GENERAL OPERATION INSTRUCTIONS
SYSTEM PREPARED FOR:
SPACESAVER ORDER NUMBER:
CONTROL FUNCTIONS ............................................. 2
TOUCH AND HOLD CONTROL ................................ 2
ONE TOUCH CONTROL ............................................ 2
STOPPING CARRIAGE TRAVEL ................................ 2
TOUCH AND HOLD - MANUAL RESET .................... 2
ONE TOUCH - MANUAL RESET ................................ 3
PHOTOELECTRIC SAFETY SWEEP ......................... 3
ELECTRO-MECHANICAL SAFETY SWEEP ............. 3
REV. 1.0
SPACESAVER
POWER PRO
ELECTRIC CONTROLS
THIS SYSTEM INCLUDES:
FOR
PAGE
AISLE ENTRY SAFETY ................................................ 4
POWER OVERRIDE PACK .......................................... 4
KEYLOCK FUNCTIONS ......................................... 4-5
BOTTOM MOUNT LOCK .......................................... 5
WAIST-HIGH LOCK ................................................. 5-6
REMOTE CONTROL ................................................... 6
OVERHEAD AISLE LIGHTS ........................................ 6
AISLEGUARD SAFETY.............................................6
1
PAGE
Spacesaver Corporation
Advertisement
Table of Contents
Summary of Contents for Spacesaver POWER PRO
-
Page 1: Table Of Contents
GENERAL OPERATION INSTRUCTIONS SPACESAVER POWER PRO ELECTRIC CONTROLS SYSTEM PREPARED FOR: SPACESAVER ORDER NUMBER: THIS SYSTEM INCLUDES: PAGE PAGE CONTROL FUNCTIONS ..........2 AISLE ENTRY SAFETY ..........4 TOUCH AND HOLD CONTROL ........ 2 POWER OVERRIDE PACK .......... 4 ONE TOUCH CONTROL ..........2 KEYLOCK FUNCTIONS ......... -
Page 2: Control Functions
POWER PRO ELECTRIC CONTROL OPERATION Spacesaver electric systems may include all or some of the many Spacesaver safety devices offered for operator protection. The intent here is to describe the proper use of the electric controls. This document, coupled with your on site training, will provide the means for the safe, efficient and non-abusive use of the system. -
Page 3: One Touch - Manual Reset
The red light will stop blinking and turn steady. Gently press the appropriate move button to open the safety locked aisle. The safety locked aisle will fully open, allowing entry and removal of the obstruction. Normal operation has now been restored. Spacesaver Corporation... -
Page 4: Aisle Entry Safety
12 months or more frequently if used often. Use 16 D size batteries. 10. The Power Pro system has several different “lock” options available. 10.1 Lock the entire system to either side and shut down every control head allowing no access for optimum security. -
Page 5: Bottom Mount Lock
12.4 Rotate the key 1/2 turn to lock or unlock. The key should be kept by an area supervisor when not in use. 12.5 If the lock is located on carriage one, move all carriages closed to the right and lock to disable any system operation. Spacesaver Corporation... -
Page 6: Remote Control
U.S.A.: 1450 Janesville Ave., Ft. Atkinson, WI 53538, (920) 563-5546, 1-800-492-3434, FAX: (920) 563-2702 CANADA: 266 King Street East, Toronto, Ontario M5A 4L5, (416) 360-1022, 1-800-544-3679, FAX: (416) 360-7290 WEBSITE: www.spacesaver.com E-MAIL: ssc@spacesaver.com Copyright © 2000, Spacesaver Corporation. Printed in U.S.A. REV. 2.0/OP-0040 SSC/EPD 7/04... - Page 7 This method of operation should only be used when the problem causing the carriage shut-down cannot be corrected by the operator. Spacesaver Area Contractor service personnel should be called at once to correct the problem. This device should be used only by supervisors and service personnel.
- Page 8 1450 Janesville Avenue, Fort Atkinson, WI 53538, (920) 563-6362, 1-800-492-3434, FAX: (920) 563-2702 CANADA: 266 King Street East, Toronto, Ontario M5A 4L5, (416) 360-1414, 1-800-544-3679, FAX: (416) 360-7290 WEBSITE: www.spacesaver.com E-MAIL: ssc@spacesaver.com Copyright ©, 2000 by Spacesaver Corporation. All Rights Reserved. Printed in U.S.A. OP-0041 SSC/ECONO 5/00...
