ICE CONTROL SPREADER
MODEL: FSM AUGER
SERIAL #:
MANUAL # 134376
Order parts from the authorized dealer covering your area.
DEALER:
Phone #:
ALWAYS GIVE THE MODEL AND SERIAL NUMBER.
To obtain parts promptly, give part name and part number.
Give post office address, town, and state where the parts are to be shipped. UPS (United
Parcel Service) and other carriers will not ship to a post office box. You must use a street
address. Also be sure to specify whether material is to be shipped by freight, express, parcel
post, or UPS. All UPS shipments will be normal surface routing unless specified otherwise.
Confirm all telephone or FAX orders in writing.
Credit for new parts not needed must be obtained from the dealer from whom they were
purchased.
Unless claims for shortages or errors are made immediately upon receipt of goods, they will not
be considered.
Inspect all goods received immediately upon receipt. When damaged goods are received,
insist that a full description of the damage be made by the carrier agent on the freight bill. If
this description is insisted upon, full damage can be collected from the transportation company.
No responsibility is assumed for delay or damage to merchandise while in transit. Dealer's
responsibility ceases upon delivery of shipment to the transportation company from whom a
receipt is received showing that shipment was in good condition when delivered to them.
Therefore, claims (if any) should be filed with the transportation company and not with the
dealer.
INSTRUCTIONS FOR ORDERING PARTS
08/22/18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ICE CONTROL FSM AUGER and is the answer not in the manual?

Questions and answers

Summary of Contents for Henderson ICE CONTROL FSM AUGER

  • Page 1 ICE CONTROL SPREADER MODEL: FSM AUGER SERIAL #: MANUAL # 134376 INSTRUCTIONS FOR ORDERING PARTS Order parts from the authorized dealer covering your area. DEALER: Phone #: ALWAYS GIVE THE MODEL AND SERIAL NUMBER. To obtain parts promptly, give part name and part number. Give post office address, town, and state where the parts are to be shipped.
  • Page 2 08/22/18...
  • Page 3 Customer Service & Parts Department HENDERSON PRODUCTS, INC. 1085 S. Third St. PH: (563) 927-2828 Manchester, IA 52057 TF: (800) 359-4970 FX: (563) 927-2521 Email Sales: sales@hendersonproducts.com Email Parts: parts@hendersonproducts.com Email Service: service@hendersonproducts.com Website: www.hendersonproducts.com 07/18...
  • Page 5 4. Repairs or modifications done by others, or parts from other sources outside the company's factory are not covered by this warranty. 5. No agent, employee, or representative of Henderson Products, Inc. has any authority to make any affirmation, representation, or warranty concerning Henderson Products, Inc. products, except as specifically stated above.
  • Page 7: Warranty Card

    HENDERSON PRODUCTS, INC. WARRANTY CARD Warranty card must be in the files of HENDERSON PRODUCTS, INC. within 14 days after delivery to the initial user. The Dealer is responsible to see that the card is completed with information required and returned.
  • Page 9: Table Of Contents

    TABLE OF CONTENTS FSM AUGER Spreader Manual #134376 Page No. Title Page Customer Service Page Warranty Information Warranty Card Table of Contents I. Safety Information ....................1-00 A. Safety Information ................1-01 - 1-02 B. Decal and Serial Number Locations ............. 1-03 II.
  • Page 10 V. General Information .................... 5-00 A. Bolt Torque Data ..................5-01 B. Dimension Chart................... 5-02 C. Approximate Density of Common Materials ..........5-03 D. Table of Weights and Measures ..............5-04 08/23/18...
  • Page 11: Safety Information

    SAFETY INFORMATION 08/18 Page 1-00...
  • Page 12 THIS PAGE IS LEFT BLANK INTENTIONALLY. 08/18...
  • Page 13 SAFETY The Safety-Alert Symbol. This symbol is on safety signs on the equipment and in the manual. This symbol indicates to you the potential for personal injury and/or property damage. Hazard Seriousness Levels. The DANGER signal word indicates - DANGER immediate hazards which WILL result in severe personal injury or death.
  • Page 14 SAFETY Persons who install, mount, operate, or service this equipment must be properly instructed and warned. Read operator manuals completely before operating equipment. Read decal instructions, cautions, and warnings. Decals and decal locations are shown on the following page. Check spreader to ensure that all shields and grates are in place. Use care when mounting and dismounting.
  • Page 15: Decal And Serial Number Locations

