Summary of Contents for Electronic Technologies ES3010
-
Page 2: Table Of Contents
CONTENT I. Safety Precautions and Procedures..........2 II. Introduction ..................3 III．Measuring Range and Accuracy ........... 4 IV．Technical Specifications ..............5 V．Tester Structure ................7 VI．Measuring Principle ................ 7 VII. Function Quick Check ..............8 VIII. Operation Methods ................ 9 1．Switch On/Off ................ -
Page 3: Safety Precautions And Procedures
I. Safety Rules and Precautions Thanks for your purchase of Digital Earth Resistance Tester of our company. Before you use the instrument for the first time, in order to avoid possible electric shock or personal injury, please be sure to: read and strictly observe the safety rules and precautions listed in this manual. -
Page 4: Introduction
u During usage of tester, please stop using it when exposed metal is caused by broken enclosure or testing wires. u Please don’t keep or store the tester in the spot with high-temperature and moisture, or condensation, and under direct daylight radiation for a long time. u For replacing battery, please confirm testing wire has moved apart the meter, and FUNCTION SWITCH rotary switch is in “OFF”... -
Page 5: Measuring Range And Accuracy
display and microprocessor technology to meet the requirements of two-wire and three-wire test resistance. Suitable for telecommunications, electricity, meteorology, computer rooms, oil fields, power distribution lines, iron tower transmission lines, gas stations, factory grounding networks, lightning rods and so on. Instrument testing is precise, fast, simple, stable and reliable. -
Page 6: Technical Specifications
IV．Technical Specifications Earthing Resistance 0.01Ω～3000Ω Accuracy±1.5%rdg±5dgt Range Ground resistance 0.01Ω resolution Grounding 0.01～600V AC Accuracy±1.5%rdg±3dgt voltage range Ground voltage 0.01V resolution 23 ° C ± 5 ° C, 75% rh or less (Auxiliary earth Reference conditions resistance 100Ω±5%, voltage to ground <10V) Earth ground resistance measurement, voltage to Function ground... - Page 7 earthing rod Voltage to ground: about 3 times/second; earth Measuring Rate ground resistance: about 5 seconds/time Measuring Over 5000 times Times Measuring voltage to ground: measuring below AC Circuit Voltage 600V 500 sets, flash display “FULL” icon to indicate storage Data Storage is full Data read function: “MR”...
-
Page 8: Tester Structure
IEC61010-1 、 IEC1010-2-31 、 IEC61557-1,5 、 Protection Type IEC60529(IP54)、Pollution grade 2、CAT Ⅲ 300V V．Tester Structure 1. MEM Button 2. ALARM Button 3. BACKLIGHT Button 4. LCD 5.TEST Button 6.SET Button 7.UP Button 8.DOWN Button 9. Rotary Switch for Selecting Function Button VI．Measuring Principle 1. -
Page 9: Function Quick Check
measuring object E (ground electrode) and H (current electrode); seeking potential difference V of E and S (voltage electrode) , then to determine the ground resistance Rx Rx=V/I 3．It’s operating error(B) is an error obtained within the rated operating conditions, and calculated with the intrinsic error(A) and the error(E) due to variations. -
Page 10: Operation Methods
MEM Button Data Lock/Store/View Button Alarm function start/alarm threshold setting R and U Measure gear selection VIII. Operation Methods 1．Switch On/Off Turn the function key to the corresponding test position and turn it on. Turn the function key to the OFF position to turn off the instrument, the meter will be automatically turned off, and after turning off, it will be turned to the OFF position and restart.. -
Page 11: 4．Wire Resistance Verification
Before measuring earth ground resistance, firstly please confirm voltage to ground must be lower than 10V. Otherwise, the measurement value may cause excessive Note error. At that time, firstly cut off power on measured earthing equipment and make resistance measurement after the earthing voltage is reduced. -
Page 12: 6．Simple Method For Measuring Ground Resistance
around, which shall be measured separately. Try to choose the spot with more water to deeply bury auxiliary earthing rods H and S, in order to reduce auxiliary earth ground resistance and thus reduce indication error. Precision measurement grounding resistance adopts three-wire connection, auxiliary grounding rod and test line are all connected, switch function to measure resistance R mode, press key to press “TFRT”... -
Page 13: 7．Backlight Control
metal auxiliary earthing object when making measurement. Earth ground resistance simple testing wire connection is as following figure, and refer to precision measurement for other operations. Simple method for measurement of earth ground resistance, its reading on Tester is the total value of earth ground resistance value of measured earthing object and that of commercial earthing object, namely: RE=RX＋re In which: RE is the Tester reading value;... -
Page 14: 8．Alarm Settings
8．Alarm Settings After power on, short press “ ” to turn on and off the alarm function. Short press "SET" key to set the resistance alarm value, press " " key to move the cursor, press " " or " " key to change the current size, and then press "SET"... -
Page 15: Battery Replacement
figure after deletion. IX. Battery Replacement The instrument is powered by six 1.5V LR14 batteries. When the battery power is reduced, the power indicator bar is reduced. When the voltage drops to 5V, the battery symbol “ ” is displayed. X．Accessories Tester 1 PC... - Page 16 GuangZhou ZhengNeng Electronics Technology Co. Address: 2F, No.15 Baoshu Road, Taihe, Baiyun District, Guangzhou, Guangdong, China Toll-free call：4000-1515-38 Tel：86-20-36544172 Fax：86-20-37319075 Post：510540 WebSite：www.znele.com...
