For use with the following starting serial numbers:
Model
HTS3-3640BA 0100
ATTENTION:
ALL WARRANTY WORK MUST BE APPROVED
BY BROWN MFG. CORP.
BEFORE WORK BEGINS
Owner / Operator Manual
Serial Number
WARNING
Before operating your machine,
stop and read this owners manual.
Do not attempt to operate the unit
until you fully understand the
material covered in this manual.
Without the knowledge contained
in this manual, injury or death can
result.

Advertisement

Table of Contents
loading

Related Manuals for BROWN HTS3-3640BA

Summary of Contents for BROWN HTS3-3640BA

  • Page 1 For use with the following starting serial numbers: Model Serial Number HTS3-3640BA 0100 ATTENTION: ALL WARRANTY WORK MUST BE APPROVED BY BROWN MFG. CORP. BEFORE WORK BEGINS Owner / Operator Manual WARNING Before operating your machine, stop and read this owners manual.
  • Page 2 Copyright ©2000 Brown Manufacturing Corporation, Ozark, Alabama. All photos and illustrations are property of Brown Manufacturing Corporation. This publication may be freely reproduced, either in whole or in part, provided that the content herein is not altered. We encourage you to make copies of this manual and to distribute it to every operator of the machine.

  • Page 3: Table Of Contents

    Contents Warranty ........................... 4 Registration ........................6 Equipment Safety ......................9 Assembly........................18 Operation ........................20 Maintenance ........................22 Troubleshooting ......................28 Specifications ......................... 29 Replacement Parts ......................30...

  • Page 4: Warranty

    Limited Warranty 1. LIMITED WARRANTIES 1.01. . Brown Manufacturing Corp. warrants for one year from the purchase date to the original non-commercial, governmental, or municipal purchaser (“Purchaser”) and warrants for ninety (90) days to the original commercial or industrial purchaser (“Purchaser”) that the goods purchased are free from defects in material or workmanship.
  • Page 5 A) Warranty is ONE-YEAR (12 months) for Seals (After one year, seals are considered to be WEARING PARTS and replacement is user’s responsibility). B) User’s Bearing Blocks may be rebuilt by Brown Manufacturing Corp. or replaced by new or rebuilt Bearing Blocks at the option of Brown Manufacturing Corp.

  • Page 6: Registration

    Please complete the form below and mail to: Brown Mfg. Corp. - 6001 E. Hwy. 27 - Ozark, AL 36360 BROWN MANUFACTURING CORP. ® WARRANTY REGISTRATION INFORMATION Brown Model ______________ Serial No._________ Purchase Date (mm/dd/yy) ___/___/____ Purchaser Last Name _____________________ First Name____________________ M.I._____ Street &...
  • Page 7 Please complete the form below and mail to: Brown Mfg. Corp. - 6001 E. Hwy. 27 - Ozark, AL 36360 BROWN MANUFACTURING CORP. ® WARRANTY REGISTRATION INFORMATION Brown Model ______________ Serial No._________ Purchase Date (mm/dd/yy) ___/___/____ Purchaser Last Name _____________________ First Name____________________ M.I._____ Street &...
  • Page 8 *If the Owner’s Manual becomes lost or damaged, contact Brown Mfg. or your local Brown dealer for free replacement, or it can be downloaded and printed from our web site...

