Installer's Guide
Convertible Air Handlers
2 — 5 Ton
TEM6A0B24H21SB
TEM6A0B30H21SB
TEM6A0C36H31SB
TEM6A0C42H41SB
TEM6A0C48H41SB
TEM6A0D48H41SB
TEM6A0C60H51SB
TEM6A0D60H51SB
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and
air-conditioning equipment can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or altered
equipment by an unqualified person could result in death or serious injury. When working on the equipment, observe all precautions in the
literature and on the tags, stickers, and labels that are attached to the equipment.
March 2018
The TEM6 series air handler is designed for installation in a closet,
utility room, alcove, basement, crawlspace or attic. These versatile
units are applicable to air conditioning and heat pump
applications. Several models are available to meet the specific
requirements of the outdoor equipment. Field installed electric
resistance heaters are available.
S S A A F F E E T T Y Y W W A A R R N N I I N N G G
1 1 8 8 - - G G F F 7 7 4 4 D D 1 1 - - 1 1 K K - - E E N N
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ingersoll-Rand TEM6A0B24H21SB
Summary of Contents for Ingersoll-Rand TEM6A0B24H21SB
- Page 1 Installer’s Guide Convertible Air Handlers 2 — 5 Ton TEM6A0B24H21SB TEM6A0B30H21SB TEM6A0C36H31SB TEM6A0C42H41SB TEM6A0C48H41SB TEM6A0D48H41SB TEM6A0C60H51SB TEM6A0D60H51SB The TEM6 series air handler is designed for installation in a closet, utility room, alcove, basement, crawlspace or attic. These versatile units are applicable to air conditioning and heat pump applications.
- Page 2 SAFETY SECTION AIR HANDLERS I I m m p p o o r r t t a a n n t t : : This document contains a wiring diagram, W W A A R R N N I I N N G G a parts list, and service information.
- Page 3 S S A A F F E E T T Y Y S S E E C C T T I I O O N N A A I I R R H H A A N N D D L L E E R R S S W W A A R R N N I I N N G G N N o o t t e e : : Air handlers have been evaluated in accordance with the Code of Federal Regulations, Chapter...
-
Page 4: Table Of Contents
Table of Contents Features ........5 Heater Pressure Drop Table . -
Page 5: Features
Features Table 1. Standard Features additional 1/4” rise over the width or depth of the unit is allowed to create additional sloping towards • MULTI-POSITION UPFLOW, DOWNFLOW, HORIZONTAL LEFT the drain. Unit must be positioned between level AND HORIZONTAL RIGHT and ¼”... - Page 6 F F e e a a t t u u r r e e s s Negative Refrigerant piping external to the unit shall be sized Pressure in accordance with the instructions of the manufacturer of the outdoor equipment. 6. M M e e t t e e r r i i n n g g D D e e v v i i c c e e Drain Pan All units are shipped and installed with an internally-checked, non-bleed TXV designed for air...
- Page 7 F F e e a a t t u u r r e e s s Figure 2. Dip Switches Consult all schematic and pictorial wiring diagrams of this unit and the outdoor equipment to determine compatibility of wiring connections and COOLING HEATING FAN OFF...
- Page 8 F F e e a a t t u u r r e e s s contactor will close and start the compressor and 13. O O p p e e r r a a t t i i o o n n a a l l a a n n d d C C h h e e c c k k o o u u t t P P r r o o c c e e d d u u r r e e s s condenser fan motor.
-
Page 9: Field Wiring
Field Wiring Single Stage, Cooling Only Single Stage, HP Outdoor Outdoor Thermostat Air Handler Thermostat Air Handler Unit Unit 24 VAC HOT 24 VAC HOT 24 VAC 24 VAC Common Common Blue Blue COOL/HEAT COOL/HEAT 1st STAGE 1st STAGE HEATING HEATING 2nd STAGE 2nd STAGE... - Page 10 F F i i e e l l d d W W i i r r i i n n g g 2 Stage, 2 Step, Cooling Only 2 Stage, 2 Step, HP Outdoor Outdoor Thermostat Air Handler Thermostat Air Handler Unit Unit 24 VAC HOT...
-
Page 11: Electrical Data
Electrical Data 18-GF74D1-1K-EN... -
Page 12: Performance And Electrical Data
Performance and Electrical Data Table 4. Air Flow Performance TEM6A0B24H21SB COOLING AIRFLOW PERFORMANCE, WET COIL, NO FILTER, NO HEATER OUTDOOR DIP SWITCH SETTING EXTERNAL STATIC PRESSURE SPEED AIRFLOW AIRFLOW UNIT SIZE SETTING SETTING POWER (TONS) 353 CFM/ Watts 401 CFM/... - Page 13 P P e e r r f f o o r r m m a a n n c c e e a a n n d d E E l l e e c c t t r r i i c c a a l l D D a a t t a a Table 6.
- Page 14 P P e e r r f f o o r r m m a a n n c c e e a a n n d d E E l l e e c c t t r r i i c c a a l l D D a a t t a a Table 8.
- Page 15 P P e e r r f f o o r r m m a a n n c c e e a a n n d d E E l l e e c c t t r r i i c c a a l l D D a a t t a a Table 10.
- Page 16 P P e e r r f f o o r r m m a a n n c c e e a a n n d d E E l l e e c c t t r r i i c c a a l l D D a a t t a a Table 12.