- Page 9 Think of this as another way to create a stationary carriage for the Pro- grammable Electric and the Power Pro systems. If used on a Power Assist system all carriages will lock.
- Page 10 PROGRAMMING/OPERATION INSTRUCTIONS POWER ASSIST / POWERPRO ® WITH TOUCHPAD CONTROL The following procedure allows the user to program the TouchPad Control with their own 4-digit code. Upon initial power-up the TouchPad Control code is set to 1 2 3 4. To change code.
- Page 12 Power override should be used only during times of a power outage. Spacesaver area contractor service personnel should be called at once to correct any problem necessitating the use of the safety override key. The safety override key should be used only by supervisors or service personnel.
- Page 13 CANADA: 266 King Street East, Toronto, Ontario M5A 4L5, (416) 360-1022, 1-800-544-3679, FAX: (416) 360-7290 Commonwealth House, 148-153 High Holborn, London WC1V 6PJ, (020) 7404-7441, FAX: (020) 7404-7442 WEBSITE: www.spacesaver.com E-MAIL: ssc@spacesaver.com Copyright ©, 2002 by Spacesaver Corporation. All Rights Reserved. Printed in U.S.A. OP-0205 SSC/ECONO 2/02...
- Page 14 Attention Service Person Only ® Power Assist & PowerPro TouchPad Control Installation, Setup and Service Subject: Function and use of 2 pin jumper locations at JP1-8. Location JP1 – Beeper options: No jumper: Beeper will sound when keys are pushed. Jumper: Beeper will not sound when keys are pushed.
- Page 15 * Default code greater than 4: (5=1-2-3-4-5) (6=1-2-3-4-5-6) (7=1-2-3-4-5-6-7) OP-0206...
- Page 16 Attention Service Person Only INSTALLATION, SET UP & SERVICE INSTRUCTIONS PROGRAMMABLE ELECTRIC, POWER ASSIST & ® POWERPRO WITH UNIVERSAL TOUCHPAD CONTROL Subject: Function and use of 2 pin jumper locations at JP1-8. Location JP1 – Beeper options: No jumper: Beeper will sound when keys are pushed. Jumper: Beeper will not sound when keys are pushed.
- Page 17 OP-0210...
- Page 18 8. Make certain that all system safety devices are operational. 9. Call your local Spacesaver repre- sentative immediately, if a safety device requires attention. REV. 2.0/OP-9145 SSC/ECONO 5/00...
- Page 19 2. Form #2 is a check for the installer to confirm, in detail, that Spacesaver’s specifications for installation have been met & the Field Quality Form is to note discrepancies with manufacturing product.
- Page 22 SPACESAVER ® WARRANTY ACTIVATION CARD Thank you for your purchase from the Spacesaver Group! Please follow the instructions below to activate your warranty: Visit our website at www.spacesaver.com. Click on "Warranty" in the bottom right hand corner. Enter the required information in the Customer Profile Section which includes the Customer Job Number indicated at the bottom of this.
- Page 23 10-YEAR LIMITED WARRANTY: Spacesaver also warrants that all carriage drive motors shall be free from defects in materials and workmanship for ten (10) years from the date of the customer’s written acceptance of installation. During the 10-year warranty period, all parts will be provided at no cost.
- Page 24 Spacesaver. All warranty service for any equipment manufactured by Spacesaver must be performed by an authorized Spacesaver factory representative. This warranty shall be void if any portion of the purchase price shall be due but unpaid in accordance with the terms pursuant to which the equipment was sold.
- Page 25 Cette garantie est régie par les modalités et conditions standard de la garantie. Voir tous les détails de a garantie au verso de ce certificat de garantie/formulaire d’acceptation de système qui s’appliquent à vos produits Spacesaver.
- Page 26 Spacesaver ne sera tenue responsable des dommages accidentels, accessoires, spéciaux ou autres, ni de la perte de profits ou de revenus, soit à la suite d’un bris de contrat ou de garantie, la négligence de Spacesaver, ou autrement. Spacesaver ne pourra être tenue responsable des conseils ou de l’aide fournis par un tiers en-dehors de la portée des spécifications de Spacesaver...