    DECAL AND SERIAL NUMBER LOCATIONS PARTS LIST ITEM PART# DESCRIPTION 50983 DECAL,CAUTION,MOUNT/DISMOUNT 50986 DECAL, CAUTION, KEEP HANDS OUT 73800 DECAL,AUGER,SAFETY 74474 PLATE,SERIAL 81226 DECAL,LOGO, 2.7 X 6.8 81226L DECAL,LOGO, 2.7 X 6.8,LH 85276 DECAL, NOTICE, HYD 52371 DECAL, WARNING, STAY CLEAR DECAL, SAFETY (ICE) 75250 OPPOSITE SIDE...
  • Page 16 THIS PAGE IS LEFT BLANK INTENTIONALLY. Page 1-04 08/18...
  • Page 17: Installation/General Operating Procedures

    INSTALLATION/GENERAL OPERATING PROCEDURES 08/18 Page 2-00...
  • Page 18 THIS PAGE IS LEFT BLANK INTENTIONALLY. 08/18...
  • Page 19: Mounting Instructions

    MOUNTING INSTRUCTIONS PARTS LIST QTY. ITEM PART NO. DESCRIPTION 89868* STRAP,RATCHET,HOLDOWN TRUNNION LATCH KIT * OPTIONAL ACCESSORIES ** SEE TRUNNION LATCH OPTION INSTALL STRAPS ON HOOKS AT FRONT AND REAR CORNERS OF SPREADER. FRONT AND REAR STRAPS SHOULD BE PULLING IN OPPOSITE DIRECTIONS. DEALER TO SUPPLY HOOK POINTS ON BODY Mtginstr Page 2-01...
  • Page 20: Fsm Hydraulic Requirements

    FSM HYDRAULIC REQUIREMENTS AUGER MOTOR: • Char-Lynn 11.9 CIR motor. • Maximum 20 GPM @ 2250 PSI. SPINNER MOTOR • Char-Lynn 2.2 CIR Motor. • Maximum 10 gpm @ 1800 PSI. MINIMUM PUMP REQUIREMENTS: • 15 gallon hydraulic oil reservoir (minimum). •...
  • Page 21 SCREEN INSTALLATION PARTS PARTS LIST ITEM PART NO DESCRIPTION 134338 SCREEN,WLDT,STD,8',FSM 137768 SCREEN,WLDT,STD,9',FSM 141311 SCREEN,WLDT,STD,10',FSM HX17181 MOUNT,WLDT,HINGE,SCREEN,W/HOLES SCREW,CP,HX,1/2NC X 1 11413 50793 WASHER,FLAT,1/2" SAE,SS 11021.304 NUT.LOCK,NYLON INSERT,1/2-13NC,SS 00373 PIN,HAIR,.188 61049 PIN,MOUNT,BRACKET SCREENS Page 2-03 08/18...
  • Page 22: Instructions For Spinner Use

    INSTRUCTIONS FOR SPINNER USE • SPREAD PATTERN ADJUSTMENT The unit has adjustable external and internal deflectors for complete control of direction of the spread pattern. The width of the spread pattern is 4’ to 32’. The slower the ground speed, the more product that can be applied. Before putting your spreader into service, check over the mechanical and hydraulic systems.
  • Page 23: Material Spread Pattern

    MATERIAL SPREAD PATTERN 29.35 Note: Spinner direction is clockwise. MATERIAL SPREAD PATTERN Gate opening, internal baffle position and lower shroud baffle at the rear of the spreader, as well as the conveyor speed and spinner speed, affect the material spread pattern. Use the following procedure for proper adjustment of the spreader, spread pattern.
  • Page 24 SINGLE AUGER - 11.9 CIR Motor W/ 3.6:1 GEARCASE APPLICATION RATE, LBS/MILE, SALT 70 LBS/FT^3 20 MPH 25 MPH 30 MPH 35 MPH 40 MPH 45 MPH 5 MPH 10 MPH 15MPH AUGER @1000 PSI SALT SALT SALT SALT SALT SALT SALT SALT...
  • Page 25: Service And Maintenance

