Zitta PIWIL000-0005 Quick Start Manual

Drain mural wall drain

Advertisement

Quick Links

81, Theodore-Viau,
Terrebonne, Quebec, Canada, J6Y 0J8
Tel: 1-855-492-4242
450-704-2323
Fax: 1-866-735-6885
info@zitta.ca
www.zitta.ca
Drain Mural
Wall Drain
NETTOYAGE ET ENTRETIEN DE
VOTRE DRAIN
Les détergents liquides doux pour vaisselle
sont suffisants pour garder une surface propre
et brillante. Rincez à fond et asséchez avec un
chiffon propre.
Attention: Les détergents en poudre ou
liquides abrasifs peuvent endommager les
surfaces.
Ne jamais mettre en contact la surface
apparente avec des produits corrosifs tel que
les produits de débouchage.
NE PAS UTILISER:
Des produits de nettoyage contenant des
chlorures, de l'alcool, de l'ammoniac ou
de l'essence minérale.
De la laine d'acier, tampon à récurer ou
brosses.
CARE AND CLEANING OF YOUR
DRAIN
Mild dishwashing liquids will keep the surfaces
bright and clean. Rinse well and dry with a
clean cloth.
Caution: Powder detergent and liquid abrasive
cleaners may damage surfaces.
Do not allow the visible surface to come into
contact with corrosive products such as drain
cleaners.
DO NOT USE:
Cleaning agents that contains chlorides,
alcohol, ammonia or mineral spirits.
Steel wool, scouring pad or wire brushes.
81, Theodore-Viau,
Terrebonne, Quebec, Canada, J6Y 0J8
Tel: 1-844-579-1784
450-915-1879
Fax: 1-866-735-6885
info@novodrain.ca
www.novodrain.ca
MANUEL D'INSTALLATION / INSTALLATION MANUAL
IMPORTANT
Inspectez le produit avant de procéder à l'installation.
La garantie sera nulle si le produit est installé avec des défauts
ATTENTION
Veuillez lire attentivement ce manuel d'instructions avant de commencer l'installation.
Conserver ce manuel pour référence
IMPORTANT
Thoroughly inspect your product before proceeding with the installation.
The warranty will no longer apply if the product is installed with a conspicuous defect.
CAUTION
Carefully read all instructions before starting the installation.
Keep this manual for later
reference.brosses.
apparents.brosses.
ultérieure.brosses.
PIWIL000-0005

Advertisement

loading
Need help?

Need help?

Do you have a question about the PIWIL000-0005 and is the answer not in the manual?