  • Page 9: Equipment Safety

    *Second copy is to stay with the unit at all times. This will provide the operator the information needed for safe and proper operation of the unit. *If the Owner’s Manual becomes lost or damaged, contact Brown Mfg. at 800-633-8909 or your local Brown dealer for free replacement or can be downloaded and printed from our web site www.brownmfgcorp.com.
  • Page 10 Unauthorized modifications to the equipment are not recommended. This could impair the function, safety, and life of the machine. • For any part of this manual that you do not understand, contact your dealer or Brown Manufacturing Corporation at (800) 633-8909. •...
  • Page 11 The following safety decals should be attached to the equipment at all times. Should any decals become damaged or lost, it is the responsibility of the owner to replace it. Additional decals may be obtained from the dealer or Brown Manufacturing Corporation. WARNING...
  • Page 12 Equipment Safety Safety Decals (continued) CAUTION To Avoid Injury or Machine Damage: •When servicing machine use proper tools and equipment. •Refer to operations manual for instructions. Part No.: SD-SW2, All models. DANGER ROTATING BLADES To prevent serious injury or death from rotating blades: •...
  • Page 13 237-0009 Safety Decal: No Step. (Both Sides and Rear) 237-0002 Safety Decal: High Pressure Fluid Hazard (Both Sides) DC-3-11-002 Brown Logo (Sides and Front) Serial Plate Tree Saw Serial Plate 237-SDW2 Danger Decal: Do Not Operate Without Shatterproof Cab Door...
  • Page 14 Equipment Safety Warning! Transport with WARNING care. Transport with care. Use slow-moving Before transporting to a new location, make certain vehicle emblem that the slow-moving vehicle (SMV) emblem is and flashing light. installed and is clearly visible. Use flashing lights Follow local and follow local traffic regulations.
  • Page 15 Equipment Safety Warning! Prepare for WARNING emergencies. Prepare for Keep fire extinguisher and first aid kit available. Fire emergencies. Inspect fire extinguisher and check for charge Keep fire daily. Check first aid kit for expired contents and extinguisher and keep stocked. first aid kit available.
  • Page 16 Equipment Safety Warning! WARNING Wear protective clothing. Wear protective clothing. Wear close-fitting clothing and other protective devices appropriate for the job. Warning! Roll-over WARNING protection. Use only with skid steer equipped Do not operate the TreeSaw on any tractor not with a certified equipped with a certified roll-over protective struc- roll-over protective...
  • Page 17 Equipment Safety Danger! Keep riders off DANGER machine. Riders can be Riders can be seriously injured or killed by injured or killed. entanglement or by falling. Keep riders off machine. Warning! High Pressure Fluid Hazard. The Hydraulic Tree Saw is equipped with hydraulic hoses and cylinders, use all safety precautions when working around hydraulic componenents.
  • Page 18 Cutting Attitude Barking up a tree the correct way! Recommended Cutting Attitude The blade level with the ground. If you have to bark up a tree do it this way. Make sure the tree falls away from you. Don’t try this at home , or on the range.

  • Page 19: Assembly

    Assembly FOR ANY QUESTION ABOUT PROPER ASSEMBLY PLEASE CONTACT YOUR LOCAL DEALER OR CALL BROWN MFG. AT 1-800-633-8909...

  • Page 20: Operation

    Tree Saw has ceased before dismounting to making adjustments. Your Brown Tree Saw is designed to cut at ground level, however for optimum blade and tip life adjust to approximately 1” above ground level.
  • Page 21 Operation Starting Tree Saw Power for operating the Tree Saw is supplied from the Skid steer hydraulics. Refer to your Skid steer manual for instructions on engaging and disengaging the hydraulic remote. Operating Speed Proper operating speed for equipment will depend upon the height, density, and type of the material to be cut.

  • Page 22: Maintenance

    Warning! Use only blades and blade tips supplied by Brown Manufacturing Corporation. Failure to do so will void all warranty and can cause injury or death. Only Brown has access to the engineering and test data necessary to produce a high-quality blade that meets all safety and quality requirements.
  • Page 23 Do not overgrease. Make certain both fittings are tightened securely before operating. Ordering replacement parts Please contact the nearest Brown dealer for replacement parts. Or call Brown Mfg. at 800-633-8909 for parts or technical information. Please have model and serial number available when ordering parts.
  • Page 24 Maintenance Ordering replacement parts Please contact the nearest Brown dealer for replacement parts. Or call Brown Mfg. at 800-633-8909 for parts or technical information. Please have model and serial number available when ordering parts.
  • Page 25 8. NEVER – Allow an untrained operator to operate this equipment. 9. ALWAYS – Install genuine Brown replacement parts, all other replacement parts will void warranty. 10. ALWAYS – REMAIN in cab until the blade has stopped rotating and all skid steer shut down procedures have been completed.
  • Page 26 Please record all maintenance and repair services performed on the TreeSaw. This log may help identify reoccurring problems with your TreeSaw and may be requested by the manufacturer when making warranty claims. Additional log pages may be copied or ordered from Brown Mfg. Corp. Date...
  • Page 27 Notes Ordering replacement parts Please contact the nearest Brown dealer for replacement parts. Or call Brown Mfg. at 800-633-8909 for parts or technical information. Please have model and serial number available when ordering parts.

