MICROWAVE HOOD COMBINATION
This product is suitable for use above electric or gas cooking products up to 36" (91.4 cm) wide.
These installation instructions cover different models. The appearance of your particular model may differ slightly from the
illustration in these installation instructions.
NOTES:
Proper installation is the responsibility of the installer.
Product failure due to improper installation is not covered under the warranty.

MICROWAVE HOOD COMBINATION SAFETY

We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word "DANGER" or "WARNING."
These words mean:
WARNING
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
IMPORTANT: Read Installation Instructions thoroughly before beginning installation. Save Installation Instructions for local house
inspector's use.
8206587
INSTALLATION INSTRUCTIONS
MICROWAVE HOOD COMBINATION SAFETY .............................. 1
INSTALLATION REQUIREMENTS ................................................... 2
Tools and Parts............................................................................... 2
Location Requirements................................................................... 2
Product Dimensions ....................................................................... 3
Electrical Requirements .................................................................. 3
INSTALLATION INSTRUCTIONS ..................................................... 4
Remove Mounting Plate ................................................................. 4
Rotate Blower Motor....................................................................... 4
Locate Wall Stud(s) ......................................................................... 6
Mark Rear Wall................................................................................ 7
Drill Holes in Rear Wall.................................................................... 7
Attach Mounting Plate to Wall ........................................................ 8
Prepare Upper Cabinet................................................................... 8
Install Damper Assembly ................................................................ 9
Install the Microwave Oven ............................................................ 9
Complete Installation .................................................................... 10
VENTING DESIGN SPECIFICATIONS............................................ 11
ASSISTANCE ................................................................................... 12
Replacement Parts ....................................................................... 12
Accessories................................................................................... 12
Your safety and the safety of others are very important.
DANGER

Table of Contents

You can be killed or seriously injured if you don't immediately
follow instructions.
You can be killed or seriously injured if you don't follow
instructions.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TMH16XSB and is the answer not in the manual?

Questions and answers

Related Manuals for Estate TMH16XSB

Summary of Contents for Estate TMH16XSB

  • Page 1: Table Of Contents

    IMPORTANT: Read Installation Instructions thoroughly before beginning installation. Save Installation Instructions for local house inspector’s use. 8206587 Table of Contents MICROWAVE HOOD COMBINATION SAFETY ... 1 INSTALLATION REQUIREMENTS ... 2 Tools and Parts... 2 Location Requirements... 2 Product Dimensions ... 3 Electrical Requirements ...

  • Page 2: Installation Requirements

    Grounded electrical outlet inside upper cabinet. See “Electrical Requirements” section. NOTES: If installing the microwave oven near a left sidewall, make sure there is at least 6" (15.2 cm) of clearance between the wall and the microwave oven, so that the door can open fully.

  • Page 3: Product Dimensions

    A separate circuit serving only this microwave oven. For all cord connected appliances: The microwave oven must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current.

  • Page 4: Installation Instructions

    1. Remove any remaining contents from the microwave oven cavity. 2. Remove the mounting plate by peeling off the strips of tape that attach it to the back of the microwave oven, and set the mounting plate aside. A. Mounting plate B.
  • Page 5 6. Reattach blower motor to back of microwave oven with 2 screws removed in Step 3. 7. Reattach damper plate. Make sure damper plate tabs are inserted into the slots in the top of the microwave oven A. Screws B. Damper plate C.

  • Page 6: Locate Wall Stud(S)

    NOTE: If no wall studs exist within the cabinet opening, do not install the microwave oven. See illustrations in “Possible Wall Stud Configurations.” Possible Wall Stud Configurations These depictions show examples of preferred installation configurations with the mounting plate. No Wall Studs at Corner Holes...

  • Page 7: Mark Rear Wall

    Mark Rear Wall The microwave oven must be installed on a minimum of 1 wall stud, preferably 2, using a minimum of 1 lag screw, preferably 2. 1. Using measuring tape, find and clearly mark the vertical centerline of the opening.

  • Page 8: Attach Mounting Plate To Wall

    The “rear wall” arrows must be against the rear wall so that the holes cut into the upper cabinet align with the holes in the top of the microwave oven. NOTE: If the upper cabinet has a frame around it, trim the template edges so that it fits inside the frame, against the upper cabinet bottom.

  • Page 9: Install Damper Assembly

    3/8" (10 mm) holes. 2. Make sure the microwave oven door is closed and taped shut. 3. Using 2 or more people, lift microwave oven and hang it on support tabs at the bottom of mounting plate.

  • Page 10: Complete Installation

    NOTE: If microwave oven does not need to be adjusted, skip steps 7-9. 7. If adjustment is required, rotate microwave oven downward. Using 2 or more people, lift microwave oven off of mounting plate, and set aside on a protected surface.

  • Page 11: Venting Design Specifications

    If venting through the roof, and rectangular to round transition is used, be sure there is at least 3" (7.6 cm) of clearance between the top of the microwave oven and the transition piece. See “Rectangular to Round Transition” illustration.

  • Page 12: Assistance

    Part Number 8205871 Filler Panel Kits are available from your dealer to use when installing this microwave oven in a 36" (91.4 cm) or 42" (106.7 cm) wide opening. The filler panels come in pairs. Each panel is 3" (7.6 cm) wide.