    SERVICE AND MAINTENANCE 08/18 Page 3-00...
  • Page 26 THIS PAGE IS LEFT BLANK INTENTIONALLY. 08/18...
  • Page 27: Spreader Lubrication

    SPREADER LUBRICATION Proper lubrication is a prime factor in the performance and life of a machine. Special care should be exercised in the selection of lubricants and in keeping them free of foreign matters. Lube applicators should be clean before using and all fittings, caps, and plugs should be cleaned before lubrication or before opening for any reason.
  • Page 28: Lubrication Chart

    LUBRICATION CHART PARTS LIST QTY. ITEM DESCRIPTION IDLER BEARING GREASE ZERK FRONT VIEW Lubchart Page 3-02 08/18...
  • Page 29: Maintenance

    MAINTENANCE A. Cleaning: Regular cleaning will greatly contribute to the life of your spreader. Accumulations of chemicals cause corrosion and build-up that is harmful. Empty and clean the unit after each days use, if possible, and certainly if it will stand idle for any length of time. High pressure water and steam are two effective cleaning agents.
  • Page 30 THIS PAGE IS LEFT BLANK INTENTIONALLY. Page 3-04 08/18...
  • Page 31: Parts

    PARTS AND ASSEMBLIES 08/18 Page 4-00...
  • Page 32 THIS PAGE IS LEFT BLANK INTENTIONALLY. 08/18...
  • Page 33: Auger Idler Bearing Assembly

    AUGER IDLER BEARING ASSENBLY PARTS LIST QTY. ITEM PART NO. DESCRIPTION 88616 BEARING,FLANGE,2-BOLT 88528 BOLT,CRRG,5/8NCX2_SHORT_NECK 88562 NUT,LOCK,5/8NC 111430.304 NUT,LOCK,NYLON_INSERT,3/8NC,SS 50801 BOLT,CRRG,3/8NCX1,SS 134319 PANEL,FRONT,AUGER,FSM 134430 BRACKET,ADJUSTING,AUGER,FSM 50799 BOLT,CRRG,1/4NCX3/4,SS 52360 NUT,CENTERLOCK,1/4-20NC,SS 50792 WASHER,FLAT,1/4,SS 50794 WASHER,FLAT,3/8,SS IDLER BEARING ASSY Page 4-01 09/18...
  • Page 34: Conveyor Assembly

    CONVEYOR ASSEMBLY PARTS LIST ITEM SS P/N DESCRIPTION 106396 SCREW, CP, HX, 7/8NC X 5 106397 NUT,HEX,7/8NC, SLFLK NYLON 106696.304 WASHER, .519 ID X 1.248 OD, .12 11021.304 NUT.LOCK,NYLON INSERT,1/2-13NC 129568 ADAPTER,BUSHING,UHMW,2.563/3.375 134358.201 PLATE,MOUNT,MOTOR,AUGER 150939 GEARCASE/MOTOR ASSY,FSMA 341002 AUGER,RH, 8' X 7",VAR 341003 AUGER,RH, 9' X 7",VAR 341004...
  • Page 35: Trunnion Latch Option

    TRUNNION LATCH OPTON PARTS LIST ITEM QTY. PART NO. DESCRIPTION 10544 BOLT,CARR,1/2NC X 1 1/4 50418 NUT, TOPLOCK FLG, 1/2-13NC 110928 ANGLE,TRUNNION WELDED AT DEALER/INSTALL 74545 PIN,TAILGATE,LATCH 110929 BRKT,TRUNNION LATCH Trunnion latch Page 4-03 08/18...
  • Page 36: Tip Up Spinner Chute Assembly