Questions and answers

Summary of Contents for Zitta PIWIL000-0005

  • Page 1 PIWIL000-0005 81, Theodore-Viau, Terrebonne, Quebec, Canada, J6Y 0J8 Tel: 1-855-492-4242 450-704-2323 Fax: 1-866-735-6885 info@zitta.ca www.zitta.ca Drain Mural Wall Drain NETTOYAGE ET ENTRETIEN DE VOTRE DRAIN Les détergents liquides doux pour vaisselle sont suffisants pour garder une surface propre et brillante. Rincez à fond et asséchez avec un chiffon propre.
  • Page 2 INTRODUCTION ET RECOMMANDATIONS / INTRODUCTION AND RECOMMENDATIONS Avant de commencer les travaux, assurez-vous de lire attentivement Before proceeding, carefully read all instructions. les instructions de montage. Consultez le code du bâtiment de votre région afi n de vous assurer Consult local building codes to ensure that the installation que votre installation respecte les normes en vigueur.
  • Page 3 CONTENU / PARTS LIST QTÉ DESCRIPTION CODE Membrane de drain protectrice PDXX01WIM00 Protective drain membrane Écrou d’ajustement M4 / Adjustment nut M4 PV003699 Caniveau / Gutter rough-in PDXX01WIC00 Patin de nivellement / Levelling feet (1 1/4’’) PV002099 Patin de nivellement / Levelling feet (2’’) PV002199 Support de grille ajustable / Ajustable grate support PDXX01WIM00...
  • Page 4 INSTALLATION AVEC RACCORD D’UNION / UNION FITTING INSTALLATION Solive / Joist Sous-plancher / Subfloor Mur / Wall Tuyau d’évacuation / Waste pipe Raccord d’union / Union fitting** Caniveau / Gutter rough-in Support de grille ajustable / Ajustable grate support Grille du drain de douche / Shower drain grate Patin de nivellement / Levelling feet Crépine / Strainer **Non-inclus...
  • Page 5 COUPER LE MUR / CUT THE WALL 1’’ Gypse 1/2’’ Gypsum 1/2’’ 6’’ COUPER LE SOUS-PLANCHER / CUT THE SUBFLOOR COUPER LE SOUS-PLANCHER / CUT THE SUBFLOOR 4’’ 101m MARQUER LE CENTRE MARK THE CENTRE Percer avec emporte-pièce. Drill with holesaw.
  • Page 6 ASSEMBLER ET AJUSTER / ASSEMBLE AND ADJUST FIXER LE DRAIN ET SERRER LE RACCORD / SET DRAIN AND TIGHTEN THE COUPLING...
  • Page 7 TEST D’ÉTANCHÉITÉ DE LA CONNEXION / CONNECTION LEAK TEST Vérifi er l’étanchéité de la connexion sous le sous-plancher. Check underneath the subfl oor to ensure that the connection is waterproof. INSTALLER LE GYPSE / INSTALL GYPSUM...
  • Page 8 VISSER LE DRAIN / SCREW THE DRAIN Mettre du silicone dans tout les trous. Put silicon in the all holes. 4’’ 101mm SURFACE EN PENTE / SLOPED SURFACE Plier la membrane protectrice de drain Fold the protecting drain membrane MORTIER / MORTAR OU / OR MOUSSE / FOAM OU / OR...
  • Page 9 INSTALLER LA MEMBRANE / INSTALL MEMBRANE MEMBRANE TEXTILE / TEXTILE MEMBRANE OU / OR MEMBRANE LIQUIDE / LIQUID MEMBRANE CELLER LES JOINTS / SEAL THE JOINTS Appliquer de la colle le long de la bride après avoir appliqué la membrane. Apply glue on the edge of the fl...
  • Page 10 COLLER LA MEMBRANE PROTECTRICE DU DRAIN / GLUE THE PROTECTIVE DRAIN MEMBRANE Appliquer sur les deux côtés de la membrane. Apply on both sides of the membrane. TEST D’ÉTANCHÉITÉ DE LA MEMBRANE / MEMBRANE LEAK TEST Boucher le trou du drain et vérifi er l’étanchéité de la membrane sous le sous-plancher.
  • Page 11 AJUSTER DE LA GRILLE / ADJUSTING THE GRATE Retirer la grille Remove the grate Aligner la grille avec les tuiles Align the grate with the tiles Ajuster et serrer le support de grille Adjust and tighten grate support TUILAGE / TILING...
  • Page 12 JOINT DE COULIS / JOINT CEMENT Ne pas remplir l’entrée du drain. Do not fi ll up the drain entry. NETTOYER LES TUILES ET JOINTS / CLEAN TILES AND JOINTS...
  • Page 13 Need help? Contact us! Besoin d’aide? Contactez nous! Tel: 1-855- 492-4242 450-704-2323 Tel: 1-855- 492-4242 450-704-2323 Fax: 1-866-735-6885 Fax: 1-866-735-6885 Service@zittagroup.com Service@zittagroup.com Info@zittagroup.com Info@zittagroup.com www.zittagroup.com www.zittagroup.com...
  • Page 14 81, Theodore-Viau, Terrebonne, Quebec, Canada, J6Y 0J8 Tel: 1-855-492-4242 450-704-2323 Fax: 1-866-735-6885 info@zitta.ca www.zitta.ca 81, Theodore-Viau, Terrebonne, Quebec, Canada, J6Y 0J8 Tel: 1-844-579-1784 450-915-1879 Fax: 1-866-735-6885 info@novodrain.ca www.novodrain.ca...
