Element X Amplifier

Installation Manual

Please take a few minutes and read this manual BEFORE starting

the installation! This amplifier manual is not "vehicle specific"

so reading before starting will help you choose a good

mounting location, and help plan your wiring.

Metrix Audio and Hogtunes Inc. are Owned by Powersports Audio Inc., Barrie, Ontario, Canada

All Products Designed and Engineered In Canada

Table of Contents

Need help?

Do you have a question about the Element X and is the answer not in the manual?

Questions and answers

Summary of Contents for Metrix Audio Element X

Page 1 This amplifier manual is not “vehicle specific” so reading before starting will help you choose a good mounting location, and help plan your wiring. Metrix Audio and Hogtunes Inc. are Owned by Powersports Audio Inc., Barrie, Ontario, Canada All Products Designed and Engineered In Canada...
Page 2 Element X is a 2 channel amplifier rated at 75 watts per channel at 4 ohms. It comes equipped with 2 pairs of stereo output plugs (1 pair of left and right “Mains”, and 1 pair of left and right “EXT’s”) allowing a total of 4 (2 pairs) of 4 ohm speakers to be...
Page 3 Input refers to getting music from your device or radio into the amplifier. Element X has 3 ways to get music into the amp. Please read below and choose the one that works for your installation. On the same side of the amplifier that has the power wires coming out, you will see a removable rubber “plug”...
Page 4 The blue wire is the ‘remote turn on” and tells the amplifier to turn on or off when the blue wire “sees” 12v or not. If you are running a Metrix Audio MA4-BT, you can attach the blue wire on the amplifier to the same place you have switched power attached to for MA4-BT.
Page 5 Setting the amps crossover: Behind the rubber plug (removed earlier) you will see a 3 position switch labeled HP, LP, and AP. In order to give maximum flexibility, Element X can run in three configurations: High Pass (HPF) The amp only allows music above 60 Hz to play...
Page 6 Warranty Information: Metrix Audio’s Element X amplifier is warranted for a period of 12 months from the original purchase date. The warranty applies to the original (retail) owner of the system only. Proof of purchase is required for all warranty claims. Please visit the warranty section of our website at www.metrixaudio.com and fill out the...
Page 7 Quick Reference Wiring Chart A = 3 Pin Power Harness Connector B = Positive Wire Fuse (RED) C = Ground Wire (Black) D = Remote Turn On Lead (Blue) E = Hi Level Input (see page 3) F = Low Level Input G = Left EXT Output H = Left Output I = Right EXT Output...
Page 8 Warranty Information: Metrix Audio’s Element X amplifier is warranted for a period of 12 months from the original purchase date. The warranty applies to the original (retail) owner of the system only. Proof of purchase is required for all warranty claims.
