- Page 1 Thermo Check Wall Mount Infrared Thermometer Dual Temperature Mode Automatic Sensor High Temperature Alarm 1200 Rechargeable Battery Model No.: iG-K3X...
-
Page 2: Table Of Contents
Directory Statement ------------------------------------------------------------------------------------------- 2 Scope of application------------------------------------------------------------------------------- 2 Structural componets ---------------------------------------------------------------------------- 2 Part name ------------------------------------------------------------------------------------------- 3 Technical indicators ------------------------------------------------------------------------------- 4 How to use------------------------------------------------------------------------------------------- 4 Operating steps --------------------------------------------------------------------------------- 5-6 Function key descripition ------------------------------------------------------------------------ 7 Contraindications, precautions, warnings ------------------------------------------------ 7-8 Installation and replacement of batteries --------------------------------------------------- 9 Daily maintenance-------------------------------------------------------------------------------- 10 Trouble shooting ---------------------------------------------------------------------------------- 10... -
Page 3: Statement
Statement Please read this manual carefully before use. The ambient temperature to use this product is 16 C to 35 C and the optimal temperature is 25 Please do not use product in an environment above 35 C or below 16 Please do not place this product too close to charge object to avoid electric shock. -
Page 4: Part Name
Signal receiver Part Name Hang slot Digital screen Audio Language switch Power key Count Key F switch Memory data Hang slot Battery cover The horn Charging port... -
Page 5: Technical Indicators
Technical indicators Product Name ThermoCheck Product Model iG-K3X Measuring distance 1 cm - 7cm Measuring rang 32.0° C – 43.0° C (89.6° F- 109.4° F) Response time 0.5s Operating environment Temperature: 16° C - 35° C (60.8° F – 95° F) Relative humidity: ≤80% Transportation storage environment Temperature: 0°... -
Page 6: Operating Steps
Operating steps 1. Measurement operation Figure 1 Figure 2 Figure 3 1cm ~ 7cm 1.1. Anthropometric Press the measurement key to turn on the thermometer. At this time, the full screen is displayed, as shown in Figure (1). Switch the thermometer to human body temperature mode and measure the temperature of ... - Page 7 1.2 Description of measurement results. Figure 4 Figure 5 Body Pattern: “Lo” is display on the screen, when the temperature is less than 32. 0. 32.0 ≤ temperature > 37.2, the thermometer will notify saying "Normal Temperature" 37.2 ≤ temperature > 37.9, the thermometer will notify saying "High Temperature" 37.9 ≤...
-
Page 8: Function Key Descripition
Display icon definition Count key: Press the count key to view the total number of readings (Do not use when power is off) Long press the count key to clear the total number of reading to 0. Display will show 0000 and then return to the temperature measurement interface. - Page 9 When the room temperature changes greatly, the medical infrared thermometer should be placed in the room for 20 minutes before use. When the person to be measured comes from a place that is significantly different from the measured ambient temperature. Stay in the environment for more than 5 minutes and wait for the ambient temperature before measuring.
-
Page 10: Installation And Replacement Of Batteries
Battery installation and replacement 1. Battery installation or replacement Open the battery cover and replace the battery. Pay attention to the correct position of the positive and negative electrodes. when the instrument is not working the static current is extremely small, but it is recommended to remove the battery when it is not use for a long time. -
Page 11: Daily Maintenance
Routine maintenance During the use of the product, please follow the prompts when you find the following conditions. External dirt: Wipe the dirt with a clean soft cloth or wipe with a cotton swab and medical alcohol. Wiping with medical alcohol can also have sterilization effect, but watch out for excessive water or alcohol to prevent damage to the inside of the product. - Page 12 Imported and Marketed By: iGear Tech Pvt. Ltd. 204, Sai Corporate Park, Laxmi Nagar, Off Link Road, Goregaon West, Mumbai - 400104. In case of consumer complaints: Toll free number - 1800 22 8495 Email: sales@igear.asia (Between 10am to 5pm, Mon- Fri)