    TIP UP SPINNER CHUTE ASSEMBLY Parts List ITEM 201SS DESCRIPTION 107111.201 BAFFLE,WLDT,CHUTE,LOWER 111430.304 NUT,HEX,3/8-16NC,SLFLKG,NYLON COMPLETE CHUTE ASSEMBLY 114401.201 BAFFLE,WLDT,CHUTE,LOWER PN: #1148543 118605.304 ROD,CHUTE,FSM,1/2" X 19.00 127533.201 BRACKET,WLDT,TIP-UP,FSM 134431 MOTOR,HYD,2.2 CIR,4B 148540.201 BRACKET,WLDT,TIP-UP,FSM,AUGER 148542.201 CHUTE,WLDT,HYD,FSM,TIP-UP 148544.201 BRACKET,TIP-UP,AUGER,FSM 50790 WASHER,LOCK,3/8 ID,SPRING,SS 50800 BOLT,CRRG,3/8NC X 3/4,SS 50801 BOLT,CRRG,3/8NC X 1,SS...
  • Page 37: Spinner Chute Assembly

    SPINNER CHUTE ASSEMBLY Parts List ITEM 201SS DESCRIPTION 107111.201 BAFFLE,WLDT,CHUTE,LOWER 114401.201 BAFFLE,WLDT,CHUTE,LOWER,UTAH COMPLETE CHUTE ASSEMBLY 134327.201 CHUTE,WLDT,HYD,FSM PN: #134326 134431 MOTOR,HYD,2.2 CIR,4B 50790 WASHER,LOCK,3/8 ID,SPRING,SS 50800 BOLT,CRRG,3/8NC X 3/4,SS 50801 BOLT,CRRG,3/8NC X 1,SS 50806 SCREW,CP,HX,3/8NC X 3/4 G5,SS 52371 DECAL,WARNING,STAY CLEAR 52768 NUT,CENTERLOCK,3/8-16NC,SS 52769...
  • Page 38: Spinner Assembly, 18" Poly4-06

    SPINNER ASSEMBLY, 18" POLY BILL OF MATERIALS ITEM QTY. PART NO. DESCRIPTION 75452 SPINNER PLATE,18",POLYURETHANE 87224 HUB,WLDT 50327 SCREW.CAP,HEX,1/4NC X 1 74332 NUT,FLG,WHIZLOCK,1/4NC 10552 WASHER,FLAT,STD,1/4 ID 52768 NUT,CENTERLOCK,3/8NC,SS 52769 SCREW,CAP,HX,3/8NC X 2,SS (18.00) 87226_spinner Page 4-06 08/18...
  • Page 39: Extended Grease Tube

    EXTENDED GREASE TUBE PARTS LIST ITEM 201SS DESCRIPTION 00306 ZERK,GREASE,1/8 NPT,STR 00496.304 COUPLING,PIPE,1/8 NPT 51440 GROMMET,RUBBER 76354 HOSE,GREASE,1/8NPT X 20 77041 ADAPTER,02FP/02FPX HX15372.304 GREASE TUBE, 8' BODY 76526.304 GREASE TUBE, 9' BODY 319109.304 GREASE TUBE,10' BODY DETAIL F SCALE 1 / 11 DETAIL G SCALE 1 / 11 REMOVE BEARING ZERK...
  • Page 40 THIS PAGE IS LEFT BLANK INTENTIONALLY. Page 4-08 08/18...
  • Page 41: Auger Safety Interlock

    AUGER SAFETY INTERLOCK PARTS LIST ITEM PART NO. QTY. DESCRIPTION 85391 ADAPTER,BULKHEAD,12MP/12MJ 10729A COUPLING,QD,FEMALE,12NPT 10729B COUPLING,QD,MAIL,12NPT 75786 ADAPTER,12MJ/12MP 85394 HOSE,12FJX/12FJX,13.00 85392 ADAPTER,BULKHEAD,12MJ/12MJ 73893 ELBOW,12MJ/10MB HX23210 HOSE,12FJX/12FJX,72" 73593 ADAPTER,12MJ/10MB 96470 CLAMP,VINYL COATED,1-1/8 50801 BOLT,CRRG,3/8NC X 1,SS 111430.304 NUT,LOCK,NYLON INSERT,3/8-16NC PRESSURE RETURN PRESSURE AUGER ROTATION...
  • Page 42: Lights