- Page 17 P P e e r r f f o o r r m m a a n n c c e e a a n n d d E E l l e e c c t t r r i i c c a a l l D D a a t t a a Table 14. Electrical Data TEM6A0B24H21SB HEATER DATA 240 Volt 208 Volt No.
- Page 18 P P e e r r f f o o r r m m a a n n c c e e a a n n d d E E l l e e c c t t r r i i c c a a l l D D a a t t a a Table 16.
- Page 19 P P e e r r f f o o r r m m a a n n c c e e a a n n d d E E l l e e c c t t r r i i c c a a l l D D a a t t a a Table 17.
- Page 20 P P e e r r f f o o r r m m a a n n c c e e a a n n d d E E l l e e c c t t r r i i c c a a l l D D a a t t a a Table 18.
-
Page 21: Minimum Airflow Cfm
Minimum Airflow CFM TEM6A0B24H21SB, TEM6A0B30H21SB Heater Minimum Heater Airflow CFM With Heat Pump Without Heat Pump BAYHTR1504BRK, BAYHTR1504LUG BAYHTR1505BRK, BAYHTR1505LUG BAYHTR1508BRK, BAYHTR1508LUG BAYHTR1510BRK, BAYHTR1510LUG BAYHTR1517BRK 1050 BAYHTR3510LUG BAYHTR3517LUG TEM6A0C36H31SB, TEM6A0C42H41SB Heater Minimum Heater Airflow CFM With Heat Pump Without Heat Pump... - Page 22 M M i i n n i i m m u u m m A A i i r r f f l l o o w w C C F F M M TEM6A0B24H21SB, TEM6A0B30H21SB Airflow Performance with Auxiliary Heat...
-
Page 23: Outline Drawing
Outline Drawing NOTE: THIS UNIT IS APPROVED FOR INSTALLATION CLEARANCES TO COMBUSTIBLE MATERIAL AS STATED ON THE UNIT RATING NAMEPLATE PRODUCT DIMENSIONS Flow Gas Line Air Handler Model Control Braze TEM6A0B24, 30 46.77 18.50 16.50 16.75 4.68 7.33 20.09 TEM6A0C36, 42 51.27 23.50 21.50... -
Page 24: Heater Pressure Drop Table
Heater Pressure Drop Table Number of Racks Heater Racks Airflow Heater Model No. of Racks Air Pressure Drop — Inches W.G. BAYHTR1504 1800 0.02 0.04 0.06 0.14 BAYHTR1505 1700 0.02 0.04 0.06 0.14 BAYHTR1508 1600 0.02 0.04 0.06 0.13 BAYHTR1510 1500 0.02 0.04... -
Page 25: Coil Conversion Instructions
Coil Conversion Instructions Table 19. Downflow Figure 5. All other models Follow the conversion steps when installing the air handler in downflow configuration. Remove the front panels from the air handler. The coil and line set panel do not need to be separated. Remove the fasteners on both sides of the coil. - Page 26 C C o o i i l l C C o o n n v v e e r r s s i i o o n n I I n n s s t t r r u u c c t t i i o o n n s s Table 19.
- Page 27 C C o o i i l l C C o o n n v v e e r r s s i i o o n n I I n n s s t t r r u u c c t t i i o o n n s s Table 19.
- Page 28 C C o o i i l l C C o o n n v v e e r r s s i i o o n n I I n n s s t t r r u u c c t t i i o o n n s s Table 19.
-
Page 29: Coil Conversion
C C o o i i l l C C o o n n v v e e r r s s i i o o n n I I n n s s t t r r u u c c t t i i o o n n s s Coil Conversion Table 20. - Page 30 C C o o i i l l C C o o n n v v e e r r s s i i o o n n I I n n s s t t r r u u c c t t i i o o n n s s Table 20.
- Page 31 C C o o i i l l C C o o n n v v e e r r s s i i o o n n I I n n s s t t r r u u c c t t i i o o n n s s Table 20.
- Page 32 C C o o i i l l C C o o n n v v e e r r s s i i o o n n I I n n s s t t r r u u c c t t i i o o n n s s Table 20.
- Page 33 C C o o i i l l C C o o n n v v e e r r s s i i o o n n I I n n s s t t r r u u c c t t i i o o n n s s Table 20.
- Page 34 C C o o i i l l C C o o n n v v e e r r s s i i o o n n I I n n s s t t r r u u c c t t i i o o n n s s Table 20.
- Page 35 C C o o i i l l C C o o n n v v e e r r s s i i o o n n I I n n s s t t r r u u c c t t i i o o n n s s Table 20.
- Page 36 C C o o i i l l C C o o n n v v e e r r s s i i o o n n I I n n s s t t r r u u c c t t i i o o n n s s Table 20.
-
Page 37: Checkout Procedures
Checkout Procedures The final phase of the installation is the system Checkout Procedures. The following list represents the most common items covered in a Checkout Procedure. Confirm all requirements in this document have been met. All wiring connections are tight and properly secured. Supply registers and return grilles are open, unobstructed, and air filter is installed. - Page 38 N N o o t t e e s s 18-GF74D1-1K-EN...
- Page 39 N N o o t t e e s s 18-GF74D1-1K-EN...
