 6 N E T W R A P C Y L I N D E R 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...

  • Page 140: 4100283 Twine Cylinder

    4 1 0 0 2 8 3 T W I N E C Y L I N D E R 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...

  • Page 141: 4100193 Tension Cylinders

    4 1 0 0 1 9 3 T E N S I O N C Y L I N D E R S 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...

  • Page 142: 4100241 Gate Cylinders

    4 1 0 0 2 4 1 G A T E C Y L I N D E R S 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...

  • Page 143: 4100252 Pickup Lift Cylinder

    4 1 0 0 2 5 2 P I C K U P L I F T C Y L I N D E R 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...

  • Page 144: 4100322 Kicker Cylinder

    4 1 0 0 3 2 2 K I C K E R C Y L I N D E R 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...

  • Page 145: 3800381 Pressure Gauge

    3 8 0 0 3 8 1 P R E S S U R E G A U G E 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...

  • Page 146: 7501134 Oiling System

    7 5 0 1 1 3 4 O I L I N G S Y S T E M 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...

  • Page 147: Hydraulic Parts List

    H Y D R A U L I C P A R T S L I S T ITEM PART QTY. PART DESCRIPTION 3701262 TUBELINES\BALER 3800381 GAUGE\3000PSI\REAR STEM 3800453 FTG\3/4MORX9/16MJIC\90 3800472 FTG\7/16MORX7/16MJIC\90 3800512 FTG\7/8MORX3/4FOR\ADPT 3800530 FTG\3/4MORX9/16MJIC\ST 3800538 FTG\7/8MORX9/16MJIC\90 3800546 FTG\3/4MJICX3/4FJIC\90\SW 3800586 FTG9/16MORX7/16MJIC\ST 3800631...

  • Page 148: Trailer Light Harness

    T R A I L E R L I G H T H A R N E S S 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 149 A Tradition of Innovation Since 1966 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...

  • Page 150: Decals

    D E C A L S 5 7 2 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 151 D E C A L S ITEM PART QTY. PART DESCRIPTION 6500020 DECAL\LOGO\HYBSTR\SNBRS\3 6500040 DECAL\WARN\SHIELD\PROT 6500057 DECAL\CAUT\ADJ.DRAW BAR 6500082 DECAL\WARN\ROTATN;PART;> 6500085 DECAL\DNGR\ROTATNG;DR-LNE 6500208 DECAL\WARN\GENERAL 6500219 DECAL\DNGR\MOVING;PRTS\> 6500220 DECAL\WARN\HI;PRESS;FLUID 6500302 16 FT DECAL\LOGO\STRIP\3\RD&BLK 6500304 DECAL\LOGO\HYBSTR\1-3/4\W/ 6500339 DECAL\WARN\PINCH;POINT 6500366 DECAL\SMV 6500378 DECAL\LOGO\572 6500434 DECAL\2X9\RED\REFCT 6500435...

  • Page 152: Decals Locations

    D E C A L S L O C A T I O N S 6500085 6500366 6500434 6500434 6500040 6500219 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 153 D E C A L S L O C A T I O N S 6500470 6500468 6500469 6500339 6500219 6500220 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 154 D E C A L S L O C A T I O N S 6500378 6500304 6500020 6500304 6500471 6500435 6500208 6500057 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 155 D E C A L S L O C A T I O N S 6500472 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...
  • Page 156 A Tradition of Innovation Since 1966 5 7 2 R o u n d B a l e r P A R T S R E F E R E N C E...

  • Page 157: Round Baler Documentation Comment Form

    572 Round Baler Documentation Comment Form DuraTech Industries welcomes your comments and suggestions regarding the quality and usefulness of this manual. Your comments help us improve the documentation to better meet your needs. • Did you find any errors? • Is the information clearly presented? • Does the manual give you all the information you need to operate the equipment safely and effectively? • Are the diagrams and illustrations correct?
  • Page 158 Please fill out the delivery report on the following pages. The white copy is to be returned to: DuraTech Industries International Inc. P.O. Box 1940 Jamestown, ND 58402-1940 The yellow copy is the dealer copy; the pink copy is to be retained by the customer.

  • Page 159: Tractor Wiring Harness

    T R A C T O R W I R I N G H A R N E S S 5 7 2 R O U N D B A L E R P A R T S R E F E R E N C E FO-1...

  • Page 160: Machine Wiring Harness

    M A C H I N E W I R I N G H A R N E S S 5 7 2 R O U N D B A L E R P A R T S R E F E R E N C E FO-2...

Table of Contents