    LIGHTS PARTS LIST ITEM PART NO DESCRIPTION 10827 CLAMP,VINYL COATED, .375 115730.304 NUT,HEX,1/4-20NC,SLFLKG,NYLON 116048 LIGHT,STT,RED,6.5 OVAL,LED,STD 147298 LIGHT,WORK,4.5" ROUND,LED 149903 HARNESS,LIGHT,FSM,LH 149917 HARNESS,LIGHT,FSM,RH 50799 BOLT,CRRG,1/4NC X 3/4 G2, SS 50946 NUT,HEX,#10-24NC,SS 50948 WASHER,FLAT,STD,#10,SS 51145 GROMMET,RUBBER,.813ODX.5IDX.25 77260 GROMMET,LIGHT,6" OVAL 77517 FITTING,COMPRESSION, 1/2" 77518 NUT, JAM, COMP, PLASTIC 80249...
  • Page 43 LIGHTS DETAIL A SCALE 1 / 10 149931 LIGHTS Page 4-11 08/18...
  • Page 44: Fsm Stands

    FSM STANDS PARTS LIST ITEM PART NO DESCRIPTION **50794 WASHER,FLAT,3/8,SS 126928.201 - 8' STNAD ASSEMBLY 50793 WASHER,FLAT,STD,1/2 ID, SS 126924.201 - 9' STAND ASSEMBLY 11021.304 NUT.LOCK,NYLON INSERT,1/2-13NC 126848.201 - 10' STAND ASSEMBLY ** 111430.304 NUT,LOCK,NYLON INSERT,3/8-16NC ** 50806 SCREW,CP,HX,3/8NC X 3/4 G5,SS ** 50807 SCREW,CP,HX,3/8NC X 1,SS 11413...
  • Page 45 FSM STANDS " 48" 8' STAND = 10' 9" 9' STAND = 11' 9" 10' STAND = 12' 9" STAND Page 4-13 08/18...
  • Page 46 THIS PAGE IS LEFT BLANK INTENTIONALLY. Page 4-14 08/18...
  • Page 47: General Information

    GENERAL INFORMATION 08/18 Page 5-00...
  • Page 48 THIS PAGE IS LEFT BLANK INTENTIONALLY. 08/18...
  • Page 49: Bolt Torque Data

    BOLT TORQUE DATA The chart provided contains information concerning standard hardware used on this machine. It is recommended that all fasteners be tightened to the torque values specified. The grade of the bolt is identified by the markings on the head of the bolt. GENERAL BOLT TORQUE DATA IN FT/LB.
  • Page 50: Dimension Chart

    DIMENSION CHART DECIMALS OF AN INCH For each 1/64 of an inch With Millimeter Equivalents Millimeters Millimeters Fraction 1/64 Decimal (Approx.) Fraction 1/64 Decimal (Approx.) .015625 0.397 .515625 13.097 1/32 .03125 0.794 17/32 .53125 13.494 .046875 1.191 .546875 13.891 1/16 .0625 1.588 9/16...
  • Page 51: Approximate Density Of Common Materials

    APPROXIMATE DENSITY OF COMMON MATERIALS MATERIAL #/FT KG/M LBS/GAL Ashes 35-40 560-640 Cargill CG-90 surface saver 10.15-10.45 Cement 90-118 1440-1890 Clay, damp 1,761 Coal-anthracite, lumpy 50-54 800-860 Coal-bituminous, lump 50-60 800-960 Coal-lignite 1,250 Coke 23-32 369-513 Earth, moist 1,250 Earth, mud 1,730 Flue, dirt 1,600...
  • Page 52: Table Of Weights And Measures

    TABLE OF WEIGHTS AND MEASURES Dry Measure Surveyor’s Measure 2 pints = 1 quart 7.92 inches = 1 link 1 quart = 67.2 cu. in. 25 links = 1 rod 1 British bushel = 1.032 U.S. bushel 4 rods = 1 chain 8 quarts = 1 peck 10 sq.