  • Page 28: Troubleshooting

    1. Increase cutting height 2. Cutting in sandy or rocky conditions 2. Increase cutting height 3. Inadequate carbide tips 3. Replace with Brown carbide tips 4. Ground speed too fast 4. Slow ground speed Not cutting clean 1. Dull carbide tips 1.

  • Page 29: Specifications

    Standard Features All welded, steel frame Ordering replacement parts Please contact the nearest Brown dealer for replacement parts. Or call Brown Mfg. at 800-633-8909 for parts or technical information. Please have model and serial number available when ordering parts.

  • Page 30: Replacement Parts

    Replacement Parts HTS3-3640BA 260-3060 260-2095 Ref. No. Part No. Description 233-260-2515 Hydraulic Control Block installed with HC56C16Z Bolt and WUS38Z flat washer 233-260-3080C High Flow Piston Motor 260-2090 Tree Saw Base Weldment 260-0525 36” Blade with Cutting Tips, Through Hole Design (See Page 34 for install.)
  • Page 31 Replacement Parts HTS3-3640BA 260-0525 260-2115 Saw Blade Detail Bolt Lock 260-2095 Ref. No. Part No. Description 255-2601 Carbide Overlay Tooth, Flat Bottom HS86S5C24 Hex Socket Shoulder ⅜” x 1 1/2” NC Grade 8 NNF85CZ Nylock Flange Nut 5/16” NC Grade 8...
  • Page 32 Replacement Parts HTS3-3640BA INSET I 260-0020 Herbicide Tank INSET II 233-260-4000 (2) 233-6HTOF6 233-6400-16-12 233-232-8010 Case Drain Hose 233-HT6OF6 Inset III 233-HTOF4 Ref. No. Part No. Description HC58C24Z Access Panel Bolts ½” - 13 x 1 ½” Grade 5 Zinc WSA50Z Access Panel Flat Washers ½”...
  • Page 33 Replacement Parts HTS3-3640BA Ref. No. Part No. Description 233-260-4220 Rotator Control Hose #1 233-260-4225 Rotator Control Hose #2 (not shown, on left side) 233-6801-04-04 Rotator Fitting ¼” JIC Male x #4 SAE/ORB Male 90º 233-260-2415 Hoses, Control Block to Motor 233-S16-J16-JF16 1”...
  • Page 34 Replacement Parts HTS3-3640BA 3 53 260-4000 Overhung Load Adapter Ref. 13 Page 30 260-0550 See Page 31 for details MH-01 260-3060 Blade Lock Plate Ref. 5A Page 30 Ref. No. Part No. Description 260-2041 Saw Blade Hub 255-1401 1/4” Vent PTF Relief Fitting Straight 255-1418 Adapter Fitting ¼”...
  • Page 35 Electrical Connections HTS Fuse Block To: 12 Volt Power To: Ground Purple or Blue Tilt 1 Black Green or Yellow Orange Ground Pump Tilt 2 Ref. No. Part No. Description 260-4005 Cab 3 Button Wiring Harness (In-Cab Wiring Harness) optional 260-4015 Intermediate Wiring Harness (Into Cab) optional 239-78075...
  • Page 36 700-260-3630 HC810F32Z Hub Washer Bolt Illustration 6-1 Ordering replacement parts Please contact the nearest Brown dealer for replacement parts. Or call Brown Mfg. at 800-633-8909 for parts or technical information. Please have model and serial number available when ordering parts.
  • Page 37 Hub/Blade Installation SECTION 6 – Blade Install 1. Align the center slot of 260-3060 Blade Lock Plate with the 5/8” bolt holding the hub on. be sure that the 6 holes on the hub are fully visible. If they are not visible, tighten the 5/8” center bolt until they are. 2.
  • Page 38 Notes Ordering replacement parts Please contact the nearest Brown dealer for replacement parts. Or call Brown Mfg. at 800-633-8909 for parts or technical information. Please have model and serial number available when ordering parts.
  • Page 39 Revisions Date Page Revision Change Made...
  • Page 40 For use with the following starting serial numbers: Model Serial Number HTS3-3640BA 0100 Version 1000.0.0 October 2019...
