9 Yard Outdoor Collection

D E S I G N E D I N 2 0 1 8

A S S E M B LY N O T E S | R E V 0 1

R O O F L E S S L I V I N G R O O M .

Trick out Mother Nature with this fully upholstered modular outdoor sofa

system. Configure as needed to get the most out of your outdoor space.

N E E D A H A N D ?

844.425.8368 for assistance.

Table of Contents

Need help?

Do you have a question about the 9 Yard Outdoor Series and is the answer not in the manual?

Questions and answers

Summary of Contents for BluDot 9 Yard Outdoor Series

Page 1 R O O F L E S S L I V I N G R O O M . N E E D A H A N D ? Contact us at service@bludot.com or Trick out Mother Nature with this fully upholstered modular outdoor sofa 844.425.8368 for assistance.
Page 2 Parts & Hardware PT. 1681 PT. 9001 Foot Straight Connector Corner Connector Module *Part quantities vary based on product. Refer to page 2 for part breakdown. 1 | 8 4 4 . 4 2 5 . 8 3 6 8 9 YA R D O U T D O O R C O L L E C T I O N...
Page 3 Foot Straight Connector* Corner Connector* Square Corner Ø Double Armless Ø Armless Ø Left Arm Ø Right Arm Ø Pentagon *Straight connectors ship with x2 bolts. Corner connectors ship with x3 bolts. A S S E M B LY N O T E S S E R V I C E @ B L U D O T.
Page 4 Step 01 A S S E M B L E C O N N E C T O R S . Attach adjustable feet to straight connectors and corner connectors as necessary. The amount required will depend on desired configuration. 3 | 8 4 4 .
Page 5 Step 02 I N S TA L L C O N N E C T O R S A N D L E G S . Align adjacent modules and install connectors as shown. Do not fully tighten bolts until all bolt locations have been installed.
Page 6 Step 03 C O N N E C T A D D I T I O N A L M O D U L E S . Continue adding legs to additional modules and aligning them with existing pieces. Ensure that the connector hole locations are aligned.
Page 7 Step 04 I N S TA L L C O N N E C T O R S . Install remaining bolts on connectors. Tighten remaining loose bolts to secure modules in place. Repeat installation steps for additional modules. PT. 1 68 1 x 2 PT.
Page 8 Additional Information NOTE This product is upholstered with Sunbrella fabrics. Sunbrella fabrics are treated to be water and stain © repellant, and do not promote mildew growth. We recommend regular cleaning as mildew can grow on dirt and dust embedded in the fabric. CLEAN Vacuum your upholstery regularly, this will help prevent dirt and dust from becoming embedded in the fabric.
